AERMEC NRL 080 User manual

EN
60Hz
Technical manual
NRL 080-180
CHILLER
REVERSIBLE HEAT PUMP
• EXTERNAL UNIT
• HIGH EFFICENCY
• HOT WATER PRODUCING UP TO 131°F / 55°C
• POWER SUPPLY 60Hz
INRLFTY. 14_09.4086981_04

3Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
AERMEC S.p.A. reserves the right at all times to make any modification for the improvement of its product and is not obliged to add these modification to machines of
previous manufacture that have already been delivered or are being built.
Dear Customer,
Thank you for choosing AERMEC. It is the fruit of many years of experience and special design studies and has
been made of the highest grade materials and with cutting edge technology.
In addition, all our products bear the EC mark indicating that they meet the requirements of the European
Machine Directive regarding safety. The standard of quality is permanently being monitored and AERMEC
products are therefore a synonym for Safety, Quality and Reliability.
The data may undergo modifications considered necessary for the improvement of the product, at any time
and without the obligation for any notice thereof.
Thank you again.
AERMEC S.p.A

4Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
INDEX
2. COMPONENTS AND CONFIGURATIONS ........................................ 6
1. DESCRIPTION AND CHOCE OF UNIT .............................................. 6
3. CONFIGURATOR............................................................................... 7
4. COOLING CIRQUIT........................................................................... 8
4.1. NRL ONLY COOLING ....................................................................... 8
4.2. COOLING CIRQUIT NRL HEAT PUMP.............................................. 9
5. DESCRIPTION OF COMPONENTS ................................................. 10
5.1. CHILLER CIRCUIT ........................................................................... 10
5.2. FRAME AND FANS ......................................................................... 10
5.3. HYDRAULIC CIRCUIT STANDARD COMPONENTS........................ 10
5.4. HYDRAULIC COMPONENTS FOR CONFIGURABLE VERSIONS .... 10
5.5. SAFETY AND CONTROL COMPONENTS ....................................... 10
5.6. ELECTRICAL PANEL CONTROL AND POWER................................ 10
6. ACCESSORIES................................................................................. 12
6.1. MECHANICAL ACCESSORIES......................................................... 12
6.2. ELECTRICAL ACCESORIES ............................................................. 12
  ............................ 13
  ............................ 14
9. TECHINICAL DATA VERS. "HA" HIGH EFFICIENCY ....................... 15
10. TECHNICAL DATA VERS. "HA" HIGH EFFICIENCY ........................ 16
11. OPERATIONG LIMITS..................................................................... 17
11.1. OPERATIONG LIMITS IN COOLING MODE GRAPH ¹.................... 17
11.2. OPERATIONG LIMITS IN HOT MODE GRAPH ¹............................. 17
11.3. PROJECT DATA ............................................................................... 17
12. CORRECTIVE FACTORS .................................................................. 18
12.1. INPUT POWER AND COOLING CAPACITY "°"/ "H" ...................... 18
12.2. HEATING CAPACITY AND INPUT POWER ..................................... 19
 ................................ 19
12.4. DEPOSIT FACTORS......................................................................... 19
13. PRESSURE DROP............................................................................ 20
13.1. SYSTEM SIDE TOTAL PRESSURE DROP ONLY
COOLING VERSION....................................................................... 20
13.2. SYSTEM SIDE TOTAL PRESSURE DROP HEAT PUMP
IN COOLING MODE ...................................................................... 20
13.3. SYSTEM SIDE TOTAL PRESSURE DROP HEAT PUMP
IN HEATING MODE ....................................................................... 20
14. USEFUL HEADS .............................................................................. 21
14.2. ONLY COOLING HIGH PUMP USEFUL HEADS
  ...................................................... 21
14.1. HEAT HIGH PUMP USEFUL HEADS
  ...................................................... 21
14.4. ONLY COOLING LOW PUMP USEFUL HEADS
  ...................................................... 22
14.3. HEAT LOW PUMP USEFUL HEADS
  ...................................................... 22
15. ETHYLENE GLYCOL SOLUTIONS.................................................... 23
14.5. HOW TO INTERPRET GLYCOL CURVES ......................................... 23
17. EXPANSION TANK CALIBRATION .................................................. 24
16. MINIMUM WATER CONTENT ....................................................... 24
18. PART LOAD ..................................................................................... 25
19. SOUND DATA.................................................................................. 26
20. CONTROL AND SAFETY PARAMETERS CALIBRATION ................. 26
20.1. THERMOMAGNETIC...................................................................... 27

5Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN

6Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
1. DESCRIPTION AND CHOCE OF UNIT
2. COMPONENTS AND CONFIGURATIONS
COMPONENTS VERSIONS
COOLING CIRCUIT ° H C D T
 yes yes no no no
 yes yes no yes yes
 no no no no yes
 no no no yes no
AIR SIDE EXCHANGE yes yes yes yes yes
COMPRESSOR yes yes yes yes yes
DEHYDRATOR FILTER yes yes yes yes yes
HIGH PRESSURE SWITCH yes yes yes yes yes
HIGH PRESSURE TRANSDUCER yes yes yes yes yes
LOW PRESSURE TRANSDUCER yes yes yes yes yes
LIQUID INDICATOR yes yes yes yes yes
LIQUID TANK no yes no no yes
 no yes no no yes
LIQUID SEPARATOR no yes no no yes
CYCLE REVERSE VALVE no yes no no yes
Chillers and heat pumps for outdoor condensed in the
air with R410A Series NRL have been designed and
manufactured to satisfy heating and cooling needs
and the production of domestic hot water (DHW) in
medium to small commercial or residential buildings.
Maximum reliability
The presence of several scroll compressors allows NRL
chillers various partialisations of the cooling capacity.
Models:
1. NRL "°" standard chiller
2. NRL "H" heat pump *
3. NRL "C" motocondensing
The versions can be in different set-ups at the same
time in order to satisfy a wide range of plant enginee-
ring solutions:
1. "A" HIGH EFFICIENCY
2. "E" SILENCED HIGH EFFICIENCY
3. "D" WITH DESUPERHEATER
4. "T" WITH TOTAL RECOVERY
Standards and Directives respected on
designing and constructing the unit:
PROTECTION RATING
1. IP 24
ACOUSTIC PART:
1. ISO DIS 9614/2

2. 
3. SOUND PRESSURE (EN ISO 3744)
REFRIGERANT GAS:
This unit contains fluoride gases with
greenhouse effect covered by the
Kyoto Protocol. Maintenance and
disposal must only be performed by
qualified staff.
STANDARD:
UL 1995
Heating and cooling equipment.
ANSI/NFPA
Standard 70 National Electrical code
(N.E.C.).
CSA C.22.1.- C.22.2
Safety Standard Electrical Installation.
* Possibility of production of D.H.W.
- only "I" version (fan speed modulating for condensation control).
- VMF


7Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
3. CONFIGURATOR
Field
1, 2, 3 Code NRL
4, 5, 6, 7 Size 080/090/100/125/140/150/165/180
8 Thermostatic valve
°
Standard mechanical thermostatic valve with produced water up to 39,2°F / +4°Cx
Y Mechanical thermostatic valve with produced water from 39,2°F / +4°C to -42,8°F / -6°C
X Electronic thermostatic valve min. Water out temp 39,2°F / +4°C, (contact the factory for lower temperatures)
9 Models
°Cooling Only
HHeat pump
CWithout evaporator
10 Heat recovery
°Without recovery
D With Desuperheater (data on demand)
TWith Total recovery (data on demand)
11 Version
AHigh efficiency
E High efficiency, low noise (data on demand for sizes from 080 to 180)
12 Coils
°
Alluminium
R Copper
S Copper tin plated
V Epoxy coated
13 Fans
°Standard
(not available for 208V power supply)
I(mandatory for 208V power supply)
14 Power supply
6230V ±10% -3-60Hz with thermomagnetic switches (data on demand for size 090 to 180)
7460V ±10% -3-60Hz with thermomagnetic switches
8575V ±10% -3-60Hz with thermomagnetic switches
9208V ±5% -3-60Hz with thermomagnetic switches
15, 16 Hydronic kit
00 Without hydronic kit
01 Tank and single low head pump
02 Tank and single low head pump and reserve pump
03 Tank and single high head pump
04 Tank and single high head pump and reserve pump
P1 Single low head pump
P2 Single low head pump and reserve pump
P3 Single high head pump
P4 Single high head pump and reserve pump

YD / YT / YH
HT / HC
CT / CD
T01 / T02 / T03 / T04
"I" ventilation mandatory for Desuperheater "D" option

8Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
4. COOLING CIRQUIT
CN
TEV
IDL IDL
HPT HPS
LPT
CP CP
LPT
BHE
HPT HPS
TEV
F F
CN
KEY
BHE: SCAMBIATORE A PIASTRE
CN: BATTERIA ALETTATA
CP: COMPRESSORE
F: FILTRO DEIDRATATORE
HPS: PRESSOSTATO DI ALTA PRESSIONE
HPT: TRASDUTTORE ALTA PRESSIONE
IDL: INDICATORE DI LIQUIDO
LPT: TRASDUTTORE BASSA PRESSIONE
KEY:
BHE PLATE HEAT EXCHANGER
CN AIR SIDE EXSCHANGE
CP
COMPRESSOR
FFILTER DRIER
HPS HIGH PRESSURE SWITCH
HPT HIGH PRESSURE TRANSDUCERS
IDL LIQUID INDICATOR
LPT LOW PRESSURE TRANSDUCER
4.1. NRL ONLY COOLING

9Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
KEY
AL: ACCUMULO DEL LIQUIDO
BHE: SCAMBIATORE A PIASTRE
CN: BATTERIA ALETTATA
CP: COMPRESSORE
CV: VALVOLA DI NON RITORNO
F: FILTRO DEIDRATATORE
HPS: PRESSOSTATO DI ALTA PRESSIONE
HPT: TRASDUTTORE ALTA PRESSIONE
IDL: INDICATORE DI LIQUIDO
LPT: TRASDUTTORE BASSA PRESSIONE
LS: SEPARATORE DI LIQUIDO
VIC: VALVOLA INVERSIONE CICLO
HPT HPS
LS
VIC VIC
LS
HPS
LPT LPT
HPT
BHE
IDL IDL
CP
CN
CV CV
CV
CV
CV
CN
TEV TEV
F
AL
F
CV
CV
AL
CP
CV
KEY:
AL FLUID STORAGE TANK
BHE PLATE HEAT EXCHANGER
CN AIR SIDE EXCHANGE
CP
COMPRESSOR
CV 
FFILTER DRIER
HPS HIGH PRESSURE SWITCH
HPT HIGH PRESSURE TRANSDUCERS
IDL LIQUID INDICATOR
LPT LOW PRESSURE TRANSDUCERS
LS LIQUID SEPARATOR
VIC REVERSE CYCLE VALVE
4.2. COOLING CIRQUIT NRL HEAT PUMP

10 Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
5. DESCRIPTION OF COMPONENTS
5.1. CHILLER CIRCUIT
SCROLL COMPRESSORS
High efficiency scroll-type hermetic compressors, as-
sembled on elastic antivibration supports, driven by a
2-pole electric motor with internal thermal protection.
of the electric heater casing included as standard. The
heater is automatically powered when the unit stops,
provided that the unit is kept under tension.
WATER SIDE HEAT EXCHANGER
Of the plate-type (AISI 316), externally insulated with
closed cell material to reduce thermal dispersion.
Fitted, as standard, with antifreeze heater.
5.1.1. WATER FEATURES
SOURCE SIDE HEAT EXCHANGER
Made with copper pipes and aluminium louvered fins
blocked by mechanical expansion of the pipes. Provi-
ded with protective grid.
DESUPERHEATER / TOTAL RECOVERY
Unit with (AISI 316) heat plate, insulated externally
with closed cell material to reduce heat loss.
CYCLE INVERSION VALVE

4way cycle inversion valve. Inverts the flow of refrige-
rant gas.
LIQUID STORAGE TANK

Compensates the difference in volume between louve-
res coil and plate exchanger, withholding excess liquid.
DEHYDRATOR FILTER
Hermetic-mechanical with cartridges made of ceramic
and hygroscopic material, able to withhold impurities
and any traces of humidity present in the cooling
circuit.

Allows the passage of the refrigerant in just one
direction.
MECHANICAL THERMOSTATIC VALVE
The mechanical valve, with external equaliser positio-
ned at the evaporator inlet, modulates the flow of gas
to the evaporator, according to the heat load, in order
to ensure a correct heating level of the intake gas.
SOLENOID VALVE
The valve closes when the compressor turns off,
preventing the flow of refrigerant gas towards the
evaporator.
INDICATOR FOR LIQUID PASSAGE WITH HUMIDITY
PRESENCE SIGNAL
Used to check the refrigerant gas load and the eventual
presence of humidity in the cooling circuit.
LIQUID AND PRESSING LINE TAPS

Allows interruption of the refrigerant in the case of
extraordinary maintenance.
LIQUID SEPARATOR

Located on the suction point of the compressor, to pro-
tect against any flowback of liquid refrigerant, flooded
start-ups, operation in the presence of liquid.
BY PASS SOLENOIDE VALVE

By-passes the thermostatic valve during the defrosting
cycle.
5.2. FRAME AND FANS
SUPPORT FRAME
Load-bearing structure Made of hot-galvanised steel
sheet of a suitable thickness, varnished with polyester
powders able to resist atmospheric agents over time.
VENTILATION UNIT
Axial fan, balanced statically and dynamically. The elec-
tric fans are protected electrically by magnet-circuit
breakers and mechanically by anti-intrusion metal
grids, according to the IEC EN 60335-2-40 Standard.
5.3. HYDRAULIC CIRCUIT STANDARD COM
PONENTS

Equipped with steel filtering mesh; prevents the heat
exchangers from clogging.

It checks that there is circulation of water.If
this is not the case, it blocks the unit
WATER TEMPERATURE PROBE (IN-OUT)
5.4. HYDRAULIC COMPONENTS FOR CONFI
GURABLE VERSIONS
CIRCULATION PUMP

Depending on the characteristics of the pump chosen,
it offers a useful head to overcome the pressure drops
in the system.
EXPANSION TANK


With nitrogen pre-load membrane.
SAFETY VALVE
Equipped with a piped discharger and intervenes by
discharges the over pressure in case of anomalous
pressures.
STORAGE TANK
In order to reduce the thermal dispersion and elimina-
te the phenomenon of the formation of condensation,
it is insulated with polyurethane material of a suitable
thickness. It is required to reduce the number of peaks
of the compressor and to even the temperature of
water to be sent to the utilities.
STORAGE TANK DRAIN TAP
5.5. SAFETY AND CONTROL COMPONENTS

With fixed calibration, placed on high pressure side of
cooling circuit, inhibits functioning of compressor if
abnormal work pressure occurs.
HIGH PRESSURE TRANSDUCER
Placed on high pressure side of cooling circuit, signals
the work pressure to control board, generating a pre-
warning in case abnormal pressure occurs.
LOW PRESSURE TRANSDUCER
Allows displaying, on the microprocessor board display,
the value of the compressor's suction pressure (one
per circuit) on the low-pressure side of the cooling
circuit
SAFETY VALVE
Equipped with a piped discharger and intervenes by
discharges the over pressure in case of anomalous
pressures.
- Set at 45 bar on the branch HP
- Set at 30 bar on the branch LP
LOW PRESSURE SWITCH
5.6. ELECTRICAL PANEL CONTROL AND
POWER
Electric board in compliance with standards EN 60204-
1/IEC 204-1, complete with:
- door lock main isolating switch,
- fuses and contactors for compressors and fans,
- terminals for REMOTE PANEL,
- spring type control circuit terminal board,
- outdoor electric board with double door and
gaskets,
- electronic controller,
- evaporator pump and recovery pump control
consent relay
- all numbered cables.
PH 6-8
Electric
conductivity
less than 200 mV/cm
(77°F / 25°C)
Chloride ions less than 50 ppm
Sulphuric acid ions less than 50 ppm
Total iron less than 0.3 ppm
Alkalinity M less than 50 ppm
Total hardness less than 50 ppm
Sulphur ions none
ammonia ions none
Silicone ions less than 30 ppm

11Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN

IT is possible to access the electrical panel by discon-
necting the voltage, then using the opening lever of
the panel itself. This lever can be blocked with one or
more padlocks during maintenance, in order to prevent
the machine being powered up accidentally.

This allows the chiller command operations to
be given from a distance. compressor protection ther-
momagnetic switch; fan protection thermomagnetic
switch; auxiliary protection thermomagnetic switch;
discharge gas temperature control thermostat
CONTROL KEYPAD
Provides full control functions. For a detailed
description refer to the user manual.
ELECTRONIC REGULATION
Microprocessor board
Composed of management & control board
and display board.
Functions performed
adjustment of evaporator inlet water temperature with thermostatic control
up to 6 steps and proportional control over the speed of the fans (with DCPX
accessory)
compressor start up delay
rotation sequence compressors;
compressor operating hours count.
start/stop;
reset;
permanent memory of alarms;
autostart after power failure.
multilingual messaging;
working with local or remote control.
(accessory PGD1)
Machine state display
ON/OFF compressors.
alarms summary
Alarm Management
high pressure.
flow switch.
low pressure.
antifreeze.
overload compressors;
overhead fans;
overload pumps.
Viewing of the following parameters
water inlet temperature;
water outlet temperature;
delta T;
high pressure;
low pressure;
hold time to reboot;
alarms display

• a) without password:
cold set;
total differential;
• b) with password:
antifreeze set;
time exclusion low pressure;
display language;
access code.
For more information refer to the user manual.
ATTENTION
In heat pump models the desuperheater

warranty will be come void.

12 Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
6. ACCESSORIES
NRL 0800 0900 1000 1250 1400 1500 1650 1800
A - E GP260 GP260 GP260 GP500 GP500 GP500 GP500 GP500
HA - HE GP350 GP350 GP350 GP500 GP500 GP500 GP500 GP500
NRL NRL0800A NRL0900A NRL1000A NRL1250A NRL1400A NRL1500A NRL1650A NRL1800A
00 AVX 704 AVX 710 AVX 716 AVX 7012 AVX 7009 AVX 7009 AVX 734 AVX 737
P2 / P4 AVX 706 AVX 712 AVX 712 AVX 7014 AVX 7009 AVX 7009 AVX 736 AVX 736
P1 / P3 AVX 706 AVX 712 AVX 712 AVX 7014 AVX 7009 AVX 7009 AVX 736 AVX 736
02 / 04 AVX 705 AVX 711 AVX 711 AVX 7013 AVX 7010 AVX 7010 AVX 735 AVX 738
01 / 03 AVX 705 AVX 711 AVX 711 AVX 7013 AVX 7010 AVX 7010 AVX 735 AVX 738
NRL NRL0800HA NRL0900HA NRL1000HA NRL1250HA NRL1400HA NRL1500HA NRL1650HA NRL1800HA
00 AVX 7003 AVX 7006 AVX 7006 AVX 7009 AVX 7009 AVX 7009 AVX 734 AVX 737
P2 / P4 AVX 7005 AVX 7008 AVX 7008 AVX 7011 AVX 7011 AVX 7011 AVX 736 AVX 736
P1 / P3 AVX 7005 AVX 7008 AVX 7008 AVX 7011 AVX 7011 AVX 7011 AVX 736 AVX 736
02 / 04 AVX 7004 AVX 7007 AVX 7007 AVX 7010 AVX 7010 AVX 7010 AVX 735 AVX 738
01 / 03 AVX 7004 AVX 7007 AVX 7007 AVX 7010 AVX 7010 AVX 7010 AVX 735 AVX 738
ELECTRICAL ACCESORIES
• AER485: RS-485 interface for supervision systems with
MODBUS protocol.
• AERWEB300
Accessory AERWEB allows remote control of a chiller
through a common PC and an ethernet connection over
a common browser; 4 versions available:
AERWEB300-6: Web server to monitor and remote con-
trol max. 6 units in RS485 network;
AERWEB300-18: Web server to monitor and remote con-
trol max. 18 units in RS485 network;
AERWEB300-6G: Web server to monitor and remote con-
trol max. 6 units in RS485 network with integrated GPRS
modem;
AERWEB300-18G: Web server to monitor and remote
control max. 18 units in RS485 network with integrated
GPRS modem;
• AER485P1: RS-485 interface for supervising systems with
MODBUS protocol.
• PGD1: Simplified remote panel. Allows control of basic
unit functions and alarm notification. Remote mounted
up to 500 m away with TWISTED PAIR SCREENED cable
and TCONN6J000.
• DCPX: Low ambient device for cooling operation below
10°C down to -10°C. The
• DRE: It allows the reduction of peak power necessary for
the machine during start-up phase.
Accessories can only be fitted in the factory.
• DUALCHILLER: Simplified control system to switch on and
off, and command, two chillers (using Aermec GR3 com-
mand) in a single system, as if they were a single unit.
• MULTICHILLER:
Control system to switch the individual chillers on and off,
and command them, in a system in which several units
are installed in parallel, always ensuring a constant delive-
ry to the evaporators.
• PGS: Daily/Weekly Programmer.
Allows you to programme two time bands per day (two
switch on/off cycles) and to have differentiated program-
ming for each day of the week.
• PRM1-PRM2 FACTORY FITTED ACCESSORY. It is a manual
pressure switch electrically wired in series with the exi-
sting automatic high pressure switch on the compressor
discharge pipe.
MECHANICAL ACCESSORIES
•AVX: Sprung anti-vibration supports. Select the AVX
model from the compatibility table.
•VT: Group of anti-vibration, to be installed under the
base.
• GP: Protection grille, protects the external coil from acci-
dental knocks.
For more information please contact us.
Versions with Total Recovery and Condensing Units
are equipped with GR3 electronics (standard remote panel)
All the other versions have pCO5 electronics
(remote panel available as accessory)

13Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
7. TECHNICAL DATA vers. A - HIGH EFFICIENCY
Model 080 090 100 125 140 150 165 180
Cooling capacity (1)(2) Alls Tons 53.57 62.56 72.25 93.92 102.22 110.27 120.48 130.67
Total power input Alls kW 65.70 76.00 87.00 112.10 121.40 130.90 151.99 173.32
Total power input with LOW PUMP Alls kW 68.60 77.20 92.40 118.40 127.60 135.50 158.06 179.05
Total power input with HIGH PUMP Alls kW 69.60 79.70 94.40 120.90 131.10 139.00 163.56 184.55
Water flow rate Alls gpm 128 150 173 225 245 264 289 313
Total pressure drop Alls psi 87566789
Useful head with LOW - PUMP Alls A / E psi 19 19 20 15 20 18 17 14
Useful head with HIGH - PUMP Alls A / E psi 36 36 36 30 36 32 39 36
ENERGY INDICES
EER Alls BTU/Wat 9,81 10,13 9,74 9,79 9,97 10,11 9,51 9,05
IPLV Alls BTU/Wat 13,80 14,14 13,85 13,91 14,05 14,09 13,42 12,84
PROTECTION RATING
IP Alls 24 24 24 24 24 24 24 24
DESUPERHEATER
Heating power recovered Alls BTU/h 224.860 262.735 303.681 393.420 429.247 464.051 505.679 547.308
Water flow Alls gpm 49.91 58.31 67.4 87.32 95.27 102.99 112.23 121.47
Pressure drop Alls psi 0.87 1.16 1.16 1.74 2.03 1.89 2.32 2.47
Q.ty Alls nr. 22222222
Defrost electric heater Alls nr. / W 2 / 40 2 / 40 2 / 40 2 / 40 2 / 40 2 / 40 2 / 40 2 / 40
Water content Alls l 1,9 / 1,9 1,9 / 2,3 2,3 / 2,3 2,6 / 2,6 2,6 / 3,3 3,3 / 3,3 3,3 / 3,8 3,8 / 3,8
Water connections Alls inch 2" 2" 2" 2" 2" 2" 2" 2"
Total input current (1)
230V A 206.8 -------
460V A 105.6 122.0 136.5 182.8 193.7 204.2 236.3 268.7
575V A 86.2 98.6 109.4 148.8 156.6 164.1 190.8 217.7
SCROLL COMPRESSORS
Quantity / circuits - n°/n° 4/2 4/2 4/2 4/2 4/2 4/2 5/2 6/2
HEAT EXCHANGER SYSTEM SIDE
Exchanger capacity - gal 3,4 4,4 7,0 8,0 8,7 8,7 8,7 8,7
Water connections - Ø 3" 3" 4" 4" 4" 4" 4" 4"
COOLING (AHRI CONDITIONS)
Outlet water temperature 6,7°C / 44,6°F
Flow rate 0,043 l/s kW
External temperature 35°C / 95°F
DESUPERHEATER/ TOTAL RECOVERY
Entering water 45°C
Leaving water 50°C
(3) HEATING (AHRI CONDITIONS)
Inlet water temperature 40°C / 104°F
Outlet water temperature 45°C / 113°F
External air temperature 7°C b.s / 6°C b.u.
AHRI conditions
leaving water 6.7°C/44.6°F
flow rate 0.043 l/s per kW (full load)
Load 100% air 35°C /95°F
Load 75% air 26.7°C/80.06°F
Load 50% air 18.3°C /64.94°F
Load 25% air 12.8°C/55.04°F
DATA REFERED NO PUMP VERSION

14 Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
8. TECHNICAL DATA vers. A - HIGH EFFICIENCY
MODEL 800 900 1000 1250 1404 1504 1655 1800
COOLING + TOTAL RECOVERY
Cooling capacity Alls ton 47.10 55.03 63.51 82.57 89.87 96.96 105.94 114.92
Total power input Alls KW 64,70 74,3 91,4 111,7 120,9 129,7 153,3 176,8
Total Recovery
Heating power recovered Alls BTU/h 774.897 901.147 1.058.446 1.352.914 1.470.292 1.583.916 1.768.172 1.952.086
Water flow Alls gpm 171.98 200 234.91 300.27 326.32 351.53 392.43 433.25
Pressure drop Alls psi 12.04 12.47 14.07 13.49 13.05 13.20 13.49 14.21
Q.ty Alls n° 1 1 1 1 1 1 1 1
Defrost electric heater Alls nr. / W 2 / 150 2 / 150 2 / 150 2 / 150 2 / 150 2 / 150 2 / 150 2 / 150
Water content Alls l 17 21 24 28 32 35 39 43
Water connections Alls inch 3" 3" 3" 3" 3" 3" 3" 3"
DEFROST ELECTRIC HEATER
Water content Alls n°/gal 1 x 185 1 x 185 1 x 185 1 x 185 1 x 185 1 x 185 1 x 185 1 x 185
WATER CONNECTIONS
Expansion tank Alls n°/gal 2 x 6.60 2 x 6.60 2 x 6.60 2 x 6.60 2 x 6.60 2 x 6.60 2 x 6.60 2 x 6.60
Expansion tank calibration Alls psi 21.75 21.75 21.75 21.75 21.75 21.75 21.75 21.75
LOW HEAD PUMP
Pump input current
230V A 10.4 - - - - - - -
460V A 4.94 4.94 4.94 4.94 6.23 6.23 8.43 8.43
575V A 3.95 3.95 3.95 3.95 4.98 4.98 6.74 6.74
HIGH HEAD PUMP
Pump input current
230V A 13.10 - - - - - - -
460V A 6.2 8.43 8.43 8.43 11.48 11.48 16.69 16.69
575V A 4.98 6.74 6.74 6.74 9.19 9.19 13.35 13.35
SAFETY VALVE
Safety valve calibration Alls psi 87 87 87 87 87 87 87 87
FAN MOTORS
Quantity n° 4 4 4 8 8 8 8 8
Air flow CFM 48616 47908 47672 96288 94636 92984 92984 92984
Fan input current
230V A 26.0 - - - - - - -
460V A 15.2 15.2 15.2 30.4 30.4 30.4 30.4 30.4
575V A 13.28 13.28 13.28 26.56 26.56 26.56 26.56 26.56
Fan power input
230V
kW 8.0 8.0 8.0 16.0 16.0 16.0 16.0 16.0 460V
575V 8.72 8.72 8.72 17.44 17.44 17.44 17.44 17.44
SOUND DATA
Sound pressure Alls db(A)
56 57 57 62 63 64 64 64
Sound power Alls db(A)
88 89 89 94 95 96 96 96
The data reported can be changed at any time if deemed necessary from Aermec
R410A Gas refrigerant Kg/lbs C1 28,0 / 61,63 29,3 / 64,60 34,8 / 76,72 55,0 / 121,25 55,3 / 121,92 72,6 / 160,06 72,6 / 160,06 72,6 / 160,06
Kg/lbs C2 28,0 / 61,63 32,3 / 71,21 34,8 / 76,72 55,0 / 121,25 72,6 / 160,06 72,6 / 160,06 72,6 / 160,06 72,6 / 160,06
Oil Kg/lbs C1 6.8 / 14.99 6.8 / 14.99 9.4 / 20.72 13.6 / 29.98 13.6 / 29.98 12.6 / 27.77 12.6 / 27.77 20.4 / 44.97
Kg/lbs C2 6.8 / 14.99 9.4 / 20.72 9.4 / 20.72 13.6 / 29.98 12.6 / 27.77 12.6 / 27.77 20.4 / 44.97 20.4 / 44.97
DIMENSION
Height
Alls
in 96 96 96 96 96 96 96 96
Width in 87 87 87 87 87 87 87 87
Depth in 134 134 134 226 226 226 226 226
Weight when empty Alls lbs 4134 4475 4850 7275 7496 7760 8113 8422
Sound power
Aermec determines sound power values in agreement with the
9614-2 Standard.
Sound Pressure
Sound pressure measured in free field conditions with reflec-
tive surface (directivity factor Q=2) at 394 in/10mt distance
from external surface of unit, in compliance with ISO 3744
regulations.

15Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
DATI TECNICI VERSIONE "°"DATI TECNICI VERSIONE "H"DATI TECNICI VERSIONE "C"
9. TECHINICAL DATA vers. "HA" HIGH EFFICIENCY - HEATING PUMP
Model 080 090 100 125 140 150 165 180
Cooling capacity (1)(2) Alls Tons 54.30 61.91 70.91 91.94 98.72 106.01 113.34 123.05
Total power input Alls kW 65.70 76.00 87.00 112.10 121.40 130.90 151.99 173.32
Total power input with LOW PUMP Alls kW 68.70 79.00 90.00 115.10 125.40 134.90 157.49 178.82
Total power input with HIGH PUMP Alls kW 69.70 81.50 92.50 117.60 128.90 138.40 162.99 184.32
Water flow rate Alls gpm 130 148 170 220 236 254 271 294
Total pressure drop Alls psi 6 6 7 5 5 5 6 7
Useful head with LOW - PUMP 230V/ 460V psi 21 20 18 16 22 20 20 17
Useful head with HIGH - PUMP 230V/ 460V psi 37 37 34 31 38 35 42 40
Useful head with LOW - PUMP 575V psi 21 20 18 16 22 20 20 17
Useful head with HIGH - PUMP 575V psi 37 37 34 31 38 35 42 40
Heating capacity (3) Alls BTU/h 666703 786738 886417 1119532 1214852 1311794 1528820 1701940
Total power input Alls kW 66.15 77.99 89.71 116.69 126.91 134.47 157.41 173.40
Total power input with LOW PUMP Alls kW 69.15 80.99 92.71 119.69 130.91 138.47 162.91 178.90
Total power input with HIGH PUMP Alls kW 70.15 83.49 95.21 122.19 134.41 141.97 168.41 184.40
Water flow rate Alls gpm 148 174 197 248 269 291 339 377
Total pressure drop Alls p.s.i. 7 8 9 6 7 7 10 12
Useful head with LOW - PUMP 230V/ 460V psi 19 17 14 12 17 14 12 7
Useful head with HIGH - PUMP 230V/ 460V psi 32 33 30 26 31 27 34 29
Useful head with LOW - PUMP 575V psi 19 17 14 12 17 14 12 7
Useful head with HIGH - PUMP 575V psi 32 33 30 26 31 27 34 29
ENERGY INDICES
EER Alls BTU/Watt 9,91 9,77 9,77 9,83 9,75 9,71 8,94 8,51
COP Alls Watt/Watt 2.95 2.95 2.89 2.81 2.80 2.86 2.84 2.87
IPLV Alls BTU/Watt 13,93 13,66 13,90 13,93 13,73 13,52 13,25 12,84
PROTECTION RATING
IP Alls 24 24 24 24 24 24 24 24
DESUPERHEATER
Heating power recovered Alls BTU/h 227.590 259.664 297.880 348.548 413.893 444.943 474.629 514.551
Water flow Alls gpm 50.51 57.63 66.11 85.35 91.86 98.75 105.34 114.2
Pressure drop Alls psi 0.87 1.16 1.16 1.60 1.86 1.74 2.03 2.18
Q.ty Alls nr. 2 2 2 2 2 2 2 2
Defrost electric heater Alls nr. / W 2 / 40 2 / 40 2 / 40 2 / 40 2 / 40 2 / 40 2 / 40 2 / 40
Water content Alls l 1,9 / 1,9 1,9 / 2,3 2,3 / 2,3 2,6 / 2,6 2,6 / 3,3 3,3 / 3,3 3,3 / 3,8 3,8 / 3,8
Water connections Alls inch 2" 2" 2" 2" 2" 2" 2" 2"
ELECTRICAL DATA
Cooling - Total input current (1)
230V A 211.2 - - - - - - -
460V A 108.9 122.5 136.6 179.5 191.8 204.5 236.6 269.0
575V A 89.4 99.4 110.0 146.3 155.1 164.3 191.0 217.9
Heating - Total input current (3)
230V A 207.0 - - - - - - -
460V A 103.6 123.1 143.3 174.7 196.8 214.4 242.8 276.8
575V A 82.8 98.5 114.6 139.8 157.5 171.6 207.8 221.5
(3) HEATING (AHRI CONDITIONS)
Inlet water temperature 40°C / 104°F
Outlet water temperature 45°C / 113°F
External air temperature 7°C b.s / 6°C b.u.
AHRI conditions
leaving water 6.7°C/44.6°F
flow rate 0.043 l/s per kW (full load)
Load 100% air 35°C /95°F
Load 75% air 26.7°C/80.06°F
Load 50% air 18.3°C /64.94°F
Load 25% air 12.8°C/55.04°F
DATA REFERED NO PUMP VERSION
(1) COOLING (AHRI CONDITIONS)
Outlet water temperature 6,7°C / 44,6°F
Flow rate 0,043 l/s kW
External temperature 35°C / 95°F
DESUPERHEATER
Entering water 45°C
Leaving water 50°C

16 Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
10. TECHNICAL DATA vers. "HA" HIGH EFFICIENCY - HEATING PUMP
Model 080 090 100 125 140 150 165 180
SCROLL COMPRESSORS
Quantity / circuits n°/n° 4/2 4/2 4/2 4/2 4/2 4/2 5/2 6/2
HEAT EXCHANGER SYSTEM SIDE
Exchanger capacity gal 4,4 5,3 7,0 8,7 8,7 9,9 9,9 9,9
Water connections Ø 3" 3" 4" 4" 4" 4" 4" 4"
HYDRONIC GROUP SYSTEM SIDE
STORAGE TANK
Storage tank capacity Alls n°/gal 1 x 185 1 x 185 1 x 185 1 x 185 1 x 185 1 x 185 1 x 185 1 x 185
EXPANSION TANK
Expansion tank Alls n°/gal 2 x 7 2 x 7 2 x 7 2 x 7 2 x 7 2 x 7 2 x 7 2 x 7
Expansion tank calibration Alls psi 21.75 21.75 21.75 21.75 21.75 21.75 21.75 21.75
LOW HEAD PUMP
Pump input current
230V A 10.40 - - - - - - -
460V A 4.9 4.94 4.94 4.94 6.23 6.23 8.43 8.43
575V A 3.95 3.95 3.95 3.95 4.98 4.98 6.74 6.74
HIGH HEAD PUMP
Pump input current
230V A 13.10 - - - - - - -
460V A 6.2 8.43 8.43 8.43 11.48 11.48 16.69 16.69
575V A 4.98 6.74 6.74 6.74 9.19 9.19 13.35 13.35
SAFETY VALVE
Safety valve calibration Alls psi 87 87 87 87 87 87 87 87
FAN MOTORS
Quantity n° 6 6 6 8 8 8 8 8
Air flow CFM 73632 73632 73632 99592 99592 99592 99120 97704
Fan input current
230V A 39.0 - - - - - - -
460V A 22.8 22.8 22.8 30.4 30.4 30.4 30.4 30.4
575V A 19.92 19.92 19.92 26.56 26.56 26.56 26.6 26.6
Fan power input
230V kW 12.0 - - - - - - -
460V kW - 12.0 12.0 16.0 16.0 16.0 16.0 16.0
575V kW 13.08 13.08 13.08 17.44 17.44 17.44 17.4 17.4
SOUND DATA
Sound pressure Alls db(A) 57 60 61 62 63 64 64 64
Sound power Alls db(A) 89 92 93 94 95 96 96 96
The data reported can be changed at any time if deemed necessary from Aermec
R410A Gas refrigerant Kg/lbs C1 54,7 / 120,59 55,1 / 121,47 55,7 / 122,80 81,9/180,56 81,9/180,56 85,0 / 187,39 85,0 / 187,39 85,0 / 187,39
Kg/lbs C2 54,7 / 120,59 55,1 / 121,47 55,7 / 122,80 81,9/180,56 81,9/180,56 85,0 / 187,39 85,0 / 187,39 85,0 / 187,39
Oil Kg/lbs C1 6.8 / 14.99 6.8 / 14.99 9.4 / 20.72 13.6 / 29.98 13.6 / 29.98 12.6 / 27.77 12.6 / 27.77 20.4 / 44.97
Kg/lbs C2 6.8 / 14.99 9.4 / 20.72 9.4 / 20.72 13.6 / 29.98 12.6 / 27.77 12.6 / 27.77 20.4 / 44.97 20.4 / 44.97
DIMENSION
Height in 96 96 96 96 96 96 96 96
Width in 87 87 87 87 87 87 87 87
Depth in 167 167 167 226 226 226 226 226
Weight when empty lbs 5732 5952 6129 8113 8179 8223 8554 8818
Sound power
Aermec determines sound power values in agreement with the
9614-2 Standard.
Sound Pressure
Sound pressure measured in free field conditions with reflec-
tive surface (directivity factor Q=2) at 394 in/10mt distance
from external surface of unit, in compliance with ISO 3744
regulations.

17Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
Models 800 900 1000 1250 1400 1500 1650 1800
ELECTRICAL DATA MODELS WITHOUT PUMP + "°" ON/OFF FAN
Alimentation 230V60Hz
MODELS WITHOUT PUMP
LRA A 533,3 716,4 752,7 912,8 961,5 979,8 1046,7 1083,3
MCA A 263,0 303,8 340,1 414,3 469,1 517,9 554,4 584,9
MOP A 318,8 377,7 414,0 499,6 578,8 627,5 664,0 670,1
Recom FUSE A 300 350 400 450 500 600 600 600
MODELS WITH LOW PUMP
LRA A 543,3 726,4 762,7 922,8 974,7 993,0 1065,1 1101,7
MCA A 273,0 313,8 350,1 424,3 482,3 531,1 572,8 603,3
MOP calc A 328,8 387,7 424,0 509,6 592,0 640,7 682,4 688,5
Recom FUSE A 300 350 400 500 500 600 600 600
MODELS WITH HIGH PUMP
LRA A 546,5 734,8 771,1 931,2 983,5 1001,8 1081,3 1117,9
MCA A 276,2 322,2 358,5 432,7 491,1 539,9 589,0 619,5
MOP A 332,0 396,1 432,4 518,0 600,8 649,5 698,6 704,7
Recom FUSE A 300 350 400 500 600 600 600 700
Alimentation 460/3/60Hz
MODELS WITHOUT PUMP
LRA A 276,5 326,7 335,9 432,6 483,1 508,3 525,1 516,4
MCA A 130,4 139,8 149,0 213,0 241,2 266,4 283,2 296,8
MOP A 156,7 170,2 179,5 254,9 295,7 320,9 337,7 338,7
Recom FUSE A 150 150 175 250 250 300 300 300
MODELS WITH LOW PUMP
LRA A 281,5 331,7 340,9 437,6 489,7 514,9 534,3 525,6
MCA A 135,4 144,8 154,0 218,0 247,8 273,0 292,4 306,0
MOP A 161,7 175,2 184,5 259,9 302,3 327,5 346,9 347,9
Recom FUSE A 150 175 175 250 300 300 300 300
MODELS WITH HIGH PUMP
LRA A 283,1 335,9 345,1 441,8 494,1 519,3 542,4 533,7
MCA A 137,0 149,0 158,2 222,2 252,2 277,4 300,5 314,1
MOP A 163,3 179,4 188,7 264,1 306,7 331,9 355,0 356,0
Recom FUSE A 150 175 175 250 300 300 350 350
Alimentation 575/3/60Hz
MODELS WITHOUT PUMP
LRA A 219,2 268,1 270,6 372,3 387,9 417,1 422,6 441,8
MCA A 116,9 118,9 121,4 177,7 210,6 239,8 245,3 247,2
MOP A 140,6 143,5 146,0 212,5 260,0 289,2 294,7 282,0
Recom FUSE A 125 125 125 200 250 250 250 250
MODELS WITH LOW PUMP
LRA A 223,2 272,1 274,6 376,3 393,2 422,4 430,0 449,1
MCA A 120,9 122,9 125,4 181,7 215,9 245,1 252,7 254,6
MOP A 144,6 147,5 150,0 216,5 265,2 294,5 302,1 289,3
Recom FUSE A 125 125 150 200 250 250 300 250
MODELS WITH HIGH PUMP
LRA A 224,5 275,5 278,0 379,7 396,7 425,9 436,5 455,6
MCA A 122,2 126,3 128,8 185,1 219,4 248,6 259,2 261,0
MOP A 145,9 150,9 153,4 219,8 268,8 298,0 308,5 295,8
Recom FUSE A 125 150 150 200 250 250 300 250
Models 800 900 1000 1250 1400 1500 1650 1800
ELECTRICAL DATA MODELS WITHOUT PUMP + "I" EC INVERTER FAN
Alimentation 208V60Hz
MODELS WITHOUT PUMP
LRA A 537,3 720,4 756,7 920,8 969,5 987,8 1054,7 1091,3
MCA A 267,0 307,8 344,1 422,3 477,1 525,9 562,4 592,9
MOP A 322,8 381,7 418,0 507,6 586,8 635,5 672,0 678,1
Recom FUSE A 300 350 400 500 500 600 600 600
MODELS WITH LOW PUMP
LRA A 547,3 730,4 766,7 930,8 982,7 1001,0 1073,1 1109,7
MCA A 277,0 317,8 354,1 432,3 490,3 539,1 580,8 611,3
MOP calc A 332,8 391,7 428,0 517,6 600,0 648,7 690,4 696,5
Recom FUSE A 300 350 400 500 600 600 600 600
MODELS WITH HIGH PUMP
LRA A 550,5 738,8 775,1 939,2 991,5 1009,8 1089,3 1125,9
MCA A 280,2 326,2 362,5 440,7 499,1 547,9 597,0 627,5
MOP A 336,0 400,1 436,4 526,0 608,8 657,5 706,6 712,7
Recom FUSE A 300 400 400 500 600 600 700 700
Alimentation 230V60Hz
MODELS WITHOUT PUMP
LRA A 537,3 720,4 756,7 920,8 969,5 987,8 1054,7 1091,3
MCA A 267,0 307,8 344,1 422,3 477,1 525,9 562,4 592,9
MOP A 322,8 381,7 418,0 507,6 586,8 635,5 672,0 678,1
Recom FUSE A 300 350 400 500 500 600 600 600
MODELS WITH LOW PUMP
LRA A 547,3 730,4 766,7 930,8 982,7 1001,0 1073,1 1109,7
MCA A 277,0 317,8 354,1 432,3 490,3 539,1 580,8 611,3
MOP calc A 332,8 391,7 428,0 517,6 600,0 648,7 690,4 696,5
Recom FUSE A 300 350 400 500 600 600 600 600
MODELS WITH HIGH PUMP
LRA A 550,5 738,8 775,1 939,2 991,5 1009,8 1089,3 1125,9
MCA A 280,2 326,2 362,5 440,7 499,1 547,9 597,0 627,5
MOP A 336,0 400,1 436,4 526,0 608,8 657,5 706,6 712,7
Recom FUSE A 300 400 400 500 600 600 700 700
Alimentation 460/3/60Hz
MODELS WITHOUT PUMP
LRA A 276,5 326,7 335,9 432,6 483,1 508,3 525,1 516,4
MCA A 130,4 139,8 149,0 213,0 241,2 266,4 283,2 296,8
MOP A 156,7 170,2 179,5 254,9 295,7 320,9 337,7 338,7
Recom FUSE A 150 150 175 250 250 300 300 300
MODELS WITH LOW PUMP
LRA A 281,5 331,7 340,9 437,6 489,7 514,9 534,3 525,6
MCA A 135,4 144,8 154,0 218,0 247,8 273,0 292,4 306,0
MOP A 161,7 175,2 184,5 259,9 302,3 327,5 346,9 347,9
Recom FUSE A 150 175 175 250 300 300 300 300
MODELS WITH HIGH PUMP
LRA A 283,1 335,9 345,1 441,8 494,1 519,3 542,4 533,7
MCA A 137,0 149,0 158,2 222,2 252,2 277,4 300,5 314,1
MOP A 163,3 179,4 188,7 264,1 306,7 331,9 355,0 356,0
Recom FUSE A 150 175 175 250 300 300 350 350
Alimentation 575/3/60Hz
MODELS WITHOUT PUMP
LRA A 276,9 327,1 336,3 433,4 483,9 509,1 525,9 517,2
MCA A 130,8 140,2 149,4 213,8 242,0 267,2 284,0 297,6
MOP A 157,1 170,6 179,9 255,7 296,5 321,7 338,5 339,5
Recom FUSE A 150 150 175 250 250 300 300 300
MODELS WITH LOW PUMP
LRA A 281,9 332,1 341,3 438,4 490,5 515,7 535,1 526,4
MCA A 135,8 145,2 154,4 218,8 248,6 273,8 293,2 306,8
MOP A 162,1 175,6 184,9 260,7 303,1 328,3 347,7 348,7
Recom FUSE A 150 175 175 250 300 300 300 300
MODELS WITH HIGH PUMP
LRA A 283,5 336,3 345,5 442,6 494,9 520,1 543,2 534,5
MCA A 137,4 149,4 158,6 223,0 253,0 278,2 301,3 314,9
MOP A 163,7 179,8 189,1 264,9 307,5 332,7 355,8 356,8
Recom FUSE A 150 175 175 250 300 300 350 350

18 Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
Models 800 900 1000 1250 1400 1500 1650 1800
ELECTRICAL DATA MODELS WITHOUT PUMP + "°" ON/OFF FAN
Alimentation 230V60Hz
MODELS WITHOUT PUMP
LRA HA 546,3 729,4 765,7 912,8 961,5 979,8 1046,7 1083,3
MCA HA 276,0 316,8 353,1 414,3 469,1 517,9 554,4 584,9
MOP HA 331,8 390,7 427,0 499,6 578,8 627,5 664,0 670,1
Recom FUSE HA 300 350 400 450 500 600 600 600
MODELS WITH LOW PUMP
LRA HA 556,3 739,4 775,7 922,8 974,7 993,0 1065,1 1101,7
MCA HA 286,0 326,8 363,1 424,3 482,3 531,1 572,8 603,3
MOP calc HA 341,8 400,7 437,0 509,6 592,0 640,7 682,4 688,5
Recom FUSE HA 300 400 400 500 500 600 600 600
MODELS WITH HIGH PUMP
LRA HA 559,5 747,8 784,1 931,2 983,5 1001,8 1081,3 1117,9
MCA HA 289,2 335,2 371,5 432,7 491,1 539,9 589,0 619,5
MOP HA 345,0 409,1 445,4 518,0 600,8 649,5 698,6 704,7
Recom FUSE HA 300 400 400 500 600 600 600 700
Alimentation 460/3/60Hz
MODELS WITHOUT PUMP
LRA HA 284,1 334,3 343,5 432,6 483,1 508,3 525,1 516,4
MCA HA 138,0 147,4 156,6 213,0 241,2 266,4 283,2 296,8
MOP HA 164,3 177,8 187,1 254,9 295,7 320,9 337,7 338,7
Recom FUSE HA 150 175 175 250 250 300 300 300
MODELS WITH LOW PUMP
LRA HA 289,1 339,3 348,5 437,6 489,7 514,9 534,3 525,6
MCA HA 143,0 152,4 161,6 218,0 247,8 273,0 292,4 306,0
MOP HA 169,3 182,8 192,1 259,9 302,3 327,5 346,9 347,9
Recom FUSE HA 150 175 175 250 300 300 300 300
MODELS WITH HIGH PUMP
LRA HA 290,7 343,5 352,7 441,8 494,1 519,3 542,4 533,7
MCA HA 144,6 156,6 165,8 222,2 252,2 277,4 300,5 314,1
MOP HA 170,9 187,0 196,3 264,1 306,7 331,9 355,0 356,0
Recom FUSE HA 150 175 175 250 300 300 350 350
Alimentation 575/3/60Hz
MODELS WITHOUT PUMP
LRA HA 225,9 274,8 277,3 372,3 387,9 417,1 422,6 441,8
MCA HA 123,5 125,5 128,0 177,7 210,6 239,8 245,3 247,2
MOP HA 147,2 150,2 152,7 212,5 260,0 289,2 294,7 282,0
Recom FUSE HA 125 150 150 200 250 250 250 250
MODELS WITH LOW PUMP
LRA HA 229,9 278,8 281,3 376,3 393,2 422,4 430,0 449,1
MCA HA 127,5 129,5 132,0 181,7 215,9 245,1 252,7 254,6
MOP HA 151,2 154,2 156,7 216,5 265,2 294,5 302,1 289,3
Recom FUSE HA 150 150 150 200 250 250 300 250
MODELS WITH HIGH PUMP
LRA HA 231,2 282,1 284,6 379,7 396,7 425,9 436,5 455,6
MCA HA 128,8 132,9 135,4 185,1 219,4 248,6 259,2 261,0
MOP HA 152,5 157,5 160,0 219,8 268,8 298,0 308,5 295,8
Recom FUSE HA 150 150 150 200 250 250 300 250
Models 800 900 1000 1250 1400 1500 1650 1800
ELECTRICAL DATA MODELS WITHOUT PUMP + "I" EC INVERTER FAN
Alimentation 208V60Hz
MODELS WITHOUT PUMP
LRA HA 552,3 735,4 771,7 920,8 969,5 987,8 1054,7 1091,3
MCA HA 282,0 322,8 359,1 422,3 477,1 525,9 562,4 592,9
MOP HA 337,8 396,7 433,0 507,6 586,8 635,5 672,0 678,1
Recom FUSE HA 300 350 400 500 500 600 600 600
MODELS WITH LOW PUMP
LRA HA 562,3 745,4 781,7 930,8 982,7 1001,0 1073,1 1109,7
MCA HA 292,0 332,8 369,1 432,3 490,3 539,1 580,8 611,3
MOP calc HA 347,8 406,7 443,0 517,6 600,0 648,7 690,4 696,5
Recom FUSE HA 300 400 400 500 600 600 600 600
MODELS WITH HIGH PUMP
LRA HA 565,5 753,8 790,1 939,2 991,5 1009,8 1089,3 1125,9
MCA HA 295,2 341,2 377,5 440,7 499,1 547,9 597,0 627,5
MOP HA 351,0 415,1 451,4 526,0 608,8 657,5 706,6 712,7
Recom FUSE HA 350 400 450 500 600 600 700 700
Alimentation 230V60Hz
MODELS WITHOUT PUMP
LRA HA 552,3 735,4 771,7 920,8 969,5 987,8 1054,7 1091,3
MCA HA 282,0 322,8 359,1 422,3 477,1 525,9 562,4 592,9
MOP HA 337,8 396,7 433,0 507,6 586,8 635,5 672,0 678,1
Recom FUSE HA 300 350 400 500 500 600 600 600
MODELS WITH LOW PUMP
LRA HA 562,3 745,4 781,7 930,8 982,7 1001,0 1073,1 1109,7
MCA HA 292,0 332,8 369,1 432,3 490,3 539,1 580,8 611,3
MOP calc HA 347,8 406,7 443,0 517,6 600,0 648,7 690,4 696,5
Recom FUSE HA 300 400 400 500 600 600 600 600
MODELS WITH HIGH PUMP
LRA HA 565,5 753,8 790,1 939,2 991,5 1009,8 1089,3 1125,9
MCA HA 295,2 341,2 377,5 440,7 499,1 547,9 597,0 627,5
MOP HA 351,0 415,1 451,4 526,0 608,8 657,5 706,6 712,7
Recom FUSE HA 350 400 450 500 600 600 600 600
Alimentation 460/3/60Hz
MODELS WITHOUT PUMP
LRA HA 284,7 334,9 344,1 433,4 483,9 509,1 525,9 517,2
MCA HA 138,6 148,0 157,2 213,8 242,0 267,2 284,0 297,6
MOP HA 164,9 178,4 187,7 255,7 296,5 321,7 338,5 339,5
Recom FUSE HA 150 175 175 250 250 300 300 300
MODELS WITH LOW PUMP
LRA HA 289,7 339,9 349,1 438,4 490,5 515,7 535,1 526,4
MCA HA 143,6 153,0 162,2 218,8 248,6 273,8 293,2 306,8
MOP HA 169,9 183,4 192,7 260,7 303,1 328,3 347,7 348,7
Recom FUSE HA 150 175 175 250 300 300 300 300
MODELS WITH HIGH PUMP
LRA HA 291,3 344,1 353,3 442,6 494,9 520,1 543,2 534,5
MCA HA 145,2 157,2 166,4 223,0 253,0 278,2 301,3 314,9
MOP HA 171,5 187,6 196,9 264,9 307,5 332,7 355,8 356,8
Recom FUSE HA 150 175 175 250 300 300 350 350
Alimentation 575/3/60Hz
MODELS WITHOUT PUMP
LRA HA 224,7 273,6 276,1 370,7 386,3 415,5 421,0 440,2
MCA HA 122,3 124,3 126,8 176,1 209,0 238,2 243,7 245,6
MOP HA 146,0 149,0 151,5 210,9 258,4 287,6 293,1 280,4
Recom FUSE HA 125 125 150 200 250 250 250 250
MODELS WITH LOW PUMP
LRA HA 228,7 277,6 280,1 374,7 391,6 420,8 428,4 447,5
MCA HA 126,3 128,3 130,8 180,1 214,3 243,5 251,1 253,0
MOP HA 150,0 153,0 155,5 214,9 263,6 292,9 300,5 287,7
Recom FUSE HA 150 150 150 200 250 250 300 250
MODELS WITH HIGH PUMP
LRA HA 230,0 280,9 283,4 378,1 395,1 424,3 434,9 454,0
MCA HA 127,6 131,7 134,2 183,5 217,8 247,0 257,6 259,4
MOP HA 151,3 156,3 158,8 218,2 267,2 296,4 306,9 294,2
Recom FUSE HA 150 150 150 200 250 250 300 250

19Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
11. OPERATIONG LIMITS
Note:
1 In summer mode the unit can be started
with external air 46°C/114.8°F and water inlet
35°C/95°F. In winter mode the unit can be
started with external air -15°C/5°F and water
inlet 10°C/50°F




way valve that allows bypassing water from the



11.1. OPERATIONG LIMITS IN COOLING MODE GRAPH ¹
11.2. OPERATIONG LIMITS IN HOT MODE GRAPH ¹
11.3. PROJECT DATA ATTENTION
Contact our technical sales depart-
ment if the unit needs to operated
outside the operating limits
ATTENTION
If the unit is installed in particu-
larly windy areas, we recommend
providing for windbreak to avoid
malfunctioning.
The units, in standard configuration, are not suitable
for installation in salty environments. For functioning li-
mits, please refer to the diagrams below, valid for AHRI
standard conditions.
Wind breaks should be implemented if the unit is
installed in particularly windy areas, to prevent a
malfunction of the unit.
REFRIGERANT SIDE High pressure
side
Low pressure
side
Acceptable maximum pressure bar/PSI 45/653 30/435
Acceptable maximum temperature °C / °F 120 / 248 51 / 131
Acceptable minimum temperature °C / °F -30 /- 22 -30 / -22
WATER SIDE
Acceptable maximum pressure bar/PSI 6/87
Hydarulic circuit safety valve
(only in version with storage tank or with pump)
Calibrated at 6/87 bar/PSI and with piped discharge, which intervents
by discharging overpressure if abnormal work pressure occur.
External air temperature b.s.
Temperature of the water
produced CONDENSER
External air temperature b.s.
Temperature of the water produced EVAPORATOR
5
14
23
32
41
50
59
68
77
86
95
104
113 114,8 °F
46 °C
36 °C
96,8 °F
122
-15
-10
-5
0
5
10
15
20
25
30
35
40
45
50
°C
°C
°F
°F
-6 -7 -8 -5 -4 -3 -2 -1
0 1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20
17,6 19,4 21,2 23,0 24,8 26,6 28,4 30,2 32,0 33,8 35,6 37,4 39,2 41,0 42,8 44,6 46,4 48,2 50,0 51,8 53,6 55,4 57,2 59,0 60,8 62,6 64,4 66,2 68,0
 


STANDARD
functioning
Functioning only with "I" funs
Functioning with
glycoled water
Functioning only with "I"
funs +
water glycoled
25
20
15
30
35
40
45
50
55
60
-10-15-20 -5 0 5 10 15 20 25 30 35 40 45 50
°C
°C
°F
°F
145-4 23 32 41 50 59
59
68
68
77
77
86
86
95
95
104
104
113
113
122
122
131
140
42 °C
107,6 °F
-15 °C
5 °F
55 °C 131 °F
STANDARD
functioning
Functioning
only with "I"
funs

20 Aermec cod. 14_09.4086981_04
NRL 800-1800 60Hz
EN
Outside air temperature b.s. b.s. °C/ °F Outside air temperature b.s. °C/ °F
CORRECTION COEFFICIENTS (Ca) CORRECTION COEFFICIENTS (Cf)
0,6
0,7
0,8
0,9
1
1,1
1,2
1,3
1,4
-4-6 -2 0 2 4 6 6.7 8 10 12 14 16
18
40°C / 104°F
45°C / 113 °F
46°C / 114.8 °F
35°C / 95°F
30°C /
86°F
25°C / 77°F
20°C / 68°F
39.2
21.2
28.4 0 35.6 39.2 42.8 44.1 46.4 50 53.6 57.2 60.8 64.4
°C
°F
0,4
0,5
0,6
0,7
0,8
0,9
1
1,1
1,2
1,3
1,4
1,5
1,6
-6 -4 -2 0 2 4 6 6.7 8 10 12 14 16 18
39.2
21.2
28.4 0 35.6 39.2 42.8 46.444.1 50 53.6 57.2 60.8 64.4
°C
20°C / 68°F
25°C / 77°F
30°C / 86°F
35°C / 95°F
40°C 104°F
45°C 113 °F
46°C 114.8 °F
°F
INPUT POWER IN COOLING MODE CORRECTIVE COEFFICIENTS
COOLING CAPACITY CORRECTIVE COEFFICIENTS
12. CORRECTIVE FACTORS
12.1. INPUT POWER AND COOLING CAPA
CITY "STANDARD VERSION"/ "HEAT
PUMP VERSION IN COOLING MODE"
The cooling capacity efficiency and electrical input
power in conditions differing from normal conditions
are obtained by multiplying the nominal values (Pf, Pa)
by the respective corrective co-efficients (Cf, Ca).
The following diagrams show how to obtain corrective
coefficients to use for units in their various versions
in cooling mode; external air temperature, to which
reference is made, is shown in correspondence to each
curve.
KEY:
Cf: Corrective coefficient of the
cooling capacity.
Ca: Corrective coefficient of the
input power.

FROM 10.01°F / 5.56°C.

use Tab. 10.3.1. to obtain the correction factors of the
cooling capacity and input power. In order to consider
exchanger dirtying, use the relative dirtying factors
Tab.10.4.1.
