AEMC BR07 User manual

RESISTANCE AND
CAPACITANCE BOXES
BR07
BC05
ENGLISH User Manual
DECADE RESISTANCE BOX
MODEL BR07
150V CAT II
0
1
2
3
456
7
8
9
10
X
1MΩ
0.1mA
0
1
2
3
456
7
8
9
10
X
100kΩ
1mA
0
1
2
3
456
7
8
9
10
X
10kΩ
7mA
0
1
2
3
456
7
8
9
10
X
1kΩ
20mA
0
1
2
3
4
56
7
8
9
10
X
100Ω
70mA
0
1
2
3
456
7
8
9
10
X
10Ω
200mA
0
1
2
3
4
5
6
7
8
9
10
X
1Ω
700mA
150V CAT II
0
1
2
3
4
56
7
8
9
10
X
1µF
0
1
2
3
456
7
8
9
10
X
100nF
0
1
2
3
456
7
8
9
10
X
10nF
0
1
2
34
56
7
8
9
10
X
1nF
0
1
2
3
456
7
8
9
10
X
100pF
DECADE
CAPACITANCE
BOX
MODEL BC05
www.ShopAEMC.ca
Shop for AEMC products online at: 1.877.766.5412

www.ShopAEMC.ca
Shop for AEMC products online at: 1.877.766.5412

Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
certifies that this instrument has been calibrated using
standards and instruments traceable to international
standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
An NIST traceable certificate may be requested at
the time of purchase, or obtained by returning the
instrument to our repair and calibration facility, for
a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer.
Serial #: ________________________________
Catalog #: 2131.25/2131.26
Model #: BR07/BC05
Please fill in the appropriate date as indicated:
Date Received: _________________________________
Date Calibration Due: _______________________
www.ShopAEMC.ca
Shop for AEMC products online at: 1.877.766.5412

Table of Contents
1.1 International Electrical Symbols.................................................................2
1.2 Receiving Your Shipment...........................................................................2
1.3 Ordering Information ..................................................................................2
1.4 Description ................................................................................................3
1.5 Operation ................................................................................................4
1.5.1 Resistance Box Model BR07 .................................................4
1.5.2 Capacitance Decade Box Model BC05...................................4
1.6 GeneralSpecications ...............................................................................5
1.7 Maintenance...............................................................................................5
Repair and Calibration..........................................................................................6
Technical and Sales Assistance ...........................................................................6
www.ShopAEMC.ca
Shop for AEMC products online at: 1.877.766.5412

Decade Box Models BR07 / BC05 3
CHAPTER 1
ENGLISH
Warning
• OnlyusethesedecadeboxesonCategoryIIinstallationsforvoltages
that do not exceed 150V in relation to the earth.
1.1 International Electrical Symbols
This symbol on the instrument indicates a WARNING and that the operator
must refer to the user manual for instructions before operating the instru-
ment. In this manual, the symbol preceding instructions indicates that if the
instructions are not followed, bodily injury, installation/sample and product
damage may result.
Ground (Earth) Terminal
Protective Ground (Earth)
1.2 Receiving Your Shipment
Make sure that the contents shipped are consistent with the packing list. Notify
your distributor of any missing items. If the equipment appears to be damaged,
leaclaimimmediatelywiththecarrierandnotifyyourdistributoratonce,giving
a detailed description of any damage. Save the damaged packing container to
substantiate your claim.
1.3 Ordering Information
Decade Resistance Box Model BR07 ...........................................Cat. #2131.25
Decade Capacitance Box Model BC05 .........................................Cat. #2131.26
All decade boxes are shipped with a 9.8" (25cm) safety lead with Ø 4mm connectors
Replacement Parts:
Safety lead with connectors Ø 4mm, length 9.8" (25cm) .................Cat. #2131.35
www.ShopAEMC.ca
Shop for AEMC products online at: 1.877.766.5412

4 Decade Box Models BR07 / BC05
1.4 Description
Resistance Boxes:
Model BR07: 7 decades - 1Ωto 11.11111MΩ
covering all the resistance values from 1Ωto 11.11111MΩ
Capacitance Box:
Model BC05: 5 decades - 0.1nF to 11.111µF
covering all the capacitance values from 0 to 11.111µF
These decade boxes are built into a metal bench-top box. They are used for test-
ing and calibration.
The main function of these decade boxes is to create a resistance, capacitance
orinductancewithaspecicvaluebyusingacombinationoftherotarydecade
switches.
They are equipped with Ø 4mm safety terminals for connection.
For safe use, they comply with standard EN 61010-1 (2001).
www.ShopAEMC.ca
Shop for AEMC products online at: 1.877.766.5412

Decade Box Models BR07 / BC05 5
1.5 Operation
The ground (earth) terminal must be connected to a protective ground (earth)
before taking any measurements.
Do not inject any voltage measurements greater than 150V to ground (earth) and
comply with the maximum acceptable current for each decade switch.
1.5.1 Resistance Box Model BR07
• Resistancebox:7decadescoveringarangefrom1Ωto 11.11111MΩ
• 11positionswitches
• OutputonsafetysocketsØ4mm
• Accuracy:1%±10mΩon all ranges
Connect the ground (earth) terminal to a protective ground (earth)
before taking any measurements. Do not forget the resistance of the
measurement leads in the overall accuracy, particularly on the rst
decade.
Types Multiplying factor in Ω
BR07 1 10 100 1k 10k 100k 1M
Accuracy 1%
±10mΩ
1%
±10mΩ
1%
±10mΩ
1%
±10mΩ
1%
±10mΩ
1%
±10mΩ
1%
±10mΩ
Max
current
mADC
700mA 200mA 70mA 20mA 7mA 1mA 0.1mA
1.5.2 Capacitance Decade Box Model BC05
• Capacitanceboxwith5decades;11positionswitches
• Totalcapacitance11.111µF
• Veryhighinsulation
• OutputonsafetysocketsØ4mm
• Theresidualcapacitanceisapproximately25pF
• Accuracy:3%onalltheranges(residualcapacitancededucted)
Type Multiplying factor in nF
BC05 0.1 1 10 100 1k
Connect the ground (earth) terminal to a protective ground (earth)
before taking any measurements. Comply with the maximum oper-
ating voltage of 300VDC or 230VAC at 50Hz and the voltage of 150V
maximum to ground (earth).
After each use, discharge the voltage stored by the capacitors into a
resistance with an appropriate value.
www.ShopAEMC.ca
Shop for AEMC products online at: 1.877.766.5412

6 Decade Box Models BR07 / BC05
1.6 General Specifications
Operating Temperature: 14° to 131°F (-10° to + 55°C)
Storage Temperature: -40° to 158°F (-40° to + 70°C)
Relative Humidity: 20%<RH<96%
Altitude: 2000m
Dimensions - BR07: 16 x 3.4 x 3" (410 x 86 x 76mm)
Weight - BR07: 3 lbs (1.4kg)
Dimensions - BC05: 12 x 3.4 x 3” (310 x 86 x 76mm)
Weight - BC05: 2.2 lbs (1kg)
Watertightness (as per EN 60529 Ed. 92): Protection index IP 40
Rated Voltage: 150V
Installation Category II - Pollution level 2
1.7 Maintenance
The decade boxes must be disconnected from any electrical source
before cleaning or maintenance.
For maintenance, only use the specied factory spare parts.The manufacturer
cannot be held responsible for any accidents that occur due to repairs done out-
sideitsafter-salesdepartmentorcertiedrepairagents.
To clean the console, use a cloth with a little soapy water. Never use abrasive
products or solvents. Rinse with a damp cloth and then wipe quickly with a dry
cloth or pulsed air.
www.ShopAEMC.ca
Shop for AEMC products online at: 1.877.766.5412

www.ShopAEMC.ca
Shop for AEMC products online at: 1.877.766.5412

8 Decade Box Models BR07 / BC05
Limited Warranty
The Decade Boxes are warranted to the owner for a period of one year from
the date of original purchase against defects in manufacture. This limited war-
ranty is given by AEMC®Instruments, not by the distributor from whom it was
purchased. This warranty is void if the unit has been tampered with, abused or
if the defect is related to service not performed by AEMC®Instruments.
Full warranty coverage and product registration is available on our website at
www.aemc.com/warranty.html.
Please print the online Warranty Coverage Information for your records.
What AEMC®Instruments will do:
If a malfunction occurs within the one-year period, you may return the instrument
tousforrepair,providedwehaveyourwarrantyregistrationinformationonle
or a proof of purchase. AEMC®Instruments will, at its option, repair or replace
the faulty material.
Warranty Repairs
What you must do to return an Instrument for Warranty Repair:
First, request a Customer Service Authorization Number (CSA#) by phone
or by fax from our Service Department (see address below), then return the
instrument along with the signed CSA Form. Please write the CSA# on the
outside of the shipping container. Return the instrument, postage or shipment
pre-paidto:
Ship To: Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
 15FaradayDrive•Dover,NH03820USA
 Phone:(800)945-2362(Ext.360)
[phone] (Ext. 360)
 Fax: (603)742-2346or(603)749-6309
 E-mail:[email protected]
Caution: To protect yourself against in-transit loss, we recommend you insure
your returned material.
NOTE: You must obtain a CSA# before returning any instrument.
