AGA DC3G User manual

AGA DUAL C NTR L
Model No’s: DC3G & DC5G
Installation
Guide
12/14 EI S 516911
PLEASE READ THESE INSTRUCTI NS BEF RE C MMENCING SITE SURVEY
R INSTALLING THIS APPLIANCE.
IMPORTA T : SAVE I STRUCTIO S FOR FUTURE REFERE CE
IMPORTA T : CO SERVER CES I STRUCTIO S POUR REFERE CE FUTURE
For use in USA/Canada

SECTI N PAGE
PRODUCT SAFETY 3
GE ERAL OTES 4
DELIVERY REQUIREME TS 4
GE ERAL I STALLATIO REQUIREME TS 4
APPLIA CE DIME SIO S - AGA DC3G 5
APPLIA CE DIME SIO S - AGA DC5G 6
TECH ICAL DATA 7
I STALLATIO 7 - 10
CO ECTIO TO THE POWER SUPPLY - AGA DC3G 11
POWER SUPPLY - HOTCUPBOARD DC5G 12
MAI S CABLE ROUTI G - AGA DC3G 13
MAI S SUPPLY LOCATIO - AGA DC5 14
(HOTCUPBOARD OPTIO )
FLUE SYSTEM 15 - 18
WIRI G DIAGRAM - AGA DC3G 19
GAS SUPPLY - U.S. PIPE THREADS 20
AIR SUPPLY 20
HOTCUPBOARD I STALLATIO 21 - 27
WIRI G DIAGRAM - AGA DC5G (HOTCUPBOARD OPTIO ) 27
COMMISSIO I G 28 - 29
YEARLY SERVICE 29 - 30
REPLACEME T PARTS 30
I STRUCTIO S 30
C NTENTS
2

3
PR DUCT SAFETY
MEANING/DESCRIPTI N SIGNIFICATI N/DESCRIPTI NSYMB L
WARNING/CAUTI N
An appropriate safety instruction
should be followed or caution to a
potential hazard exists.
AVERTISSEMENT
Une consigne de sécurité
appropriée doivent être suivies ou
garde d’un danger potentiel
exists.
DANGER US V LTAGE
To indicate hazards arising from
dangerous voltages.
TENSI N DANGEREUSE
Pour indiquer les dangers
résultant des tensions
dangereuses.
PR TECTIVE EARTH (GR UND)
To identify any terminal which is
intended for connection to an
external conductor for protection
against electric shock in case of a
fault, or the terminal of a
protective earth (ground)
electrode.
TERRE DE PR TECTI N
Pour marquer bornes destin ées à
être raccordées à un conducteur
de protection extérieur contre les
chocs éclectiques en cas de
défaut d’isolement, ou pour
marquer la borne de la terre de
protection.
HEAVY
This product is heavy and
reference should be made to the
safety instructions for provisions
of lifting and moving.
L URD
Ce produit est lourd et doit être
fait référence auc consignes de
sécurité relatives aux dispositions
de soulever et déplacer.
DISC NNECT MAINS SUPPLY
Disconnect incoming supply be-
fore inspection or maintenance.
APPAREIL À LASER DE
CLASSE 2
Alimentation d’entr ée Débrancher
avant inspection ou d’entretien.
REFER T MANUAL
Refer to relevant instructions
detailed within the product
manual.
ATTENTI N, SURFACE TRÉS
CHAUDE
Reportez-vous aux instructions
applicables, indiquées dans le
manuel du produit.

GENERAL N TES
N TE: THESE I STALLATIO I STRUCTIO S SHOULD BE LEFT WITH THE RA GE A D THE USER TO RETAI
FOR FUTURE REFERE CE.
DELIVERY REQUIREMENTS
The AGA DC3 arrives on 1 pallet.
The AGA DC5 (Hotcupboard Option) arrives on 2 pallets.
There must be access to the kitchen to manipulate a foot print of 39 9/16” (1005mm) x 29 1/8” (740mm). A wooden
template (skate with castor wheels) of dimensions 39 9/16” (1005mm) x 29 1/8” (740mm) could be used to check if the
AGA Dual Control fully built appliance is able to fit through the property grounds and doors into its installation position in
the kitchen. It must also be considered that the height of the appliance is 37 3/4” (960mm) off pallet and 43 1/4 ” (1100mm)
on the pallet, so high level obstacles/restrictions must not be overlooked.
If this skate/template can be manipulated through the property grounds and doorsinto position, then the AGA Dual
Control can be installed as intended with no re-work.
GENERAL INSTALLATI N REQUIREMENTS
The installation of the range must be in accordance with the relevant requirements of the local Wiring and Building
Regulations. It should be in accordance also with any relevant requirements of the local or state codes.
In your own interest and that of safety to comply with the law, all appliances should be installed by an authorized AGA
distributor in accordance with the relevant regulations.
CAUTI N:
THIS UNIT IS HEAVY, PR PER EQUIPMENT AND ADEQUATE
MANP WER MUST BE USED IN M VING THE RANGE T
AV ID DAMAGE T THE UNIT R THE FL R
4

5
APPLIANCE DIMENSI NS - AGA DC3G
Fig. 1 DES 516847
Range Dimensions
When surveying for a range installation the actual clearance required for the ‘body’ of the appliance should be increased by
3/8” beyond the figures quoted above. This allows safe margin to take into account the natural dimensional variations found
in major castings. In particular the width across the appliance recess could be critical.
APPLIANCE WEIGHT (Excludes Packaging)
Model: AGA Dual Control (DC3G) - 996lb (452kg)
GAS C NNECTI N - AGA DC3G NLY
1/4” PT MALE
A B C D E F G H J K L M P Q R
mm 987 948 910 680 1388 760 1145 698 116 10 565 689 43 118 55 634
inch 38 7/837 3/835 7/8 26 3/4 54 5/829 7/845 1/827 1/24 9/16
3/8
22 1/427 1/81 3/44 5/82 1/8 25

6
APPLIANCE DIMENSI NS - AGA DC5G
Fig. 2 DES 516848
Range Dimensions
When surveying for a range installation the actual clearance required for the ‘body’ of the appliance should be increased by
3/8” beyond the figures quoted above. This allows safe margin to take into account the natural dimensional variations found
in major castings. In particular the width across the appliance recess could be critical.
APPLIANCE WEIGHT (Excludes Packaging)
Model: AGA Dual Control (DC3) - 996lb (452kg)
Hotcupboard - 242lb (110kg)
Data plate located behind plinth.
A B C D E F G H J K L M P Q R
mm 1478 948 910 680 1388 760 1145 698 116 10 565 689 43 118 55 634
inch 58 1/437 3/835 7/826 3/454 5/829 7/845 1/827 1/24 9/16 3/822 1/427 1/81 3/44 5/82 1/8 25

Side Clearances
A 1/8” (3mm) gap is required each side between the range top plate and adjoining work surfaces that may be fitted, this is to
allow for the safe removal of the top plate should this be required at a later date.
Where ranges are to be fitted against a side wall a 4 9/16” (116mm) clearance is required on the right and left hand side for
oven door access.
If the AGA is to be installed in a brick recess, then the minimum clearance should be increased by at least 3/8” (10mm), to
allow for the walls not being square.
In addition a minimum clearance of 39 3/8” (1000mm) must be available at the front of the range to enable the range to be
serviced.
ATURAL GAS
MAXIMUM HEAT I PUT 6,800 Btu/hr
Thermostat Bypass 70
Main Burner Injector 112
Gas Supervision Injector 4212
Minimum Inlet Pressure 5” w.g.
Burner Pressure 4” w.g.
Models AGA DC3G and DC5G
TECHNICAL DATA
INSTALLATI N
Range Base or Hearth
It is essential that the base or hearth on which the range stands should be level and be capable of supporting the total
weight of the range 8.9 cwt. The base of the built-in AGA plinth must be level and sit above the finished height for service
access.
Plinth
The front plinth cover is removable and must not be obstructed by flooring or tiles. If necessary the range must be raised
by the thickness of the tiles to ensure the plinth can be removed.
Rear Wall
7
Since this appliance runs continuously, please take note of these IMP RTANT instructions:
Combustible Walls
Houses constructed of combustible materials (such as all-timber or stud wall partitions and batoned plasterboarded
walls) require special wall heat protection features.
on-combustible material behind a range must be of at least 1” (25mm) thick insulation board (Monolux or equivalent),
up to hotplate level.
SPECIAL N TE: Ensure electric cabling or plastic services do not pass within or on the outside of the wall, behind
or directly above the range.
This type of material can age prematurely when exposed to continuous higher ambient temperature.
Alternatively the range can be spaced 1 1/2” (38mm) away from the wall to create an air gap.
The air gap must be left open and N T blocked off across the top edge.

8
Tiling
When the range is to stand in a recess or against a wall which is to be tiled, under no circumstances should the tiles overlap
the range top plate, access to remove the hotplate must be allowed for servicing at a later date.
A gap of at least 3/8” (10mm) must be observed from the rear of the top plate and the wall behind the range.
verhead Cabinets
To eliminate the risk of burns or fires by reaching over hot surface units, cabinet storage space located above the surface
units should be avoided.

9
OTE: A Y OVERHEAD FITTED CABI ETS MUST OT EXCEED 13” PROJECTED DEPTH ABOVE THE RA GE. DIM ‘D’ TO BE OT LESS THA THE ORMAL WIDTH OF THE RA GE.
Fig. 3 DES 516668

Top Plate Adjustment - AGA DC3 (See Fig. 3)
In general, adjustment of the top plate is to be avoided. However minimum use of the top plate adjusters can be used to
improve the alignment of the top plate.
Fig. 3 DES 516751
