AEG NC7003000 User manual

NC7003000
EN
OVEN USER MANUAL

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to keep all your AEG
appliances looking spotless and working perfectly. Along with a wide range of
accessories designed and built to the high quality standards you would expect,
from specialist cookware to cutlery baskets, from bottle holders to delicate
laundry bags…
Visit the webshop at:
www.aeg.com/shop
2

CONTENTS
4 Safety information
7 Product description
8 Before first use
9 Control panel
10 Daily use
12 Clock functions
13 Additional functions
14 Using the accessories
16 Helpful hints and tips
24 Care and cleaning
28 What to do if…
29 Installation
32 Environment concerns
32 GREAT BRITAIN & IRELAND -
Guarantee/Customer Service
The following symbols are used in this user
manual:
Important information concerning your
personal safety and information on how to
avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice
Contents 3

SAFETY INFORMATION
Before the installation and use, read this manual carefully:
• For your personal safety and the safety of your property
• For the respect of the environment
• For the correct operation of the appliance.
Always keep these instructions with the appliance also if you move or sell it.
The manufacturer is not responsible if incorrect installation or use results in damage.
Children and vulnerable people safety
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in safe
way and understand the hazards involved. Children shall not play with the appliance.
• Keep all packaging away from children. There is the risk of suffocation or physical injury.
•WARNING: Keep children and animals away from the appliance when the door is open
or the appliance is in the operation, because it becomes hot. There is the risk of injury or
other permanent disability.
• If the appliance has Child Lock or Key Lock (Control Lock) function, use it. It prevents
children and animals from accidental operation of the appliance.
General safety
• Do not change the specifications of this appliance. There is the risk of injury and damage
to the appliance.
• Do not let the appliance stay unattended during operation.
• Switch off the appliance after each use.
Installation
• Only an approved electrician can install and connect the appliance. Contact an approved
service centre. This is to prevent the risks of structural damage or physical injury.
• Make sure that the appliance is not damaged because of transport. Do not connect a
damaged appliance. If necessary, contact the supplier.
• Remove all packaging, stickers and layers from the appliance before first use. Do not re-
move the rating plate. It can invalidate the guarantee.
• Make sure that the appliance is disconnected from the power supply during the installa-
tion.
• Be careful when you move the appliance. The appliance is heavy. Always use safety
gloves. Do not lift the appliance by the handle.
• The electrical installation must have an isolation device which lets you disconnect the
appliance from the mains at all poles. The isolation device must have a contact opening
width of minimum 3 mm.
• You must have correct isolation devices: line protecting cut-outs, fuses (screw type fuses
removed from the holder), earth leakage trips and contactors.
4Safety information

• Before the installation, make sure that the kitchen cabinet has the recess dimensions ap-
plicable.
• Make sure that the appliance is installed below and adjacent safe structures.
• Keep the minimum distances to the other appliances and units.
• The appliance cannot be positioned on a base.
• Built in ovens and built in cooking surfaces are attached with special connection system.
To prevent damage to the appliance, only use an appliance with the appliances from the
same manufacturer.
Electrical connection
• The appliance must be earthed.
• Make sure that the electrical data on the rating plate agree with your domestic power
supply.
• Information on the voltage is on the rating plate.
• Always use a correctly installed shockproof socket.
• Do not use multi-way plugs, connectors and extension cables. There is the risk of fire.
• Do not replace or change the mains cable. Contact the service centre.
• Make sure not to squash or cause damage to the mains plug (if applicable) and cable
behind the appliance.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug – if
applicable.
Use
• The appliance is only for domestic use. Do not use the appliance for commercial and in-
dustrial use.
• Only use the appliance for domestic cooking tasks. This is to prevent physical injury to
persons or prevent damage to property.
• Do not use the appliance as a work surface or storage surface.
• The interior of the appliance becomes hot during use. There is the risk of burns. Do not
touch the heating elements in the appliance. Use gloves when you insert or remove the
accessories or pots.
• Be careful when you remove or install the accessories to prevent damage to the oven
enamel.
• Always stay away from the appliance when you open the door while the appliance is in
operation. Hot steam can release. There is the risk of skin burns.
• To prevent damage or discoloration to the enamel:
– do not put any objects directly on the appliance floor and do not cover it with alumi-
nium foil;
– do not put hot water directly into the appliance;
– do not keep moist dishes and food in the appliance after you finish the cooking.
• Discoloration of the enamel has no effect on the performance of the appliance so it is
not a defect in the sense of the warranty law.
• Do not apply pressure on the open door.
Safety information 5

• Always close the appliance door when you cook, even while grilling.
Care and cleaning
• Before maintenance, switch off the appliance and disconnect the appliance from the
power supply.
• Before maintenance, make sure that the appliance is cold. There is the risk of burns.
There is the risk that the glass panels can break.
• Keep the appliance clean at all times. A build-up of fats or other foodstuff can result in a
fire.
• Regular cleaning prevents the surface material from deteriorating
• Use a deep baking tray for very moist cakes to prevent that fruit juices cause stains that
can be permanent.
• For your personal safety and the safety of your property, only clean the appliance with
water and a soap. Do not use flammable products or products that can cause corrosion.
• Do not clean the appliance with steam cleaners, high-pressure cleaners, sharp objects,
abrasive cleaning agents, abrasive sponges and stain removers
• If you use an oven spray, follow the instructions from the manufacturer.
• Do not clean the glass door with abrasive cleaning agents or metal scraper. Heat resist-
ant surface of the inner glass can break and shatter.
• When the door glass panels are damaged they become weak and can break. You must
replace them. Contact the service centre.
• Be careful when you remove the door from the appliance. The door is heavy!
• Do not clean catalytic enamel (if applicable).
Risk of fire
• Open the door carefully. The use of ingredients with alcohol can cause a mixture of alco-
hol and air. There is the risk of fire.
• Do not let sparks or open flames come near the appliance when you open the door.
• Do not put flammable products or items that are wet with flammable products, and/or
fusible objects (made of plastic or aluminium) in, near or on the appliance.
Oven lamp
• Bulb lamps used in this appliance are special lamps selected for household appliances use
only. They cannot be used for the full or partial illumination of a household room.
• If it becomes necessary to replace the lamp use one of the same power and specifically
designed for household appliances only.
• Disconnect the appliance from the power supply before the replacement of the oven
lamp. There is the risk of electrical shock.
Service centre
• Only an approved engineer can repair or work on the appliance. Contact an approved
service centre.
• Use only original spare parts.
6Safety information

Disposal of the appliance
• To prevent the risk of physical injury or damage
– Disconnect the appliance from the power supply.
– Cut off the mains cable and discard it.
– Discard the door catch. This prevents children or small animals from being closed in-
side of the appliance. There is the risk of suffocation.
PRODUCT DESCRIPTION
General overview
1
1
2
3
4
5
6
2
2
5
5
6
4
4
3
6
1
2
3
4
3
1Electronic programmer
2Heating element
3Oven lamp
4Fan and rear wall heating element
5Heating element
6Shelf positions
Oven accessories
•Oven shelf
For cookware, cake tins, roasts.
•The roasting pan grid
To put in the deep roasting pan.
•Deep roasting pan
To bake and roast or as pan to collect fat.
Product description 7

BEFORE FIRST USE
WARNING!
Refer to "Safety information" chapter.
Initial Cleaning
• Remove all parts from the appliance.
• Clean the appliance before first use.
Refer to chapter "Care and Cleaning".
Setting the time
The oven only operates after time set.
When you connect the appliance to the electrical supply or in case of a power cut, the Time
function indicator flashes automatically.
To set the current time use the or button.
After approximately 5 seconds, the flashing stops and the display shows the time of day set.
You can only change the Time of day if :
• the switch-on lock is not on
• none of the clock functions Duration or End is set
• no oven function is set.
Pre-heating
1. Set function and maximum temperature.
2. Let the appliance operate without the food for approximately 1 hour.
3. Set function and maximum temperature.
4. Let the appliance operate without the food for approximately 10 minutes.
5. Set function and maximum temperature.
6. Let the appliance operate without the food for approximately 10 minutes.
This is to burn off the residue in the appliance. The accessories can become more hot than
usually. When you pre-heat the appliance for the first time, the appliance can make an
odour and smoke. This is the usual effect. Make sure the airflow is sufficient.
8Before first use

CONTROL PANEL
Control panel
7 6 5 4 2
1
3
Number Button Function Description
1
–Display Shows current settings of the oven.
2
Clock function
button To set a clock function.
3
Setting buttons To set the value for the temperature and time.
4
Temperature but-
ton To show an oven temperature.
5
Oven function se-
lection To set an oven function or programme.
6
Oven selection To switch between top and main oven.
7
On/Off To set the oven on or off.
Indicators of display
21 5 6 43 7 8
Number Name Description
1
Top/Main oven indicator Shows which oven operates.
2
Oven function indicator Shows the function.
3
Lamp/Defrost indicator Shows the Lamp/Defrost function is active.
Control panel 9

Number Name Description
4
Heat indicator Shows the heat setting.
5
Temperature/Clock indi-
cator
Shows the temperature and the time in minutes.
6
Keep warm indicator Shows that keep warm function is active.
7
Cooking time/End time/
Period of operation
Shows the time setting for clock functions.
8
Clock function indicator To set the clock function and minute minder.
DAILY USE
WARNING!
Refer to "Safety information" chapter.
Switching the appliance on and off
Press the On/Off button to switch the appliance on or off.
Top oven functions
Oven function Application
Light To light up the oven interior.
True Fan
To bake and roast on one oven level at the same
time. Decrease the oven temperatures (20-40 °C)
compared with Conventional.
Fan Baking
To bake on one oven level with a more intensive
browning and a crispy base. Set the oven tempera-
tures 20-40 °C lower than when using Conventional.
Conventional Cooking To bake and roast on one oven level.
Slow Cook To prepare very lean, tender roasted food.
Rotitherm Roasting To roast larger joints of meat or poultry on one level.
Also to gratinate and brown.
Full Grill To grill flat food in large quantities. To toast bread.
Economy Grill To grill flat food items in small quantities in the mid-
dle of the grill. To make toast.
Fan Controlled Defrost-
ing To defrost frozen food.
Base Heating Finishing To bake cakes with crispy or crusty bases and to pre-
serve food.
10 Daily use

Main oven functions
Oven function Application
Light To light up the oven interior.
True Fan
To roast or roast and bake the food that requires the
same cooking temperature, using more than one
shelf, without flavour transference.
Fan Baking
To bake on one oven level with a more intensive
browning and a crispy base. Set the oven tempera-
tures 20-40 °C lower than when using Conventional.
Slow Cook To prepare very lean, tender roasted food.
Conventional Cooking To bake and roast on one oven level.
Rotitherm Roasting To roast larger joints of meat or poultry on one shelf
position. To brown.
Full Grill To grill flat food in large quantities. To toast bread.
Economy Grill To grill flat food items in small quantities in the
middle of the grill. To make toast.
Keep Warm To keep food warm.
Fan Controlled Defrost-
ing To defrost frozen food.
Base Heat Finishing To bake cakes with crispy or crusty bases and to pre-
serve food.
Selecting an oven
1. Switch on the appliance using the On/Off button.
2. Press the button repeatedly until the desired oven appears (Top / Main )
Setting the oven function
Use to set the oven function.
The display shows the recommended temperature.
If you do not change this temperature in less than approximately 5 seconds, the appliance
starts to heat.
When the appliance operates at the set temperature, an acoustic signal sounds.
You can change the oven function while the oven operates.
Changing the oven temperature
Press the or button to set the temperature.
Daily use 11

Checking the oven temperature
Press the Temperature check button to display the current temperature of the oven.
Switching off the oven function
Use again and again, until the display does not show an oven function.
Heat- up indicator
If you switch on an oven function, the bars on the display come on one by one. The bars
show that the oven temperature increases.
Residual heat indicator
When you switch off the oven, the bars on the display show the residual heat.
CLOCK FUNCTIONS
Clock functions
1
7 6 5
2 3 4
1Time of day
2Duration
3End
4Minute Minder
5Selection button
6Setting button (Plus)
7Setting button (Minus)
SYMBOL FUNCTION DESCRIPTION
Minute Minder To set a countdown (max. 99 minutes). This function has no
effect on the operation of the appliance.
Duration To set how long the appliance has to be in operation.
End To set the switch-off time for an oven function.
You can use Duration and End at the same time, if the ap-
pliance is to be switched on and off automatically later.
Time of day To set, change or control the time of day.
• If you set a clock function, the symbol flashes for approximately 5 seconds. In these 5
seconds, touch or to set the time.
• If you set the time, the symbol continues to flash for approximately 5 seconds. After
these 5 seconds, the symbol comes on. The time starts to count down.
Setting the clock functions
1. Switch on the appliance.
12 Clock functions

2. Use again and again until the display shows the necessary clock function and the
related symbol, for example Minute Minder .
3. Use or to set the necessary time.
You can hear an acoustic signal for 2 minutes when the time is completed, “00.00” and
the related function indicator flash. The appliance switches off.
4. Use any button to switch off the acoustic signal.
With Minute Minder the oven must be switched on to set the clock function.
With Duration and End the oven switches off automatically.
With Duration and End you must set the oven function and the temperature first,
then you can set the clock function.
Heat+Hold
To keep the prepared food warm for 30 minutes, after the cooking is completed.
Switching on Heat+Hold
1. Set clock functions Duration and/or End .
2. Use Selection again and again, until the display shows the symbol Keep warm .
3. Use , the display shows “00:30”
4. When the set oven function is completed, a signal sounds and Heat+Hold starts. The
set oven function operates at 80°C for 30 minutes. The oven then switches off auto-
matically.
The temperature for the set oven function must be above 80°C.
ADDITIONAL FUNCTIONS
Cooling fan
When the appliance operates, the cooling fan switches on automatically. If you switch off
the appliance, the cooling fan continues to operate until the appliance cools down.
Switch-on lock
WARNING!
When the switch-on lock is set, you can not operate the oven.
Switching on the switch-on lock
1. Switch on the appliance. No oven function must be set.
2. Use Selection and at the same time, until the display shows “SAFE”. The switch-
on lock is switched on.
Switching off the switch-on lock
1. If necessary, switch on the appliance.
2. Use Selection and at the same time, until the display stops to show "SAFE". The
switch-on lock switches off.
Additional functions 13

Key lock
This function prevents that you accidentally change the oven function.
Switching on the key lock
1. If necessary, switch on the appliance.
2. Set an oven function.
3. Use Selection and at the same time, until the display shows “LOC”. The key lock
is switched on.
Switching off the key lock
1. Use Selection and at the same time, until the display stops to show "LOC". The
key lock switches off.
The key lock is automatically canceled when the oven function is switched off.
Automatic cut-out
The appliance switches off after some time:
• if you do not switch off the appliance;
• if you do not change the oven temperature.
The last temperature set flashes in the temperature display.
Oven temperature Switch-off time
30 °C -120 °C 12.5 h.
120 °C - 200 °C 8.5 h.
200 °C -250 °C 5.5 h.
250 °C -maximum °C 3.0 h.
After an automatic cut-out, switch off the oven fully. Then you can switch it on again.
If you set the clock function Duration or End , the automatic cut-out switches off.
USING THE ACCESSORIES
WARNING!
Refer to "Safety information" chapter.
Inserting the Oven Accessories
Put in the slide-in accessories so that the double side edges are at the back of the oven and
point down to the bottom. Push the slide-in accessories between the guide-bars of one of
the oven levels.
14 Using the accessories

The deep roasting pan and the oven shelf have
double side edges. These edges and the shape of
the guide-bars causes the anti-tilt safety for the
oven accessories.
Inserting the oven shelf and deep roasting pan
together
Put the oven shelf on the deep roasting pan. Push
the deep roasting pan between the guide-bars of
one of the oven levels.
Grilling set
The grilling set includes the roasting pan grid and the deep roasting pan.
You can use the roasting pan grid in two positions: turned up and down.
To roast larger pieces of meat or poultry on one level:
1. Put the roasting pan grid in the deep
roasting pan. The supports of the roast-
ing pan grid must point up.
2. Put the deep roasting pan in the appli-
ance, on the necessary shelf level.
Using the accessories 15

To grill flat dishes in large quantities and to toast:
1. Put the roasting pan grid in the deep
roasting pan. The supports of the roast-
ing pan grid must point down.
2. Put the deep roasting pan in the appli-
ance, on the necessary shelf level.
HELPFUL HINTS AND TIPS
WARNING!
Refer to "Safety information" chapter.
The temperature and baking times in the tables are guidelines only. They depend on the
recipes, quality and quantity of the ingredients used.
CAUTION!
Use a deep baking tray for very moist cakes. Fruit juices can cause permanent stains on the
enamel.
Top oven
The top oven is the smaller of the two ovens. It has 6 shelf levels. Use is to cook smaller
quantities of food. It gives especially good results when used to cook fruitcakes, sweets and
savoury flants or quiche.
Main oven
The main oven is particularly suitable for cooking larger quantities of food.
Baking
General instructions
• Your new oven may bake or roast differently to the appliance you had before. Adapt your
usual settings (temperature, cooking times) and shelf levels to the values in the tables.
• With longer baking times, the oven can be switched off about 10 minutes before the end
of baking time, to use the residual heat.
When you use frozen food, the trays in the oven can twist during baking. When the
trays get cold again, the distortion will be gone.
How to use the Baking Tables
• We recommend to use the lower temperature the first time.
16 Helpful hints and tips

• If you cannot find the settings for a special recipe, look for the one that is almost the
same.
• Baking time can be extended by 10-15 minutes, if you bake cakes on more than one lev-
el.
• Cakes and pastries at different heights do not always brown equally at first. If this oc-
curs, do not change the temperature setting. The differences equalize during the baking
procedure.
Tips on baking
Baking results Possible cause Remedy
The cake is not
browned sufficiently
below
Incorrect oven level Put the cake on a lower oven level
The cake sinks (be-
comes soggy, lumpy,
streaky)
Oven temperature too high Use a lower setting
The cake sinks (be-
comes soggy, lumpy,
streaky)
Baking time is too short Set a longer baking time
Do not set higher temperatures to de-
crease baking times
The cake sinks (be-
comes soggy, lumpy,
streaky)
Too much liquid in the mix-
ture
Use less liquid. Look at the mixing times,
specially when you use mixing machines
Cake is too dry Oven temperature too low Set a higher oven temperature
Cake is too dry Baking time too long Set a shorter baking time
Cake does not brown
equally
Oven temperature too high
and baking time too short
Set a lower oven temperature and a longer
baking time
Cake does not brown
equally
No equal mixture Put the mixture equally on the baking tray
Cake does not cook in
the baking time set
Temperature too low Use a slightly higher oven temperature
setting
Top oven
Baking
Shelf Positions are not critical but ensure that oven shelves are evenly spaced when more
than one is used (e.g. shelf positions 1 and 3)
Food Temperature
[°C]
Approx Cook Time
(mins)
Biscuits 170 - 190 10 - 20
Bread 200 - 220 30 - 35
Bread rolls/buns 200 - 220 10 - 15
Cakes:
Helpful hints and tips 17

Food Temperature
[°C]
Approx Cook Time
(mins)
- Small & Queen 160 - 170 18 - 25
- Sponges 160 - 170 20 - 30
- Victoria Sandwich 160 - 170 18 - 25
- Madeira 140 - 150 75 - 90
- Rich Fruit 140 - 150 120 - 150
- Gingerbread 140 - 150 75 - 90
- Meringues 90 - 100 150 - 180
- Flapjack 160 - 170 25 - 30
- Shortbread 130 - 150 45 - 65
Casseroles:
- Beef/Lamb 140 - 160 150 - 180
- Chicken 140 - 160 75 - 90
Convenience Foods Follow manufacturer´s instructions.
Fish 160 - 180 20 - 30
Fish Pie (Potato Topped) 170 - 180 20 - 30
Fruit Pies, Crumbles 170 - 190 30 - 50
Milk Puddings 140 - 160 90 - 120
Pasta Lasagne etc. 160 - 180 40 - 50
Pastry:
- Choux 180 - 190 30 - 40
- Eclairs, Profiteroles 170 - 180 30 - 40
- Flaky/Puff Pies 180 - 190 30 - 40
Shortcrust:
- Mince Pies 180 - 190 15 - 20
- Meat Pies 180 - 200 25 - 35
- Quiche, Tarts, Flans 170 - 190 25 - 50
Scones 210 - 220 8 - 12
Shepard´s Pie 180 - 190 30 - 40
Soufflés 170 - 180 20 - 30
Vegetables:
- Baked Jacket Potatoes 180 - 190 60 - 90
- Roast Potatoes 180 - 190 60- 90
Yorkshire Pudding:
18 Helpful hints and tips

Food Temperature
[°C]
Approx Cook Time
(mins)
- Large 180 - 190 25 - 40
- Individual 200 - 210 15 - 25
Roasting Meat, Poultry See roasting chart.
Baking
Food Shelf Position Temperature
[°C]
Approx Cook Time
(mins)
Apple Pie 2160 - 180 160 - 180
Plate Tart 2160 - 180 25 - 50
Pizza 2Follow manufacturer´s instructions.
Quiches/Tarts 2160 - 180 25 - 50
Main oven
Baking
Shelf Positions are not critical but ensure that oven shelves are evenly spaced when more
than one is used (e.g. shelf positions 1 and 3)
Food Temperature
[°C]
Approx Cook Time
(mins)
Biscuits 180 - 190 10 - 20
Bread 190 - 210 30 - 35
Cakes:
- Small & Queen 160 - 170 18 - 25
- Sponges 160 - 170 20 - 25
- Madeira 140 - 160 60 - 75
- Rich Fruit 130 - 140 120 - 150
- Christmas 130 - 140 180 - 270
Fish 160 - 180 20 - 30
Fruit Pies, Crumbles 170 - 180 30 - 50
Milk Puddings 140 - 160 60 - 90
Pastry:
- Choux 180 - 190 30 - 40
- Shortcrust 180 - 190 25 - 35
- Flaky 180 - 190 30 - 40
- Puff Follow manufacturer´s instructions; Reduce the temperature for
Fan oven by 20°C
Helpful hints and tips 19

Food Temperature
[°C]
Approx Cook Time
(mins)
Plate Tarts 180 - 190 25 - 45
Quiches/Flans 170 - 180 25 - 45
Scones 210 - 230 8 - 12
Roasting: Meat and Poultry 160 - 180 see Roasting Chart
Baking
Food Shelf Position Temperature [°C] Approx Cook Time (m)
Apple Pie 3160 - 180 50 - 60
Plate Tart 3180 - 200 25 - 50
Pizza 3Follow manufacturer´s instructions
Quiches/Tarts 3180 - 200 25 - 50
Baking
Food Temperature
[°C]
Approx Cook Time
(mins) Shelf Position
Biscuits 180 - 190 10 - 20 3
Bread 200- 220 30 - 35 3
Cakes:
- Small & Queen 170 - 180 18 - 25 3
- Sponges 170 - 180 20 - 25 3
- Madeira 150 - 160 60 - 75 3
- Rich Fruit 140 - 150 120 - 150 3
- Christmas 140 - 150 180 - 270 3
Fish 170 - 180 20 - 30 3
Fruit Pies, Crumbles 180 - 200 30 - 50 3
Milk Puddings 150 - 170 60 - 90 3
Pastry:
- Choux 180 - 190 30 - 40 3
- Shortcrust 190 - 200 25 - 35 3
- Flaky 190 - 210 30 - 40 3
- Puff Follow manufacturer´s instructions
Plate Tarts 190 - 200 25 - 45 3
Quiches/Flans 200 - 210 25 - 45 3
Scones 220 - 230 8 - 12 3
20 Helpful hints and tips
