Agilent Technologies 82357B User manual

Agilent Technologies
Agilent 82357B
USB/GPIB Interface
User’s Guide

ii
Notices
© Agilent Technologies, Inc. 2006, 2007
No part of this manual may be reproduced in
any form or by any means (including elec-
tronic storage and retrieval or translation
into a foreign language) without prior agree-
ment and written consent from Agilent
Technologies, Inc. as governed by United
States and international copyright laws.
Manual Part Number
82357-90003
Edition
Third Edition, March 30, 2007
Printed in Malaysia
Agilent Technologies, Inc.
3501 Stevens Creek Blvd.
Santa Clara, CA 95052 USA
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connec-
tion with the furnishing, use, or per-
formance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accor-
dance with the terms of such license.
Restricted Rights Legend
U.S. Government Restricted Rights. Soft-
ware and technical data rights granted to
the federal government include only those
rights customarily provided to end user cus-
tomers. Agilent provides this customary
commercial license in Software and techni-
cal data pursuant to FAR 12.211 (Technical
Data) and 12.212 (Computer Software) and,
for the Department of Defense, DFARS
252.227-7015 (Technical Data - Commercial
Items) and DFARS 227.7202-3 (Rights in
Commercial Computer Software or Com-
puter Software Documentation).
Safety Notices
CAUTION
A CAUTION notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and
met.

iii
U.S. Government Restricted Rights
The Software and Documentation have been developed entirely at private
expense. They are delivered and licensed as “commercial computer
software” as defined in DFARS 252.227- 7013 (Oct 1988), DFARS
252.211-7015 (May 1991) or DFARS 252.227-7014 (Jun 1995), as a
“commercial item” as defined in FAR 2.101(a), or as “Restricted computer
software” as defined in FAR 52.227-19 (Jun 1987) (or any equivalent
agency regulation or contract clause), whichever is applicable. You have
only those rights provided for such Software and Documentation by the
applicable FAR or DFARS clause or the Agilent standard software
agreement for the product involved.
General Warranty
The material contained in this document is provided “as is,” and is subject
to being changed, without notice, in future editions. Further, to the
maximum extent permitted by applicable law, Agilent disclaims all
warranties, either express or implied with regard to this manual and any
information contained herein, including but not limited to the implied
warranties of merchantability and fitness for a particular purpose. Agilent
shall not be liable for errors or for incidental or consequential damages in
connection with the furnishing, use, or performance of this document or
any information contained herein. Should Agilent and the user have a
separate written agreement with warranty terms covering the material in
this document that conflict with these terms, the warranty terms in the
separate agreement will control. Duration and conditions of warranty for
this product may be superseded when the product is integrated into
(becomes a part of) other Agilent products. During the warranty period,
Agilent will, at its option, either repair or replace products which prove to
be defective. The warranty period begins on the date of delivery or on the
date of installation if installed by Agilent.

iv
Warranty Service
For warranty service or repair, this product must be returned to a service
facility designated by Agilent. For products returned to Agilent for
warranty service, the Buyer shall prepay shipping charges to Agilent and
Agilent shall pay shipping charges to return the product to the Buyer.
However, the Buyer shall pay all shipping charges, duties, and taxes for
products returned to Agilent from another country.
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting from improper
or inadequate maintenance by the Buyer, Buyer-supplied products or
interfacing, unauthorized modification or misuse, operation outside of the
environmental specifications for the product, or improper site preparation
or maintenance.
The design and implementation of any circuit on this product is the sole
responsibility of the Buyer. Agilent does not warrant the Buyer’s circuitry
or malfunctions of Agilent products that result from the Buyer’s circuitry.
In addition, Agilent does not warrant any damage that occurs as a result of
the Buyer’s circuit or any defects that result from Buyer-supplied products.
To the extent allowed by local law, Agilent makes no other warranty,
expressed or implied, whether written or oral with respect to this product
and specifically disclaims any implied warranty or condition of
merchantability, fitness for a particular purpose or satisfactory quality.
Exclusive Remedies
To the extent allowed by local law, the remedies provided herein are the Bu
yer’s sole and exclusive remedies. Agilent shall not be liable for any direct,
indirect, special, incidental, or consequential damages (including lost
profit or data), whether based on warranty, contract, tort, or any other legal
theory.

v
Technology Licenses
The hardware and/or software described in this document are furnished
under a license and may be used or copied only in accordance with the
terms of such license.

vi
Safety Summary
The following general safety precautions must be observed during all
phases of operation of this instrument. Failure to comply with these
precautions or with specific warnings elsewhere in this manual violates
safety standards of design, manufacture, and intended use of the
instrument. Agilent Technologies, Inc. assumes no liability for the
customer’s failure to comply with these requirements.
Safety Notices
WARNING
A WARNING notice denotes a hazard. It calls attention to an operating
procedure, practice, or the like that, if not correctly performed or
adhered to, could result in personal injury or loss of life. Do not proceed
beyond a WARNING notice until the indicated conditions are fully
understood and met.
CAUTION
A CAUTION notice denotes a hazard. It calls attention to an operating
procedure, practice, or the like that, if not correctly performed or adhered
to, could result in damage to the product or loss of important data. Do not
proceed beyond a CAUTION notice until the indicated conditions are fully
understood and met.

vii
Safety Symbols
The following symbol on the instrument and in the documentation
indicates precautions that must be taken to maintain safe operation of the
instrument.
Regulatory Markings
The Instruction Documentation Symbol. The product is marked with this symbol
when it is necessary for the user to refer to the instructions in the supplied docu-
mentation.
The CE mark shows that the product complies with all the relevant European
Legal Directives.
ICES/NMB-001 indicates that this ISM device complies with Canadian ICES-001.
The CSA mark is a registered trademark of the Canadian Standards Association. A
CSA mark with the indicators “C” and “US” means that the product is certified for
both the U.S. and Canadian markets, to the applicable American and Canadian
standards.
The C-tick mark is a registered trademark of the Spectrum Management Agency
of Australia. This signifies compliance with the Australian EMC Framework regu-
lations under the terms of the Radio Communications Act of 1992.
This product complies with the WEEE Directive (2002/96/EC) marking require-
ment. The affixed product label indicates that you must not discard this electri-
cal/electronic product in domestic household waste.
The UL Mark is a registered trademark of Underwriters Laboratories Inc. UL listing
mark with the indicators "C" and "US" indicates the product compliance with
both Canadian and U.S. requirements.

viii
General Safety Information
WARNING
• Do not use the device if it appears damaged or defective.
• Observe all markings on the device before connecting any wiring to
the device.
• Do no operate the device in the presence of flammable gases or
fumes.
• Do no install substitute parts or perform any unauthorized
modification to the device.
CAUTION
• Use the device with the cables provided.
• Repair or service that is not covered in this manual should only be
performed by qualified personnels.

ix
Waste Electrical and Electronic Equipment (WEEE) Directive
2002/96/EC
This instrument complies with the WEEE Directive (2002/96/EC) marking
requirement. This affixed product label indicates that you must not discard
this electrical/electronic product in domestic hoursehold waste.
Product Category:
With reference to the equipment types in the WEEE directive Annex 1, this
instrument is classified as a “Monitoring and Control Instrument” product.
The affixed product label is shown as below:
Do not dispose in domestic household waste
To return this unwanted instrument, contact your nearest Agilent office, or
visit:
www.agilent.com/environment/product
for more information.

x
Environmental Conditions
This instrument is designed for indoor use only. Table 1 shows the general
environmental requirements for the product.
Table 1 Environmental Requirements
General Maintenance
To remove the dirt or moisture in the enclosure:
• Wipe the case with a damp cloth and mild detergent.
• Do not use abrasives or solvents.
• Wipe the contacts in each terminal with a clean swab dipped in
alcohol.
Environmental Conditions Requirements
Temperature 0 °C to 55 °C (Operating)
–40 °C to +70 °C (Non-operating)
Humidity Operating up to 90 % at 40 °C (Non-condensing)
Non-operating up to 90 % at 65 °C (Non-condensing)
CAUTION
This product is designed for use in compliance with:
• IEC 61010-1:2001/EN 61010-1:2001
• USA: UL61010-1: 2004
• Canada: CSA C22.2 No. 61010-1:2004

xi
DECLARATION OF CONFORMITY
According to ISO/IEC Guide 22 and CEN/CENELEC EN 45014
Generic example
Manufacturer’s Name: Agilent Technologies Microwave Products (M) Sdn. Bhd
Manufacturer’s Address: Bayan Lepas Free Industrial Zone,
11900, Bayan Lepas, Penang, Malaysia
Declares under sole responsibility that the product as originally delivered
Product Name: Agilent USB/GPIB Interface Converter
Models Number: 82357B
Product Options: This declaration covers all options of the above product(s)
complies with the essential requirements of the following applicable European Directives, and
carries the CE marking accordingly:
Low Voltage Directive (73/23/EEC, amended by 93/68/EEC)
EMC Directive (89/336/EEC, amended by 93/68/EEC)
and conforms with the following product standards:
EMC Standard
StandardStandard
Standard
Limit LimitLimit
Limit
IEC 61326-1:1997+A1:1998 / EN 61326-1:1997+A1:1998
CISPR 11:1990 / EN55011:1991 Class A Group 1
IEC 61000-4-2:1995+A1:1998 / EN 61000-4-2:1995 4 kV CD, 8 kV AD
IEC 61000-4-3:1995 / EN 61000-4-3:1995 3 V/m, 80-1000 MHz
IEC 61000-4-4:1995 / EN 61000-4-4:1995 0.5 kV signal lines, 1 kV power lines
IEC 61000-4-5:1995 / EN 61000-4-5:1995 0.5 kV line-line, 1 kV line-ground
IEC 61000-4-6:1996 / EN 61000-4-6:1996 3 V, 0.15-80 MHz
IEC 61000-4-11:1994 / EN 61000-4-11:1994 1 cycle / 100%
Canada: ICES-001:1998
Australia/New Zealand: AS/NZS 2064.1
The product was tested in a typical configuration with Agilent Technologies test systems.
Safety IEC 61010-1:2001 / EN 61010-1:2001
Canada: CSA C22.2 No. 61010-1:2004
USA: UL 61010-1: 2004
This DoC applies to above-listed products placed on the EU market after:
5-Jan-2007
Date Mack Soh
Quality Manager
For further information, please contact your local Agilent Technologies sales office, agent or distributor,
or Agilent Technologies Deutschland GmbH, Herrenberger Straße 130, D 71034 Böblingen, Germany.
Template: A5971-5302-2, Rev. B.01 82357B Rev 1.0

xii
Product Regulations
Performance
Criteria
IEC 61326-1:1997+A1:1998 / EN 61326-1:1997+A1:1998
CISPR 11:1990 / EN 55011:1991
– Group 1 Class A
IEC 61000-4-2:1995+A1:1998 / EN 61000-4-2:1995 (ESD 4kV CD, 8kV AD) B
IEC 61000-4-3:1995 / EN 61000-4-3:1995 (3V/m, 80% AM) A
IEC 61000-4-4:1995 / EN 61000-4-4:1995 (EFT 0.5kV line-line, 1kV line-earth) B
IEC 61000-4-5:1995 / EN 61000-4-5:1995 (Surge 0.5kV line-line, 1kV line-earth) B
IEC 61000-4-6:1996 / EN 61000-4-6:1996 (3V, 0.15~80 MHz, 80% AM, power line) A
IEC 61000-4-11:1994 / EN 61000-4-11:1994 (Dips 1 cycle, 100%) B
Canada: ICES-001:1998
Australia/New Zealand: AS/NZS 2064.1
EMC
IEC 61010-1:2001 / EN 61010-1:2001
Canada: CSA C22.2 No. 61010-1:2004
Safety
USA: UL 61010-1: 2004
Additional Information:
The product herewith complies with the essential requirements of the Low Voltage Directive 73/23/EEC and the
EMC Directive 89/336/EEC (including 93/68/EEC) and carries the CE Marking accordingly (European Union).
1
Performance Criteria:
A Pass - Normal operation, no effect.
B Pass - Temporary degradation, self recoverable.
C Pass - Temporary degradation, operator intervention required.
D Fail - Not recoverable, component damage.
N/A – Not applicable
Notes:
Regulatory Information for Canada
ICES/NMB-001:1998
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est confomre à la norme NMB-001 du Canada.
Regulatory Information for Australia/New Zealand
This ISM device complies with Australian/New Zealand AS/NZS 2064.1

xiii
In This Guide ...
1Installing the Agilent 82357B Chapter 1 shows a suggested seven-step
process to install the 82357B and the Agilent IO Libraries Suite, to connect
the 82357B to your PC, to configure the 82357B and to program GPIB
instruments via the 82357B.
2Using the Agilent 82357B Chapter 2 describes normal operating states
for the 82357B and provides the guidelines to use the 82357B.
3Troubleshooting the Agilent 82357B Chapter 3 provides
troubleshooting guidelines of the 82357B including hardware and
software checks and also the service and support information for the
82357B.
4Product Specifications Chapter 4 lists the 82357B technical
specifications and supplementary information.

xiv

Contents 1
Contents
Notices ii
U.S. Government Restricted Rights iii
General Warranty iii
Warranty Service iv
Limitation of Warranty iv
Exclusive Remedies iv
Technology Licenses v
Safety Summary vi
Safety Notices vi
Safety Symbols vii
Regulatory Markings vii
General Safety Information viii
Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC ix
Environmental Conditions x
General Maintenance x
In This Guide ... xiii
1 Installing the Agilent 82357B
Steps to Install the 82357B 6
Step 1: Before You Install the 82357B 7
•Check Your Shipment 7
•Check System Requirements 8
Step 2: Installing Agilent IO Libraries Suite 9
•Checking for Installed Agilent IO Libraries 9
•Installing Agilent IO Libraries Suite 11
Step 3: Installing the 82357B Driver 12
Step 4: Connecting the 82357B 13
•82357B Hardware Description 13
•Connecting the 82357B to Your PC 14
•Connecting the 82357B to a USB Hub 15
•Observing Windows Plug-and-Play Manager Sequence (Windows XP Only) 17
Step 5: Configuring the 82357B 21
•Setting 82357B Default Configuration 21
•Setting 82357B Custom Configuration 23

Contents 2
Step 6: Connecting GPIB Instruments 26
•Connecting a Single GPIB Instrument 26
•Connecting Multiple GPIB Instruments 27
Step 7: Programming via the 82357B 28
•Establishing Instrument Communication 28
•Programming GPIB Instruments 29
2 Using the Agilent 82357B
Modes of Operation 33
•Initial 82357B Operating States 33
•Introduction to 82357B Operating Modes 34
•Single 82357B Operation 35
•Multiple 82357B Operation 37
•SRQ Operation 37
Setting Configuration Parameters 39
•Changing Configuration Parameters 39
•Changing Modes of Operation 40
•Setting Timeout Floor Values 41
•Setting 82357B High-Performance Operation 42
3 Troubleshooting the Agilent 82357B
Troubleshooting Flowchart 45
•Observe the LED States 45
Hardware Checks 47
•Check USB Cables, USB Interface, Host PC 47
•Reboot PC 47
•Check Device Manager 48
Software Installation Checks 49
•Check Suspend/Resume Operation 49
•Verify Agilent IO Libraries Suite Installation 49
•Verify 82357B USB Driver Installation 51
Software Configuration Checks 53
•Checking IO Control Operation 53
•Check USB Scanner 54
Service and Support Information 55

Contents 3
•82357B Service Information 55
•Contacting Agilent 55
4 Product Specifications
Technical Specifications 57
Supplementary Information 59
•GPIB Modes of Operation Supported 59
•IEEE-488.1 and IEEE-488.2 Compliance 59
•SRQ Response Time 59
•Default T1 Delay 60
•Maximum 82357B System Configuration 60
Index 62

Contents 4
List of Figures
Figure 1-1, “Steps to Install the 82357B” 6
Figure 1-2, “Contents of Agilent 82357B USB/GPIB Interface” 7
Figure 1-3, “IO Libraries Suite Icon” 9
Figure 1-4, “82357B Hardware Features” 14
Figure 1-5, “Connecting the 82357B to Your PC” 14
Figure 1-6, “Connecting the 82357B to a USB Hub” 16
Figure 1-7, “Welcome to the Found New Hardware Wizard” 18
Figure 1-8, “Completing the Found New Hardware Wizard” 19
Figure 1-9, “Please wait while the wizard installs the software... Dialog Box” 20
Figure 1-10, “Agilent 82357B USB/GPIB Interface Detected Dialog Box” 22
Figure 1-11, “Agilent 82357B USB/GPIB Interface Detected Dialog Box” 24
Figure 1-12, “Connection from Single GPIB Instrument to the GPIB Port” 26
Figure 1-13, “Typical Way of Connecting Three GPIB instruments to an 82357B” 27
Figure 1-14, “Typical System Installation - 82357 USB/GPIB Interface” 31
Figure 2-15, “Sequence of initial operating states” 34
Figure 2-16, “Agilent 82357B (HighSpeed) Interface - USB/GPIB” 40
Figure 3-1, “Troubleshooting Flowchart” 46

5
Agilent 82357B USB/GPIB Interface
User’s Guide
Agilent Technologies
1
Installing the Agilent 82357B
Steps to Install the 82357B 6
Step 1: Before You Install the 82357B 7
Step 2: Installing Agilent IO Libraries Suite 9
Step 3: Installing the 82357B Driver 12
Step 4: Connecting the 82357B 13
Step 5: Configuring the 82357B 21
Step 6: Connecting GPIB Instruments 26
Step 7: Programming via the 82357B 28
This chapter shows a suggested seven-step process to install the 82357B
and the Agilent IO Libraries Suite, to connect the 82357B to your PC, to
configure the 82357B and to program GPIB instruments via the 82357B.
NOTE
The Agilent 82357B USB/GPIB Interface is supported ONLY for PCs with Windows 2000 or
Windows XP Professional operating systems.
The operating systems below are specifically not supported:
•Windows ME
•Windows 98 First (“Gold”) Edition
•Windows 98 (Second Edition)
•Windows 95
•Windows NT 4.0 (OS does not support USB)
In case of difficulty in installing the 82357B, see Chapter 3, “Troubleshooting the Agilent
82357B”.

6 82357B USB/GPIB Interface User’s Guide
1 Installing the Agilent 82357B
Steps to Install the 82357B
Figure 1- 1 below shows a suggested sequence of steps to install and
configure the 82357B and to communicate between your PC and GPIB
instruments.
Figure 1-1 Steps to Install the 82357B
Step 1: Before You Install the 82357B
•Check your shipment
•Check system requirements
Step 2: Installing Agilent IO Libraries Suite
•Check for installed Libraries
•Install the Libraries
Step 3: Installing the 82357B Driver
•Install driver
Step 4: Connecting the 82357B
•Connect to a USB Port
•Observe plug-and-play manager
Step 5: Configuring the 82357B
•Set default configuration OR ...
•Set custom configuration
Step 6: Connecting GPIB Instruments
•Connect a single GPIB instrument OR ...
•Connect multiple GPIB instruments
Step 7: Programming via the 82357B
•Establish communication
•Program GPIB instruments
