Aero-motive AN-10 User manual

AEROMOTIVE
Part # 12606
AN-10 100 micron Fuel Cell Filter Element
INSTALLATION INSTRUCTIONS
This product is not legal for sale or use on emission-controlled vehicles except when used as a direct
replacement part matching OEM specification.
WARNING!
Always be aware of flammable situations. Drilling and grinding can be
potential ignition sources. Extinguish all open flames, prohibit smoking and
eliminate all sources of ignition in the area of the vehicle and workspace before
proceeding with the installation. Ensure you are working in a well ventilated area
with an approved fire extinguisher nearby.
WARNING!
Installation of this product requires modification to a fuel tank/ the fuel
system, failure to satisfy all safety considerations will result in fire, explosion,
injury and/or loss of life to yourself and/or others. All fuel system components
MUST be located as far from heat sources as possible, like exhaust, engine block,
etc.
WARNING!
Mechanical and hydraulic lifting devices can tip over or lower accidentally
due to incorrect maneuvering or technical errors. A falling object can cause
injury and/or loss of life to yourself and/or others. When working under the
vehicle, always use stands, and ensure that the ground or floor is stable and
level. Never crawl under a vehicle which is only supported by a jack.
WARNING!
The fuel system is under pressure. Do not open the fuel system until the
pressure has been relieved. Refer to the appropriate vehicle service manual for
the procedure and precautions for relieving the fuel system pressure.
CAUTION!
When installing this product always wear safety glasses and other
appropriate safety appeal. A drilling operation will cause flying metal chips. Flying
metal chips can cause eye injury.
CAUTION:
Installation of this product requires detailed knowledge of automotive systems
and repair procedures. We recommend that this installation be carried out by a
qualified automotive technician. Careless installation of this product can result in
damage to the product, injury or loss of life to yourself and/or others.

Compatible Fuels:
Pump Gas
Race Gas
E85
Alcohol/Ethanol
Parts Included:
1ea AN-10 100 micron Fuel Filter Element
1ea Sealing washer
1ea AN-10 O-Ring
Aeromotive system components are not legal for sale or use on emission controlled motor vehicles.
The following steps are typical of most installations:
1. Once the engine has been allowed to cool, disconnect the negative battery cable and relieve the fuel system
pressure, referring to the appropriate vehicle service manual for the procedure and precautions for doing so.
2. The Aeromotive fuel filter is designed to mount utilizing either a crush washer or O-ring seal as shown below.
3. Once you have decided what best suites your application, ensure that the fuel tank / cell is completely drained of
fuel and any internal foam is removed.
Warning: Installation of this product requires working inside a fuel cell / tank, failure to
satisfy all safety considerations will result in fire, explosion, injury and/or loss of life to
yourself and/or others.
CAUTION: Remove any spilled fuel from the area before proceeding proceeding!
4. For AN-10 crush washer applications; Remove the nut on the bulkhead fitting if applicable, replace the crush
washer where needed, install the filter element on the fitting and tighten.
5. For AN-10 O-ring sealed applications; Install the supplied O-ring on the AN-10 fitting using some light oil to ease the
installation, install the filter element on the fitting and tighten.
6. Replace any foam that was removed from the fuel cell, it may be necessary to notch the foam around the installed
fuel filter.

7. Refill the fuel cell, if any leaks are detected, immediately remove any spilled fuel and repair the leak(s) before
proceeding.

Contact US
RGA NUMBER REQUIRED FOR ALL RETURNS TO AEROMOTIVE.
To obtain an RGA number, please call (913) 647–7300 and ask for the Returns and Repairs department.
•Shipping Address
Aeromotive Inc.
7805 Barton St.
Lenexa, KS 66214
•Sales & Returns
Aeromotive Inc.
11414 W 79th Street.
Lenexa, KS 66214
General Inquiries and Tech Line: [phone]
General Email: [e-mail]
Tech Email: [e-mail]
The Aeromotive Tech Lines are open Monday through Friday from 9:30AM to 5:00PM Central Standard Time.

WARNING: This product can expose you to chemicals,
including chromium, which is known to the State of California
to cause cancer or birth defects or other reproductive harm.
For more information, visit: www.p65Warnings.ca.gov
Aeromotive, Inc. 7805 Barton Street, Lenexa, KS 66214 Phone: [phone] Fax: [phone]
AEROMOTIVE, INC. LIMITED WARRANTY
This Aeromotive Product, with proof of purchase dated on or after January 1, 2003, is warranted to
be free from defects in materials and workmanship for a period of one year from the original date of
purchase. No warranty claim will be valid without authentic, dated proof of purchase.
This warranty is to the original retail purchaser and none other and is available directly from
Aeromotive and not through any point of distribution or purchase.
If a defect is suspected, the retail purchaser must contact Aeromotive directly to discuss the problem,
possible solutions and obtain a Return Goods Authorization (RGA), if deemed necessary by the
company. Please call 913-647-7300 and dial option 3 for the technical service dept. All returns must
be shipped freight pre-paid to the company and with valid RGA before they will be processed.
Aeromotive will examine any product returned with the proper authorization to determine if the failure
resulted from a defect or from abuse, improper installation, misapplication or alteration. Aeromotive
will then, at it’s sole discretion, return, repair or replace the product.
If any Aeromotive product is determined defective, buyer’s exclusive remedy is limited in value to the
sale price of the good. In no event shall Aeromotive be liable for incidental or consequential
damages.
Aeromotive expressly retains the right to make changes and improvements in any product it
manufactures and sells at any time. These changes and improvements may be made without notice
at any time and without any obligation to change the catalogs or printed materials.
Aeromotive expressly retains the right to discontinue at any time and without notice any Aeromotive
product that it manufactures or sells.
This warranty is limited and expressly limits any implied warranty to one year from the date of the
original retail purchase on all Aeromotive products.
No person, party or corporate entity other than Aeromotive shall have the right to: determine whether
or not this Limited Warranty is applicable to any Aeromotive product, authorize any action
whatsoever under the terms and conditions of this Limited Warranty, assume any obligation or
liability of any nature whatsoever on behalf of Aeromotive under the terms and conditions of this
Limited Warranty.
This Limited Warranty covers only the product itself and not the cost of installation or removal.
This Limited Warranty is in lieu of and expressly excludes any and all other warranties, expressed or
implied. This Limited Warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
