Swimming Pool Heat Pump
Proteam i-Series Inverter Installation
and Operation Manual
Automated Environmental Systems Ltd.
Unit 1, 1 Wimbledon Road, Brandon, IP27 0ND
01842 819130 | [email protected]

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Contents
1. Models .................................................................................................2
2.Product appearance............................................................................2
3. Specifications......................................................................................3
4. Dimensions........................................................................................15
5. Wiring diagram..................................................................................17
6. Operation range ................................................................................19
7. Refrigerant system diagram.............................................................19
8. Accessories.......................................................................................20
9. Installation.........................................................................................20
10. Controller.........................................................................................27
11. Unit Functions.................................................................................32
12. Maintenance....................................................................................34
13. Trouble-shooting.............................................................................35
14. Wifi function.......................................................................................40
Appendix ...............................................................................................53
1

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
1. Models
Heating capacity Cooling capacity Model Power supply
1.60kW - 5.30kW 1.50kW - 2.80kW i5 230V~,1Ph,50Hz
1.60kW - 7.20kW 1.70kW - 3.60kW i7 230V~,1Ph,50Hz
1.90kW - 9.20kW 1.80kW - 4.60kW i9 230V~,1Ph,50Hz
2.70kW - 10.90kW 2.40kW - 6.00kW i11 230V~,1Ph,50Hz
3.40kW - 14.30kW 3.20kW - 7.87kW i14 230V~,1Ph,50Hz
4.30kW - 17.40kW 3.90kW - 9.60kW i17 230V~,1Ph,50Hz
4.80kW - 21.20kW 4.30kW - 11.50kW i21 230V~,1Ph,50Hz
6.20kW - 25.10kW 5.80kW - 13.90kW i25 230V~,1Ph,50Hz
6.60kW - 29.00kW 6.20kW - 16.00kW i29 230V~,1Ph,50Hz
7.70kW - 31.70kW 7.20kW - 17.50kW i32 230V~,1Ph,50Hz
Notes:
Heating and cooling capacity based on the below conditions.
Heating: Outdoor ambient temperature = 26ºC and RH70%; inlet/outlet water temperature = 26ºC/28ºC.
Cooling: Outdoor ambient temperature = 35ºC; inlet/outlet water temperature = 28ºC/26ºC.
2. Product appearance
Model Unit dimension Packing dimension Net / gross weight
i5 860×330×668 950×410×800 35 / 42
i7 860×330×668 950×410×800 38 / 45
i9 860×330×668 950×410×800 40 / 48
i11 986×356×668 1,080×435×800 44 / 54
i14 986×356×668 1,080×435×800 46 / 56
i17 986×356×668 1,080×435×800 56 / 66
i21 1,076×426×720 1,161×490×855 67 / 80
i25 1,076×426×720 1,161×490×855 72 / 85
i29 1,176×451×822 1,261×515×957 90 / 108
i32 1,176×451×822 1,261×515×957 98 116
2

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
3. Specifications
Model i5 i7
Power supply 230V~, 1Ph, 50Hz 230V~, 1Ph, 50Hz
Air temperature: 15ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 1.10 - 3.80 1.30 - 5.10
Power input kW 0.14 - 0.75 0.17 - 1.06
COP 5.10 - 7.90 4.80 - 7.80
Boost mode Heating capacity kW 3.80 5.10
COP 5.10 4.80
Smart mode Heating capacity kW 3.04 4.08
COP 5.91 5.90
Silent mode Heating capacity kW 2.01 2.55
COP 6.82 6.75
Air temperature: 26ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 1.60 - 5.30 1.60 - 7.20
Power input kW 0.13 - 0.88 0.13 - 1.19
COP 6.25 - 14.50 6.22 - 14.55
Boost mode Heating capacity kW 5.30 7.20
COP 6.31 6.26
Smart mode Heating capacity kW 4.40 5.92
COP 7.70 7.65
Silent mode Heating capacity kW 2.80 3.70
COP 10.50 10.42
Air temperature: 35ºC, inlet/outlet water temperature: 28ºC/26ºC
Cooling capacity kW 1.50 - 2.80 1.70 - 3.60
Power input kW 0.20 - 0.62 0.22 - 0.80
EER 4.51 - 7.55 4.48 - 7.53
Boost mode Heating capacity kW 2.80 3.60
EER 4.51 4.48
Smart mode Heating capacity kW 2.24 2.88
EER 5.62 5.60
Silent mode Heating capacity kW 1.70 2.16
EER 6.95 6.92
Max. input kW 1.23 1.50
Max. current A 5.35 6.53
Water flow m3/h 2 - 3 3 - 4
Water pressure drop kPa 16 16
Running temperature range -15ºC - 43ºC -15ºC - 43ºC
Advised swimming pool size 10m
3
- 20m
3
15m
3
- 30m
3
Refrigerant system pressure (Max. / Min.) 1.5MPa / 4.15MPa 1.5MPa / 4.15MPa
3

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Continued:
Model i5 i7
Refrigerant Type R32 R32
Charged kg 0.5 0.7
GWP value 675 675
Equivalent CO2Ton 0.3375 0.4725
Compressor
Brand GMCC GMCC
Model KSK103D53UFZ KSK103D53UFZ
Type DC inverter, rotary DC inverter, rotary
Quantity 1 1
Capacity kW 3.220 (@60rps) 3.220 (@60rps)
Input kW 0.839 (@60rps) 0.839 (@60rps)
Current A 5.70 (@60rps) 5.70 (@60rps)
Oil type / charged Estel oil VG74 / 320ml Estel oil VG74 / 320ml
Air side
heat-exchanger
Material Hydrophilic aluminum & Inner groove copper tube
Rows 1 1
Tube size mm Φ7 Φ9.52
Fan motor
Fan type Axial Axial
Fan size mm Φ429×119 Φ429×119
Motor type BLDC BLDC
Motor model RD34HA RD34HA
Motor Brand LT LT
Quantity 1 1
Speed rpm 1,000 1,000
Throttling type Electronic Expansion valve
Water side heat-exchanger Titanium heat-exchanger with PVC casing
Sound pressure
level
@1m dB(A) 35.3 - 43.1 37.7 - 46.1
@4m dB(A) 27.4 - 35.8 29.5 - 36.6
@10m dB(A) 19.1 - 27.2 19.5 - 27.4
Water pipe
connection
Inlet G1-1/2 G1-1/2
Outlet G1-1/2 G1-1/2
Controller (Standard: LCD) LWC04-V01 LWC04-V01
Anti-UV cover Yes Yes
Water resistance IP×4 IP×4
Dimension
(L×W×H)
Unit mm 860×330×668 860×330×668
Packing mm 950×410×800 950×410×800
Weight Net kg 35 38
Gross kg 42 45
Notes:
1. Advised swimming pool size is the size of the pool with IOSthermal cover at night and when not in use.
2. The specification may be changed for product improvement, please refer to the nameplate of product.
4

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Model i9 i11
Power supply 230V~, 1Ph, 50Hz 230V~, 1Ph, 50Hz
Air temperature: 15ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 1.60 – 6.70 2.18 - 8.13
Power input kW 0.21 - 1.34 0.28 - 1.59
COP 5.00 - 7.70 4.9 - 7.8
Boost mode Heating capacity kW 5.95 8.13
COP 5.00 4.90
Smart mode Heating capacity kW 4.76 6.50
COP 5.88 5.76
Silent mode Heating capacity kW 2.98 4.07
COP 6.67 6.53
Air temperature: 26ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 1.90 - 9.20 2.70 - 10.90
Power input kW 0.13 - 1.28 0.18 - 1.74
COP 6.24 - 14.71 6.27 - 14.8
Boost mode Heating capacity kW 9.20 10.90
COP 6.24 6.27
Smart mode Heating capacity kW 7.45 8.94
COP 7.80 7.84
Silent mode Heating capacity kW 4.60 5.45
COP 10.40 10.45
Air temperature: 35ºC, inlet/outlet water temperature: 28ºC/26ºC
Cooling capacity kW 1.80 - 4.60 2.40 - 6.00
Power input kW 0.28 - 1.20 0.33 - 1.39
EER 4.47 - 7.46 4.32 - 7.34
Boost mode Heating capacity kW 4.60 6.00
EER 4.47 4.32
Smart mode Heating capacity kW 3.68 4.80
EER 5.59 5.40
Silent mode Heating capacity kW 2.30 3.00
EER 6.88 6.65
Max. input kW 1.66 1.93
Max. current A 7.24 8.4
Water flow m3/h 3 - 5 4 - 6
Water pressure drop kPa 17 18
Running temperature range -15ºC - 43ºC -15ºC - 43ºC
Advised swimming pool size 20m
3
- 40m
3
25m
3
- 50m
3
Refrigerant system pressure (Max. / Min.) 1.5MPa / 4.15MPa 1.5MPa / 4.15MPa
5

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Continued:
Model i9 i11
Refrigerant Type R32 R32
Charged kg 1.0 1.3
GWP value 675 675
Equivalent CO2Ton 0.6750 0.8775
Compressor
Brand GMCC GMCC
Model KTN150D42UFZ KTN150D42UFZ
Type DC inverter, twin-rotary DC inverter, twin-rotary
Quantity 1 1
Capacity kW 4.680 (@60rps) 4.680 (@60rps)
Input kW 1.185 (@60rps) 1.185 (@60rps)
Current A 7.70 (@60rps) 7.70 (@60rps)
Oil type / charged Estel oil RB74AF / 670ml Estel oil RB74AF / 670ml
Air side
heat-exchanger
Material Hydrophilic aluminum & Inner groove copper tube
Rows 1 1
Tube size mm Φ9.52 Φ9.52
Fan motor
Fan type Axial Axial
Fan size mm Φ429×119 Φ420×153
Motor type BLDC BLDC
Motor model RD34HA MWS100-8K-PD7
Motor Brand LT Match-well
Quantity 1 1
Speed rpm 1,000 800
Throttling type Electronic Expansion valve
Water side heat-exchanger Titanium heat-exchanger with PVC casing
Sound pressure
level
@1m dB(A) 38.1 - 47.2 38.3 - 48.1
@4m dB(A) 29.4 - 37.3 30.4 - 37.9
@10m dB(A) 20.5 - 27.9 20.6 - 28.2
Water pipe
connection
Inlet G1-1/2 G1-1/2
Outlet G1-1/2 G1-1/2
Controller (Standard: LCD) LWC04-V01 LWC04-V01
Anti-UV cover Yes Yes
Water resistance IP×4 IP×4
Dimension
(L×W×H)
Unit mm 860×330×668 986×356×668
Packing mm 950×410×800 1,080×435×800
Weight Net kg 40 44
Gross kg 48 54
Notes:
1. Advised swimming pool size is the size of the pool with IOSthermal cover at night and when not in use.
2. The specification may be changed for product improvement, please refer to the nameplate of product.
6

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Model i14 i17
Power supply 230V~, 1Ph, 50Hz 230V~, 1Ph, 50Hz
Air temperature: 15ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 2.86 - 10.65 3.49 - 13.00
Power input kW 0.38 - 2.17 0.47 - 2.64
COP 4.9 - 7.6 4.85 - 7.44
Boost mode Heating capacity kW 10.65 13.00
COP 4.90 4.85
Smart mode Heating capacity kW 8.52 10.40
COP 5.76 5.71
Silent mode Heating capacity kW 5.33 6.50
COP 6.53 6.47
Air temperature: 26ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 3.40 - 14.30 4.30 - 17.40
Power input kW 0.23 - 2.32 0.29 - 2.85
COP 6.15 - 14.62 6.00 - 14.50
Boost mode Heating capacity kW 14.30 17.40
COP 6.15 6.00
Smart mode Heating capacity kW 11.44 14.01
COP 7.69 7.50
Silent mode Heating capacity kW 7.15 8.70
COP 10.25 10.00
Air temperature: 35ºC, inlet/outlet water temperature: 28ºC/26ºC
Cooling capacity kW 3.20 - 7.87 3.90 - 9.60
Power input kW 0.43 - 1.78 0.51 - 2.30
EER 4.41 - 7.42 4.24 - 7.40
Boost mode Heating capacity kW 7.87 9.60
EER 4.41 4.24
Smart mode Heating capacity kW 6.30 7.68
EER 5.51 5.30
Silent mode Heating capacity kW 3.94 4.80
EER 6.78 6.52
Max. input kW 2.21 3.17
Max. current A 9.6 13.77
Water flow m3/h 5 - 7 6 - 8
Water pressure drop kPa 18 19
Running temperature range -15ºC - 43ºC -15ºC - 43ºC
Advised swimming pool size 30m
3
- 60m
3
35m
3
- 70m
3
Refrigerant system pressure (Max. / Min.) 1.5MPa / 4.15MPa 1.5MPa / 4.15MPa
7

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Continued:
Model i14 i17
Refrigerant Type R32 R32
Charged kg 1.5 1.58
GWP value 675 675
Equivalent CO2Ton 1.0125 1.2150
Compressor
Brand GMCC GMCC
Model KTN150D42UFZ KTM240D57UMT
Type DC inverter, twin-rotary DC inverter, twin-rotary
Quantity 1 1
Capacity kW 4.680 (@60rps) 7.715 (@60rps)
Input kW 1.185 (@60rps) 2.085 (@60rps)
Current A 7.70 (@60rps) 9.40 (@60rps)
Oil type / charged Estel oil VG74 / 670ml Estel oil VG74 / 670ml
Air side
heat-exchanger
Material Hydrophilic aluminum & Inner groove copper tube
Rows 2 2
Tube size mm Φ7 Φ9.52
Fan motor
Fan type Axial Axial
Fan size mm Φ420×153 Φ420×153
Motor type BLDC BLDC
Motor model MWS100-8K-PD7 MWS100-8K-PD7
Motor Brand Match-well Match-well
Quantity 1 1
Speed rpm 800 800
Throttling type Electronic Expansion valve
Water side heat-exchanger Titanium heat-exchanger with PVC casing
Sound pressure
level
@1m dB(A) 38.5 - 48.6 41.5 - 52.5
@4m dB(A) 30.6 - 38.2 32.8 - 40.5
@10m dB(A) 20.8 - 28.6 23.0 - 31.8
Water pipe
connection
Inlet G1-1/2 G1-1/2
Outlet G1-1/2 G1-1/2
Controller (Standard: LCD) LWC04-V01 LWC04-V01
Anti-UV cover Yes Yes
Water resistance IP×4 IP×4
Dimension
(L×W×H)
Unit mm 986×356×668 986×356×668
Packing mm 1,080×435×800 1,080×435×800
Weight Net kg 46 56
Gross kg 56 66
Notes:
1. Advised swimming pool size is the size of the pool with IOSthermal cover at night and when not in use.
2. The specification may be changed for product improvement, please refer to the nameplate of product.
8

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Model i21
Power supply 230V~, 1Ph, 50Hz
Air temperature: 15ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 3.76 - 15.70
Power input kW 0.48 - 2.75
COP 5.10 - 7.52
Boost mode Heating capacity kW 15.70
COP 5.10
Smart mode Heating capacity kW 12.56
COP 6.00
Silent mode Heating capacity kW 7.85
COP 6.80
Air temperature: 26ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 4.80 - 21.20
Power input kW 0.33 - 3.38
COP 6.36 - 14.55
Boost mode Heating capacity kW 21.20
COP 6.36
Smart mode Heating capacity kW 17.17
COP 7.95
Silent mode Heating capacity kW 10.60
COP 10.60
Air temperature: 35ºC, inlet/outlet water temperature: 28ºC/26ºC
Cooling capacity kW 4.30 - 11.50
Power input kW 0.57 - 2.62
EER 4.38 - 7.48
Boost mode Heating capacity kW 11.50
EER 4.38
Smart mode Heating capacity kW 9.20
EER 5.48
Silent mode Heating capacity kW 5.75
EER 6.74
Max. input kW 3.29
Max. current A 14.3
Water flow m3/h 7 - 9
Water pressure drop kPa 20
Running temperature range -15ºC - 43ºC
Advised swimming pool size 40m
3
- 80m
3
Refrigerant system pressure (Max. / Min.) 1.5MPa / 4.15MPa
9

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Continued:
Model i21
Refrigerant Type R32
Charged kg 2.0
GWP value 675
Equivalent CO2Ton 1.3500
Compressor
Brand GMCC
Model KTM240D57UMT
Type DC inverter, twin-rotary
Quantity 1
Capacity kW 7.715 (@60rps)
Input kW 2.085 (@60rps)
Current A 9.40 (@60rps)
Oil type / charged Estel oil VG74 / 670ml
Air side
heat-exchanger
Material Hydrophilic aluminum & Inner groove copper tube
Rows 1.5
Tube size mm Φ9.52
Fan motor
Fan type Axial
Fan size mm Φ458.5×152
Motor type BLDC
Motor model MWS100-8K-PD
Motor Brand Match-well
Quantity 1
Speed rpm 800
Throttling type Electronic Expansion valve
Water side heat-exchanger Titanium heat-exchanger with PVC casing
Sound pressure
level
@1m dB(A) 42.3 - 53.1
@4m dB(A) 33.2 - 40.9
@10m dB(A) 23.6 - 32.2
Water pipe
connection
Inlet G1-1/2
Outlet G1-1/2
Controller (Standard: LCD) LWC04-V01
Anti-UV cover Yes
Water resistance IP×4
Dimension
(L×W×H)
Unit mm 1,076×426×720
Packing mm 1,161×490×855
Weight Net kg 67
Gross kg 80
Notes:
1. Advised swimming pool size is the size of the pool with IOSthermal cover at night and when not in use.
2. The specification may be changed for product improvement, please refer to the nameplate of product.
10

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Model i25 i29
Power supply 230V~, 1Ph, 50Hz 230V~, 1Ph, 50Hz
Air temperature: 15ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 5.15 - 18.52 5.43 - 21.28
Power input kW 0.68 - 3.77 0.73 - 4.30
COP 4.91 - 7.53 4.95 - 7.51
Boost mode Heating capacity kW 18.52 21.28
COP 4.91 4.95
Smart mode Heating capacity kW 14.82 17.02
COP 5.74 5.82
Silent mode Heating capacity kW 9.26 10.54
COP 6.51 6.60
Air temperature: 26ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 6.20 - 25.10 6.60 - 29.00
Power input kW 0.43 - 4.05 0.46 - 4.75
COP 6.20 - 14.52 6.10 - 14.54
Boost mode Heating capacity kW 25.10 29.00
COP 6.20 6.10
Smart mode Heating capacity kW 20.10 23.20
COP 7.60 7.63
Silent mode Heating capacity kW 12.52 14.55
COP 10.15 10.17
Air temperature: 35ºC, inlet/outlet water temperature: 28ºC/26ºC
Cooling capacity kW 5.80 - 13.90 6.20 - 16.00
Power input kW 0.80 - 3.35 0.82 - 3.73
EER 4.15 - 7.22 4.29 - 7.54
Boost mode Heating capacity kW 13.90 16.00
EER 4.15 4.29
Smart mode Heating capacity kW 11.10 12.80
EER 5.18 5.36
Silent mode Heating capacity kW 6.95 8.00
EER 6.40 6.60
Max. input kW 4.49 4.91
Max. current A 19.52 21.35
Water flow m3/h 8 - 11 9 - 12
Water pressure drop kPa 23 25
Running temperature range -15ºC - 43ºC -15ºC - 43ºC
Advised swimming pool size 65m
3
- 110m
3
70m
3
- 130m
3
Refrigerant system pressure (Max. / Min.) 1.5MPa / 4.15MPa 1.5MPa / 4.15MPa
11

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Continued:
Model i25 i29
Refrigerant Type R32 R32
Charged kg 2.6 3.0
GWP value 675 675
Equivalent CO2Ton 1.7550 2.0250
Compressor
Brand GMCC GMCC
Model KTF310D43UMT KTQ420D1UMU
Type DC inverter, twin-rotary DC inverter, twin-rotary
Quantity 1 1
Capacity kW 10.0010 (@60rps) 13.700 (@60rps)
Input kW 2.765 (@60rps) 3.700 (@60rps)
Current A 5.38 (@60rps) 7.02 (@60rps)
Oil type / charged Estel oil VG74 / 1,000ml Estel oil VG74 / 1,400ml
Air side
heat-exchanger
Material Hydrophilic aluminum & Inner groove copper tube
Rows 2 2
Tube size mm Φ9.52 Φ7
Fan motor
Fan type Axial Axial
Fan size mm Φ458.5×152 Φ525×135
Motor type BLDC BLDC
Motor model MWS100-8K-PD MWS100-8K-PD4
Motor Brand Match-well Match-well
Quantity 1 1
Speed rpm 800 800
Throttling type Electronic Expansion valve
Water side heat-exchanger Titanium heat-exchanger with PVC casing
Sound pressure
level
@1m dB(A) 44.7 - 54.9 45.6 - 57.1
@4m dB(A) 35.6 - 41.8 36.4 - 44.7
@10m dB(A) 24.6 - 33.7 26.6 - 36.5
Water pipe
connection
Inlet G1-1/2 G1-1/2
Outlet G1-1/2 G1-1/2
Controller (Standard: LCD) LWC04-V01 LWC04-V01
Anti-UV cover Yes Yes
Water resistance IP×4 IP×4
Dimension
(L×W×H)
Unit mm 1,076×426×720 1,176×451×822
Packing mm 1,161×490×855 1,261×515×957
Weight Net kg 72 90
Gross kg 85 108
Notes:
1. Advised swimming pool size is the size of the pool with IOSthermal cover at night and when not in use.
2. The specification may be changed for product improvement, please refer to the nameplate of product.
12

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Model i32
Power supply 230V~, 1Ph, 50Hz
Air temperature: 15ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 6.34 - 23.68
Power input kW 0.87 - 4.80
COP 4.90 - 7.60
Boost mode Heating capacity kW 23.68
COP 4.90
Smart mode Heating capacity kW 18.94
COP 5.76
Silent mode Heating capacity kW 11.84
COP 6.53
Air temperature: 26ºC, RH70%, inlet/outlet water temperature: 26ºC/28ºC
Heating capacity kW 7.70 - 31.70
Power input kW 0.54 - 5.21
COP 6.11 - 14.60
Boost mode Heating capacity kW 31.70
COP 6.11
Smart mode Heating capacity kW 25.68
COP 7.64
Silent mode Heating capacity kW 15.85
COP 10.18
Air temperature: 35ºC, inlet/outlet water temperature: 28ºC/26ºC
Cooling capacity kW 7.20 - 17.50
Power input kW 0.97 - 4.17
EER 4.21 - 7.44
Boost mode Heating capacity kW 17.50
EER 4.21
Smart mode Heating capacity kW 14.00
EER 5.26
Silent mode Heating capacity kW 8.75
EER 6.48
Max. input kW 5.80
Max. current A 25.2
Water flow m3/h 12 - 15
Water pressure drop kPa 28
Running temperature range -15ºC - 43ºC
Advised swimming pool size 80m
3
- 150m
3
Refrigerant system pressure (Max. / Min.) 1.5MPa / 4.15MPa
13

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
Continued:
Model i32
Refrigerant Type R22
Charged kg 3.3
GWP value 675
Equivalent CO2Ton 2.2275
Compressor
Brand GMCC
Model KTQ420D1UMU
Type DC inverter, twin-rotary
Quantity 1
Capacity kW 13.700 (@60rps)
Input kW 3.700 (@60rps)
Current A 7.02 (@60rps)
Oil type / charged Estel oil VG74 / 1,400ml
Air side
heat-exchanger
Material Hydrophilic aluminum & Inner groove copper tube
Rows 2
Tube size mm Φ9.52
Fan motor
Fan type Axial
Fan size mm Φ522×140
Motor type BLDC
Motor model MWS100-8K-PD4
Motor Brand Match-well
Quantity 1
Speed rpm 800
Throttling type Electronic Expansion valve
Water side heat-exchanger Titanium heat-exchanger with PVC casing
Sound pressure
level
@1m dB(A) 47.2 - 59.7
@4m dB(A) 37.9 - 46.9
@10m dB(A) 27.3 - 38.2
Water pipe
connection
Inlet G1-1/2
Outlet G1-1/2
Controller (Standard: LCD) LWC04-V01
Anti-UV cover Yes
Water resistance IP×4
Dimension
(L×W×H)
Unit mm 1,176×451×822
Packing mm 1,261×515×957
Weight Net kg 98
Gross kg 116
Notes:
1. Advised swimming pool size is the size of the pool with IOSthermal cover at night and when not in use.
2. The specification may be changed for product improvement, please refer to the nameplate of product.
14

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
4. Dimensions
i5 / i7 / i9 (Unit: mm)
i11 / i14 / i17 (Unit: mm)
15

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
i21 / i25 (Unit: mm)
i29 / i32 (Unit: mm)
16

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114 5. Wiring diagram
i5 / i7/ i9 / i11 / i14 / i17 / i21 / i25:
17

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
i29 / i32:
18

Proteam i-Series Inverter Installation and Operation Manual (R32) v.190114
6. Operation range
Air ambient temperature range Setting temperature range
-15ºC - 43ºC Cooling: 8ºC - 25ºC; Heating: 15ºC - 40ºC
7. Refrigerant system diagram
Notes:
Hi-pressure switch: When the refrigerant pressure in the system is higher than 4.5MPa, the
hi-pressure switch will be triggered and the unit will shut down. When the refrigerant pressure in
the system is lower than 3.5MPa, the pressure switch will be re-activated and the unit will start
again.
Lo-pressure switch: When the refrigerant pressure in system is lower than 0.05MPa, the switch
will be triggered and the signal of hi-pressure switch will be shutdown. When the refrigerant
pressure in system is higher than 0.15MPa, the pressure switch will be recovered.
19
