Agam Water Bar User manual

User Guide
Návod pro uživatele

EN User Guide . . . . . . . . . . . . . . . . . . . . . . . . . EN-1
CZ Návod pro uživatele . . . . . . . . . . . . . . . . . . CZ-1

EN
EN-1
Introduction
Thank you for purchasing Agam Water Bar, the advanced home and small-office water bar.
Agam Water Bar is an innovative, user-friendly water purification solution that was designed
and developed by experts to provide you with pure, ice cold to boiling hot water with maximum
ease at all times.
We congratulate you on joining and hope you will enjoy all the features of your new, pure water
bar.
Sincerely,
Agam Water Bar
Table of Contents
1. Description of Water Bar
1.1 General Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-2
1.2 Operation Panel with Touch Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-2
2. Operation
2.1 Cold Water Dispensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-3
2.2 Hot Water Dispensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-3
2.3 Boiling Hot Water Dispensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-3
2.4 Hot/Boiling Water Dispensing with “Child Lock” Mode. . . . . . . . . . . . . . . . . . . . . EN-4
2.5 Room Temperature Water Dispensing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-4
2.6 Predefined Cold Water Dispensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-4
2.7 Predefined Hot Water Dispensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-4
3. Main Menu – Settings
3.1 Setting the Clock and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-5
3.2 Setting Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-5
3.3 Setting Predefined Water Quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-7
3.4 Setting the Power Saving Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-8
3.5 Setting Menu Language. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-10
3.6 Ring/Beep setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-10
3.7 Restoring to Factory Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-11
3.8 Setting the Child Lock Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-12
4. Maintenance and Service
4.1 Replacement of Filter and UV Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-12
4.2 Cleaning the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-13
4.3 Flushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-13
4.4 Weekends / Vacations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-13
5. Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-14
6. Technical Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-16
7. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-17

EN
EN-2
1 Description of Water Bar
1.1 General Overview
1. Operation Panel with Touch Screen
2. Removable Top Pad
3. Faucet
4. Removable Drip Tray
with Drip Collector
5. Tray Grid
6. Power Cable
7. Main Switch ON/OFF
8. Heating System Switch ON/OFF
9. Water Inlet Port
1. Cold water dispensing button
2. Cold water temperature display (the higher the mark
is on the temperature indication bar the colder the
water will be).
3. Power saving mode is activated
4. Automatic shutdown and wake-up timer is activated
5. Clock
6. Date
7. Hot water temperature display (the higher the mark is
on the temperature indication bar the hotter the water
will be).
8. “Child Lock” mode is activated
9. UV lamp is ON (flickering light display)
10. Digital display indicating the unit’s mode
11. Hot water dispensing button
12. Predefined room temperature water dispensing
button (MIX)
13. Extra hot water dispensing button
14. Back button (return to previous menu)
15. Touch screen
16. Entering main menu button and confirming settings
17. Predetermined cold/hot water dispensing button
1.2 Operation Panel with Touch Screen
13425678910
11
13
12 14 15 16 17
Cold water dispensing
Press any button to stop
1
3
5
98
67
4
2

EN
EN-3
2 Operation
2.1 Cold Water Dispensing
Place an empty cup below the water spout. To dispense
cold water, press the button briefly. The “Cold Water
Cup” icon will appear during water dispensing. To stop water
dispensing, press any button.
Note: To set cold water quantity, please see section 3.3.
To fill bottles, pull out the tray.
2.2 Hot Water Dispensing
Place an empty cup below the water spout. To dispense hot
water, press the button briefly and then press the
button briefly. The “Hot Water Cup” icon will appear during
water dispensing. To stop water dispensing, press any
button.
Note: To set hot water quantity, please see section 3.3.
To meet a high level of safety and the most stringent standards, we incorporated
a safety mechanism for hot water in the water bar even when the „Child Lock”
mode is not activated –for the safety of your children. To enable hot/boiling water
dispensing, please press two buttons briefly.
2.3 Boiling Water Dispensing
Place an empty cup below the water spout. To dispense hot
water, press the button briefly. The “Boiling. Please
wait…” notice will be displayed.
After the water temperature reaches near boiling temperature,
the “End of boiling” notice will appear on the display.
To dispense boiling water, press the button briefly and
then press the button. To stop water dispensing, press
any button.
Notice: the boiling limit of Agam Water Bar is up to 97 ºC
- 98 ºC.
Cold water dispensing
Press any button to stop
04-04-2012 (WED) 09:15
Hot water dispensing
Press any button to stop
Boiling
Please wait...
04-04-2012 (WED) 09:15
04-04-2012 (WED) 09:15
End of boiling
04-04-2012 (WED) 09:15
