Sony STR-DA4300ES - Multi Channel Av Receiver User manual

STR-DA4300ES
ES 7.1 Channel Surround Sound A/V Receiver
Key Features
Xross Media Bar ® inspired graphic user interface
Faroudja ® DCDi™ Cinema Up Scaling Technology
4
BRAVIA ® Theatre Sync Technology
iPod ® Ready with DIGITAL MEDIA PORT (TDM - IP1 Sold
Separately)
100 Watts X 7 Power Amplifier (8 ohms, 20Hz - 20kHz, 0.09%
THD)
Optimized for Blu - ray Disc™and other HD sources
6
Accepts x.v.Color™(xvYCC) and Deep Color signal
Accepts 1080p & 24p via HDMI™
6
Accepts 8ch Linear PCM through HDMI™
3
Accepts Dolby ® Digital +, Dolby ® TrueHD
Key Technologies
Optimized for Blu - ray DiscTM and Other HD Sources The STR -DA4300ES is engineered to be the ideal Blu-ray Disc® A/V
receiver, fully compatible with Sony® family of Blu-ray Disc Players. Superior video switching and audio performance ensure seamless
compatibility with today's demanding HD sources. The STR-DA4300ES features up to three High Definition Multimedia Interface
(HDMI™ ) inputs which are capable of accepting resolutions up to 1080p, offering the full video quality that Blu-ray Disc® format can
deliver.
2
Up to 8 channels of Linear PCM audio plus Dolby Labs ® (Dolby Digital +/Dolby TrueHD) and dts ® (DTS HD) The STR -
DA4300ES will offer full compatibility with Blu-ray Disc® format's linear PCM (uncompressed) output, producing up to eight channels
of "high quality" audio reproduction. The STR-DA4300ES will also have the ability to support the latest audio formats from Dolby
Labs® ( Dolby Digital Plus/Dolby TrueHD) and dts® ( DTS HD).
HDMI "Active Intelligence" The receiver can detect and receive the best possible video and audio signals from all connected
devices-making connection and performance as simple as plugging in a single wire. Sony's HDMI "Active Intelligence," produces both
audio and video through one HDMI cable.
Faroudja ® DCDi CINEMA Chipset for Up Scaling to 1080p IC processor developed by Faroudja®, and first used by Sony,
which will up scale and up convert all video signals (less than 1080p) to 1080p via HDMI . This chipset corrects image jaggedness;
reduces block noise and reproduces true to original colors. The end result is a beautiful and smooth high definition image.
3
Cross Media Bar Inspired Graphic User Interface An on -screen menu system that simplifies the most complex operations of an
A/V receiver for home theater applications. This advanced menu system incorporates icons, an easy to follow "tree" system and a
blending technique so users know exactly where they are amongst the various settings while still watching their main video source (up
to 1080i). Enhancements made to this year's menu include access to DIGITAL MEDIA PORT accessories, the ability to assign HDMI inputs
and independent A/V sync control for each input. It's simple. Just pick up the remote and whole new experience will be revealed.
HDMI Up Scaling Video sources connected via composite, S-video and component cables can not only be up converted to a
HDMI™video output but can also be up scaled from its native signal to 1080p (i.e. 480i to 1080p) thus minimizing the number of
connections needed from the receiver to the television display. HDMI supports resolutions up to 1080p and enables both HD video and
uncompressed streaming audio to be transmitted through a single cable.
2
Down Conversion Component and S-video sources can be down converted to lower resolution outputs, thus customizing video
connectivity to home theater requirements from a single source. Also, both receivers can take HD sources from component video and
down convert the signal for use with composite or S-Video ouputs. This is ideal for distributing video through multiple rooms with less
wires.
Digital Cinema Auto Calibration An ideal listening experience is only a button away. Simply place the included microphone in
your listening position, push a single button and speaker position, distance and delays are automatically calibrated. Sony's Digital
Signal Processing uses feedback between the microphone and receiver to optimize sound settings.
Sirius and XM Connect - and - Play™Ready with Neural Surround A world of digital radio at your fingertips. Connect the
optional antenna for either Sirius and/or XM subscription service and enjoy the variety and quality of digital radio with the superior
sound quality of an A/V receiver. In addition to stereo, you can enjoy 5.1 surround broadcasting. XM radio is a satellite radio service
that provides pay-for-service radio, analogous to cable television.
1

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 04/02/2008
STR-DA4300ES
ES 7.1 Channel Surround Sound A/V Receiver
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
Video
UpConversion: Yes (HDMI, Component
1080p)
UpScaling: Yes (HDMI Up Scaling up to
1080p)
Audio
Dolby ® DigitalDecoding: Yes
Dolby ® Pro Logic ® IIDecoding: Yes
DTS ® 96/24Decoding: Yes
DTS ® NEO:6Decoding: Yes
Dolby ® Digital EX Decoding: Yes
Dolby ® Pro Logic ® IIX Decoding: Yes
AmplificationRelocation: Yes
Digital Cinema Sound™ Technology: Yes
Dolby ® Pro Logic ® Decoding: Yes
dts ® - ES Decoding: Yes
Dolby ® Digital plus Decoding: Yes
Dolby ® TrueHD: Yes
dts ® Decoding: Yes (dts ® HD Master
Audio)
Convenience
A/B Speaker Switch: Yes (A / B / A+B)
On Screen Display: Yes
HDMI™ Technology: Intelligent A/V Selector
Digital Cinema Auto Calibration: Yes (Mic -
Stereo)
Specifications
Speaker
Center Speaker Terminal: Yes
Surround Back Speakers: Yes
Surround Speaker Terminal: Screw Binding
Posts
Speaker Terminal Type: Screw Binding
Posts (A & B)
Audio
Impedance: 8 Ohms
Channel Power Rating: 7.1 Channel Power
Rating: 100W X 7 Amp Power (8 ohms,
20Hz - 20Khz, THD 0.09%)
SoundFields: Cinema - 4; Music - 7; Auto
Format Decoding - 14; 2 Channel - 1;
Headphone - 4
Zones: 2 Zone/2 Room Control with 2nd
Room Audio
TunerType: Auto Tuning, Direct Tuning,
Station Name, Presets 30/30/30
(XM/FM/AM)
Convenience
AM/FM Memory Presets: 30 FM - 30 AM
XM ® Connect and Play™Compatible: Yes
(Neural 5.1 Surround Sound Decoding)
XM ® MemoryPresets: 30
PresetMemory: 30 Sirius ® Presets
Inputs and Outputs
Component Video (Y/Pb/Pr) Output(s): 1
(Rear)
Composite Video Output(s): 3 (Rear - 1
Monitor Output, 2 Video Outputs)
Optical Audio Output(s): 2 (Rear)
Component Video (Y/Pb/Pr ) Input(s): 3
(Rear)
Composite Video Input(s): 5 (1 Front/4
Rear)
Coaxial Audio Digital Input(s): 3 (Rear)
Optical Audio Input(s): 5 (1 Front/4 Rear)
RCA Audio Input(s): 5 (Rear)
RCA Audio Output(s): 2 (Rear)
Multi - ChannelInput(s): 1 (Rear, 7.1
Channel)
PhonoInput(s): 1 (Rear)
RS232Control: 1 (Rear)
IRInput(s): 2 (Rear)
IROutput(s): 1 (Rear)
HeadphoneOutput(s): 1 (Front - Gold)
SubwooferOutput(s): 1 (Rear)
HD Component Video Input(s): 3 (Rear)
HD Component Video Output(s): 1 (Rear)
Antenna Terminal (AM Loop): 1 (Rear)
Antenna Terminal (FM 75 Ohm): 1 (Rear)
HDMI™ConnectionInput(s): 3 (Rear)
HDMI™ConnectionOutput(s): 1 (Rear)
Repeater
DIGITAL MEDIA PORT (Connector): Yes
Control - SConnection(s): Yes
12V Trigger Output(s): 3
Digital Media Port (Input): Yes
Hardware
RemoteControl: Yes (Advanced
Learning/Pre Programed)
Power
Power Consumption (in Operation): 480W
PowerRequirements: AC120V, 60 Hz
Power Consumption (in Standby): 1W
Dimensions
Weight: 33 lbs 1 oz (15Kg)
Measurements: 16 15/16 x 6 3/4 x 16
15/16" (430 x 171.5 x 430mm)
Supplied Accessories
Instruction Manual
FM Wire Antenna
AM Loop Antenna
Size AA Batteries: 2
1 Way LCD Pre Programmed Macro capable
Learning Remote Commander ® Remote
Control
1 Basic Remote Commader
Mono Mic (for Auto Calibration only)
Color: Black
UPC Code: 027242715127
1.Requiressatelliteradiosubscriptionandantennasoldseparately.
Antennaplacementrestrictionsapply.
2.HDSourcerequiresHDMIand/orcomponentvideoconnectivity.
3.RequiresHDMIconnectorandcompatibleHDTVwithequivalent
displaycapability. Image quality may vary.
4.Requires HDMI connector and compatible HDTV with1080/60pand
24p display capability.
5.BraviaTheatre Sync feature must be in each device for One Touch
Control.Please refer to owner's manual.
©2007Sony Electronics Inc.
Sony,BRAVIA, Theatre sync, Xross Media Bar, x.v.Color, Precision Cinema
Progressive,Remote Commander and DigitalCinemaSound are
trademarksof Sony. Blu - rayDisc isatrademark. Dolby,DolbyDigital,
ProLogicare registered trademarks of Dolby Laboratories. dtsisa
trademarkofDigitalTheater Systems, L.P. HDMI, the HDMI logo and High -
DefinitionMultimedia Interfacearetrademarks orregisteredtrademarks
ofHDMI Licensing LLC.Allother trademarks areproperty of their
respectiveowners.
Featuresandspecificationsaresubjectto change without notice. All
Weights and Measures are approximate.
