AEG BS7304001 User manual

BS7304001
BS7304021 EN User manual

CONTENTS
1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7. CLOCK FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8. AUTOMATIC PROGRAMMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
9. USING THE ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
10. ADDITIONAL FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
11. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
12. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
13. WHAT TO DO IF… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
14. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
15. GREAT BRITAIN & IRELAND - GUARANTEE/CUSTOMER SERVICE . . . . . . . . . . . . . . . . . 48
16. EUROPEAN GUARANTEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading to get
the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.aeg.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
2www.aeg.com

1. SAFETY INFORMATION
Before the installation and use of the appliance, careful-
ly read the supplied instructions. The manufacturer is
not responsible if an incorrect installation and use cau-
ses injuries and damages. Always keep the instructions
with the appliance for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they are supervised by an adult or a
person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance
when it operates or when it cools down. Accessible
parts are hot.
• If the appliance has a child safety device, we recom-
mend that you activate it.
• Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
• Only a qualified person must install this appliance
and replace the cable.
• Internally the appliance becomes hot when in opera-
tion. Do not touch the heating elements that are in
the appliance. Always use oven gloves to remove or
put in accessories or ovenware.
• Do not use a steam cleaner to clean the appliance.
• Before maintenance cut the power supply.
ENGLISH 3

• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can
scratch the surface, which may result in shattering of
the glass.
• Only use the core temperature sensor recommended
for this appliance.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must in-
stall this appliance.
• Remove all the packaging.
• Do not install or use a damaged appli-
ance.
• Obey the installation instruction sup-
plied with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not pull the appliance by the han-
dle.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is instal-
led below and adjacent safe struc-
tures.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical informa-
tion on the rating plate agrees with
the power supply. If not, contact an
electrician.
• Always use a correctly installed shock-
proof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Contact the Service or an electrician to
change a damaged mains cable.
• Do not let mains cables to come in
touch with the appliance door, spe-
cially when the door is hot.
• The shock protection of live and insu-
lated parts must be fastened in such a
way that it cannot be removed without
tools.
• Connect the mains plug to the mains
socket only at the end of the installa-
tion. Make sure that there is access to
the mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to discon-
nect the appliance. Always pull the
mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
4www.aeg.com

• The electrical installation must have an
isolation device which lets you discon-
nect the appliance from the mains at
all poles. The isolation device must
have a contact opening width of mini-
mum 3 mm.
2.2 Use
WARNING!
Risk of injury, burns or electric
shock or explosion.
• Use this appliance in a household en-
vironment.
• Do not change the specification of this
appliance.
• Make sure that the ventilation open-
ings are not blocked.
• Do not let the appliance stay unatten-
ded during operation.
• Deactivate the appliance after each
use.
• Be careful, when you open the appli-
ance door while the appliance is in op-
eration. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with wa-
ter.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Always keep the appliance door
closed when the appliance is in opera-
tion.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other ob-
jects in the appliance directly on the
bottom.
– do not put aluminium foil directly on
the bottom of the appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food
in the appliance after you finish the
cooking.
– be careful when you remove or in-
stall the accessories.
• Discoloration of the enamel has no ef-
fect on the performance of the appli-
ance. It is not a defect in the sense of
the warranty law.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be perma-
nent.
Steam Cooking
WARNING!
Risk of burns and damage to the
appliance.
• Do not open the appliance door dur-
ing steam cooking. Steam can release.
2.3 Care and Cleaning
WARNING!
Risk of injury, fire or damage to
the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold. There
is the risk that the glass panels can
break.
• Replace immediately the door glass
panels when they are damaged. Con-
tact the Service.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Clean regularly the appliance to pre-
vent the deterioration of the surface
material.
• Remaining fat or food in the appliance
can cause fire.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal ob-
jects.
ENGLISH 5

• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
2.4 Internal light
• The type of light bulb or halogen lamp
used for this appliance, is only for
household appliances. Do not use it
for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same specifi-
cations.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. PRODUCT DESCRIPTION
21
11
5
4
6
7
9
10
5
4
3
2
18
3
1Control panel
2Electronic programmer
3Water drawer
4Socket for the core temperature sen-
sor
5Heating element
6Lamp
7Fan
8Rear wall heating element
9Steam generator with cover
10 Shelf support, removable
11 Shelf positions
3.1 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
6www.aeg.com

Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
Trivet
• For roasting and grilling.
Use the trivet only with the
Grill- / roasting pan.
Core temperature sensor
To measure how far the food is cooked.
Steam set
One unperforated and one perforated
food container.
The steam set drains the condensing wa-
ter away from the food during steam
cooking. Use it to prepare food that
should not be in the water during the
cooking (e.g. vegetables, pieces of fish,
chicken breast). The set is not suitable
for food that needs to soak in the water
(e.g. rice, polenta, pasta).
Sponge
For absorbing the remaining water from
the steam generator.
4. BEFORE FIRST USE
WARNING!
Refer to the Safety chapters.
4.1 Initial Cleaning
• Remove all parts from the appliance.
• Clean the appliance before first use.
ENGLISH 7

Refer to chapter "Care and
Cleaning".
4.2 Setting and changing the
time
After the first connection to the mains,
all symbols in the display are on for
some seconds. For the subsequent few
seconds the display shows the software
version.
After the software version goes off, the
display shows h and 12:00.
Setting the time of day:
1. Touch or to set the hours.
2. Touch or .
3. Touch or to set the minutes.
4. Touch or .
The Temperature / Time display shows
the new time.
Changing the time of day
You can change the time of day only
when the appliance is off. Touch .
flashes in the display. To set the new
time of day, use the above procedure.
5. CONTROL PANEL
5.1 Electronic programmer
1 2 3 4 5 6 7 8 9 10
Use the sensor fields to operate the ap-
pliance.
Sensor
Field
Function Description
1
-DISPLAY Shows the current settings of the appli-
ance.
2
ON / OFF To activate and deactivate the appli-
ance.
3
OPTIONS To set an oven function, an automatic
programme or a cleaning function (se-
lected models only). Straight access to
an oven function when the appliance is
off.
4
MY FAVOURITE
PROGRAMME To store your favourite programme. Use it to have access to your favourite
programme directly or when the appli-
ance is deactivated.
8www.aeg.com

Sensor
Field
Function Description
5
TEMPERATURE /
FAST HEAT UP To set and see the cavity temperature or the core temperature sensor temper-
ature (if present). If you press and hold
it for three seconds, it turns the Fast
heat up function ON or OFF. Straight
access to the temperature setting of
the first oven function when the appli-
ance is off.
6
UP, DOWN To move up or down in the menu.
7
OK To confirm a selection or setting. To
move down in the menu.
8
OVEN LIGHT To activate or deactivate the oven
lamp.
9
CLOCK To set the clock functions.
10
MINUTE MINDER To set the Minute Minder.
5.2 Display
ABC
DEFG
A) Oven function symbol
B) Temperature / Time display
C) Clock / Residual heat display (also
Minute minder and Time of day)
D) Residual heat indicator
E) Indicators for the clock functions (re-
fer to the table "Clock functions")
F) Heat up indicator
G) Number of oven function/pro-
gramme
5.3 Other indicators in the display
Sym-
bols
Name Description
Functions You can choose an oven function.
Automatic pro-
gramme
You can choose an oven programme.
My favourite pro-
gramme
The favourite programme operates.
/ kgr / gr An oven programme with a weight input
operates.
/ h / min A clock function operates.
ENGLISH 9

Sym-
bols
Name Description
Temperature / Fast
heat up
The function operates.
Temperature You can see or change the temperature.
Core temperature
sensor
The core temperature sensor is in the core
temperature sensor socket.
Oven light The light is off.
Minute minder The minute minder function operates.
5.4 Heat up indicator
If you activate an oven function, the bars
come on in the display. The bars
show that the temperature in the appli-
ance increases or decreases.
When the appliance is at the set temper-
ature, the bars go off the display.
6. DAILY USE
WARNING!
Refer to the Safety chapters.
To operate the appliance you can use:
•The manual mode - to set a heating
function, the temperature and the
cooking time manually.
•automatic programmes - to prepare
a dish when you do not have knowl-
edge or experience in cooking.
6.1 Oven Functions
Oven function Application
1Full Steam For vegetables, fish, potatoes, rice, pasta or spe-
cial side-dishes.
2Half Steam +
Heat For dishes with a high moisture content and for poaching fish, custard royale and terrines.
3Quarter Steam
+ Heat To bake bread, roast large pieces of meat or to warm up chilled and frozen meals.
4ECO Steam ECO functions let you to optimize the energy
consumption during cooking. Thus it is necessary
to set the cooking time first. To get more informa-
tion about the recommended settings, refer to
the cooking tables with the equivalent usual oven
function.
5Moist Fan Bak-
ing For energy-saving baking and cooking of mainly dry bakery items as well as for baking in tins on 1
shelf position.
10 www.aeg.com

Oven function Application
6True Fan Cook-
ing To bake maximum on 3 oven shelf positions at the same time and to dry food. Set the tempera-
ture 20 - 40 °C lower than for Conventional Cook-
ing.
7Pizza Setting To bake food on 1 shelf position for a more inten-
sive browning and a crispy bottom. Set the tem-
perature 20 - 40 °C lower than for Conventional
Cooking.
8Slow Cook To prepare very lean, tender roasted food.
9Conventional
Cooking To bake and roast food on 1 shelf position.
10 Frozen Foods To make your convenience food like e.g. French
Fries, Wedges, spring rolls crispy.
11 Turbo Grilling To roast larger meat joints or poultry with bones
on 1 shelf position. Also to gratinate and to
brown.
12 Fast Grilling To grill flat food in large quantities. To toast
bread.
13 Grilling To grill flat food and to toast.
14 Keep Warm To keep food warm.
15 Defrost To defrost frozen food.
16 Bottom Heat To bake cakes with a crispy base, and to preserve
food.
17 ECO Roasting ECO functions let you to optimize the energy
consumption during cooking. Thus it is necessary
to set the cooking time first. To get more informa-
tion about the recommended settings, refer to
the cooking tables with the equivalent usual oven
function.
18 Steam Clean-
ing To clean the oven interior using steam.
6.2 Setting the oven function
1. Activate the appliance with or
. The display shows the set tempera-
ture, the symbol and the number of
the oven function.
2. Touch or to set an oven
function.
3. Touch or the appliance starts
automatically after five seconds.
If you activate the appliance and
do not set an oven function or
programme, the appliance deac-
tivates automatically after 20 sec-
onds.
6.3 Changing the temperature
Touch / to change the tempera-
ture in steps of 5 °C.
ENGLISH 11

When the appliance is at the set temper-
ature, an acoustic signal sounds three
times and the Heat up indicator goes
out.
6.4 Checking the temperature
You can see the temperature in the ap-
pliance when the function or programme
operates.
1. Touch . The Temperature / Time
display shows the temperature in the
appliance. If you want to change the
oven temperature, touch one
more time and use or .
2. Touch to go back to the set
temperature or the display shows it
automatically after five seconds.
6.5 Fast heat up function
The Fast heat up function decreases the
heat up time.
Activating the Fast heat up function:
Touch and hold for more than three
seconds.
If you activate the Fast heat up function,
the bars on the display flash one by
one and comes on to show that
the function operates.
Additional information:
• Do not put food into the oven when
the Fast heat up function operates.
• The Fast heat up is not available with
all oven functions. An acoustic signal
sounds if the Fast heat up is not avail-
able for the set function.
6.6 Steam cooking
The water drawer cover is in the control
panel.
1. Press the cover to open the water
drawer.
2. Fill the water drawer with 800 ml of
water.
The water supply is sufficient for ap-
proximately 50 minutes.
Do not put water directly into the
steam generator!
Use only water as the liquid. Do
not use filtered (demineralised)
or distilled water.
3. Activate the appliance.
4. Set the Steam function (refer to the
"Oven functions" table) and the
temperature.
5. Touch to set the DURATION or
END function (refer to "Setting the
END" or "Setting the DURATION").
The first steam shows after approxi-
mately 2 minutes. An acoustic signal
sounds when the appliance is at ap-
proximately the set temperature.
The signal sounds again at the end
of the cooking time.
6. Touch to deactivate the acoustic
signal and the appliance.
When the steam generator is
empty, an acoustic signal
sounds.
When the appliance cools down, soak
up all remaining water from the steam
generator with the sponge. If necessary,
clean the steam generator with vinegar.
Let the appliance dry fully with the door
open.
6.7 Energy saving
The appliance contains features
which help you save energy
during everyday cooking:
•Residual heat:
– When the heating function
or programme operates, the
heating elements are deacti-
vated 10% earlier (the lamp
and fan continue to oper-
ate). For this feature to oper-
ate, the cooking time must
be longer than 30 minutes or
you must use the clock func-
tions (Duration, End, Time
delay). This feature does not
operate with the grill func-
tions.
– When the appliance is off,
you can use the heat to keep
food warm. The clock / re-
sidual heat display shows
the remaining temperature,
and the bars show the tem-
perature as it decreases.
•Cooking with the lamp off -
Touch to deactivate the
lamp during cooking.
12 www.aeg.com

•Deactivating the display - If
necessary, you can fully deacti-
vate the appliance. Touch
and at the same time until
the display goes out. This step
also activates the appliance.
•Eco functions - refer to "Oven
functions".
7. CLOCK FUNCTIONS
SYMBOL FUNCTION DESCRIPTION
TIME OF DAY To examine the time of day. For changing the
time of day refer to 'Setting and changing the
time'.
DURATION To set how long the appliance operates.
END To set when the appliance deactivates. You
can use the Duration and End functions at the
same time (Time delay), if the appliance is to
be activated and deactivated automatically
later.
SET+GO To start the appliance with the necessary set-
tings with only one touch of the sensor field,
any time later.
7.1 Count Up Timer
Use the Count Up Timer to monitor how
long the appliance operates. It is on im-
mediately when the appliance starts to
heat.
Reset the Count Up Timer: touch .
Touch until the display shows
"00:00" and the Count Up Timer starts
to count up again.
You cannot use the Count Up
Timer when Duration or End is
set.
7.2 Setting the DURATION
1. Activate the appliance and set an
oven function and temperature.
2. Touch again and again until the
display shows . flashes in the
display.
3. Use or to set the minutes for
DURATION.
4. Touch to confirm.
5. Use or to set the hours for
DURATION.
If you touch or while you
set the DURATION, the appli-
ance switches to the setting of
the END function.
6. When the set time ends, an acoustic
signal sounds for two minutes.
and time setting flash in the dis-
play. The appliance deactivates.
Touch a sensor field or open the
oven door to stop the acoustic sig-
nal.
7. Deactivate the appliance.
7.3 Setting the END
1. Activate the appliance and set an
oven function and temperature.
2. Touch again and again until the
display shows . flashes in the
display.
3. Use or to set the END (first
you set the minutes and then the
hours) and or to confirm.
4. When the set time ends, an acoustic
signal sounds for two minutes.
ENGLISH 13

symbol and the time setting flash
in the display. The appliance deacti-
vates.
5. Touch a sensor field or open the
oven door to stop the acoustic sig-
nal.
6. Deactivate the appliance.
7.4 Check result (selected
models only)
If you set the END or DURATION func-
tion, two minutes before the end of
cooking an acoustic signal sounds and
the lamp activates. The appliance goes
to the setting of the END or DURATION
function. During these two minutes you
can examine the results of the cooking,
and, if necessary, add the END or DURA-
TION time.
7.5 Setting the SET+GO
1. Set an oven function (or programme)
and temperature (refer to "Setting
the oven function" and "Changing
the temperature").
2. Set the DURATION (refer to "Setting
the DURATION").
3. Touch again and again until
flashes in the display.
4. Touch to set the SET+GO func-
tion.
The display shows and with an
indicator. This indicator shows which
clock function is activated.
5. Touch a sensor field (apart from
ON / OFF) to start the SET+GO
function.
You can use the SET+GO func-
tion only when the DURATION is
set.
7.6 Setting the MINUTE
MINDER
Use the MINUTE MINDER to set a
countdown (maximum 2 h 30 min). This
function has no effect on the operation
of the oven. You can set the MINUTE
MINDER at any time and also when the
appliance is off.
1. Touch . and "00" flash in the
display.
2. Use or to set the MINUTE
MINDER. First you set the seconds,
then the minutes and the hours.
3. Touch or the MINUTE MINDER
starts automatically after five sec-
onds.
4. When the set time ends, an acoustic
signal sounds for two minutes and
00:00 and flash in the display.
5. Touch a sensor field or open the
oven door to stop the acoustic sig-
nal.
7.7 Setting the Time delay
function
The DURATION and END func-
tions can be used at the same time, if
the oven is to be activated and deactiva-
ted automatically later. In this case, first
set the DURATION and then the END
function (refer to "Setting the DURA-
TION" and "Setting the END" ).
When the Time delay function is activa-
ted, the display shows a static symbol of
the oven function, with a dot and .
The dot shows which clock function is on
in the Clock / residual heat display.
8. AUTOMATIC PROGRAMMES
WARNING!
Refer to the Safety chapters.
8.1 RECIPE MENU
The display shows the shelf posi-
tion and the default cooking
times for all automatic recipes.
14 www.aeg.com

There are 25 automatic pro-
grammes and recipes. Use an au-
tomatic programme or recipe
when you do not have the knowl-
edge or experience on how to
prepare a dish. You can find the
list of the recipes for the auto-
matic programmes in the "Rec-
ipe book".
There are three types of automatic
programmes:
•Automaticrecipes
• Automatic programmes with weight
input
• Automatic programmes with the core
temperature sensor
8.2 Automatic programmes
Programme number Programme name
1VEGETABLES, TRADITIONAL
2POTATO GRATIN
3FARMER BREAD
4ROLLS
5FILLET OF FISH
6POACHED FISH (TROUT)
7PLUM DUMPLING
8VEAL KNUCKLE
9RICE
10 LASAGNE
11 DOUGH PROVING
12 BRAISED MEAT
13 ROAST PORK
14 ROAST VEAL
15 ROAST LAMB
16 ROAST GAME
17 CHICKEN, WHOLE
18 PIZZA
19 QUICHE LORRAINE
20 LEMON SPONGE CAKE
21 CHEESE CAKE
22 CANNELLONI
23 CONVENIENCE CAKE
24 CONVENIENCE PIZZA
25 CONVENIENCE POTATO TYPES
ENGLISH 15

You can find the recipes for the
automatic programmes specified
for this appliance on our website.
To find the proper Recipe Book
check the PNC number on the
rating plate on the front frame of
the appliance cavity.
8.3 Automatic recipes
Setting an automatic recipe:
1. Activate the appliance.
2. Touch . The display shows , a
symbol and the number of the auto-
matic programme.
3. Touch or to choose the auto-
matic recipe.
4. Touch or the automatic recipe
activates automatically after five sec-
onds.
5. When the set time ends, an acoustic
signal sounds for two minutes.
flashes.
The appliance deactivates.
6. Touch a sensor field or open the ap-
pliance door to stop the acoustic
signal.
8.4 Automatic programmes
with weight input
If you set the weight of the meat, the ap-
pliance calculates the roasting time.
1. Activate the appliance.
2. Touch .
3. Touch or to set the weight
programme (refer to the "Recipe
book").
The display shows: the cooking time,
the duration symbol , a default
weight, a unit of measurement (kg,
g).
4. Touch or the settings save auto-
matically after five seconds.
5. The appliance activates. A symbol of
the weight unit flashes in the display.
During this time you can change the
default weight value with or .
Touch .
6. When the set time ends, an acoustic
signal sounds for two minutes.
flashes. The appliance deactivates.
7. Touch a sensor field or open the
door to stop the acoustic signal.
8.5 Automatic programmes
with the core temperature
sensor
The core temperature of the food is de-
fault and fixed in programmes which use
the core temperature sensor. The pro-
gramme ends when the appliance is at
the set core temperature.
1. Activate the appliance.
2. Touch again and again until the
display shows .
3. Install the core temperature sensor
(refer to "The core temperature sen-
sor").
4. Touch or to see the core
temperature sensor programmes.
When a core temperature sensor
programme is set, the display shows
the cooking time, and .
5. Touch or the settings save auto-
matically after five seconds.
6. When the set time ends, an acoustic
signal sounds for two minutes.
flashes.
The appliance deactivates.
7. Touch a sensor field or open the
oven door to stop the acoustic sig-
nal.
9. USING THE ACCESSORIES
WARNING!
Refer to the Safety chapters.
16 www.aeg.com

9.1 Core Temperature Sensor
The core temperature sensor measures
the core temperature of the meat. When
the meat is at the set temperature, the
appliance deactivates.
There are two temperatures to set:
• The oven temperature: refer to the ta-
ble for roasting in the recipe book.
• The core temperature: refer to the ta-
ble for the core temperature sensor in
the recipe book.
Only use the core temperature
sensor supplied or the correct re-
placement parts.
1. Activate the appliance.
2.
Put the tip of the core temperature
sensor (with on the handle) into
the centre of the meat.
3. Put the plug of the core temperature
sensor into the socket at the front of
the appliance.
The display shows and the de-
fault set core temperature. The tem-
perature is 60 °C for the first opera-
tion, and the last set value for each
subsequent operation.
4. Touch or to set the core
temperature.
5. Touch or the settings save auto-
matically after 5 seconds.
Useful information:
You can set the core temperature
only when flashes. If is in
the display but does not flash before
you set the core temperature, touch
and or to set a new val-
ue.
6. Set the oven function and, if neces-
sary, the oven temperature.
The display shows the current core
temperature and the temperature
bar, which shows the relation be-
tween the set oven temperature and
the current oven temperature.
Useful information:
The core temperature sensor must
stay in the meat and in the socket
during the cooking.
While the appliance calculates the
approximate duration time, the val-
ue of the Count Up Timer function
shows in the Timer / residual heat
display. When the first calculation
ends, an acoustic signal sounds and
the Timer / residual heat display
shows —:— and then the approxi-
mate duration of the cooking. The
appliance continues to calculate the
duration during the cooking. The
display updates at intervals with the
new duration value.
7. When the meat is at the set core
temperature, the core temperature
and flash. An acoustic signal
sounds for two minutes. Touch a
sensor field to deactivate the acous-
tic signal.
8. Remove the core temperature sen-
sor from the socket and remove the
meat from the appliance.
WARNING!
Be careful when you remove the
core temperature sensor. It is
hot. There is a risk of burns.
9. Deactivate the appliance.
When you put the core tempera-
ture sensor into the socket, you
cancel the settings for the clock
functions.
When you cook with the core tempera-
ture sensor, you can change the temper-
ature shown in the Temperature / Time
display. After you put the core tempera-
ture sensor into the socket and set an
oven function and temperature, the dis-
play shows the current core tempera-
ture.
ENGLISH 17

Touch again and again to see
three other temperatures:
• The set core temperature
• The current oven temperature
• The current core temperature.
The set core temperature changes into
the current core temperature and the
current oven temperature changes into
the set oven temperature.
9.2 Inserting the oven accessories
The deep pan and the wire shelf have
side edges. These edges and the shape
of the guide-bars are a special device to
prevent the cookware from slipping.
Inserting the wire shelf and the deep
pan together
Put the wire shelf on the deep pan. Push
the deep pan between the guide-bars of
one of the oven levels.
9.3 Trivet and Grill- / Roasting
pan
WARNING!
Be careful when you remove the
accessories from a hot appliance.
There is a risk of burns.
You can use the trivet to roast larger
pieces of meat or poultry on one shelf
position:
• Put the trivet into the deep pan so
that the supports of the wire shelf
point up.
• Put the deep pan into the oven on the
necessary shelf position.
18 www.aeg.com

You can use the trivet to grill flat
dishes in large quantities and to toast:
• Put the trivet into the deep pan so
that the supports of the wire shelf
point down.
• Put the deep pan into the oven on the
necessary shelf position.
10. ADDITIONAL FUNCTIONS
10.1 My Favourite Programme
function
Use this function to save your favourite
temperature and time settings for an
oven function or programme.
1. Set the temperature and time for an
oven function or programme.
2. Touch and hold for more than
three seconds. An acoustic signal
sounds.
3. Deactivate the appliance.
Using My Favourite Programme
function:
•To activate the function touch .
The appliance activates your favourite
programme.
•To deactivate the function touch .
The appliance deactivates your favour-
ite programme.
When the function operates, you
can change the time and temper-
ature.
10.2 Child Lock
The Child Lock prevents an accidental
operation of the appliance.
Activating and deactivating the Child
Lock function:
1. Deactivate the appliance with .
Do not set an oven function.
2. Touch and hold and at the
same time for 2 seconds. An acous-
tic signal sounds.
SAFE comes on or goes out in the dis-
play.
10.3 Function Lock
You can activate the function only when
the appliance operates. The Function
Lock prevents an accidental change of
the oven function.
Activating / deactivating the Function
Lock function:
1. Activate the appliance.
2. Activate an oven function or setting.
3. Touch and hold and at the
same time for 2 seconds. An acous-
tic signal sounds.
Loc comes on or goes out in the display.
You can deactivate the appliance when
the Function Lock is on. When you deac-
tivate the appliance, the Function Lock
deactivates.
10.4 Settings menu
The settings menu lets you to add or re-
move functions from the main menu (for
example: you can set on or off the Resid-
ual heat indicator). Settings menu has six
settings (from SET1 to SET6).
ENGLISH 19

Settings menu
Indicator of the setting
menu
Description Value to set
SET1 SET+GO ON / OFF
SET2 RESIDUAL HEAT INDI-
CATOR ON / OFF
SET3
1)
KEY TONE CLICK / BEEP / OFF
SET4 FAULTY TONE ON / OFF
SET5 SERVICE MENU ON / OFF
SET6 RESTORE SETTINGS YES / NO
1) It is not possible to deactivate the tone of the ON / OFF sensor field.
You can set the settings menu
only when the appliance is off.
Activate the Settings menu:
1. If necessary, deactivate the appli-
ance .
2. Touch and hold for three sec-
onds.
The display shows "SET1" and "1"
flashes.
3. Touch / to set the setting.
4. Touch .
5. Touch / to change the value
of the setting.
6. Touch .
10.5 Automatic switch-off
For safety reasons the appliance deacti-
vates automatically after some time:
• if an oven function operates.
• if you do not change the oven temper-
ature.
Temperature Switch-off time
30 °C - 115 °C 12.5 h
120 °C - 195 °C 8.5 h
200 °C - 230 °C 5.5 h
After the Automatic switch-off, touch a
sensor field to operate the appliance
again.
The Automatic switch-off works
with all oven functions, apart
from Slow Cook, Core tempera-
ture sensor, Duration, End, Time
delay.
10.6 Brightness of the display
There are two modes of display
brightness:
• Night brightness - when the appliance
is deactivated, the brightness of the
display is lower between 10 PM and 6
AM.
• Day brightness:
– When the appliance is activated.
– If you touch a sensor field during
the night brightness (apart from
ON / OFF), the display goes back to
the day brightness mode for the
next 10 seconds.
– If the appliance is deactivated and
you set the Minute Minder. When
the Minute Minder function ends,
the display goes back to the night
brightness.
10.7 Cooling fan
When the appliance operates, the cool-
ing fan activates automatically to keep
the surfaces of the appliance cool. If you
deactivate the appliance, the cooling fan
20 www.aeg.com
