AGI WESTFIELD MKX 13 Series User manual

Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
Part Number: 30796 R7
Revised: January 2020
Swing-Away Grain Auger
MKX 13
Assembly Manual
This manual applies to:
MKX 13-64, MKX 13-74
Original Instructions

New in this Manual
The following changes have been made in this revision of the manual:
Description Section
New spout design Section 4.11 – Install the Spout on page 33
Hubs pre-installed on axle Section 4.14 – Assemble the Frame on page 39
Added 15' swing tube assembly Section 4.19 – Install Low Profile Intake Hopper on
page 48
Transition pre-installed to swing tube Section 4.19 – Install Low Profile Intake Hopper on
page 48
Updated swing tube assembly Section 4.19 – Install Low Profile Intake Hopper on
page 48
New lift arm design Section 4.21 – Install the Hopper Lift Arm and Winch
on page 52
Modified 64' swing brackets Section 4.21 – Install the Hopper Lift Arm and Winch
on page 52
Added cable clamp instructions

SWING-AWAY GRAIN AUGER – MKX 13
30796 R7 3
CONTENTS
1. Introduction ............................................................................................................................................ 5
2. Safety....................................................................................................................................................... 6
2.1 Safety Alert Symbol and Signal Words...................................................................................... 6
2.2 General Product Safety ............................................................................................................. 6
2.3 Rotating Flighting Safety ........................................................................................................... 7
2.4 Rotating Parts Safety................................................................................................................. 7
2.5 Hand Winch Safety .................................................................................................................... 7
2.6 Hydraulic Winch Safety ............................................................................................................. 8
2.7 Drives and Lockout Safety......................................................................................................... 8
2.7.1 PTO Driveline Safety................................................................................................... 8
2.7.2 Hydraulic Power Safety .............................................................................................. 9
2.8 Tire Safety................................................................................................................................ 10
2.9 Personal Protective Equipment............................................................................................... 10
2.10 Safety Equipment .................................................................................................................. 11
2.11 Safety Decals ......................................................................................................................... 11
2.11.1 Decal Installation/Replacement............................................................................. 12
2.11.2 Safety Decal Locations and Details ........................................................................ 12
3. Features................................................................................................................................................. 22
4. Assembly ............................................................................................................................................... 24
4.1 Assembly Safety ...................................................................................................................... 24
4.2 Check Shipment....................................................................................................................... 24
4.3 Before You Begin ..................................................................................................................... 24
4.4 Brand and Model Decal Placement ........................................................................................ 25
4.5 Identify and Arrange Auger Tube Sections ............................................................................. 25
4.6 Install Hydraulic Lift Cylinders................................................................................................. 26
4.7 Connect Auger Tube Sections Together ................................................................................. 27
4.8 Install the Track Shoe, Trackstop, and Cable Roller................................................................ 28
4.9 Install the Boot on the Auger Tube......................................................................................... 31
4.10 Install the Boot Tow Bar........................................................................................................ 33
4.11 Install the Spout .................................................................................................................... 33
4.12 Set the Thrust Adjuster ......................................................................................................... 34
4.13 Install Truss Support Brackets and Truss Cables .................................................................. 34
4.14 Assemble the Frame.............................................................................................................. 39
4.15 Connect the Auger Tube to the Frame ................................................................................. 41
4.16 Install the Auger Tube Lift Cylinders and Cables .................................................................. 43
4.17 Connect Hydraulic Hoses and Ball Valve............................................................................... 44
4.18 Connect the PTO Driveline .................................................................................................... 47
4.19 Install Low Profile Intake Hopper.......................................................................................... 48
4.20 Install the Frame Deflector Plates......................................................................................... 51
4.21 Install the Hopper Lift Arm and Winch ................................................................................. 52
4.22 Hopper Transport Position.................................................................................................... 55
4.23 Install the Hitch Jack.............................................................................................................. 56
4.24 Install the Plastic Manual Container ..................................................................................... 57
5. Specifications ........................................................................................................................................ 58
6. Appendix ............................................................................................................................................... 59

SWING-AWAY GRAIN AUGER – MKX 13
4 30796 R7
6.1 Bolt Torque.............................................................................................................................. 59

30796 R7 5
11.. IInnttrroodduuccttiioonn
This manual describes how to assemble a Westfield Swing-Away Grain Auger.
Before assembling, please read this manual. Familiarize yourself with the process and the necessary
precautions for efficient and safe assembly.
Everyone present at the assembly site is required to be familiar with all safety precautions.
Keep this manual available for frequent reference and review it with new personnel. Call your local
distributor or dealer if you need assistance or additional information.
SWING-AWAY GRAIN AUGER – MKX 13 1. INTRODUCTION

6 30796 R7
22.. SSaaffeettyy
2.1. Safety Alert Symbol and Signal Words
This safety alert symbol indicates important safety messages in this manual. When you see
this symbol, be alert to the possibility of injury or death, carefully read the message that
follows, and inform others.
Signal Words: Note the use of the signal words DANGER,WARNING,CAUTION, and NOTICE with the safety
messages. The appropriate signal word for each message has been selected using the definitions below as a
guideline.
Indicates an imminently hazardous situation that, if not avoided, will result in serious injury or
death.
Indicates a hazardous situation that, if not avoided, could result in serious injury or death.
Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation that, if not avoided, may result in property damage.
2.2. General Product Safety
It is the owner, operator, and maintenance personnel's responsibility to read and understand all safety
instructions, safety decals, and manuals and follow them when operating or maintaining the equipment.
• Owners must give instructions and review the information initially and annually with
all personnel before allowing them in the work area. Untrained users/operators
expose themselves and bystanders to possible serious injury or death.
• Use for intended purposes only.
• Do not modify the auger in any way without written permission from the manufacturer. Unauthorized
modification may impair the function and/or safety. Any unauthorized modification will void the warranty.
• Follow a health and safety program for your worksite. Contact your local occupational health and safety
organization for information.
2. SAFETY SWING-AWAY GRAIN AUGER – MKX 13

30796 R7 7
2.3. Rotating Flighting Safety
• KEEP AWAY from rotating flighting.
• DO NOT remove or modify flighting guards, doors, or covers.
Keep in good working order. Have replaced if damaged.
• DO NOT operate the auger without all guards, doors, and
covers in place.
• NEVER touch the flighting. Use a stick or other tool to
remove an obstruction or clean out.
• Shut off and lock out power to adjust, service, or clean.
2.4. Rotating Parts Safety
• Keep body, hair, and clothing away from rotating pulleys,
belts, chains, and sprockets.
• Do not operate with any guard removed or modified. Keep
guards in good working order.
• Shut off and remove key or lock out power source before
inspecting or servicing machine.
2.5. Hand Winch Safety
When Equipped:
• Inspect lift cable before using. Replace if frayed or damaged. Make sure lift cable is seated
properly in cable sheaves and cable clamps are secure.
• Tighten brake lock by turning winch handle clockwise at least two clicks after lowering the
auger.
• Raise the swing hopper fully before towing.
• Do not lubricate winch brake discs.
SWING-AWAY GRAIN AUGER – MKX 13 2. SAFETY

8 30796 R7
2.6. Hydraulic Winch Safety
When Equipped:
• Keep away from rotating cable drum and winch cable. Do not touch or grab cable while
winch is being operated or use hands to guide the cable. Failure to heed could result in
serious injury.
• Inspect cable and cable clamps before installing and using hydraulic winch. Replace cable if
frayed or damaged. Tighten cable clamps if necessary.
• Do not continue to supply power to hydraulic winch after the swing hopper is fully lifted.
• Do not disconnect hydraulic quick couplers when lines are pressurized.
• Make sure lift cable is seated in cable pulley.
• Always keep a minimum of 3 cable wraps on the cable drum.
2.7. Drives and Lockout Safety
Inspect the power source(s) before using and know how to shut down in an emergency.
Whenever you service or adjust your equipment, make sure you shut down the power
source and unplug or remove the key (as applicable) to prevent inadvertent start-up and
hazardous energy release. Know the procedure(s) that applies to your equipment from the
following power source(s). Ensure that all personnel are clear before turning on power to
equipment.
2.7.1 PTO Driveline Safety
Drive
• Keep body, hair, and clothing away from rotating PTO
driveline.
• Make certain the driveline shields telescope and rotate freely
on driveline before attaching.
• Make certain the driveline is securely attached at both ends.
• Do not operate auger unless all driveline, tractor, and
equipment shields are in place and in good working order.
• Do not exceed the specified operating speed.
• Keep universal joint angles small and equal. Do not exceed
maximum recommended length for PTO driveline.
• Engage tractor park brake and/or chock wheels.
Lockout
• Position all controls in neutral, shut off tractor’s engine, and remove key from tractor.
• If removing key is impossible, remove PTO driveline from tractor.
2. SAFETY SWING-AWAY GRAIN AUGER – MKX 13

30796 R7 9
2.7.2 Hydraulic Power Safety
Power Source
• Refer to the rules and regulations applicable to the power
source operating your hydraulic drive.
• Do not connect or disconnect hydraulic lines while system is
under pressure.
• Keep all hydraulic lines away from moving parts and pinch
points.
• Escaping hydraulic fluid under pressure will cause serious
injury if it penetrates the skin surface (serious infection or
toxic reaction can develop). See a doctor immediately if
injured.
• Use metal or wood as a backstop when searching for
hydraulic leaks and wear proper hand and eye protection.
• Check all hydraulic components are tight and in good
condition. Replace any worn, cut, abraded, flattened, or
crimped hoses.
• Clean the connections before connecting to equipment.
• Do not attempt any makeshift repairs to the hydraulic fittings
or hoses with tape, clamps, or adhesive. The hydraulic
system operates under extremely high pressure; such repairs
will fail suddenly and create a hazardous and unsafe
condition.
Lockout
• Always place all hydraulic controls in neutral and relieve
system pressure before disconnecting or working on
hydraulic system.
SWING-AWAY GRAIN AUGER – MKX 13 2. SAFETY

10 30796 R7
2.8. Tire Safety
Failure to follow proper procedures when mounting a tire on a
wheel or rim can produce an explosion that may result in
serious injury or death.
• DO NOT attempt to mount a tire unless you have the proper
equipment and experience to do the job.
• Have a qualified tire dealer or repair service perform
required tire maintenance.
• When replacing worn tires, make sure they meet the original
tire specifications. Never undersize the replacement tire.
• DO NOT weld to the tire rim with the tire mounted on the
rim. This action may cause an explosion which could result in
serious injury or death.
• Inflate tires to the manufacturer’s recommended pressure.
• Tires should not be operated at speeds higher than their
rated speed.
• Keep wheel lug nuts tightened to manufacturer’s
recommendations.
• Never reinflate a tire that has been run flat or seriously
under-inflated without removing the tire from the wheel.
Have the tire and wheel closely inspected for damage before
remounting.
2.9. Personal Protective Equipment
The following Personal Protective Equipment (PPE) should be worn when operating or maintaining the
equipment.
Safety Glasses
• Wear safety glasses at all times to protect eyes from debris.
Coveralls
• Wear coveralls to protect skin.
Hard Hat
• Wear a hard hat to help protect your head.
2. SAFETY SWING-AWAY GRAIN AUGER – MKX 13
