Agilent Technologies N6314A User manual

User’s Guide
Agilent Technologies
N6314A and N6315A
Type-N 50 Ohm RF Cables
Manufacturing Part Number: 5964-7333
Printed in USA
Print Date: February 2008
Supersedes: July 2005
© Copyright © Agilent Technologies, Inc. 2003, 2005, 2008

User’s Guide 5964-7333 2
Documentation Warranty
THE MATERIAL CONTAINED IN THIS DOCUMENT IS PROVIDED “AS IS,” AND IS
SUBJECT TO BEING CHANGED, WITHOUT NOTICE, IN FUTURE EDITIONS.
FURTHER, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, AGILENT
DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED WITH REGARD TO
THIS MANUAL AND ANY INFORMATION CONTAINED HEREIN, INCLUDING BUT
NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. AGILENT SHALL NOT BE LIABLE FOR ERRORS OR
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE
FURNISHING, USE, OR PERFORMANCE OF THIS DOCUMENT OR ANY
INFORMATION CONTAINED HEREIN. SHOULD AGILENT AND THE USER HAVE A
SEPARATE WRITTEN AGREEMENT WITH WARRANTY TERMS COVERING THE
MATERIAL IN THIS DOCUMENT THAT CONFLICT WITH THESE TERMS, THE
WARRANTY TERMS IN THE SEPARATE AGREEMENT WILL CONTROL.
DFARS/Restricted Rights Notice
If software is for use in the performance of a U.S. Government prime contract or subcontract,
Software is delivered and licensed as “Commercial computer software” as defined in DFAR
252.227-7014 (June 1995), or as a “commercial item” as defined in FAR 2.101(a) or as
“Restricted computer software” as defined in FAR 52.227-19 (June 1987) or any equivalent
agency regulation or contract clause. Use, duplication or disclosure of Software is subject to
Agilent Technologies’ standard commercial license terms, and non-DOD Departments and
Agencies of the U.S. Government will receive no greater than Restricted Rights as defined in
FAR 52.227-19(c)(1-2) (June 1987). U.S. Government users will receive no greater than
Limited Rights as defined in FAR 52.227-14 (June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any technical data.

3User’s Guide 5964-7333
Printing Copies of Documentation from the Web
To print copies of documentation from the Web, download the PDF file from the Agilent web
site:
•Gotohttp://www.agilent.com.
• Enter the product model number in the Search function and click Search.
•ClickontheManuals hyperlink.
• Open the PDF of your choice and print the document.
Contacting Agilent
Assistance with test and measurements needs and information on finding a local Agilent
office are available on the Web at:
www.agilent.com/find/assist
If you do not have access to the Internet, please contact your Agilent field engineer.
NOTE In any correspondence or telephone conversation, refer to the Agilent product by
its model number and full serial number. With this information, the Agilent
representative can determine whether your product is still within its warranty
period.
Product Description
The N6314A and N6315A are type-N 50 ΩRF cables, with a specified range of DC to
12.4 GHz. These cables provide the shielded RF connections required when using network
analyzers with various test devices and equipment.

User’s Guide 5964-7333 4
Model Number N6314A
Connector Type Type-N 50Ωcable / male to male
Part Number 8120-8862
Impedance 50Ω(nominal)
Return Loss ≥ 24 dB (DC to 3 GHz)
≥ 18 dB (3 GHz to 12.4 GHz)
Length 61 cm (24 inches)
Net Weight 0.14 kg (0.31 lbs)
Shipping Weight 0.59 kg (1.30 lbs)

5User’s Guide 5964-7333
Model Number N6315A
Connector Type Type-N 50Ωcable / male to female
Part Number 8121-0027
Impedance 50Ω(nominal)
Return Loss ≥ 24 dB (DC to 3 GHz)
≥ 18 dB (3 GHz to 12.4 GHz)
Length 61.0 cm (24 inches)
Net Weight 0.12 kg (0.26 lbs)
Shipping Weight 0.57 kg (1.26 lbs)

User’s Guide 5964-7333 6
Care and Maintenance
To obtain optimum performance from RF cables, observe these precautions:
• Flex and straighten the cables as little and seldom as possible.
• Make connections carefully to avoid misalignment, connector damage, or inaccurate
measurements.
• Keep the connectors free of dirt and metallic particles by periodic inspection and cleaning.
CAUTION Cotton swabs may leave fibers on the connector that can cause inaccurate
measurement results.
• When you clean the connectors, apply clean compressed air or nitrogen. Do not use
abrasives. With a foam-tipped plastic swab, apply isopropyl alcohol to clean the connector
surfaces.
• Type-N (male) outer conductor shoulder, dielectric recession, or center conductor step
should be 0.208 inch minimum.
Visual Inspection
Visual inspection and, if necessary, cleaning should be done every time a connection is made.
Metal particles from the connector threads may fall onto the mating plane surface of the
connector when it is disconnected. One connection made with a dirty or damaged connector
can damage both connectors beyond repair.
Magnification is helpful when inspecting connectors, but it is not required and may actually
be misleading. Defects and damage that cannot be seen without magnification generally have
no effect on electrical or mechanical performance. Magnification is of great use in analyzing
the nature and cause of the damage and in cleaning connectors, but it is not required for
inspection. Use the following guidelines when evaluating the integrity of a connector.
Look for Obvious Defects and Damage First
Examine the connector first for obvious defects and damage: badly worn plating on the
connector interface, deformed threads, or bent, broken, or misaligned center conductors.
Connector nuts should move smoothly and be free of burrs, loose metal particles, and rough
spots.
What Causes Connector Wear? Connector wear is caused by connecting and disconnecting
the cable.The more use a connector gets, the faster it wears and degrades.The wear is greatly
accelerated when connectors are not kept clean, or are connected incorrectly.
Connector wear eventually degrades performance of the cable. Replace cables with worn
connectors.
The test port connectors on the network analyzer test set may have many connections each
day, and are therefore also subject to wear. It is recommended that an adapter be used as a
test port saver to minimize the wear on the test set’s test port connectors.

7User’s Guide 5964-7333
Inspect the Mating Plane Surfaces
Flat contact between theconnectors at all points on their mating plane surfaces is required for
a good connection. Look especially for deep scratches or dents, and for dirt and metal particles
on the connector mating plane surfaces. Also look for signs of damage due to excessive or
uneven wear or misalignment.
Light burnishing of the mating plane surfaces is normal, and is evident as light scratches or
shallow circular marks distributed more or less uniformly over the mating plane surface.
Other small defects and cosmetic imperfections are also normal. None of these affect electrical
or mechanical performance.
If a connector shows deep scratches or dents, particles clinging to the mating plane surfaces,
or uneven wear, clean and inspect it again. Cables with damaged connectors should be
repaired or discarded. Determine the cause of damage before connecting a new, undamaged
connector in the same configuration.
