Aeon Labs Aeotec MULTISENSOR 6 User manual

MULTISENSOR 6
View the expanded manual:
http://aeotec.com/support

Aeotec by Aeon Labs MultiSensor.
Motion sensor. Humidity sensor. Thermometer. Light sensor.
Ultraviolet sensor. Vibration sensor.
The corner of your room just got smarter.
Aeotec by Aeon Labs’ MultiSensor looks like a motion sensor and it
acts like one too. But it’s also so much more. Installing this 1 piece
of Z-Wave® technology is the same as installing 6 pieces of Z-Wave
technology. Your home control network will immediately understand
motion, temperature, humidity, light, Ultraviolet and Vibration
readings wherever MultiSensor installed. Those intelligent readings
will equate to intelligence automation. And intelligent automation will
give you the perfect, smart home.
Your MultiSensor comes packaged with a number of accessories
that will help with its installation and operation.
Package Contents:
MultiSensor
Battery Cover
Back-Mount Arm
Double-Sided Tape
Screws (×2)
Micro USB Cable
1.
2.
3.
4.
5.
6.
Familiarize yourself with your MultiSensor.
1

223
6
54
3
Unlock
Battery cover
Screw hole Action Button Light Sensor
and UV Sensor
Motion Sensor
RGB LED
Temperature Sensor
Lock
1
Version: 501010000001-AB www.aeotec.com
Certications (regional):
Z-Wave and Z-Wave Plus are registered
trademarks of Sigma Designs and its subsidiaries in
the United States and other countries
FCC ID: XBAFT100
2
USB port
Battery Holder

322
Quick start.
Your MultiSensor can be powered by battery or by USB with
an appropriate adaptor. For the purposes of installation and
setup, even if you intend to power your sensor with batteries, we
recommend utilizing the provided USB cable for setup. For this,
you’ll need an adaptor to plug your USB cable into, this can include
any USB port on a computer and most mobile phone chargers.
These steps can be performed in any location with your home, and
not necessarily in your MultiSensor’s nal installation location.
For a USB powered installation;
1. Remove the Battery cover via sliding the Unlock button and
separating the two parts of your sensor.
2. Insert the appropriate end of the provided Micro USB cable into
your sensor’s USB port. Your MultiSensor is now powered on.
Setup your power.
Do not dispose of electrical appliances as unsorted municipal
waste, use separate collection facilities.
Contact your local government for information regarding the
collection systems available.
Warning
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consul the dealer or an experienced radio/TV technician for
help.
generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Unlock

4
It’s now time to sync your MultiSensor with a Z-Wave network. The
following instructions explain how to do this using a Z-Stick or a
Minimote from Aeotec. If you’re using an alternative controller for
your Z-Wave network, please refer to its user manual for network
inclusion instructions.
If you’re using a Z-Stick:
For a battery powered installation;
1. Remove the rear part of your sensor as shown in the previous
step 1.
2. Insert CR123A batteries oriented according to the picture below.
Your MultiSensor is now powered on.
Note: If you just have only one CR123A battery, please insert the
battery into the primary battery holder.
Add your MultiSensor to your Z-Wave network.
FCC NOTICE (for USA)
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO
THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER’S
AUTHORITY TO OPERATE THE EQUIPMENT.
STORE INDOORS WHEN NOT IN USE. SUITABLE FOR DRY LOCATIONS.
DO NOT IMMERSE IN WATER. NOT FOR USE WHERE DIRECTLY EXPOSED
TO WATER.
THAT PORTION OF PRODUCTS WITH RESPECT TO WHICH DAMAGES
ARE CLAIMED. ALL CLAIMS OF ANY KIND ARISING IN CONNECTION
WITH THIS AGREEMENT OR THE SALE OR USE OF PRODUCTS SHALL BE
DEEMED WAIVED UNLESS MADE IN WRITING WITHIN THIRTY (30) DAYS
FROM AEON LABS'S DELIVERY, OR THE DATE FIXED FOR DELIVERY IN
THE EVENT OF NONDELIVERY.
THE INDEMNITY AND WARRANTY IN ABOVE ARE EXCLUSIVE AND IN LIEU
OF ALL OTHER INDEMNITIES OR WARRANTIES, WHETHER EXPRESS OR
IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including
interference that may cause undesired operation. This equipment
has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
1
2
21
Primary battery
holder
Secondary battery
holder

5
Include
If your Z-Stick is plugged into a gateway or a computer, unplug it.
Take your Z-Stick to your MultiSensor.
Press the Action Button on your Z-Stick.
Press the Action Button on your MultiSensor.
You can test if your MultiSensor has been successfully included
into your Z-Wave network by pressing its Action Button. If you
press the button and your sensor’s green LED is solid for a
few seconds, then inclusion has been successful. If the green
LED blinks when the button is pressed, the inclusion has been
unsuccessful and you should repeat the above steps.
Press the Action Button on the Z-Stick to return it to inclusion
mode. Return it to your gateway or computer.
Take your Minimote to your MultiSensor.
Press the Include button on your Minimote.
Press the Action Button on your MultiSensor.
You can test if your MultiSensor has been successfully included
into your Z-Wave network by pressing its Action Button. If you
press the Action Button and your sensor’s green LED is solid for
If you’re using a Minimote:
1.
2.
3.
4.
5.
6.
1.
2.
3.
4.
IN NO EVENT SHALL AEON LABS BE LIABLE FOR ANY INDIRECT,
INCIDENTAL, PUNITIVE, SPECIAL OR CONSEQUENTIAL DAMAGES, OR
DAMAGES FOR LOSS OF PROFITS, REVENUE, OR USE INCURRED
BY CUSTOMER OR ANY THIRD PARTY, WHETHER IN AN ACTION
IN CONTRACT, OR TORT, OR OTHERWISE EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. AEON LABS' LIABILITY AND
CUSTOMER'S EXCLUSIVE REMEDY FOR ANY CAUSE OF ACTION ARISING
IN CONNECTION WITH THIS AGREEMENT OR THE SALE OR USE OF THE
PRODUCTS, WHETHER BASED ON NEGLIGENCE, STRICT LIABILITY,
BREACH OF WARRANTY, BREACH OF AGREEMENT, OR EQUITABLE
PRINCIPLES, IS EXPRESSLY LIMITED TO, AT AEON LABS' OPTION,
REPLACEMENT OF, OR REPAYMENT OF THE PURCHASE PRICE FOR
20
Labs' affiliates, shareholders, directors, officers, employees,
contractors, agents and other representatives harmless from all
demands, claims, actions, causes of action, proceedings, suits,
assessments, losses, damages, liabilities, settlements, judgments,
nes, penalties, interest, costs and expenses (including fees and
disbursements of counsel) of every kind (i) based upon personal
injury or death or injury to property to the extent any of the foregoing
is proximately caused either by a defective product (including strict
liability in tort) or by the negligent or willful acts or omissions of
Customer or its ofcers, employees, subcontractors or agents, and/
or (ii) arising from or relating to any actual or alleged infringement
or misappropriation of any patent, trademark, mask work, copyright,
trade secret or any actual or alleged violation of any other
intellectual property rights arising from or in connection with the
products, except to the extent that such infringement exists as a
result of Aeon Labs' manufacturing processes.

6
MultiSensor can bring its intelligent readings to many locations of
your home which includes outside of your home. Please note that
when installed outdoors of your home, your MultiSensor should only
be relied on for temperature, light, humidity, and ultraviolet readings,
where as the motion sensing capabilities should be disabled on
your gateway in order to avoid false readings.
Light can impact on the quality of motion readings, it’s also
important to understand environmental changes that may impact
on other readings within your home. Specically, your MultiSensor
should not be installed in areas of artificial temperature change.
Thus, when selecting a location, avoid placing it beside or near
air conditioners, humidiers, and heaters, and avoid positioning it
directly opposite a window or direct sunlight.
Selecting a location for your MultiSensor to be installed depends on
the use case. Whatever the case or the installation location, please
ensure that it ts with your sensor’s effective motion sensing range
as described in these diagrams.
For ceiling mounting using the Back-Mount Arm:
Selecting a location for your MultiSensor.
a few seconds, then inclusion has been successful. If the green
LED blinks when the button is pressed, the inclusion has been
unsuccessful and you should repeat the above steps.
Press any button on your Minimote to return it to inclusion mode.5.
Customer shall indemnify, defend, and hold Aeon Labs and Aeon
19
The "Warranty Period" begins on the date the Products is delivered
and continues for 12 months.
Any repairs under this warranty must be conducted by an
authorized Aeon Labs service representative and under Aeon Labs'
RMA policy. Any repairs conducted by unauthorized persons shall
void this warranty.
Excluded from the warranty are problems due to accidents, acts
of God, civil or military authority, civil disturbance, war, strikes,
res, other catastrophes, misuse, misapplication, storage damage,
negligence, electrical power problems, or modification to the
Products or its components.
Aeon Labs does not authorize any person or party to assume or
create for it any other obligation or liability in connection with the
Products except as set forth herein.
Aeon Labs will pass on to Customer all manufacturers’ Material
warranties to the extent that they are transferable, but will not
independently warrant any Material.
Customer must prepay shipping and transportation charges for
returned Products, and insure the shipment or accept the risk of
loss or damage during such shipment and transportation. Aeon
Labs will ship the repaired or replacement products to Customer
freight prepaid.

7
For wall mounting using the Back-Mount Arm:
Model number: ZW100
Power supply: USB DC 5V or battery power(2×CR123A batteries,
3V, 1500mAh).
Operating temperature: 0 to 40 /32 to 104 .
Measured temperature range: -10 to 50 /14 to 122 . Accuracy:
±1 /±1.8 .
Measured humidity range: 20%RH to 90%RH. Accuracy: ±3%RH (at
25 /77 ).
Lighting: 0 LUX to 30000 LUX.
Max motion sensitivity: 5 metres.
Water proong: IP20.
Operating distance: Up to 492 feet/150 metres outdoors.
Technical specications.
C C
C C
C
FF
F F
F
FC
Warranty.
Aeon Labs warrants to the original purchaser of Products that
for the Warranty Period (as defined below), the Products will be
free from material defects in materials and workmanship. The
foregoing warranty is subject to the proper installation, operation
and maintenance of the Products in accordance with installation
instructions and the operating manual supplied to Customer.
Warranty claims must be made by Customer in writing within
thirty (30) days of the manifestation of a problem. Aeon Labs' sole
obligation under the foregoing warranty is, at Aeon Labs' option,
to repair, replace or correct any such defect that was present at
the time of delivery, or to remove the Products and to refund the
purchase price to Customer. 18
6

8
For optimal performance, your MultiSensor should NOT be
mounted directly on or near metal framing or other large metallic
objects. Large metal objects may weaken the Z-Wave wireless
signal.
If selecting an outdoor location, it’s important to position your
MultiSensor in a sheltered location. It is best if your MultiSensor
is not directly exposed to rain, and is important that the humidity
venting on your MultiSensor never is.
With your MultiSensor now part of your Z-Wave network, it’s time to
nish its physical installation.
There are 2 ways that your MultiSensor can be mounted on on a
wall or ceiling. Using the Back-Mount Plate, you can mount it at
against a wall or ceiling. Using the Back-Mount Arm you can mount
it on a surface or in a corner and angle it as desired.
To physically install your MultiSensor;
Physically install your MultiSensor.
Reattach the two parts of your MultiSensor to each other. To do
this, align the lock/unlock half-dimple markers that are under the
unlock symbol and then twist in a clockwise motion.
If USB is used to power your MultiSensor, ensure that power
can be provided to your desired installation location. Please note
that when installed in areas that where the temperature can drop
below -10°C, it is advised that USB power is used and battery
power is not.
1.
2.
The MultiSensor contains a smart Vibration sensor in. When
someone attempts to disassemble your MultiSensor, it can detect
the vibration and send an alarm notication to the main controller
and let you know.
Security or Non-security feature of your MultiSensor in
Z-wave network.
Resetting your MultiSensor.
If you want your MultiSensor as a non-security device in your
Z-wave network, you just need to press the Action Button once on
MultiSensor when you use a controller/gateway to add/include your
MultiSensor.
In order to take full advantage of all functionality the MultiSensor,
you may want your MultiSensor is a security device that uses
secure/encrypted message to communicate in Z-wave network, so
a security enabled controller/gateway is needed for the Multisensor
to be used as a security device.You need to press the MultiSensor’s
Action Button 2 times within 1 second when your security controller/
gateway starts the network inclusion.
At some stage or your primary controller is missing or inoperable,
you may also wish to reset all of your MultiSensor’s settings to their
factory defaults. To do this, press and hold the Z-Wave Button for
20 seconds and then release it. Your MultiSensor will now be reset
to its original settings, and the LED will stay solid for 2 seconds and
then turn off as a conrmation.
17

9
Tips: We suggest you choose the second method (using screws to
afx the Back-Mount Arm) would be more stable.
Attach your desired mounting accessory. This can be the Back-
Mount Arm. You can affix the Back-Mount Arm via using the
provided KA2.5×20mm screws or Double-Sided Tape.
After you have completed the afxing of Back-Mount Arm, you
will need to lock the MultiSensor to the Back-Mount Arm via
turning the MultiSensor.
3.
4.
Or
Double-Sided Tape
Waking up your MultiSensor.
Tamper protection of your MultiSensor.
If your MultiSensor is battery powered, you will need to ensure
that it is active when configuring it. To do this, press the Action
Button once, which will trigger to send out a wake up notication
command. If you want it to wake up for 10 minutes, to do this, press
and hold its Action Button for 3 seconds and then release it. Your
MultiSensor’s LED will fast blink for 10 minutes to indicate that it is
active.
When you are done configuring or communicating with your
MultiSensor, you can put it back into sleep mode to conserve
battery power. To do this, press and hold its Action button for 3
seconds and then release it. Your MultiSensor’s LED should now
be off to indicate that it is asleep.
Parameter 111-113 [4 byte decimal] can be congured through your
gateway in case the default settings of your MultiSensor are not
what you desire.
Parameter 111 will set the interval for Group 1 (parameter 101),
parameter 112 will set the interval for Group 2 (parameter 102), and
parameter 113 will set the interval for Group 3 (parameter 103).
As an example, you have set parameter 101 to 241 which will report
all of the sensors, and you want to report it every 1800 seconds.
Set parameter 111 to 1800 to accomplish this.
16
USB port
Battery Holder

The Back-Mount Arm may be locked at various angles by turning
the Friction Lock clockwise and counter-clockwise to respectively
tighten or loosen the angle of the arm.
5.
Lock
Unlock
Screw hole
60°
10
The table above shows a decimal representation of all ags that
can be set on parameter 101-103 to report specic data.
Example use of the report table.
For example, if you want to report only the temperature and light
sensor you would add 32 + 64 and set the sum (96) to parameter
101, 102, or 103.
As another example, if you want to report only the light sensor and
battery, you would add 1 + 128, then set the sum (129) to parameter
101, 102, or 103.
And if you want to report all of the sensors, you would add the
whole table together and set the sum (241) to parameter 101, 102,
or 103.
Setting an automatic report interval.
Setting automatic report ags.
Parameter 101-103 [4 byte dec] can be configured through your
gateway in case the default settings of your MultiSensor are not
what you desire.
Decimal Flag
128 Light Sensor
64 Humidity Sensor
32 Temperature Sensor
16 Ultraviolet Sensor
1 Battery Sensor
15

Your MultiSensor has built in battery level detection. It will
automatically report its battery level to the associated controller/
gateway throughout its life until the battery is fully drained and
needs replacing. The battery status will often be displayed in the
user interface of the controller/gateway.
When used properly in an optimised Z-Wave network, your
MultiSensor can be powered by batteries for 24 months before
battery replacement is necessary.
Recommendation: For networks which do not offer a method to
display the battery level of your MultiSensor, it is recommended that
the sensor be tested occasionally to ensure that the batteries still
hold enough charge to operate. Batteries naturally lose their charge
over time.
Your MultiSensor can be removed from your Z-Wave network at
any time.You’ll need to use your Z-Wave network’s main controller
to do this and the following instructions tell you how to do this using
Aeotec by Aeon Labs’ Z-Stick and Minimote controllers. If you are
using other products as your main Z-Wave controller, please refer
to the part of their respective manuals that tells you how remove
devices from your network.
Changing batteries.
Removing your MultiSensor from a Z-Wave network.
Advanced functions.
11
Setting the sensitivity of your MultiSensor.
Monitoring temperature, humidity, luminance and ultraviolet.
Parameter 6 [1 byte decimal] can be configured through your
gateway in case the default settings of your MultiSensor are not
what you desire.
For example, this parameter setting is initially set to 127 which is
the maximum sensitivity, if you set it to 64, the sensitivity will be the
normal sensitivity. If set it to 0, the sensitivity will be the minimum
sensitivity.
Your MultiSensor can report temperature, humidity, luminance and
ultraviolet across a Z-Wave network when requested. If this function
is supported by a controller, generally a gateway, the data will be
displayed within its interface. The specific Z-Wave commands
for the support of monitoring is the Multilevel Sensor Command
Class. Automatic reports are sent to association group 1, which
is setup via the Association Command Class. Please consult the
controller’s operation manual for specic instructions on setting your
MultiSensor.
Parameter 3 [2 byte decimal] can be configured through your
gateway in case the default settings of your MultiSensor are not
what you desire.
For example, this parameter setting is initially set to 240 which is the
delay time in 4 minutes or 240 seconds.You may set the value to
the desired Motion Sensor delay time to any amount of seconds as
you like. So if you want the time out to be 5 minutes after the Motion
Sensor is triggered, set this parameter to the value of 300.
14

If you’re using a Minimote:
If your Z-Stick is plugged into a gateway or a computer, unplug it.
Take your Z-Stick to your MultiSensor.
Press and hold the Action Button on your Z-Stick for 3 seconds
and then release.
Press the Action Button on your MultiSensor.
If your MultiSensor has been successfully removed from your
network, the RGB LED will be active with a colourful gradient for
3 seconds. When you press the Action Button on the MultiSensor,
its green LED will blink. If the removal was unsuccessful, the
green LED will stay solid for a few seconds when you press the
Action Button.
Press the Action Button on the Z-Stick to take it out of removal
mode.
1.
2.
3.
4.
5.
6.
12
Remove
The MultiSensor can send Basic Set Command to association
group 1, which is setup via the Association Command Class, when
the Motion Sensor detects movement to control the associated
devices to “OPEN” state. After 4 minutes by default, if the Motion
Sensor is not triggered again, the MultiSensor will send Basic Set
Command to these devices to set them to their “CLOSE” state.
However, if the Motion Sensor is triggered again within 4 minutes,
the MultiSensor will reset the timing and start timing again.
The 4 minutes delay time can be changed through the usage
of Z-Wave commands built into Z-Wave certified controllers/
gateways. (The specic Z-Wave command supporting this function
is Configuration Command Class) Please consult the operation
manual for these controllers/gateways for specic instructions on
conguringthe MultiSensor.
Monitoring motion.
Take your Minimote to your MultiSensor.
Press the Remove Button on your Minimote.
Press the Action Button on your MultiSensor.
If your MultiSensor has been successfully removed from your
network, the RGB LED will be active with a colourful gradient for
3 seconds. When you press the Action Button on the MultiSensor,
its green LED will blink. If the removal was unsuccessful, the
green LED will stay solid for a few seconds when you press the
Action Button.
Press any button on your Minimote to take it out of removal
mode.
1.
2.
3.
4.
5.
13
If you’re using a Z-Stick:
