AGCO GSI 40 Series Instructions for use

60 Ft Diameter Alpha Bin (14
Rings and Taller)
Models:
40-SERIES 4.00 IN. CORRUGATION BINS
30000 LB. PEAK LOAD ROOF WITH 40-
SERIES STIFFENERS
Construction Manual
PNEG-4460A
Version 1.0
Date: 02-26-15
PNEG-4460A

All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
2Pneg-4460A 60 Ft Diameter 40-Series Bins

Contents
Chapter 1 Safety Precautions ....................................................................................................................7
Safety Guidelines........................................................................................................................7
Cautionary Symbols ....................................................................................................................9
Safety Decals ...........................................................................................................................10
Safety Sign-off Sheet.................................................................................................................13
Chapter 2 General Overview....................................................................................................................15
General Information...................................................................................................................15
Anchor Bolt Detail .....................................................................................................................16
Anchor Bolt Charts ....................................................................................................................16
Tools Required for Construction..................................................................................................18
Guidelines for Proper Storage of Grain Bin Materials Prior to Construction.....................................18
Overview for a Typical Bin Installation .........................................................................................19
Guidelines for Construction Procedures and Lifting Jack Usage....................................................19
Guidelines for Placement of the Decal Sidewall Sheet..................................................................20
Chapter 3 Hardware requirements...........................................................................................................21
Bolt and Nut Pairings.................................................................................................................21
Hardware for Sidewall Sheets on 4 in. Corrugation Bins ...............................................................22
Bolt Torque Specifications..........................................................................................................22
Identifying Bolt Grades ..............................................................................................................23
Color Chart for Bin Hardware Bucket Lids ...................................................................................24
Bolt Identification.......................................................................................................................25
Bolt S-7482...............................................................................................................................25
Bolt S-10260.............................................................................................................................25
Bolt S-7483...............................................................................................................................25
Bolt S-7485...............................................................................................................................26
Bolt S-7487...............................................................................................................................26
Bolt S-7488...............................................................................................................................26
Bolt S-10250.............................................................................................................................27
Bolt S-10261.............................................................................................................................27
Chapter 4 Assembling Sidewall Sheets ...................................................................................................29
Guidelines for Constructing Sidewall Sheets ...............................................................................29
Color Codes for Sidewall Gauge Identification .............................................................................29
Orientation Detail for Top Sidewall Sheets ................................................................................... 30
Caulking and Bolting Detail for Standard Sidewall Sheets.............................................................31
Chapter 5 Base Angle Installation ...........................................................................................................33
Installing the Base Angle............................................................................................................33
Installing the Base Angle Shims .................................................................................................35
Anchor Bolt Washer Installation..................................................................................................36
Chapter 6 Stiffeners.................................................................................................................................37
Stiffener Starting Location..........................................................................................................38
Stiffener Splice Location ............................................................................................................39
Stiffener Part Number Description ..............................................................................................40
Color Codes for Stiffener Gauge Identification .............................................................................40
Standard Stiffeners....................................................................................................................41
Top Stiffeners............................................................................................................................42
Stiffeners Splice ........................................................................................................................43
Base Stiffeners .........................................................................................................................44
Base Boots ...............................................................................................................................45
One-Ring Top Stiffener (16 Ga) to a Two-Ring Stiffener (16 Ga)....................................................46
One-Ring Top Stiffener (15–16 Ga) to a Two-Ring Stiffener (16 Ga) ..............................................46
One-Ring Top Stiffener (15–16 Ga) to a Two-Ring Stiffener (8–14 Ga) ..........................................47
Two-Ring Stiffener (15-16 Ga) to a Two-Ring Stiffener (15–16 Ga)................................................47
Two-Ring Stiffener (8–14 Ga) to a Two-Ring Stiffener (8–14 Ga) Connection .................................48
Pneg-4460A 60 Ft Diameter 40-Series Bins 3

Two-Ring Stiffener (8–14 Ga) to a Two-Ring Stiffener (2–6 Ga) Connection ...................................48
Two-Ring Stiffener (8–14 Ga) to a Base Stiffener (8 Ga)...............................................................49
Two-Ring Stiffener (8–14 Ga) to a Base Stiffener (10–16 Ga) Connection......................................49
Two-Ring Stiffener (2–6 Ga) to a Base Stiffener (2–6 Ga) .............................................................50
Two-Ring Stiffener (15–16 Ga) to a Base Stiffener (10–16 Ga)......................................................50
Two-Ring Stiffener (2–6 Ga) to a Laminated Stiffener (2 Ga) with an Insert (10–12 Ga)...................51
Laminated Stiffeners (2 Ga) with Inserts (10–12 Ga) ....................................................................51
Laminated Stiffener (2 Ga) with an Insert (10–12 Ga) to a Laminated Base Stiffener (2 Ga) with
a Base Insert (2–12 Ga).................................................................................................52
Base Stiffener (10–16 Ga) to a Base Boot ...................................................................................52
Base Stiffener (2+12 Ga – 8 Ga) to a Base Boot ..........................................................................53
Laminated Base Stiffener (2 Ga) with Insert (2+12 to 2+10 Ga) to a Base Boot ..............................53
Standard Stiffener to a 12–Bolt Pattern Laminated Stiffener with Insert..........................................54
12–Bolt Pattern Laminated Stiffeners with Insert..........................................................................54
12–Bolt Pattern Laminated Stiffener to Laminated Base Stiffener with Inserts to a Base
Boot .............................................................................................................................55
12–Bolt Pattern Laminated Stiffener to Laminated Base Stiffener with an Inserts to a Base
Boot .............................................................................................................................56
Chapter 7 Door Assembly........................................................................................................................57
Door Assembly for Bins with 16 Rings and Shorter Heights ..........................................................57
Door Assembly for Bins with 17 Rings and Taller Heights .............................................................66
Chapter 8 Roof Assembly........................................................................................................................81
Attaching the Inside Stiffener to the Top Outside Stiffener.............................................................82
Attaching the Eave Bracket to the Inside Stiffener ........................................................................83
Attaching the Eave Angle to the Sidewall Sheet ...........................................................................84
Connecting the Tension Member to the Eave Bracket...................................................................86
Assembling a Laminated Rafter..................................................................................................87
Attaching the Center Collar Rafter Clips to the Rafter ...................................................................88
About Temperature Cable Brackets and A-Frame Assemblies ......................................................89
Assembling the Temperature Cable Bracket ................................................................................91
Attachment Locations of Purlins to Rafters ..................................................................................94
Assembling Purlin Number 5 ......................................................................................................95
Assembling Purlin Number 4 ......................................................................................................97
Assembling Purlin Number 3 ......................................................................................................99
Assembling Purlin Number 2 .................................................................................................... 101
Assembling Purlin Number 1 .................................................................................................... 103
Assembling the Center Collar................................................................................................... 105
Center Collar Placement.......................................................................................................... 114
Guidelines for Assembling and Lifting the A-Frame Rafter Sections............................................. 115
Attaching the A-Frames to the Center Collar.............................................................................. 117
Attaching the A-Frame to the Eave Bracket ............................................................................... 118
Installing the Intermediate Purlins ............................................................................................. 119
Attaching the Roof Panels........................................................................................................120
Installing the Roof Flashing ......................................................................................................124
Installing the Cap Plates Assembly ........................................................................................... 126
Installing the Conveyor Support Brackets to the Peak Cap ......................................................... 129
Chapter 9 Accessories ..........................................................................................................................131
Installing Roof Ladder Steps ....................................................................................................132
Roof Ring Placement...............................................................................................................134
Installing a Roof Ring...............................................................................................................135
Installation of Peak –To – Exhauster Ladder Kit ......................................................................... 137
Preparation for Roof Exhauster Installation................................................................................ 138
Assembly of Roof Exhauster .................................................................................................... 141
Installing Roof Exhauster Assembly.......................................................................................... 142
Installing the Manway Cover ....................................................................................................144
Installing the Center Collar Dome Cap (Optional)....................................................................... 146
4Pneg-4460A 60 Ft Diameter 40-Series Bins

Ladder Section Assembly ........................................................................................................ 149
Inside Ladder Placement .........................................................................................................150
Installing Inside Ladder Bottom Bracket .................................................................................... 153
Guidelines for Installing a Sidedraw System .............................................................................. 154
Locating the Chutes................................................................................................................. 156
Locating Discharge Opening .................................................................................................... 157
Sidewall Overlap .....................................................................................................................158
Caulking ................................................................................................................................. 159
Installing Wind Rings ...............................................................................................................160
Assembling Weather Cover for Roller Valve .............................................................................. 162
GSI Group, LLC Limited Warranty ......................................................................................... 163
Pneg-4460A 60 Ft Diameter 40-Series Bins 5

NOTES
6Pneg-4460A 60 Ft Diameter 40-Series Bins

1Safety Precautions
Topics Covered in this Chapter
▪ Safety Guidelines
▪ Cautionary Symbols
▪ Safety Decals
▪ Safety Sign-off Sheet
Safety Guidelines
Safety guidelines are general-to-specific safety rules that must be respected at all times in the grain stor-
age environment.
Our foremost concern is your safety and the safety of others associated with grain handling equipment.
This manual is to help you understand safe operating procedures and some problems that can be
encountered by the operator and other personnel.
As owner and/or operator, you are responsible to know what requirements, hazards, and precautions
exist and inform all personnel associated with the equipment or in the area. Avoid any alterations to the
equipment. It can produce a very dangerous situation, where SERIOUS INJURY or DEATH can occur.
This equipment shall be installed in accordance with the current installation codes and applicable regula-
tions, which should be carefully followed in all cases. Authorities having jurisdiction must be consulted
before installations are made.
You should consider the location of the bin site relative to power line locations or electrical transmission
equipment. Contact your local power company to review your installation plan or for information concern-
ing required equipment clearance. Clearance of portable equipment that can be taken to the bin site must
also be reviewed and considered. Any electrical control equipment in contact with the bin must be prop-
erly grounded and installed in accordance with National Electric Code provisions and all local codes.
This product is intended for the use of grain storage only. Any other use is a misuse of the product.
CAUTION
This product has sharp edges, which may cause serious injury. To avoid injury,
handle sharp edges with caution and always use proper protective clothing and
equipment.
Sidewall bundles or sheets must be stored in a safe manner. The safest method of storing sidewall bun-
dles is laying horizontally with the arch of the sheet upward, like a dome. Sidewall sheets stored on edge
must be secured so that they cannot fall over and cause injury. Use care when handling and moving side-
wall bundles.
Personnel operating or working around equipment must read this manual. This manual must be delivered
with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the
equipment.
Pneg-4460A 60 Ft Diameter 40-Series Bins 7

Chapter 1: Safety Precautions
Follow Safety Instructions — Read and Understand Manual
• Carefully read all safety messages in this manual and safety
signs on your machine. Keep signs in good condition.
Replace missing or damaged safety signs. Be sure new
equipment components and repair parts include the current
safety signs. Replacement safety signs are available from
the manufacturer.
• Learn how to operate the machine and how to use controls
properly. Do not let anyone operate without instruction.
• Keep your machinery in proper working condition. Unauthor-
ized modifications to the machine can impair the function
and/or safety and affect machine life.
• If you do not understand any part of this manual or need
assistance, contact your dealer.
Practice Safe Maintenance — Maintain Equipment and Work
Area
• Understand service procedures before doing work. Keep
area clean and dry.
• Never lubricate, service, or adjust machine while it is in oper-
ation. Keep hands, feet, and clothing away from rotating
parts.
• Keep all parts in good condition and properly installed. Fix
damage immediately. Replace worn or broken parts.
Remove any built-up grease, oil, and debris.
Prepare for Emergencies — Keep Emergency Equipment
Accessible
• Be prepared if fire starts.
• Keep a first aid kit and fire extinguisher handy.
• Keep emergency numbers for doctors, ambulance service,
hospital, and fire department near your telephone.
Wear Protective Clothing
• Wear close-fitting clothing and safety equipment appropri-
ate to the job.
• Remove all jewelry
• Tie long hair up and back.
• Wear safety glasses at all times to protect eyes from
debris.
Eye Protection
8Pneg-4460A 60 Ft Diameter 40-Series Bins

Chapter 1: Safety Precautions
• Wear gloves to protect your hands from sharp edges on
plastic or steel parts.
Gloves
• Wear steel-toed boots to help protect your feet from falling
debris. Tuck in any loose or dangling shoestrings.
Steel-Toed Boots
• A respirator may be needed to prevent breathing poten-
tially toxic fumes and dust.
Respirator
• Wear a hard hat to help protect your head. Hard Hat
• Wear appropriate fall protection equipment when working
at elevations greater than 6 ft (1.8 m).
Fall Protection
Cautionary Symbols
Cautionary symbols appear in the various decals of your product, and alerts the user of potential or immi-
nent risk of danger.
This manual contains information that is important for you, the owner/operator, to know and understand.
This information relates to protecting personal safety and preventing equipment problems.
It is the responsibility of the owner/operator to inform anyone operating or working in the area of this
equipment of these safety guidelines. To help you recognize this information, we use the symbols that are
defined below. Please read the manual and pay attention to these sections. Failure to read this manual
and its safety instructions is a misuse of the equipment and may lead to serious injury or death.
DANGER
Make sure to familiarize yourself with these symbols prior to installing, operating, or
servicing your grain equipment. Failure to do so may lead to serious injury or death.
Table 1-1 Description of the different cautionary symbols
Symbol Description
This symbol indicates an imminently hazardous situation which, if
not avoided, will result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, may result in serious injury or death.
Pneg-4460A 60 Ft Diameter 40-Series Bins 9

Chapter 1: Safety Precautions
Table 1-1 Description of the different cautionary symbols (cont'd.)
Symbol Description
This symbol indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
This symbol indicates a potentially hazardous situation which, if not
avoided, may result in property damage.
Safety Decals
The safety decals on your grain equipment are safety indicators which must be carefully read and under-
stood by all personnel involved in the installation, operation, service, and maintenance of the grain
equipment.
The manufacturer does not warrant any roof damage caused by excessive vacuum or internal pressure
from fans or other air moving systems. Adequate ventilation and/or “makeup air” devices should be pro-
vided for all powered air handling systems. The manufacturer does not recommend the use of downward
flow systems (suction). Severe roof damage can result from any blockage of air passages. Running fans
during high humidity and cold weather conditions can cause air exhaust or intake ports to freeze.
10 Pneg-4460A 60 Ft Diameter 40-Series Bins

Chapter 1: Safety Precautions
ATTENTION: Decal shown below must be present on the outside of the door cover of the two ring, 24 in.
(61 cm) porthole door cover and the roof manway cover. If a decal has been damaged or is missing in any
of these locations, contact the manufacturer for a free replacement decal.
GSI Decals
1004 E. Illinois Street
Assumption, IL 62510
Phone: [phone]
Pneg-4460A 60 Ft Diameter 40-Series Bins 11

Chapter 1: Safety Precautions
ATTENTION: Decal shown below must be present on the outside of the door cover of the two ring, 24 in.
(61 cm) porthole door cover and the roof manway cover. If a decal has been damaged or is missing in any
of these locations, contact the manufacturer for a free replacement decal.
GSI Decals
1004 E. Illinois Street
Assumption, IL 62510
Phone: [phone]
12 Pneg-4460A 60 Ft Diameter 40-Series Bins

Chapter 1: Safety Precautions
Safety Sign-off Sheet
Sign-off sheet verifying that all personnel have read and understood the safety instructions.
As a requirement of O.S.H.A., it is necessary for the employer to train the employee in the safe operating
and safety procedures for this equipment. This sign-off sheet is provided for your convenience and per-
sonal record keeping. All unqualified persons must stay out of the work area at all times. It is strongly rec-
ommended that another qualified person who knows the shutoff procedure be in the area in the event of
an emergency.
Date Employee Name Supervisor Name
Pneg-4460A 60 Ft Diameter 40-Series Bins 13

NOTES
14 Pneg-4460A 60 Ft Diameter 40-Series Bins

2General Overview
Topics Covered in this Chapter
▪ General Information
▪ Anchor Bolt Detail
▪ Anchor Bolt Charts
▪ Tools Required for Construction
▪ Guidelines for Proper Storage of Grain Bin Materials Prior to Construction
▪ Overview for a Typical Bin Installation
▪ Guidelines for Construction Procedures and Lifting Jack Usage
▪ Guidelines for Placement of the Decal Sidewall Sheet
General Information
General information, overview and instructions needed before performing work.
Read this manual carefully. This manual will provide instructions on building the sidewall and stiffeners.
You will also need to consult other instructions in building the bin.
These include, but may not be limited to:
• A stiffener and sidewall gauge layout chart. If such a chart is not included with this manual, contact
GSI.
• Roof instructions must be followed. Roof instructions are included in this manual.
• Ladders, roof stairs, roof handrails and other products are covered by separate instruction manuals.
Consult the appropriate accessory manual. Inside ladder instructions are included in this manual.
• Aeration systems and transitions are to be installed according to the instructions provided with the
system or transition.
• It is critical that the anchor bolts are installed and spaced correctly.
Pneg-4460A 60 Ft Diameter 40-Series Bins 15

Chapter 2: General Overview
Anchor Bolt Detail
The following is the minimum requirement for anchoring of standard tanks. Refer to sidedraw instructions
for special anchoring details.
• 5/8 in. diameter anchor bolt (A) is the minimum allowed, 3/4 in. diameter anchor bolt (A) is the mini-
mum with side draw flume system.
• Exposed anchor bolt thread height (B ) for 5/8 in. and 3/4 in. diameter anchor bolts are 3 in. (7.6 cm)
and 5 in. (12.7 cm) respectively.
• Overall anchor bolt length (C) for 5/8 in. and 3/4 in. diameter anchor bolts are 14 in. (35.56 cm) and
18 in. (45.72 cm) respectively.
Figure 2-1 Anchor bolt example (3/4 in. diameter anchor bolt shown)
A Anchor bolt C Anchor bolt length
BAnchor bolt thread height
Anchor Bolt Charts
Prior to setting any anchor bolts, you must be sure to have the correct anchor bolt placement. This is very
critical for stiffener alignment during bin erection.
NOTE: Refer to the proper chart to find the anchor chord dimensions that correspond to the bin that is
being built.
Start with one anchor bolt and work from it to the left to locate one quarter of the anchor bolts then to the
right to locate another quarter of the bolts. Working off of the last anchor bolts in each quarter, locate the
remaining anchor bolts in the last two quarters.
16 Pneg-4460A 60 Ft Diameter 40-Series Bins

Chapter 2: General Overview
Figure 2-2 Anchor bolt chords for 60 ft. diameter 2–post bin
Bolt Radius (B) Anchor Quantity
ft and in m
30 – 2-7/8 9.217 40
Chord (A) Length
ft and in m
1 4 – 9 1.448
2 9 – 5-9/16 2.884
3 14 – 1-7/16 4.304
4 18 – 8-5/16 5.698
5 23 – 1-3/4 7.055
Chord (A) Length
ft and in m
6 27 – 5-1/2 8.369
7 31 – 7-1/4 9.633
8 35 – 6-5/8 10.836
9 39 – 3-3/8 11.973
10 42 – 9-3/16 13.035
Pneg-4460A 60 Ft Diameter 40-Series Bins 17

Chapter 2: General Overview
Tools Required for Construction
General tools needed to perform this construction:
• Combination wrench set 7/16 in. to 1 in.
• Alignment punches 12 in. long
• 1/2 in. Drive socket set and ratchet
• Nail aprons or tool pouches to hold supplies
• Gloves for hand protection
• Tape measure
• 1/2 in. Drive electric or pneumatic torque gun with variable impact capabilities
• 1/2 in. Drive impact socket set
• Lifting jacks
• Center pole roof support
• Step ladders
• Large C-clamp or welding V-grip for clamping
NOTE: Quantities required will depend on the number of workers and size of the bin.
Guidelines for Proper Storage of Grain Bin Materials Prior to
Construction
Storage of the build materials prior to construction is important. Do not to allow moisture to remain
between sheets or panels.
Wet storage stain (rust) will develop when closely packed bundles of galvanized material, such as side-
wall and roof sheets, have moisture present. Inspect roof and sidewall bundles on arrival for any moisture.
If moisture is present, it must not be allowed to remain between the sheets. Separate the sheets or
panels immediately and wipe them down. Spray with a light oil or diesel fuel.
If possible, sidewall bundles, roof sheets and other closely packed galvanized materials should be stored
in a dry, climate controlled building. If outdoor storage is unavoidable, the materials should be stored so
that they are raised above the ground and vegetation. Any stacking and spacing materials should not be
corrosive or wet. Be sure to protect materials from the weather, but permit air movement around the bun-
dles if possible.
Storing roof bundles and sidewall sheets at a slight incline can also help minimize the presence of mois-
ture. Storing the bundles with the center of the dome up (like an arch) is one option for minimizing mois-
ture during storage. Sidewall bundles can also be stored on edge but must be secured so that they do not
fall over and cause injury.
If “white rust” or “wet storage stain” occurs, contact the manufacturer immediately about ways to minimize
the adverse effect upon the galvanized coating.
18 Pneg-4460A 60 Ft Diameter 40-Series Bins

Chapter 2: General Overview
Overview for a Typical Bin Installation
These are the typical steps one would perform when constructing a grain bin. Procedures may vary
depending on the different site requirements.
Pre-Assembly Activities
• Sorting and grouping parts
• Assemble center collar and cap plates
• Install vent to roof panels
• Assemble the rafter clips to rafters on the ground
• Install wind ring bracket to the stiffeners
Guidelines for Construction Procedures and Lifting Jack Usage
The following procedure is a guideline when using a lifting jack. Follow this general guideline when lifting
the bin as sidewall sheets are being installed.
NOTE: The roof and the top ring for odd ringed bins or the roof and two rings for even ringed bins, will be
installed prior to the beginning of bin lifting procedures. Refer to all other procedures on sidewall
and stiffener installation prior to the start of construction.
IMPORTANT: Begin building with the bin oriented for doors and material handling equipment to be in the
correct position when bin construction is complete.
1. Consider the starting location of the bin, relative to the location of the doors and other accessories.
Proper placement of lifting jacks in relationship to anchor bolts could make a difference in final loca-
tions. Note that the sidewall sheets will be staggered.
2. The bin is lifted by the use of lifting jacks. Lifting jacks are used to slowly and evenly lift the bin
during construction. Lifting jacks must be properly sized and designed to carry all loads and job site
conditions associated with the construction of the bin.
The number of lifting jacks required is best determined by personal experience and expertise. Fac-
tors such as bin size, jack design, construction conditions, support surface, etc., are all to be consid-
ered when deciding how many to use. If in doubt, use one jack on every sheet. The lifting jack must
be adequate to carry all loads. Heavy duty jacks, generally hydraulic or electric powered in the case
of large bins, should be used for commercial installation. All jacks should be secured with braces or
otherwise maintained in a stable condition.
Lifting of the bins should not be done under windy conditions.
Follow the jack manufacturers recommendations on capacity and operations.
3. Lifting brackets should be attached through the stiffener bolt holes. Normally you will need to attach
to at least four (4) bolts per stiffener.
4. Raise the bin just high enough to assemble the next ring. When lifting the bin, all jacks must lift at
an equal rate. Monitor the lift to ensure even lifting is occurring.
5. To the inside of the first ring, bolt the next ring. Be sure to stagger the sheets and select the proper
gauge material.
6. Lower the bin onto the foundation after assembling and tightening bolts on the new ring or rings.
7. Attach stiffeners to the body sheets every two (2) tiers (on the external surface of the bin). You may
want to leave sheets loose to make the attachment of the stiffeners easier.
Pneg-4460A 60 Ft Diameter 40-Series Bins 19

Chapter 2: General Overview
8. Now re-bolt the lifting brackets to the lowest ring in place thus far. Continue ring additions by repeat-
ing Step 5 and Step 6.
9. Add inside and outside ladders as you continue to raise the bin. (Refer to the manual supplied with
the ladders and platforms.)
10.Add platforms as you raise the bin. (Refer to the manual supplied with the ladders and platforms.)
11.Lower the tank and secure to the foundation before leaving the job site.
12.At the completion of the tank, set stiffeners over the anchor bolts and measure the tank to ensure it
is in a round condition. Consult with GSI for questions on tolerances.
Guidelines for Placement of the Decal Sidewall Sheet
Use the following as a general guideline the proper decal sheet placement.
NOTE: Refer to the stiffener to sidewall attachment detail and specific gauge sheet for the bin. The decal
sheets are located in the first ring from the top. They are to be spaced evenly around the diameter
of the bin.
Figure 2-3 Decal sidewall sheet
NOTE: Stiffener locations are represented with thick lines.
20 Pneg-4460A 60 Ft Diameter 40-Series Bins
