AerialBox t2100 Instructions for use

T2100 Quick Install Sheet
Thank you for choosing Dish TV for your FreeviewPlus Terrestrial R eceiver. This Q uick Start Guide will provide you
with instructions for connecting and troubleshooting your new unit. Please check that your Dish TV box contains all the
following components... T2 1 0 0 R eceiv er, 3 - Way A V L ead , 2 x A A A B atteries, 1 2 v Pow er A d ap ter, R emote Control.
Dish TV T2100 Power
IR Sensor
USB Port
Power LED
FRONT PANEL
REAR PANEL
Cable In/Out
Ethernet
USB Port
HDMI Port
Composite
12V DC Port
The T2100 is a FreeviewPlus Receiver. It requires an Aerial and good signal levels to operate correctly. It does not use a Satellite Dish.
For further help, please refer to the Technical Support Contact Details under the System Information tab in the Main Menu.
What’ s in the box ?
Please check to see whether you have all the following in this box, you should have:
Your new set top box
AV Cables
2x AAA Batteries
Remote Control
Some items missing? Please contact the retailer or store you purchased this from.
G etting Connected :
Connect the cable that comes from your
Aerial to the IN socket on the back of your set
top box. Connect the AV cable that came
with your unit between the yellow, red and
white sockets on the back panel of the unit
and your TV, or you can j ust use an HDMI
cable if you have one.
G etting S tarted :
1 - O pen the battery cover of the remote
control insert the two AAA size batteries so
the + and - marks on the batteries match the
+ and - marks inside your remote. R eplace
the battery cover.
2 - Switch your TV on and select the video
input you have connected your T21 00 to.
N ow switch the T21 00 on and wait for it to
boot up ( it should take approx. 3 0 seconds) .
3 - The “ W elcome First Time Installation”
screen should now show up, please follow all
on screen instructions to finalize the set up of
your FreeviewPlus Unit.
For futher details on operating your T21 00
unit, please refer to the User Manual tab
found in the Main Menu.
Install Sheet
®
TM
Power Supply

FreeviewPlus provides access to content and services from the Freeview
networks. The FreeviewPlus service provides a 7+ day EPG, all available
Catch Up TV on the TV, recommendations and the ability to set reminders
& favourites. All available by pressing the Green button on your remote.
For more info about FreeviewPlus, visit www.freeviewplus.com.au
FreeviewPlus provides access to content and services from the Freeview
networks. The FreeviewPlus service provides a 7+ day EPG, all available
Catch Up TV on the TV, recommendations and the ability to set reminders
& favourites. All available by pressing the Green button on your remote.
F
Troubleshooting, If you’re having trouble getting your Dish TV T2100 Terrestrial Receiver to work check some of the tips
below before you contact Technical Support.
The T2100 is a FreeviewPlus Receiver. It requires an Aerial and good signal levels to operate correctly. It does not use a Satellite Dish.
For further help, please refer to the Technical Support Contact Details under the System Information tab in the Main Menu.
new zealand australia
No Signal
Check the antenna cable connection.
No LED Indicator on Front Panel :
Main Power Lead is unplugged/turned off.
Dish TV T2100 Receiver Not Working :
Unit has stopped responding to remote/ Front
display working though no picture.
TV No Display :
Your TV is set to the wrong input/ Your TV isn’t able
to display the current output format.
Unit Doesn’t Respond To Remote:
If you are using the Remote Control and the LED
indicator does not flash when a button is pressed,
it can be due to any or all of: No batteries/ Batteries
inserted incorrectly/ Batteries are dead/ Infrared
receiver is obstructed/ Outside maximum operating
distance.
Message On TV Says “No Signal” :
Tuning Failed or Database Empty. No or Low
Signal can be the cause of this problem and it can
be due to any or all of: Aerial cable not plugged in/
Faulty Aerial Set Up/ Aerial set for wrong polarity/
Cables to old or damaged/ Poor joints in cable/
Split into too many rooms/ If using rabbit ears or
indoor antenna/ Not enough signal at location.
WiFi Not Connecting:
Router not available in list/ Router shown though
will not connect.
Make sure the power cord and adaptor are
connected correctly, and there is power available at
the power point being used.
Make sure the TV display is set to the correct
AV/HDMI input source. Check that the AV/HDMI
connections are securely connected on both the
TV and Receiver, and if necessary; please try
another AV/HDMI cable set.
Use the remote control within the recommended
SIX meters maximum from unit. Change batteries
in the remote control. Use a Digital Camera/ Cell
Phone Camera to view LED on end of remote as
you press buttons. It will flash if working. Check
there is a clear line of sight to your unit.
Plug the Aerial into the CABLE IN socket at the
back of the receiver. Align your Aerial to the closest
transmitter, ensure there are no objects the could
interrupt the signal path. You can visually inspect
connections, to make ure everything is fitted
correctly. Though you may need to contact a local
installer, to check your set up thoroughly or install
an Aerial at your location.
Try move your router to a new location to improve
signal strength - you'll usually see better reception
throughout your home if the router is in a central
location. Cordless phones, or other wireless
devices near your router can all cause wireless
interference, so move them away from your
wireless router. Elevate your router off the floor. A
router on top of a desk will be better than one
hidden behind it. Check password used is correct.
Problem/ Possible Causes What To Check
Reboot the Receiver by turning it off at the wall
(power point), wait 10 seconds, and turn it on
again.
This FreeviewPlus Digital Set Top Box gives you access to over 20
free to air digital channels, without a subscription or contract.
For more info about FreeviewPlus, visit www.freeviewplus.co.nz
This product is capable of receiving and decoding Dolby Digital Plus.
Manufactured under license from Dolby Laboratories. Dolby and the
double D symbol are trademarks of Dolby Laboratories.
This product has a HDMI Connector so that you can watch high
trademarks or registered trademarks of HDMI Licensing LLC.
®
®
