Aerospool WT9 Dynamic LSA / Club User manual

AIRCRAFT MAINTENANCE
MANUAL
Document Number:
AS-AMM-10-000
Date of Issue:
10. 10. 2018
Aircraft Models:
WT9 Dynamic LSA / Club
WT9 Dynamic LSA / Speed
THE AIRPLANE HAS TO BE MAINTAINED IN COMPLIANCE WITH INFORMATION AND
LIMITATIONS CONTAINED HEREIN.

This page is left blank intentionally

CONTENTS Chapter 01
04. 05. 2021 Effectivity: ALL Page 01-1
INTRODUCTION
01 INTRODUCTION
CONTENTS
Section Description Page
01-00 GENERAL......................................................................... 3
01-10 AIRCRAFT CLASSIFICATION ......................................... 5
01-20 MANUFACTURERS.......................................................... 7
1. AIRCRAFT MANUFACTURER..................................................7
2. ENGINE MANUFACTURER ......................................................7
3. PROPELLER MANUFACTURER ..............................................7
A. EVRA PerformanceLine 175/xxx/805.5 .............................7
B. SR 2000D, SR 3000/3, SR 2000DN, SR 3000/3N,
SR 3000/2, SR 3000/2N....................................................7
01-30 MANUAL DESCRIPTION.................................................. 9
1. GENERAL..................................................................................9
2. ARRANGEMENT OF CHAPTERS ............................................9
A. Numbering of chapters ......................................................9
B. Numbering of pages, figures and tables..........................10
3. WARNINGS, CAUTIONS, AND NOTES..................................11
4. GENERAL SAFETY INFORMATION.......................................11
5. ABBREVIATIONS....................................................................13
6. MANUAL IMPROVEMENT REQUEST FORM ........................15
7. SAFETY OF FLIGHT AND SERVICE DIFFICULTY
REPORT FORM ......................................................................16
01-40 LIST OF CHAPTERS ...................................................... 17
01-50 LIST OF EFFECTIVE PAGES......................................... 19

Chapter 01 CONTENTS
Page 01-2 Effectivity: ALL 04. 05. 2021
INTRODUCTION
01-60 REVISIONS .....................................................................49
1. MANUAL REVISIONS............................................................. 49
A. Procedure: ...................................................................... 49
2. MARKED OF REVISIONS ...................................................... 49
3. LOG OF TEMPORARY REVISIONS....................................... 50
4. LOG OF REVISIONS .............................................................. 52

GENERAL Chapter 01-00
04. 05. 2021 Effectivity: ALL Page 01-3
INTRODUCTION
01-00 GENERAL
The purpose of this manual is to provide guidance to owners, mechanics, airports,
regulatory officials, and aircraft and component manufacturers who may accomplish
maintenance, repairs, and alterations on a light sport aircraft. In addition, this practice
covers the format and content of maintenance manuals and instructions
for the maintenance, repair, and alteration of an LSA.
The instructions are given in the following manuals issued by the aircraft manufacturer and
original equipment manufacturers:
•Pilot´s Operating Handbook
•Aircraft Maintenance Manual (Doc. No. AS-AMM-10-000)
•Operators Manual for Rotax Engine Type 912 Series (Ref. No. OM-912)
•Maintenance Manual (Line Maintenance) for Rotax Engine Type 912 Series
(Ref. No. MML-912)
•Maintenance Manual (Heavy Maintenance) for Rotax Engine Types 912 and 914
Series (Ref. No. MMH-912 / MMH-914)
•Installation Manual for Rotax Engine Type 912 Series (Ref. No. IM-912)
•Operator´s Manual Electrical adjustable aircraft propeller SR 2000D (Date of issue:
23.02.2004, Rev. H or later revisions)
•Operator´s Manual Electrical adjustable aircraft propeller SR 2000DN (Date of issue:
31.01.2013, Rev. B or later revisions)
•Operator´s Manual Electrical adjustable aircraft propeller SR 3000/3 and SR 3000/2
(Date of issue: 14.03.2006, Rev. H or later revisions)
•Operator´s Manual Electrical adjustable aircraft propeller SR 3000/3N
and SR 3000/2N (Date of issue: 31.01.2013, Rev. C or later revisions)
•Manual for Mounting and Use of Rescue Ballistic Parachute Systems Series
Magnum (Edition 02-2014/04 or later revisions)
•Maintenance manuals of the installed equipment issued by the original equipment
manufacturers.
The electrical equipment is connected according to OEM wiring instructions.

Chapter 01-00 GENERAL
Page 01-4 Effectivity: ALL 04. 05. 2021
INTRODUCTION
This page is left blank intentionally

AIRCRAFT CLASSIFICATION Chapter 01-10
04. 05. 2021 Effectivity: ALL Page 01-5
INTRODUCTION
01-10 AIRCRAFT CLASSIFICATION
The aircraft WT9 Dynamic LSA is a single engine, two seats (arranged side by side),
cantilever low wing aircraft with a cruciform tail. The primary structures consist
of glass and carbon composite. The aircraft is equipped with tricycle undercarriage (fixed
or retractable) with steerable nose wheel.
The aircraft is powered by a 4 cylinder, horizontally opposed, air and water cooled,
carburettor 4-stroke engine Rotax 912 ULS / ULSFR with maximum power 73.5 kW
(100 hp) at 5800 rpm or engine Rotax 914 UL with maximum power 84.5 kW
(115 hp) at 5800 rpm.
The aircraft may be fitted with propeller EVRA PerformanceLine 175/xxx/805.5.
It is 3-bladed ground adjustable propeller with diameter 1.750 m. It has wooden core
blades covered by glass fabric with stiffened leading edges. Blades are mounted
in an aluminium hub. The propeller hub is attached to a flange and base plate and fixed
to the engine's propeller flange. Composite spinner is fixed to the base plate.
The aircraft may be fitted with propellers SR 2000D, SR 3000/3, SR 2000DN
or SR 3000/3N that are 3-blade electrically operated in-flight adjustable aircraft propellers
with diameter 1.726 m. The aircraft may be fitted with propellers SR 3000/2N with diameter
1.730 m or SR 3000/2 with diameter 1.700 m that are 2-blade electrically operated in-flight
adjustable aircraft propellers. The blades are made of combination of lash wood
and composite. The propeller can be operated in either manual or with automatic mode
as a constant speed propeller. The outer section of leading edges is protected by wear
resistant cast polyurethane or stainless steel.
The aircraft is approved for VFR day operation only.

Chapter 01-10 AIRCRAFT CLASSIFICATION
Page 01-6 Effectivity: ALL 04. 05. 2021
INTRODUCTION
This page is left blank intentionally

MANUFACTURERS Chapter 01-20
04. 05. 2021 Effectivity: ALL Page 01-7
INTRODUCTION
01-20 MANUFACTURERS
1. AIRCRAFT MANUFACTURER
Aerospool, spol. s r. o.
Letisková 10
971 03 Prievidza
Slovak republic
E-mail: [email protected]
Web: www.aerospool.sk
2. ENGINE MANUFACTURER
BRP-Powertrain GmbH&Co. KG.
Rotaxstrasse 1
A-4623 Gunskirchen
Austria
Web: www.flyrotax.com
3. PROPELLER MANUFACTURER
A. EVRA PerformanceLine 175/xxx/805.5
SARL Production EVRA
4 Avenue de la Forêt d'Halatte
F-60100 Creil
France
Web: www.helices-evra.com
B. SR 2000D, SR 3000/3, SR 2000DN, SR 3000/3N, SR 3000/2, SR 3000/2N
WOODCOMP
Vodolská 4
250 70 Odolena Voda
Czech Republic
Web: www.woodcomp.cz

Chapter 01-20 MANUFACTURERS
Page 01-8 Effectivity: ALL 04. 05. 2021
INTRODUCTION
This page is left blank intentionally

MANUAL DESCRIPTION Chapter 01-30
14. 05. 2020 Effectivity: ALL Page 01-9
INTRODUCTION
01-30 MANUAL DESCRIPTION
1. GENERAL
Aircraft Maintenance Manual is prepared in accordance with GAMA No. 2
Specification, which provides instructions for preparation and publication of manuals
for general aviation aircrafts. GAMA No. 2 Specification is compatible with ATA 100
Specification.
This Maintenance Manual does not reflect part numbers and cannot be used
for ordering replacement parts. For material purchase contact the airplane
manufacturer’s local representative or contact airplane manufacturer directly
at [email protected].
2. ARRANGEMENT OF CHAPTERS
Chapters in this manual are arranged and divided in accordance with GAMA No. 2
Specification.
Chapters are arranged in the following groups:
•INTRODUCTION (Chapter 01)
•AIRCRAFT (Chapters 04 to 12)
•AIRFRAME SYSTEMS (Chapters 20 to 39)
•AIRFRAME (Chapters 51 to 57)
•PROPELLER (Chapter 61)
•POWER PLANT (Chapters 71 to 79)
•SUPPLEMENTS (Chapter 95)
A. Numbering of chapters
Due of the relative simplicity of the aircraft and its system the numbering
of chapter has two levels.
Example:
27 –20
Sub-chapter
(Rudder)
Chapter
(Flight Controls)

Chapter 01-30 MANUAL DESCRIPTION
Page 01-10 Effectivity: ALL 14. 05. 2020
INTRODUCTION
B. Numbering of pages, figures and tables
(1) Numbering of pages:
Example:
Page 27 –11
(2) Numbering of figures:
Example:
Fig. 27 –1
(3) Numbering of tables:
Example:
Tab. 27 –1
NOTE
Numbers and names of figures and tables are written in italic.
Page No.
Chapter No.
Table No.
Chapter No.
Figure No.
Chapter No.

MANUAL DESCRIPTION Chapter 01-30
14. 05. 2020 Effectivity: ALL Page 01-11
INTRODUCTION
3. WARNINGS, CAUTIONS, AND NOTES
Warnings, cautions and notes are of the following meaning in this manual:
WARNING
AN OPERATING PROCEDURE, INSPECTION, REPAIR
OR MAINTENANCE PRACTICE, WHICH IF NOT CORRECTLY
FOLLOWED, COULD RESULT IN PERSONAL INJURY, OR LOSS
OF LIFE.
CAUTION
AN OPERATING PROCEDURE, INSPECTION, REPAIR
OR MAINTENANCE PRACTICE, WHICH IF NOT STRICTLY
OBSERVED, COULD RESULT IN DAMAGE OR DESTRUCTION
OF EQUIPMENT.
NOTE
An operating procedure, inspection, repair or maintenance condition, etc.,
which is deemed essential to highlight.
4. GENERAL SAFETY INFORMATION
The illustrations in this manual show the typical construction. They may not represent
in full detail, or the exact shape of, the parts which have the same or similar function.
Specifications are given in the SI metric system unless otherwise specified.
Before carrying out maintenance work on aircraft, read this Maintenance Manual
carefully.
If any passages of the manual are not clearly understood, or if you have questions,
please contact an authorized distributor or the manufacturer.
Aerospool company assumes no liability for any damage or injury caused
by misunderstanding of the content of the manual.
The manufacturer points out that all maintenance work must be carried out only
by qualified personnel to maintain the aircraft.
Aerospool company reserves the right at any time to terminate or change
specifications, designs, features or versions without obligation to notify.
For complete information refer to original manufacturer’s documentation, latest valid
revision.
Information contained in the original manufacturer’s documentation is mandatory,
unless stated otherwise.

Chapter 01-30 MANUAL DESCRIPTION
Page 01-12 Effectivity: ALL 14. 05. 2020
INTRODUCTION
When performing maintenance, the safety must be always considered. Always use
proper personal protective equipment, at least but not limited to:
•Wear protective gloves when handling with chemicals and sealants.
Do not use protective hand creams as they can contaminate the sealants
and surfaces.
•Wear goggles, safety glasses or face shield for eye protection.
•Do not wear loose clothing and secure long hair to prevent them
from becoming tangled in power tools.
•Wear ear plugs or muffs to protect your ears.
•Wear suitable protective shoes with non-slip soles.
Prior to performing maintenance or repair consider following general rules:
•Check that emergency parachute system actuator is locked.
•Check that MASTER SWITCH and IGNITION is set OFF.
•Disconnect the negative terminal from the battery.
•Remove all jewellery. It can conduct electricity and may cause a short
circuit or can be caught in rotating tools.
•When working with the fuel and fuel system, always work in a well-
ventilated place. Always ground the airframe during fueling/defueling
to avoid risk of fire due to static discharge. Do not manipulate with open
flame and keep all ignition sources away.
•When working with a landing gear, properly support the aircraft with jacks.
Do not work under aircraft unless it is properly supported.
•While the engine is running, keep away from the propeller.

MANUAL DESCRIPTION Chapter 01-30
14. 05. 2020 Effectivity: ALL Page 01-13
INTRODUCTION
5. ABBREVIATIONS
ADAHRS Air Data, Attitude and Heading Reference System
ADS-B Automatic Dependent Surveillance –broadcast
AOA Angle of Attack
AMM Aircraft Maintenance Manual
AR As Required
ATC Air Traffic Control
COMM Communication
CHT Cylinder Head Temperature
CRG Cable Retractor Winch with Guillotine
CS-LSA Certification Specifications for Light Sport Aeroplanes
EASA European Aviation Safety Agency
EFIS Electronic Flight Instrument System
EGT Exhaust Gas Temperature
ELT Emergency Locator Transmitter
EMS Engine Monitoring System
EPS Emergency Parachute System
FWD Forward
FG Fixed Gear
GPS Global Positioning System
IPC Illustrated Parts Catalogue
ISA International Standard Atmosphere
LH Left Hand
LVW Low Value Warning
MAC Mean Aerodynamic Chord
MAP Manifold Pressure
MEMS Microelectromechanical System
MMH Maintenance Manual Heavy
MML Maintenance Manual Line
MKR Marker
MSL Mean Sea Level
MTOW Maximum Take-off Weight
NAV Navigation
OAT Outside Air Temperature
OEM Original Equipment Manual
OM Operators Manual
PFD Primary Flight Display
RG Retractable Gear
RH Right Hand
SV SkyView
TBO Time Between Overhaul
TCAS Traffic Collision Avoidance System

Chapter 01-30 MANUAL DESCRIPTION
Page 01-14 Effectivity: ALL 14. 05. 2020
INTRODUCTION
TIS Traffic Information System
VAT Value Added Tax
VFR Visual Flight Rules
VOR VHF Omnidirectional range
XPDR Transponder

MANUAL DESCRIPTION Chapter 01-30
14. 05. 2020 Effectivity: ALL Page 01-15
INTRODUCTION
6. MANUAL IMPROVEMENT REQUEST FORM
Aerospool spol. s r. o.
Letisková 10
973 01 Prievidza
Slovak republic
[e-mail]
www.aerospool.sk
MANUAL IMPROVEMENT
REQUEST
Aerospool reference No.:
Date:
Dear owner / operator / maintainer:
In the case of suggestions for improvement to the content of the manual, or if errors or omissions
were found, please submit the proposed changes by means of MANUAL IMPROVEMENT
REQUEST form. Fill the form and sent it to the above stated address via post or email.
Your contact information:
Name:
Telephone:
Email:
Manual information:
Document number:
Revision:
Document name:
Data location in the manual (chapter number, page number, figure, table):
Description of change request (attach more sheets if necessary):
Reason of change request:

Chapter 01-30 MANUAL DESCRIPTION
Page 01-16 Effectivity: ALL 14. 05. 2020
INTRODUCTION
7. SAFETY OF FLIGHT AND SERVICE DIFFICULTY REPORT FORM
Aerospool spol. s r. o.
Letisková 10
973 01 Prievidza
Slovak republic
[e-mail]
www.aerospool.sk
SAFETY OF FLIGHT AND
SERVICE DIFFICULTY REPORT
Aerospool reference No.:
Date:
Dear owner / operator / maintainer:
For continued increasing reliability of aircrafts, we would like to ask you for your assistance
in the case of safety of flight or service difficulty. Fill the feedback form and sent it to the above
stated address via post or email.
Type of report:
□SAFETY OF FLIGHT ISSUE □SERVICE DIFFICULTY
Name:
Contact information (telephone, email, address):
Date of detection:
Aircraft type / model:
S/N:
Engine:
S/N:
Propeller:
S/N:
Flight hours:
Engine operation hours:
Safety of flight / service difficulty description (attach more sheets if necessary):

LIST OF CHAPTERS Chapter 01-40
14. 05. 2020 Effectivity: ALL Page 01-17
INTRODUCTION
01-40 LIST OF CHAPTERS
INTRODUCTION
01 INTRODUCTION
AIRCRAFT
04 AIRWORTHINESS LIMITATIONS
05 PERIODIC INSPECTIONS
06 DIMENSIONS AND AREAS
07 LIFTING AND SHORING
08 LEVELING AND WEIGHING
09 TOWING AND TAXIING
10 PARKING, MOORING
11 PLACARDS AND MARKINGS
12 SERVICING
AIRFRAME SYSTEMS
20 STANDARD PRACTICES - AIRFRAME
21 AIR CONDITIONING
23 COMMUNICATIONS
24 ELECTRICAL POWER
25 EQUIPMENT / FURNISHING
27 FLIGHT CONTROLS
28 FUEL
31 INDICATING / RECORDING SYSTEMS
32 LANDING GEAR
33 LIGHTS
34 NAVIGATION
39 INSTRUMENT AND CONTROL PANELS
AIRFRAME
51 STANDARD PRACTICES AND STRUCTURES - GENERAL
52 DOORS
53 FUSELAGE
55 STABILIZERS
56 WINDOWS
57 WINGS

Chapter 01-40 LIST OF CHAPTERS
Page 01-18 Effectivity: ALL 14. 05. 2020
INTRODUCTION
PROPELLER
61 PROPELLER
POWER PLANT
71 POWER PLANT - GENERAL
73 ENGINE - FUEL SYSTEMS
74 IGNITION
75 ENGINE COOLING
76 ENGINE CONTROLS
77 ENGINE INDICATING
78 EXHAUST
79 OIL
SUPPLEMENTS
95 OPTIONAL EQUIPMENT
