Aethra D2001 NX Instruction Manual

D2001,LOOP-BOXStateMachine
Incoming
call
Is it compatible with
profile and
instrument number?
YES Is the instrument in
Waiting for
Incoming Call state
on a specific test?
YES
The specific test
accepts the incoming
call.
NO
NO
Act as LOOPBOX
ACCEPT CALLS =
NONE ?
YES
The instrument
rejects the incoming
call.
ACCEPT CALLS =
COMPATIBLE ONLY ?
NO
Is it compatible with
instrument profile ?
YES
NO
NO
Is it compatible with
the number set in
the Own/MSN field ?
YES
The instrument
accepts the incoming
call, loops the B
channel or makes a
call-back.
YES
NO
ACCEPT CALLS =
ALL ?
NO
YES
( or the Own/MSN
field is not set)
A
