CONNECTION AND SETUP
1
1. CONNECTION AND SETUP
Before the DVR is powered on, make sure you have installed a hard disk, connected at least one camera and a
HDMI monitor. For details, please refer to the following sections.
Note: The DVR is designed to automatically detect the video system of the connected cameras (NTSC
or PAL). To make sure the system detection is correct, please check if the cameras are connected
to the DVR and power-supplied before the DVR is powered on.
1.1 SATA Hard Disk Installation
A hard disk is necessary for the recorder to save video footage, and firmware upgrade might be failed if there’s
no hard disk installed in this recorder.
Note: Here takes a 8CH model as an example of how to connect a hard disk to your device. To know
how many hard disks could be installed, please refer to the specifications of your device.
Step1: Remove the top cover, and find the hard disk connector and bracket in the device.
CR2032
Hard Disk
Connector
Bracket
Step2: Get a compatible hard disk. With the PCB side facing down, insert the hard disk to one of the hard disk
connector.
Note: To use a green hard disk, use ONLY the hard disk designed especially for surveillance to ensure
the device works properly.
CR2032
Hard Disk

CONNECTION AND SETUP
2
Step3: Fasten the hard disk to the bracket by securing the screw on the bracket.
CR2032
Hard Disk
Step4: Replace the top cover and fasten the screws you loosened in Step1.
1.2 Camera Connection
Install the camera on the wall or ceiling based on your installation environment and camera type. For installation
details, please refer to the user manual of your camera.
1.2.1 Normal / Motorized Lens Camera
1) Connecting to DVR video input
Connect the camera video output to the DVR video input port with a coaxial cable or RCA line with a BNC
connector.
2) Connecting to DVR audio input (Optional)
Connect the camera audio output to the DVR audio input port with a coaxial cable or RCA cable.
3) Connecting to power
Connect the camera with indicated power supply and make sure it’s power-supplied.
1.2.2 Speed Dome Camera
The following description is taking our brand’s speed dome camera as an example.
Note: The RS485 wiring is not needed when your DVR and speed dome camera are both our HD CCTV
series. If yes, please go to STEP 5 directly for PTZ camera setting.
Note: Speed dome camera connection for non-HD CCTV series is available only for selected DVR
models.
STEP 1: Get a RJ11 cable with the proper length to your connection.
Different RJ11 connector may have different wire layout, so the connection might be different. If you
cannot control the DVR after connection, please reverse the RJ11 cable connection with the DVR.
STEP 2: Remove one end of the insulating coating of the RJ11 cable.
Remove one end of the insulating coating of the RJ11 cable to find the RS485-A and the RS485-B wires,
and remove the insulating coating to reveal the naked wires for further connection.

CONNECTION AND SETUP
3
STEP 3: Twist the RS485-A and RS485-B wires of the RJ11 cable and the speed dome camera together.
Twist the RS485-A (red) and RS485-B (green) wires of the RJ11 cable to the RS485-A (brown) and
RS485-B (orange) wires of the speed dome camera. To protect the naked wires, use the insulation tape
to cover on the twisted wires.
STEP 4: Connect the other end of the RJ11 cable to DVR.
Solder the RS485-A (red) and RS485-B (green) wires of the RJ11 cable to the corresponding pins on the
DVR rear panel.
STEP 5: Set the camera at the DVR side.
Right click to show the main menu in the live view, and go to “ ” (ADVANCED CONFIG) “DEVICES”
to set the camera.
a) Select the device to “PTZ”.
b) Set the ID to the value the same as the one set in the camera. The default ID of the camera is 000.
c) Select the protocol to “NORMAL”.
d) Set the baud rate to the value the same as the one set in the camera. The default baud rate of the
camera is 2400.
ADVANCED CONFIG
C A M E R A CH1 CH2
CH3
CH4
DETECTION DEVICE PTZ

ALERT
ID 000
NETWORK PROTOCOL NORMAL

DISPLAY
RATE 2400

RECORD
DEVICES
DCCS
IVS
NOTIFY
EXIT
1.3 External Device Connection
Some DVR models support external device connection with RS485 and alarm I/O ports, allowing users to connect
control devices such as a keyboard controller, or connect alarm devices such as a magnetic contact or buzzer.
Check the user manual of your external device to know which pin(s) should be used, and connect it to the
corresponding pins on the DVR rear panel.
1.4 DVR Power On
This device should be operated only with the type of power source indicated on the manufacturer’s label. Connect
the indicated AC power cord to the power adapter, and plug into an electrical outlet.
If your device has a power switch on the rear panel, turn it to “—“. The power LED will be on. If your device doesn’t
have a power switch on its rear panel, the power is on once the power source is connected.
Note: Before the DVR is powered on, make sure (1) the cameras are connected and power-supplied for
the detection of the camera video system to be correct, and (2) a HDMI monitor is connected to
the DVR for correct video output detection.
Note: To ensure that your DVR works constantly and properly, it's recommended to use an UPS,
Uninterruptible Power Supply (Optional), for continuously operation.

CONNECTION AND SETUP
4
1.5 Date and Time Setting
Before operating your DVR, please set the date and time on your DVR FIRST.
Note: Please DO NOT change the date or time of your DVR after the recording function is activated.
Otherwise, the recorded data will be disordered and you will not be able to find the recorded file
to backup by time search. If users change the date or time accidentally when the recording
function is activated, it’s recommended to clear all HDD data, and start recording again.
Note: For the first time to use the DVR, please power it on for at least 48 hours continuously after the
date & time is set correctly. It helps to prevent DVR time from resetting after the disconnecting of
DVR power. If the DVR time resets after the disconnecting of DVR power, for example, caused by
a power outage, the battery might run out and please replace the battery as described in
“APPENDIX 8 DVR BATTERY REPLACEMENT” in the user manual.
Right-click to enter the DVR password with the password keypad. The default administrator password is admin.
The status will be changed from (key lock) to (unlock). Then, right-click to show the main menu, and
select (QUICK START) “TIME SETUP” to set the date & time.
QUICK START
GENERAL DATE 2009 / NOV / 17
TIME SETUP TIME 15 : 35 : 53
DAYLIGHT NTP SERVER pool.ntp.org
EaZy FORMAT Y/M/D
SYNC PERIOD OFF
GMT (GMT + 8:00) TAIPEI
EXIT
1.6 Clear Hard Disk
It’s recommended to clear all data in the hard disk for the first time to user this DVR to ensure the recorded data
are not mixed with other data previously saved in the same hard disk.
Right-click to show the main menu, and select (SYSTEM) “SYSTEM INFO” “CLEAR HDD”. The DVR
will reboot when hard disk data are cleared.
SYSTEM
ACCOUNT BAUD RATE 2400 
TOOLS HOST ID 000
SYSTEM INFO R.E.T.R 5 
BACKUP DATA AUTO KEY LOCK(S) NEVER 
BACKUP LOG CLEAR HDD HDD-0 
REGULAR REPORT RESET DEFAULT SUBMIT
REMOTE CONTROL ID 000
DEVICE TITLE OFFICE
SERIAL TYPE RS485
VIDEO FORMAT NTSC
VERSION 1019-1008-1010-1010
EXIT

CONNECTION AND SETUP
5
1.7 Password Setting
Right-click to show the main menu, and select (SYSTEM) “ACCOUNT” to change the default password of
SUPERVISOR.
There are four user levels for different access privileges: SUPERVISOR, POWER USER, NORMAL & GUEST.
For details, please refer to “4.2 User Level Creation” at page 19.
SYSTEM
ACCOUNT USER LIST
TOOLS USER NAME LEVEL
SYSTEM INFO admin SUPERVISOR
BACKUP DATA power POWER USER
BACKUP LOG normal NORMAL
REGULAR REPORT guest GUEST
EXIT ADD EDIT DEL
1.8 EaZy Networking (For selected models only)
EaZy Networking is a cloud service to connect your devices to the Internet automatically through our free mobile
app, EagleEyes, in a few steps without going through the complicated network setup including port forwarding.
Note: EaZy Networking is not a free service. We will initially provide 2GB data allowance (approx. 2185
minutes) for free. When 2GB is up, the network transmission will be down to 1 FPS. To restore the
fluency of live view, users need to subscribe a data plan from EagleEyes, or configure the network
settings by themselves.
To connect this recorder to the Internet without using EaZy Networking, get the network setup
manual from www.surveillance-download.com/user/t204.swf.
Note: Data allowance is consumed only when the device access is made via Internet, 3G mobile network,
and the network different from the device is used.
1.8.1 Setup
Before using this function, make sure:
This DVR is connected to a switch or router, and the switch or router is ready for Internet connection.
You have an iOS or Android mobile device.
Our mobile app, EagleEyes, is installed in your mobile device.
Step1: Right-click to show the main menu, and select “QUICK START” “EaZy”.
Step2: Enable EaZy Networking, and leave this page open. You’ll need to scan the QR code later.
QUICK START
GENERAL ENABLE EAZY NETWORKING ON
TIME SETUP
DAYLIGHT
EaZy
EXIT

CONNECTION AND SETUP
6
Step3: Open EagleEyes on your mobile device, and select “…” on the top left corner in the address book. Then,
click “ ”.
Step4: Click “Login” in the section of “Cloud” and register an account for “Cloud Service”. If you’ve got an account,
please just log in.
Step5: Go back to the address book and click “+” to add a new device.
There are two methods to add new devices, “EaZy” and “Manual”.
Select “EaZy”, and choose the DVR icon to continue.

CONNECTION AND SETUP
7
Step6: Click “ ” in the section of “MAC address” to open the QR code scan page, and scan the QR code on the
DVR screen mentioned in Step2. The MAC address will be filled automatically.
Fill in the Captcha code manually, and click “Apply”.
Step7: Follow the on-screen instruction to finish the rest of the settings, and see if this device is added
successfully to the address book as a cloud device.
When the device is added successfully to the cloud service, the DVR will also prompt a message,
indicating the device is added successfully.
Step8: Click the newly-added device and see if you could access successfully.
1.8.2 Checking Remaining Data Allowance
To know how much data allowance is left:
Step1: Log into the cloud service.
Step2: Select “Details” to go to account information, and select “Available Data Allowance”.

CONNECTION AND SETUP
8
1.8.3 Sharing Cloud Device Access to Other Account(s)
Note: One cloud device could be shared up to 30 cloud accounts, but the access to the device might be
failed because it is still restricted to the maximum online user setup of the device. i.e.
To allow other account to access your cloud device:
Step1: Log into the cloud service.
Step2: Select “Buddy” to go to the buddy sharing page. Then, choose the cloud device you want to share, and
click “Share to Buddy”.
Step3: Enter the cloud account or the E-mail registered by the account, and select “Add”.

CONNECTION AND SETUP
9
Step4: Check again the account to which you want to share your cloud device, and select “Next” to confirm and
continue.
Step5: Specify the access permission of the specified account, which account’s data allowance should be
consumed after access successfully, and how long the account is allowed to stay after access successfully.
Step6: Check again the configurations you made for the account to which you want to share your cloud device,
and select “Share!” to confirm.

CONNECTION AND SETUP
10

USER INTERFACE
11
2. USER INTERFACE
2.1 DVR Access
Connect your USB mouse to one of the USB ports on the DVR front panel, and check if there’s a mouse icon ( )
on the screen, indicating the USB mouse is detected properly.
Move your mouse to enter the DVR password with the password keypad. The default user name and password
are both “admin”. The status will be changed from (key lock) to (unlock).
Note: You may configure four different user levels to have different access privileges in “SYSTEM” 
“ACCOUNT”. For details, please refer to “4.2 User Level Creation” at page 19.
Password Input
2.2 Live Page
2.1.1 DVR Status
Note: Certain icons are for selected models only.
Key lock Key unlock
Overwrite on Overwrite off
Internet disconnected Internet connected
Local connection USB mouse connected
USB flash drive / device connected No USB device connected
IVS on
Timer record on Timer record off
PTZ mode on PTZ mode off
Sequence mode on Sequence mode off

USER INTERFACE
12
2.1.2 Channel Status
Note: Certain icons are for selected models only.
Live audio on Audio off Audio playback on Audio playback off
Recording PTZ control Motion event Alarm event
PIR event Virtual fence event One way pass event Scene Change event
2.1.3 Record-related Icons
1) Manual Recording
By defaults, manual recording is on ( ) when the DVR is powered on and a hard disk is installed.
2) Event Recording
The event icons, / / / / / , show on the channel status bar when their respective
events occur and the related record function is on.
3) Timer Recording
When timer recording is on, you will see “ ” on the screen.
4) HDD Overwritten
Be defaults, the HDD overwritten function is set to ON, and “ ” will be shown on the screen.
Note: To disable this function, right click to display the main menu in the live view, and go to “ ”
(ADVANCED CONFIG.) “RECORD” “OVERWRITE”.
2.3 Quick Menu Bar
Move to the arrow mark to extend the quick menu bar and show the five functions as follows:
Quick Menu: Open
Click to show the channel switch panel and select the channel you
want.
Click to display the playback control panel, and click to play the
latest recorded video clip, or click to enter the search list.
Switch to the channel you want first, and click to enter the zoom-in
mode. In this mode, click and drag the red frame on the bottom left of
the screen to move to the place you want to see. To exit this mode,
click .
Click to show the power off panel to either halt or reboot the system.

USER INTERFACE
13
2.4 Main Menu
Right-click anywhere on the screen to show the main menu as follows, and right-click again to exit.
Main Menu
QUICK START Click to set the status display, image settings,
and date & time.
SYSTEM Click to set the system configurations.
EVENT INFORMATION Click to enter the event search menu.
ADVANCED CONFIG
Click to set CAMERA, DETECTION, ALERT,
NETWORK, DISPLAY, RECORD, DEVICES*,
DCCS, IVS* and NOTIFY*.
SCHEDULE SETTING Click to set timer for record, motion detection,
alarm (in and out), Push Video, and buzzer.
* For selected models only

USER INTERFACE
14
