AGCO GSI PNEG-2235 User manual

®
Metric Roof Exhauster Assembly
(Small)
Models:
12 FT. – 54 FT. DIAMETER BINS
Installation Manual
PNEG-2235
Version 1.0
Date: 02-21-20
PNEG-2235

All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
2PNEG-2235 Metric Exhauster Assembly (Small)

Contents
Chapter 1 Safety Precautions ....................................................................................................................5
Safety Guidelines........................................................................................................................5
Safety Decals .............................................................................................................................9
Safety Sign-off Sheet.................................................................................................................10
Chapter 2 Exhauster Assembly ............................................................................................................... 11
Part Numbers............................................................................................................................ 11
Parts List ..................................................................................................................................12
Exhauster Assembly..................................................................................................................13
Limited Warranty — EME Grain Products ................................................................................17
PNEG-2235 Metric Exhauster Assembly (Small) 3

NOTES
4PNEG-2235 Metric Exhauster Assembly (Small)

1Safety Precautions
Topics Covered in this Chapter
▪ Safety Guidelines
▪ Safety Decals
▪ Safety Sign-off Sheet
Safety Guidelines
Follow Safety Instructions
Use Personal Protective Equipment
PNEG-2235 Metric Exhauster Assembly (Small) 5

Chapter 1: Safety Precautions
Do Not Enter Bin
Prevent Roof Damage due to Vacuum Pressure
6PNEG-2235 Metric Exhauster Assembly (Small)

Chapter 1: Safety Precautions
Unload Bin Correctly
Do Not Overfill the Bin
PNEG-2235 Metric Exhauster Assembly (Small) 7

Chapter 1: Safety Precautions
Stay Clear of Hoisted Equipment Sharp Edge Hazard
Store Bin Sheets Properly
Install and Operate Equipment Properly
Rotating Auger Hazard
8PNEG-2235 Metric Exhauster Assembly (Small)

Chapter 1: Safety Precautions
Safety Decals
To replace a damaged or missing decal, contact GSI to receive a free replacement.
Location Decal No. Decal
A DC-2306
B DC-2161
PNEG-2235 Metric Exhauster Assembly (Small) 9

Chapter 1: Safety Precautions
C DC-2210
Safety Sign-off Sheet
Date Employee Name Supervisor Name
ST-0007
10 PNEG-2235 Metric Exhauster Assembly (Small)

2Exhauster Assembly
Topics Covered in this Chapter
▪ Part Numbers
▪ Parts List
▪ Exhauster Assembly
Part Numbers
Table 2-1 Exhauster assembly part numbers (12 ft. – 27 ft.)
S.
No Description
Part Numbers
12 ft. 15 ft. 18 ft. 21 ft. 24 ft. 27 ft.
1
M08 x 30N
flange bolt with
LPDE sealing
washer
S-BFUBM08030BF S-BFUBM08030BF S-BFUBM08030BF S-BFUBM08030BF S-BFUBM08030BF S-BFUBM08030BF
2M08 flange nut S-BFSBM08B S-BFSBM08B S-BFSBM08B S-BFSBM08B S-BFSBM08B S-BFSBM08B
3Roof panel ETR-0378 ETR-0379 ETR-0380 ETR-0381 ETR-0382 ETR-0383
4Exhauster
mounting plate ETR-1744-12 ETR-1744-15 ETR-1744-18 ETR-1744-21 ETR-1744 ETR-1744-27
5Roof flashing ERP-4618 ETR-0638 ETR-0639 ETR-0640 ETR-0641 ETR-0642
Table 2-2 Exhauster assembly part numbers (30 ft. – 54 ft.)
S.
No Description
Part Numbers
30 ft. 33 ft. 36 ft. 42 ft. 48 ft. 54 ft.
1
M08 x 30N
flange bolt with
LPDE sealing
washer
S-BFUBM08030BF S-BFUBM08030BF S-BFUBM08030BF S-BFUBM08030BF S-BFUBM08030BF S-BFUBM08030BF
2M08 flange nut S-BFSBM08B S-BFSBM08B S-BFSBM08B S-BFSBM08B S-BFSBM08B S-BFSBM08B
3Roof panel ETR-0384 ETR-0385 ETR-0386 ETR-0388 ETR-0390 ETR-0391
4Exhauster
mounting plate ETR-1744-30 ETR-1744-33 ETR-1744-36 ETR-1744-42 ETR-1744-48 ETR-1744-54
5Roof flashing ETR-0643 ERP-4683 ETR-1177 ETR-1178 ETR-1179 ETR-1589
PNEG-2235 Metric Exhauster Assembly (Small) 11

Chapter 2: Exhauster Assembly
Parts List
Table 2-3 Exhauster assembly parts list
12 PNEG-2235 Metric Exhauster Assembly (Small)

Chapter 2: Exhauster Assembly
Exhauster Assembly
Figure 2-1 Marking or scribing the hole to be cut
Figure 2-2 Cutting the marked or scribed hole
PNEG-2235 Metric Exhauster Assembly (Small) 13

Chapter 2: Exhauster Assembly
Figure 2-3 Roof panel cutout parameters
Table 2-4 Roof panel cutout parameters
Diameter (ft.) mp(mm) a (mm) c (mm) mt(mm)
12 1439 743 200 439
15 1739 705 200 458
18 2199 708 200 456
21 2631 706 200 457
24 2599 596 200 521
27 2754 551 200 552
30 1946 338 200 769
33 1818 300 200 829
36 1813 269 200 884
42 2743 345 200 759
48 2758 297 200 833
54 2408 238 200 945
14 PNEG-2235 Metric Exhauster Assembly (Small)

Chapter 2: Exhauster Assembly
Figure 2-4 Assembling the roof exhauster
Figure 2-5 Installing the roof exhauster assembly
PNEG-2235 Metric Exhauster Assembly (Small) 15

Chapter 2: Exhauster Assembly
Figure 2-6 Installing the roof panel flashing
Figure 2-7 Sealing caulk location
16 PNEG-2235 Metric Exhauster Assembly (Small)

Chapter 2: Exhauster Assembly
Limited Warranty — EME Grain Products
The GSI Group, LLC. (“GSI”) warrants products which it manufactures, to be free of defects in materials and workmanship
under normal usage and conditions for a period of 12 months from the date of shipment (or, if shipped by vessel, 14
months from the date of arrival at the port of discharge). If, in GSI’s sole judgment, a product is found to have a defect in
materials and/or workmanship, GSI will, at its own option and expense, repair or replace the product or refund the
purchase price. This Limited Warranty is subject to extension and other terms as set forth below.
Warranty Enhancements: The warranty period for the following products is enhanced as shown below and is in
lieu of (and not in addition to) the above stated warranty period. (Warranty Period is from date of shipment.)
Product Warranty Period
Storage
Grain Bin Structural Design
▪ Roof, doors, platforms and walk arounds
▪ Flooring (when installed using GSI specified floor support system for that floor)
▪ Hopper tanks
5 Years
Conditioning
Dryer Structural Design – (Tower, Portable and TopDry)
▪ Includes (frame, portable dryer screens, ladders, access doors and platforms) 5 Years
All other Dryer parts including:
▪ Electrical (controls, sensors, switches & internal wiring) 2 Years
Bullseye Controllers 2 Years
Material
Handling
Bucket Elevators Structural Design 5 Years
Towers Structural Design 5 Years
Catwalks Structural Design 5 Years
Accessories (stairs, ladders and platforms) Structural Design 5 Years
Conditions and Limitations:
THERE ARE NO WARRANTIES THAT EXTEND BEYOND THE LIMITED WARRANTY DESCRIPTION SET FORTH
HEREIN; SPECIFICALLY, GSI DISCLAIMS ANY AND ALL OTHER WARRANTIES OF ANY KIND, EXPRESS OR
IMPLIED, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE OR USE IN CONNECTION WITH: (I) ANY PRODUCT MANUFACTURED OR SOLD BY GSI,
OR (II) ANY ADVICE, INSTRUCTION, RECOMMENDATION OR SUGGESTION PROVIDED BY AN AGENT,
REPRESENTATIVE OR EMPLOYEE OF GSI REGARDING OR RELATED TO THE CONFIGURATION, INSTALLATION,
LAYOUT, SUITABILITY FOR A PARTICULAR PURPOSE, OR DESIGN OF SUCH PRODUCTS.
The sole and exclusive remedy for any claimant is set forth in this Limited Warranty and shall not exceed the amount paid
for the product purchased. This Warranty only covers the value of the warranted parts and equipment, and does not cover
labor charges for removing or installing defective parts, shipping charges with respect to such parts, any applicable sales
or other taxes, or any other charges or expenses not specified in this Warranty. GSI shall not be liable for any other direct,
indirect, incidental or consequential damages, including, without limitation, loss of anticipated profits or benefits. Expenses
incurred by or on behalf of a claimant without prior written authorization from the GSI warranty department shall not be
reimbursed. This warranty is not transferable and applies only to the original end-user. GSI shall have no obligation or
responsibility for any representations or warranties made by or on behalf of any dealer, agent or distributor. Prior to
installation, the end-user bears all responsibility to comply with federal, state and local codes which apply to the location
and installation of the products.
This Limited Warranty extends solely to products sold by GSI and does not cover any parts, components or materials used in conjunction with the
product, that are not sold by GSI. GSI assumes no responsibility for claims resulting from construction defects, unauthorized modifications,
corrosion or other cosmetic issues caused by storage, application or environmental conditions. Modifications to products not specifically
delineated in the manual accompanying the product at initial sale will void all warranties. This Limited Warranty shall not extend to products or
parts which have been damaged by negligent use, misuse, alteration, accident or which have been improperly/inadequately maintained.
Notice Procedure:
In order to make a valid warranty claim a written notice of the claim must be submitted, using the RMA form, within 60 days of discovery of a
warrantable nonconformance. The RMA form is found on the OneGSI portal.
Service Parts:
GSI warrants, subject to all other conditions described in this Warranty, Service Parts which it manufactures for a period of 12 months from the
date of purchase unless specified in Enhancements above.
(Limited Warranty - N.A. Grain Products_ revised 19 October 2018)
PNEG-2235 Metric Exhauster Assembly (Small) 17
