MH 5 G

Technical Data,Safety Instructions, Specied Conditions of Use,
Declaration of Conformity, Mains connection, Maintenance, Symbols Please read and save these instructions!
English
55
Technische Daten, Sicherheitshinweise, Bestimmungsgemäße Verwendung,
CE-Konformitätserklärung, Netzanschluss, Wartung, Symbole Bitte lesen und aufbewahren!
Deutsch
88
Caractéristiques techniques,Instructions desécurité, Utilisationconforme aux
prescriptions, Déclaration CE de Conformité,Branchement secteur,Entretien, Symboles A lire et à conserver soigneusement
Français
1010
Dati tecnici,Norme di sicurezza,Utilizzo conforme, Dicharazione di Conformità CE,
Collegamento alla rete, Manutenzione, Simboli Si prega di leggere e conservare le istruzioni!
Italiano
1212
Datos técnicos, Instrucciones de seguridad, Aplicación de acuerdo a la nalidad,
Declaracion de Conformidad CE, Conexión eléctrica, Mantenimiento, Símbolos Lea y conserve estas instrucciones por favor!
Español
1414
Características técnicas, Instruções de segurança, Utilização autorizada,
Declaração de Conformidade CE, Ligação à rede, Manutenção, Symbole Por favor leia e conserve em seu poder!
Português
1616
Technische gegevens, Veiligheidsadviezen, Voorgeschreven gebruik van het
systeem, EC-Konformiteitsverklaring, Netaansluiting,Onderhoud, Symbolen Lees en let goed op deze adviezen!
Nederlands
1818
Tekniske data, Sikkerhedshenvisninger, Tiltænkt formål,
CE-Konformitetserklæring, Nettilslutning, Vedligeholdelse, Symboler Vær venlig at læse og opbevare!
Dansk
2020
Tekniske data, Spesielle sikkerhetshenvisninger, Formålsmessig bruk,
CE-Samsvarserklæring, Nettilkopling, Vedlikehold, Symboler Vennligst les og oppbevar!
Norsk
2222
Tekniska data, Säkerhetsutrustning, Använd maskinen Enligt anvisningarna,
CE-Försäkran, Nätanslutning, Skötsel, Symboler Läs igenom och spara!
Svenska
2424
Tekniset arvot, Turvallisuusohjeet, Tarkoituksenmukainen käyttö,
Todistus CE-standardinmukaisuudesta, Verkkoliitäntä, Huolto, Symbolit Lue ja säilytä!
Suomi
2626
Τεχνικά στοιχεία, Ειδικές υποδείξεις ασφάλειας, Χρήση σύμφωνα με το σκοπό
προορισμού, Δήλωση πιστότητας ΕΚ, Σύνδεση στο Ηλεκτρικό Δίκτυο, Συντήρηση, Σύμβολα. Παρακαλούμε να τις διαβάσετε και να τις φυλάξετε!
Ελληνικά
2828
Teknik veriler, Güvenliğiniz için talimatlar, Kullanim, CE uygunluk beyanice,
Şebeke bağlantisi, Bakim, Semboller Lütfen okuyun ve saklayın
Türkçe
3030
Technická data, Speciální bezpečnostní upozornění, Oblast využití,
CE-prohlášení o shodě, Připojení na sít, Údržba, Symboly Po přečtení uschovejte
Česky
3232
Technické údaje, Špeciálne bezpčènostné pokyny, Použitie podl’a predpisov,
CE-Vyhlásenie konformity, Siet’ová prípojka, Údrzba, Symboly Prosím prečítať a uschovať!
Slovensky
3434
Danetechniczne, Specjalnezaleceniadotyczącebezpieczeństwa, Użytkowaniezgodne z
przeznaczeniem, Świadectwo zgodnościce,Podłączenie do sieci,Utrzymanie,Symbole Należy uważnie przeczytać i zachować do wglądu!
Polski
3636
Műszaki adatok, Különleges biztonsági tudnivalók, Rendeltetésszerű használat,
Ce-azonossági nyilatkozat, Hálózati csatlakoztatás, Karbantartás, Szimbólumok Olvassa el és őrizze meg
Magyar
3838
Tehnični podatki, Specialni varnostni napotki, Uporaba v skladu z namembnostjo,
CE-izjava o konformnosti, Omrežni priključek, Vzdrževanje, Simboli Prosimo preberite in shranite!
Slovenščina
4040
Tehnički podaci, Specijalne sigurnosne upute, Propisna upotreba,
CE-Izjava konformnosti, Priključak na mrežu, Održavanje, Simboli Molimo pročitati i sačuvati
Hrvatski
4242
Tehniskie dati, Speciālie drošības noteikumi, Noteikumiem atbilstošs izmantojums,
Atbilstība CE normām, Tīkla pieslēgums, Apkope, Simboli Lūdzu, izlasīt un uzglabāt!
Latviski
4444
Techniniai duomenys, Ypatingos saugumo nuorodos, Naudojimas pagal paskirti,
CE Atitikties pareiškimas, Elektros tinklo jungtis, Techninis aptarnavimas, Simboliai Prašome perskaityti ir neišmesti!
Lietuviškai
4646
Tehnilised andmed, Spetsiaalsed turvajuhised, Kasutamine vastavalt otstarbele,
EÜ Vastavusavaldus, Võrku ühendamine, Hooldus, Sümbolid Palunlugege läbija hoidkealal!
Eesti
4848
Технические данные, Указания по безопасности, Использование, Декларация о
соответствии стандартам EC, Ïîäêëþ÷åíèå ê ýëåêòðîñåòè , Обслуживание, Символы Пожалуйста прочтите и сохранитеэту инструкцию.
Pусский
5050
Технически данни, Специални указания за безопасност, Използване попредназначение,
СЕ - Декларация за съответствие, Връзка c Електричество, Поддръжка, Символи Моля прочетете и запазете!
Български
5353
Date tehnice, Instrucţiuni de securitate, Condiţii de utilizare specifcate,
Declaraţie de conformitate, Alimentare de la reţea, Intreţinere, Simboluri Va rugăm citiţi şi păstraţi aceste instrucţiuni
Română
5656
Технички податоци, Упатства за употреба, Специфицирани услови на употреба,
ЕУ- декларација за Сообразност, Напојување од мрежата, Одржување, Симболи Ве мoлиме прочитаjте го и чувајте го ова упатство!
Македонски
5858
Технічні характеристики, Вказівки З Техніки Безпеки, Використання за призначенням,
Сертифікат Відповідності Вимогам Єс, Підключеннядо мережі, Обслуговування,Символи Прочитайте та збережіть цю інструкцію.
Українська
6161
 

  

 6464

II
V
IIII
IV
Accessory

Zubehör
Accessoires
Accessorio
 
 
 
 
 Příslušenství
 

 
 
Äîïîëíèòåëü

Accesoriu 
 


I
11
1.
3.
2.

22
II
II
1.
2.
1
2
TEST

33
III
Start Stop
III
1
1
2
2
Start Stop

IV
44

55
GB
English
WARNING! Read all safety warnings and all instruc-
tions. Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
HAMMER SAFETY WARNINGS
Wear ear protectors. Exposure to noise can cause hearing loss.
Use auxiliary handle(s), if supplied with the tool. Loss of
control can cause personal injury.
Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory may
contact hidden wiring or its own cord. Cutting accessory
contacting a“live”wire may make exposed metal parts of the power
tool“live”and could give the operator an electric shock.
Additional Safety and Working Instructions
Use protective equipment. Always wear safety glasses when working
with the machine.The use of protective clothing is recommended,
such as dust mask, protective gloves, sturdy non-slip footwear,
helmet and ear defenders.
The dust produced when using this tool may be harmful to health.
Do not inhale the dust. Use a dust absorption system and wear a
suitable dust protection mask. Remove deposited dust thoroughly,
e.g. with a vacuum cleaner.
Do not machine any materials that present a danger to health (e.g.
asbestos).
When working in walls ceiling, or oor, take care to avoid electric
cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped workpi-
eces can cause severe injury and damage.
Keep mains lead clear from working range of the machine. Always
lead the cable away behind you.
Switch the device o immediately if the insertion tool stalls! Do
not switch the device on again while the insertion tool is stalled,
as doing so could trigger a sudden recoil with a high reactive force.
Determine why the insertion tool stalled and rectify this, paying
heed to the safety instructions.
Possible causes can be:
• it is tilted in the workpiece to be machined
• breakage of the material to be used
• the power tool is overloaded
TECHNICAL DATA
Chipping Hammer
MH 5 G
Production code 4431 71 05...
... 000001-999999
Rated input 1100W
Output 550W
Rate of percussion under load max. 3000 min-1
Impact energy per stroke according to EPTA-Procedure 05/2009 7,5 J
Chuck neck diameter 66 mm
Gewicht nach EPTA-Prozedur 01/2014 6,0 kg
Noise information
Measured values determined according to EN 60745.Typically, the A-weighted noise levels of the tool are:
Sound pressure level (Uncertainty K=3dB(A))
Measured sound power level 90,0 dB (A) 101,0 dB (A)
Measured values determined according to 2000/14/EC at the user’s ear.
2000/14/EC: Conformity assessment procedure according to AnnexVI.
Notied Body: SLG Prüf- und Zertizierungs GmbH
Burgstädter Straße 20, 09232 Hartmannsdorf, Germany
Measured sound power level
Guaranteed sound power level
Wear ear protectors!
98,6 dB (A)
101 dB (A)
Vibration information
Vibration total values (triaxial vector sum) determined according to EN 60745
Chiselling: Vibration emission value ah, Cheq
Uncertainty K= 16,7 m/s2 1,5 m/s2
WARNING!
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745
and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for dierent applications,
with dierent accessories or poorly maintained, the vibration emission may dier. This may signicantly increase the exposure level over
the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched o or when it is
running but not actually doing the job. This may signicantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eects of vibration such as: maintain the tool and the accessories,
keep the hands warm, organisation of work patterns.

66
GB
English
ECDECLARATION OF CONFORMITY
We declare under our sole responsibility that the product described
under “Technical Data” fullls all the relevant provisions of the
directives
2011/65/EU (RoHS)
2000/14/EC
2006/42/EC
2014/30/EU
and the following harmonized standards have been used.
EN 60745-1:2009+A11:2010
EN 60745-2-6:2010
EN 55014-1:2017+A11:2020
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
EN IEC 63000:2018
Winnenden, 2020-11-26
Alexander Krug / Managing Director
Authorized to compile the technical le
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364Winnenden, Germany
GBDECLARATION OF CONFORMITY
We declare as the manufacturer under our sole responsibility that
the product described under „Technical Data“fullls all the relevant
provisions of the following Regulations
S.I. 2012/3032 (as amended), S.I. 2008/1597 (as amended),
S.I. 2016/1091 (as amended), S.I. 2001/1701 (as amended) and that
the following designated standards have been used:
BS EN 60745-1:2009+A11:2010
BS EN 60745-2-6:2010
BS EN 55014-1:2017+A11:2020
BS EN 55014-2:2015
BS EN 61000-3-2:2014
BS EN 61000-3-3:2013
BS EN IEC 63000:2018
Winnenden, 2020-11-26
Alexander Krug / Managing Director
Authorized to compile the technical le
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364Winnenden, Germany
Do not reach into the machine while it is running.
The insertion tool may become hot during use.
WARNING! Danger of burns
• when changing tools
• when setting the device down
Chips and splinters must not be removed while the machine is
running.
Always disconnect the plug from the socket before carrying out any
work on the machine.
OPERATION
Cold Starting
If this tool is stored for a long period of time orat cold tempera-
tures, it may not hammer initiallybecause the lubrication has
become sti.
To warm up the tool
1. Insert and lock a bit or chisel into the tool.
2. Pull the trigger and apply force to the bit or chiselagainst a
concrete or wood surface for a fewseconds. Release the trigger.
3. Repeat until the tool starts hammering.The colderthe tool is, the
longer it will take to warm up.
SPECIFIED CONDITIONS OF USE
The hammer can be used for chiselling in stone and concrete..
MAINS CONNECTION
Appliances used at many dierent locations including wet room and
open air must be connected via a residual current device (FI, RCD,
PRCD) of 30mA or less.
Connect only to single-phase AC system voltage as indicated on
the rating plate. It is also possible to connect to sockets without an
earthing contact as the design conforms to safety class II.
Only plug-in when machine is switched o.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all times.
If the supply cord of this appliance is damaged, it must only be
replaced by a repair shop appointed by the manufacturer, to avoid
hazardous situations.
Use only AEG accessories and spare parts. Should components need to
be replaced which have not been described, please contact one of our
AEG service agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state
the Article No. as well as the machine type printed on the label
and order the drawing at your local service agents or directly at:
Techtronic Industries GmbH, Max-Eyth-Straße10, 71364Winnenden,
Germany.

77
GB
English
SYMBOLS
Please read the instructions carefully before starting the
machine.
CAUTION!WARNING! DANGER!
Always disconnect the plug from the socket before carrying
out any work on the machine.
Accessory - Not included in standard equipment, available
as an accessory.
Do not dispose of electric tools together with household waste
material. Electric toolsand electronic equipment that have
reached the end of their life must be collected separately and
returned to an environmentally compatible recycling facility.
Check with your local authority or retailer for recycling advice
andcollection point.
Class II tool.Tool in which protection against electric shock does
not rely on basic insulation only, but in which additional safety
precautions, such as double insulation or reinforced insulation,
are provided.There being no provision for protective earthing or
reliance upon installation conditions.
European Conformity Mark
British Conformity Mark
Ukraine Conformity Mark
EurAsian Conformity Mark
