Agilent 16048B Test Leads
Operating Note
Third Edition
Agilent Part No. 16048-90012
May 2000
Printed in Japan
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2
Notices
The information contained in this document is subject to change without notice.
This document contains proprietary information that is protected by copyright.All rights
are reserved. No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of the Agilent Technologies.
Agilent Technologies Japan, Ltd.
Component Test PGU-Kobe
1-3-2, Murotani, Nishi-Ku, Kobe-shi, Hyogo, 651-2241 Japan
Copyright © Agilent Technologies Japan, Ltd. 1996, 1998, 2000
Manual Printing History
The manual’s printing date and part number indicate its current edition. The printing date
changes when a new edition is printed. (Minor corrections and updates that are
incorporated at reprint do not cause the date to change.) The manual part number changes
when extensive technical changes are incorporated.
August 1996 First Edition (part number : 16048-90011)
November 1998 Second Edition (part number : 16048-90012)
May 2000 Third Edition (part number : 16048-90012)
Safety Summary
The following general safety precautions must be observed during all phases of operation,
service, and repair of this instrument. Failure to comply with these precautions or with
specific WARNINGS elsewhere in this manual may impair the protection provided by the
equipment. In addition it violates safety standards of design, manufacture, and intended use
of the instrument.
Agilent Technologies assumes no liability for the customer’s failure to comply with these
requirements.
• Ground The Instrument
To avoid electric shock hazard, the instrument chassis and cabinet must be connected to
a safety earth ground by the supplied power cable with earth blade.
• DO NOT Operate In An Explosive Atmosphere
Do not operate the instrument in the presence of flammable gasses or fumes. Operation
of any electrical instrument in such an environment constitutes a definite safety hazard.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3
• Keep Away From Live Circuits
Operating personnel must not remove instrument covers. Component replacement and
internal adjustments must be made by qualified maintenance personnel. Do not replace
components with the power cable connected. Under certain conditions, dangerous
voltages may exist even with the power cable removed. To avoid injuries, always
disconnect power and discharge circuits before touching them.
• DO NOT Service Or Adjust Alone
Do not attempt internal service or adjustment unless another person, capable of
rendering first aid and resuscitation, is present.
• DO NOT Substitute Parts Or Modify Instrument
Because of the danger of introducing additional hazards, do not install substitute parts
or perform unauthorized modifications to the instrument. Return the instrument to a
Agilent Technologies Sales and Service Office for service and repair to ensure that
safety features are maintained.
• Dangerous Procedure Warnings
Warnings, such as the example below, precede potentially dangerous procedures
throughout this manual. Instructions contained in the warnings must be followed.
WARNING Dangerous voltages, capable of causing death, are presenting this instrument. Use
extreme caution when handling, testing, and adjusting this instrument.
Certification
Agilent Technologies certifies that this product met its published specifications at the time
of shipment from the factory. Agilent Technologies further certifies that its calibration
measurements are traceable to the United States National Institute of Standards and
Technology, to the extent allowed by the Institution’s calibration facility, or to the
calibration facilities of other International Standards Organization members.
Warranty
This Agilent Technologies instrument product is warranted against defects in material and
workmanship for a period corresponding to the individual warranty periods of its
component products. Instruments are warranted for a period of one year. Fixtures and
adapters are warranted for a period of 90 days. During the warranty period, Agilent
Technologies Company will, at its option, either repair or replace products that prove to be
defective.
For warranty service or repair, this product must be returned to a service facility designated
by Agilent Technologies. Buyer shall prepay shipping charges to Agilent Technologies and
Agilent Technologies shall pay shipping charges to return the product to Buyer. However,
Buyer shall pay all shipping charges, duties, and taxes for products returned to Agilent
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4
Technologies from another country.
Agilent Technologies warrants that its software and firmware designated by Agilent
Technologies for use with an instrument will execute its programming instruction when
property installed on that instrument. Agilent Technologies does not warrant that the
operation of the instrument, or software, or firmware will be uninterrupted or error free.
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting from improper or inadequate
maintenance by Buyer, Buyer-supplied software or interfacing, unauthorized modification
or misuse, operation outside the environmental specifications for the product, or improper
site preparation or maintenance.
IMPORTANT No other warranty is expressed or implied. Agilent Technologies specifically disclaims the
implied warranties of merchantability and fitness for a particular purpose.
Exclusive Remedies
The remedies provided herein are buyer’s sole and exclusive remedies. Agilent
Technologies shall not be liable for any direct, indirect, special, incidental, or
consequential damages, whether based on contract, tort, or any other legal theory.
Assistance
Product maintenance agreements and other customer assistance agreements are available
for Agilent Technologies products.
For any assistance, contact your nearest Agilent Technologies Sales and Service Office.
Addresses are provided at the back of this manual.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

MANUAL CHANGES
Agilent 16048B
Test Leads
Operating Note
MANUAL IDENTIFICATION
Model Number: 16048B
Date Printed: May 2000
Part Number: 16048-90012
This supplement contains information for correcting manual errors and for adapting the manual to newer instruments that contains
improvements or modifications not documented in the existing manual.
To use this supplement
1. Make all ERRATA corrections
2. Make all appropriate serial-number-related changes listed below
SERIALPREFIXORNUMBER MAKEMANUAL
CHANGES
All 1
KNew Item
SERIAL PREFIX OR NUMBER MAKE MANUAL
CHANGES
ERRATA
CHANGES 1
CHANGE 1 contains the information needed to adapt the 16048B’s manual.
Page 1-2 Specification
Add the following information.
Maximum Voltage……………………………………………………….±40V peak max. (AC + DC)
NOTE
Manual change supplement are revised as often as necessary to keep manuals as current and accurate as possible. Agilent Technologies
recommends that you periodically request the latest edition of this supplement. Free copies are available from all Agilent Technologies offices.
When requesting copies, quote the manual identification information from your supplement, or the model number and print date from the title
page of the manual.
Date/Div: May,2000/33
Page 1 of 1
PRINTED IN JAPAN
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1
General Information
Introduction
This operation note provides the information for operating and maintaining the HP 16048B T
est
Leads
.
Description
The HP 16048B is a direct attachement, 4-terminal pair type xture which is equipped with
four SMC(f) terminated coaxial test leads. These test leads are used to attach user-fabricated
test xtures to the instruments.
The HP 16048B has been designed for use with the following instruments:
HP 4263B LCR Meter
HP 4278A 1kHz /1MHz Capacitance Meter
HP 4279A 1MHz C-V Meter
HP 4284A Precision LCR Meter
HP 4285A Precision LCR Meter
HP 4192A LF Impedance Analyzer
HP 4194A Impedance / Gain Phase Analyzer
The HP 16048B has inherent stray capacitance
,residual inductance and residual resistance that
aect the accuracy of measured value
.The measurement errors caused by these residuals
are minimized by using the instrument's error correction functions
.The measurement
accuracy when the open, short, and cable length corrections are performed is described in the
specications section of the instrument's operation manual.
Figure 1-1. HP 16048B Test Leads
General Information 1-1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Specication
Connector Type
:::::::::::
::
::
:::: :: :: :::::::::::::::
::
::
::
::
::::::::::::::: :: :: :::
SMC (female)
Cable Length
:::::::::::
::
::
::
::::::::::::::: :: :: ::::
::
::
::
Approximately 1meter (39.4 inches)
W
eight
:::::::::
::
::
::
::
::::::::::::::: :: :: ::::
::
::
:::::::::::::
:::: :: :: ::::
::
250 grams (0.55 lbs)
Operation
Setup and measurement procedure
1. Connect the HP 16048B directly to the UNKNOWN terminals of the instrument.
2. Connect the user-fabricated test xture to the test leads.
3. P
erform the cable length correction (Set the cable length to 1 meter).
4. P
erform the open/short correction at the measurement terminal of the test xture
.
Then you can perform measurement at the test xture
.
F
or more detail about the cable length correction and open/short correction procedure
,refer to
the instrument's operation manual.
Using the connector plate
The connector plate is furnished with the HP 16048B.Figure 1-2 shows an example to use the
connector plate with the HP 16048B.By connecting the HP 16048B to the connector plate
,the
HP 16048B's outer shield conductors are connected together to construct the four-terminal-pair
measurement circuit conguration. F
or more detail about the four-terminal-pair measurement,
refer to the instrument's operation manual.
Figure 1-2. Connector Plate Application
1-2 General Information
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2
Maintenance
Maintenance principally consists of cleaning contacts and replacing worn or damaged parts
.
Figure 2-1 shows the HP 16048B replaceable parts
.Only the parts whose part numbers are in
the parts list are replaceable
.Use the correct Hewlett-P
ackard part number when ordering
replaceable parts
.
T
able 2-1. Replaceable P
arts List
Reference
Designator
HP P
art
Number Qty
.Description Note
6 2360-0192 2 Screw
11 2200-0105 1 Screw
12 2190-0206 1 W
asher
13 16047-40000 1 Stopper
15 16048-04001 1 Cover-T
op
16 1400-0719 2 Tie Rap
21 2360-0113 1 Screw
22 3050-0010 1 W
asher
23 16021-50021 1 Cable Cramp
24 16021-50022 1 Cable Cramp
30 1250-1164 4 Connector Body
16048-60030 1 T
est Lead 1thru 30
31 1250-0829 4 Connector-RF
32 2360-0115 2 Screw
33 16033-10021 1 Plate
34 16032-10022 1 Plate
35 2190-0124 4 Washer
36 2950-0078 4 Nut
37 16033-60001 1 Connector Ass'y 31 thru 36
Note
The parts not shown in T
able 2-1 cannot be replaced separately
. When these
non-replaceable parts are worn or damaged, replace the whole test lead
assembly (PN 16048-60030). 16048-60030 is Agilent internal-only part number.
Maintenance 2-1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Figure 2-1. Replaceable Parts Identication
2-2 Maintenance
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

REGIONAL SALES AND SUPPORT OFFICES
For more information about Agilent Technologies test and measurement products, applications, services, and
for a current sales office listing, visit our web site: http://www.agilent.com/find/tmdir. You can also contact one
of the following centers and ask for a test and measurement sales representative. 11/29/99
United States:
Agilent Technologies
Test and Measurement Call Center
P.O.Box 4026
Englewood, CO 80155-4026
(tel) 1 800 452 4844
Canada:
Agilent Technologies Canada Inc.
5150 Spectrum Way
Mississauga, Ontario
L4W 5G1
(tel) 1 877 894 4414
Europe:
Agilent Technologies
Test & Measurement
European Marketing Organization
P.O.Box 999
1180 AZ Amstelveen
The Netherlands
(tel) (31 20) 547 9999
Japan:
Agilent Technologies Japan Ltd.
Call Center
9-1, Takakura-Cho, Hachioji-Shi,
Tokyo 192-8510, Japan
(tel) (81) 426 56 7832
(fax) (81) 426 56 7840
Latin America:
Agilent Technologies
Latin American Region Headquarters
5200 Blue Lagoon Drive, Suite #950
Miami, Florida 33126
U.S.A.
(tel) [phone]
(fax) [phone]
Australia/New Zealand:
Agilent Technologies Australia Pty Ltd
347 Burwood Highway
Forest Hill, Victoria 3131
(tel) 1-800 629 485 (Australia)
(fax) (61 3) 9272 0749
(tel) 0 800 738 378 (New Zealand)
(fax) (64 4) 802 6881
Asia Pacific:
Agilent Technologies
24/F, Cityplaza One, 1111 King’s Road,
Taikoo Shing, Hong Kong
(tel) (852)-3197-7777
(fax) (852)-2506-9284
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group is an independent supplier of quality pre-owned equipment
Gold-standard solutions
Extend the life of your critical industrial,
commercial, and military systems
with our
superior service and support.
We buy equipment
Planning to upgrade your current
equipment? Have surplus equipment taking
up shelf space? We'll give it a
new home.
Learn more!
Visit us at artisantg.com for more info
on price quotes, drivers, technical
specifications, manuals, and documentation.
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
We're here to make your life easier. How can we help you today?
[phone] [e-mail] Iartisantg.com
