Installation Note
Agilent Technologies ESG and ESG-D Series Signal Generators
Semi-Rigid Cable Replacement Kits
Kit Numbers E4400-60059, E4400-60060, E4400-60061,
E4400-60176, E4400-60177, and E4400-60726

Notice.
The information contained in this document is subject to change without notice.
Agilent Technologies makes no warranty of any kind with regard to this material, including but not limited
to, the implied warranties of merchantability and fitness for a particular purpose. Agilent Technologies
shall notbe liable for errors contained herein or for incidental orconsequential damages in connection with
the furnishing, performance, or use of this material.
© Copyright 1997, 1998, 2003 Agilent Technologies Inc.

Installation Note E4400-90096 3
Semi-Rigid Cable Replacement Kits
E4400-60059,E4400-60060,E4400-60061,E4400-60176,E4400-60177,
and E4400-60726
Introduction
This kit contains the parts and instructions to replace the semi-rigid cables on the ESG and ESG-D
Series Signal Generators. Kits E4400-60176 and E4400-60177 are for instruments equipped with
Option UNB. Kit E4400-60726 is for instruments equipped with the E4400-60680 attenuator.
Tools Required
❏Needlenose pliers (used to remove snap rings from cable retainers)
❏5/16-inch open-end wrench
❏T-20 TORX screwdriver
❏T-15 TORX screwdriver
❏T-8 TORX screwdriver
WARNING Before you disassemble the instrument, turn the power switch off and
unplug the instrument. Failure to unplug the instrument can result in
personal injury.
CAUTION Electrostatic discharge (ESD) can damage or destroy electronic components. All
work on electronic assemblies should be performed at a static-safe workstation.
Refer to the documentation that pertains to your instrument for information
about static-safe workstations and ordering static-safe accessories.
Product Affected: . . . . . . . . . . . . . . . . . . . . . . . . . ESG and ESG-D Series Signal Generators
Models Affected: . . . . . . . . . . . . . . . . . . . . . . . . . . . E4400A/B/BU, E4420A/B/BU,
E4421A/B/BU, E4422A/B/BU,
E4430A/B/BU, E4431A/B/BU,
E4432A/B/BU, and E4433A/B/BU
Serial Numbers: . . . . . . . . . . . . . . . . . . . . . . . . . . . All
To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . (x) Agilent Service Center
(x) Personnel Qualified by Agilent Technologies
(x) Customer
Estimated Installation Time: . . . . . . . . . . . . . . . . 1 Hour
Estimated Verification Time: . . . . . . . . . . . . . . . . . 6 Hours

4 Installation Note E4400-90096
Installation Kit Parts List
Table 1 Replacement Cable Kit for W11 E4400-60059 Contents
Table 2 Replacement Cable Kit for W12 E4400-60060 Contents
Table 3 Replacement Cable Kit for W14 E4400-60061 Contents
Item Quantity Description Part Number
1 1 CBL AY-Synth Out E4400-20020
2 1 Retainer Cable E4400-40002
3 1 Retainer Ring 0410-1643
4 1 Installation Note E4400-90096
Item Quantity Description Part Number
1 1 CBL RF Aux Out E4400-20024
2 1 Retainer Cable E4400-40002
3 1 Retainer Ring 0410-1643
4 1 Installation Note E4400-90096
Item Quantity Description Part Number
1 1 CBL AY Atten Synth E4400-20019
2 1 Retainer Cable E4400-40002
3 1 Retainer Ring 0410-1643
4 1 Installation Note E4400-90096

Installation Note E4400-90096 5
Tables 4 and 5 below describe the cable replacement kits for instruments equipped with Option UNB.
Table 4 Replacement Cable Kit for W12 E4400-60176 Contents
Table 5 Replacement Cable Kit for W14 E4400-60177 Contents
Table 1 Replacement Cable Kit for W14 E4400-60726 Contents
Item Quantity Description Part Number
1 1 CBL RF Aux Out E4400-20130
2 1 Retainer Cable E4400-40002
3 1 Retainer Ring 0410-1643
4 1 Installation Note E4400-90096
Item Quantity Description Part Number
1 1 CBL AY Atten Synth E4400-20129
2 1 Retainer Cable E4400-40002
3 1 Retainer Ring 0410-1643
4 1 Installation Note E4400-90096
Item Quantity Description Part Number
1 1 CBL AY Atten Input E4400-20558
2 1 Retainer Cable E4400-40002
3 1 Retainer Ring 0410-1643
4 1 Installation Note E4400-90096

6 Installation Note E4400-90096
Functionality Check
This procedure verifies that the signal generator powers up and that the internal instrument check
identifies no errors. The internal check evaluates the correctness of operation and returns an error
message if a problem is detected.
1. Turn power on to the signal generator by pressing the power switch. The green LED will light. Let
the instrument warm up for one hour.
2. Cycle the power to the signal generator. The green LED should again be lit and the instrument will
perform a check.
3. When the display is lit, check to see if the ERR annunciator is turned on.
4. If the ERR annunciator is turned on, review the error messages in the queue by pressing Utility,
Error Info, View Next Error Message. The first error message in the queue will be shown in the text
area of the display. Refer to the error messages guide for information about the error message.
If there is more than one error message (each message will be designated as 1 of n), continue
pressing the View Next Error Message softkey until you have seen all of the messages.
5. When you have resolved all of the error messages, press Clear Error Queue(s) to delete the
messages. Then restart this procedure at step two.
NOTE For instruments with Option 1E5, ERROR 514, Reference Oven Cold will occur
whenever the signal generator is first connected to AC line power. The OVEN COLD
annunciator and the ERR annunciator will both turn on. The OVEN COLD
annunciator will automatically clear after approximately 5 minutes. The error
queue cannot be cleared, however, until the OVEN COLD annunciator has turned
off.

Installation Note E4400-90096 7
Procedure
Remove Instrument Cover
1. Remove the two strap handles (item 1) from each side of the signal generator by loosening the two
screws (item 2) on each handle.
2. Remove the four bottom feet (item 3).
3. Remove the four rear feet (item 4) from the signal generator by removing the four screws (item 5)
that secure them.
4. Slide the instrument cover (item 6) off the back of the signal generator.
Figure 2 Instrument Cover

8 Installation Note E4400-90096
Remove A9, A11, and A12 Daughterboard Card Cage Boards
Use this procedure to remove each of the following assemblies:
• Output Board (A9)
• Reference Board (A11)
• Synthesizer/Doubler Board (A12)
1. Remove the right-side cover by removing the four screws that attach it to the instrument chassis.
2. Simultaneously lift the left and right extractors (item 1) on the board you want to remove.
3. Remove the board from the card cage slot.
Figure 3 A9, A11, and A12 Daughterboard Card Cage Boards

Installation Note E4400-90096 9
Replace W11, W12, and W14 Semi-Rigid Cables
Remove Old Semi-Rigid Cables
Refer to,
Figure 4 for E4400 A-Series Signal Generators
Figure 5 for E4400 B- and BU-Series Signal Generators or
Figure 6 for E4400 B- and BU-Series Signal Generators with Option UNB
1. Remove the snap ring (item 1) from the cable retainer (item 2) on W11, W12, and W14. The cables
are now disconnected from the instrument chassis (item 3).
2. Disconnect the other end of the cables and discard.
Figure 4 W11, W12 and W14 Semi-Rigid Cable Locations
for E4400 A-Series Signal Generators

10 Installation Note E4400-90096
Figure 5 W11, W12 and W14 Semi-Rigid Cable Locations
for E4400 B- and BU-Series Signal Generators

Installation Note E4400-90096 11
Figure 6 W11, W12 and W14 Semi-Rigid Cable Locations
for E4400 B- and BU-Series Signal Generators Option UNB
Replace Semi-Rigid Cables
1. If you’re installing a new cable, refer to Figure 3. A new cable retainer (item 2) must first be
attached to the end of the cable (item 4). Verify the cable retainer is correctly attached by listening
for an audible “click” as you slide it over the end of the cable.
2. Insert the cable-retainer end of the cable assembly into the opening of the instrument chassis and
then secure it with a snap ring.
3. Connect the other end of the cable. All semi-rigid cables should be torqued to 9 in-lbs.
Replace Daughterboard Card Cage Boards
1. Replace each board into the appropriate card cage slot.
2. Simultaneously push down on the left and right extractors (item 1) on the board you are replacing.
3. Replace the right-side cover by attaching it to the instrument chassis with the four screws that were
previously removed. Torque all T-8 TORX screws to 9 in-lbs.

12 Installation Note E4400-90096
Replace Inside Cover
1. Replace inside top cover and secure it with the 11 screws which were previously removed. Torque
the screws to 9 in-lbs.
Verification
1. Power on the signal generator and check forerror messages. Let the signal generator warm up for at
least five minutes.
a. Press the front panel PRESET button to reset the signal generator.
b. Rerun the “Functionality Check” on page 6 of this installation note.
Perform the Following Adjustments and Performance Tests
NOTE These adjustments are automated using the ESG Series Support Software
Analog / Digital E4400-10001.
Adjustments
1. Gain Adjust
2. ALC adjustments
3. Power Level Accuracy
Performance Tests
1. Power Level Accuracy
2. Pulse Rise/Fall Time (Option 1E6)
3. Alternate Timeslot (Option UNA)
4. Digital Mod: Internal I/Q Quality (Options UN3, UN4, and UN8)
Replace Instrument Cover
1. Replace inside top cover and secure it with the 11 screws which were previously removed. Torque
the screws to 9 in-lbs. Refer to Figure 1.
2. Slide the instrument cover (item 6) on from the back of the signal generator.
3. Replace the four rear feet (item 4) onto the signal generator by using the four screws (item 5) that
secure them. Torque the rear feet screws (item 4) to 21 in-lbs.
4. Replace the four bottom feet (item 3).
5. Replace the two strap handles (item 1) onto each side of the signal generator using the two screws
(item 2) on each handle. Torque the strap handle screws (item 2) to 21 in-lbs.
