Agilent Technologies 82357B User manual

Agilent Technologies
Agilent 82357B
USB/GPIB Interface
User’s Guide

ii 82357B User’s Guide
Notices
© Agilent Technologies, Inc. 2006-2012
No part of this manual may be reproduced in
any form or by any means (including elec-
tronic storage and retrieval or translation
into a foreign language) without prior agree-
ment and written consent from Agilent
Technologies, Inc. as governed by United
States and international copyright laws.
Manual Part Number
82357-90003
Edition
Fifth Edition, January 1, 2012
Printed in Malaysia
Agilent Technologies, Inc.
5301 Stevens Creek Blvd.
Santa Clara, CA 95052 USA
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connec-
tion with the furnishing, use, or per-
formance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accor-
dance with the terms of such license.
Restricted Rights Legend
U.S. Government Restricted Rights. Soft-
ware and technical data rights granted to
the federal government include only those
rights customarily provided to end user cus-
tomers. Agilent provides this customary
commercial license in Software and techni-
cal data pursuant to FAR 12.211 (Technical
Data) and 12.212 (Computer Software) and,
for the Department of Defense, DFARS
252.227-7015 (Technical Data - Commercial
Items) and DFARS 227.7202-3 (Rights in
Commercial Computer Software or Com-
puter Software Documentation).
Safety Notices
CAUTION
A CAUTION notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and
met.
Trademark Acknowledgements
Microsoft, Windows, Visual Studio,
and Windows Vista are trademarks
or registered trademarks of
Microsoft Corporation in the United
States and/or other countries.

82357B User’s Guide iii
U.S. Government Restricted Rights
The Software and Documentation have been developed entirely at private
expense. They are delivered and licensed as “commercial computer
software” as defined in DFARS 252.227- 7013 (Oct 1988), DFARS
252.211-7015 (May 1991) or DFARS 252.227-7014 (Jun 1995), as a
“commercial item” as defined in FAR 2.101(a), or as “Restricted computer
software” as defined in FAR 52.227-19 (Jun 1987) (or any equivalent
agency regulation or contract clause), whichever is applicable. You have
only those rights provided for such Software and Documentation by the
applicable FAR or DFARS clause or the Agilent standard software
agreement for the product involved.
General Warranty
The material contained in this document is provided “as is,” and is subject
to being changed, without notice, in future editions. Further, to the
maximum extent permitted by applicable law, Agilent disclaims all
warranties, either express or implied with regard to this manual and any
information contained herein, including but not limited to the implied
warranties of merchantability and fitness for a particular purpose. Agilent
shall not be liable for errors or for incidental or consequential damages in
connection with the furnishing, use, or performance of this document or
any information contained herein. Should Agilent and the user have a
separate written agreement with warranty terms covering the material in
this document that conflict with these terms, the warranty terms in the
separate agreement will control. Duration and conditions of warranty for
this product may be superseded when the product is integrated into
(becomes a part of) other Agilent products. During the warranty period,
Agilent will, at its option, either repair or replace products which prove to
be defective. The warranty period begins on the date of delivery or on the
date of installation if installed by Agilent.
Warranty Service
For warranty service or repair, this product must be returned to a service
facility designated by Agilent. For products returned to Agilent for
warranty service, the Buyer shall prepay shipping charges to Agilent and
Agilent shall pay shipping charges to return the product to the Buyer.
However, the Buyer shall pay all shipping charges, duties, and taxes for
products returned to Agilent from another country.

iv 82357B User’s Guide
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting from improper
or inadequate maintenance by the Buyer, Buyer-supplied products or
interfacing, unauthorized modification or misuse, operation outside of the
environmental specifications for the product, or improper site preparation
or maintenance.
The design and implementation of any circuit on this product is the sole
responsibility of the Buyer. Agilent does not warrant the Buyer’s circuitry
or malfunctions of Agilent products that result from the Buyer’s circuitry.
In addition, Agilent does not warrant any damage that occurs as a result of
the Buyer’s circuit or any defects that result from Buyer-supplied products.
To the extent allowed by local law, Agilent makes no other warranty,
expressed or implied, whether written or oral with respect to this product
and specifically disclaims any implied warranty or condition of
merchantability, fitness for a particular purpose or satisfactory quality.
Exclusive Remedies
To the extent allowed by local law, the remedies provided herein are the Bu
yer’s sole and exclusive remedies. Agilent shall not be liable for any direct,
indirect, special, incidental, or consequential damages (including lost
profit or data), whether based on warranty, contract, tort, or any other legal
theory.
Technology Licenses
The hardware and/or software described in this document are furnished
under a license and may be used or copied only in accordance with the
terms of such license.

82357B User’s Guide v
Safety Summary
The following general safety precautions must be observed during all
phases of operation of this instrument. Failure to comply with these
precautions or with specific warnings elsewhere in this manual violates
safety standards of design, manufacture, and intended use of the
instrument. Agilent Technologies, Inc. assumes no liability for the
customer’s failure to comply with these requirements.
Safety Notices
WARNING
A WARNING notice denotes a hazard. It calls attention to an operating
procedure, practice, or the like that, if not correctly performed or
adhered to, could result in personal injury or loss of life. Do not proceed
beyond a WARNING notice until the indicated conditions are fully
understood and met.
CAUTION
A CAUTION notice denotes a hazard. It calls attention to an operating
procedure, practice, or the like that, if not correctly performed or adhered
to, could result in damage to the product or loss of important data. Do not
proceed beyond a CAUTION notice until the indicated conditions are fully
understood and met.

vi 82357B User’s Guide
Safety Symbols
The following symbol on the instrument and in the documentation
indicates precautions that must be taken to maintain safe operation of the
instrument.
Regulatory Markings
The Instruction Documentation Symbol. The product is marked with this symbol
when it is necessary for the user to refer to the instructions in the supplied
documentation.
The CE mark shows that the product complies with all the relevant European
Legal Directives.
ICES/NMB-001 indicates that this ISM device complies with Canadian
ICES-001.
The CSA mark is a registered trademark of the Canadian Standards Association.
A CSA mark with the indicators “C” and “US” means that the product is certified
for both the U.S. and Canadian markets, to the applicable American and
Canadian standards.
The C-tick mark is a registered trademark of the Spectrum Management Agency
of Australia. This signifies compliance with the Australian EMC Framework
regulations under the terms of the Radio Communications Act of 1992.
This product complies with the WEEE Directive (2002/96/EC) marking
requirement. The affixed product label indicates that you must not discard this
electrical/electronic product in domestic household waste.

82357B User’s Guide vii
General Safety Information
WARNING
• DO NOT use the device if it appears damaged or defective.
• Observe all markings on the device before connecting any wiring to
the device.
• DO NOT operate the device in the presence of flammable gases or
fumes.
• DO NOT install substitute parts or perform any unauthorized
modification to the device.
CAUTION
• Use the device with the cables provided.
• Repair or service that is not covered in this manual should only be
performed by qualified personnels.

viii 82357B User’s Guide
Waste Electrical and Electronic Equipment (WEEE) Directive
2002/96/EC
This instrument complies with the WEEE Directive (2002/96/EC) marking
requirement. This affixed product label indicates that you must not discard
this electrical/electronic product in domestic household waste.
Product Category:
With reference to the equipment types in the WEEE directive Annex 1, this
instrument is classified as a “Monitoring and Control Instrument” product.
The affixed product label is shown as below:
Do not dispose in domestic household waste
To return this unwanted instrument, contact your nearest Agilent office, or
visit:
www.agilent.com/environment/product
for more information.

82357B User’s Guide ix
Environmental Conditions
This instrument is designed for indoor use only. The table below shows
the general environmental requirements for the product.
General Maintenance
To remove the dirt or moisture in the enclosure:
• Wipe the case with a damp cloth and mild detergent.
• Do not use abrasives or solvents.
• Wipe the contacts in each terminal with a clean swab dipped in
alcohol.
Environmental Conditions Requirements
Temperature 0 °C to 55 °C (Operating)
–40 °C to +70 °C (Non-operating)
Humidity Operating up to 90% at 40 °C (Non-condensing)
Non-operating up to 90% at 65 °C (Non-condensing)
CAUTION
This product is designed for use in compliance with:
• IEC 61010-1:2001/EN 61010-1:2001
• USA: UL61010-1: 2004
• Canada: CSA C22.2 No. 61010-1:2004

x82357B User’s Guide
Declaration of Conformity (DoC)
The Declaration of Conformity (DoC) for this instrument is available on the
Agilent Web site. You can search the DoC by its product model or
description at the Web address below.
http://regulations.corporate.agilent.com/DoC/search.htm
NOTE
If you are unable to search for the respective DoC, please contact your
local Agilent representative.

82357B User’s Guide xi
Table of Contents
1 Installing the Agilent 82357B
Step 1: Checking Your Shipment 2
Step 2: Installing Agilent IO Libraries Suite 3
Step 3: Connecting the 82357B 5
82357B hardware description 5
Connecting the 82357B to your PC 6
Connecting the 82357B to a USB hub 7
Step 4: Connecting GPIB Instruments 9
Connecting a single GPIB instrument 9
Connecting multiple GPIB instruments 10
Step 5: Programming via the 82357B 11
Establishing instrument communication 11
Programming GPIB instruments 13
2 Using the Agilent 82357B
Initial 82357B Operating States 18
Introduction to 82357B operating modes 19
Single 82357B operation 20
Multiple 82357B operation 21
SRQ operation 22
Setting Configuration Parameters 23
Changing configuration parameters 23
Changing modes of operation 24
Setting timeout floor values 25
Setting 82357B high-performance operation 26
3 Troubleshooting the Agilent 82357B
Troubleshooting Flowchart 28

xii 82357B User’s Guide
Observe the LED states 28
Hardware Checks 30
Check USB cables, USB interface, host PC 30
Check Device Manager 31
Software Installation Checks 32
Check suspend/resume operation 32
Verify Agilent IO Libraries Suite installation 32
Software Configuration Checks 35
Checking IO Control operation 35
Check USB scanner 36
Service and Support Information 37
Contacting Agilent 37
4 Product Specifications
Technical Specifications 40
Supplementary Information 43

1
Agilent 82357B USB/GPIB Interface
User’s Guide
Agilent Technologies
1
Installing the Agilent 82357B
This chapter shows a suggested five- step process to install
the 82357B and the Agilent IO Libraries Suite, to connect
the 82357B to your PC and to program GPIB instruments via
the 82357B.

282357B User’s Guide
1 Installing the Agilent 82357B
Step 1: Checking Your Shipment
Your 82357B USB/GPIB Interface shipment should include
the items shown in Figure 1- 1. If any item is missing or
damaged, keep the shipping materials and contact Agilent
Technologies. See “Contacting Agilent” on page 37 later in
this guide for addresses and telephone numbers.
As you check the shipment items, verify that the 82357B
serial number at the bottom of the 82357B matches the
serial number shown on the serial number label of the
82357B Kit Box and on the 82357B Certificate of
Calibration. If the Serial Numbers do not match, contact
Agilent. If all Serial Numbers match, you may want to record
the Serial Number for future reference.
Figure 1-1 Contents of Agilent 82357B USB/GPIB Interface

Installing the Agilent 82357B 1
82357B User’s Guide 3
Step 2: Installing Agilent IO Libraries Suite
This section describes how to install the Agilent IO Libraries
Suite on your PC. The Agilent IO Libraries Suite is a
collection of libraries and utilities that gives you the ability
to use your instruments from instrument control software.
You should install the Agilent IO Libraries Suite as your first
step before installing the hardware because it installs the
necessary software and drivers to control your instruments.
If possible, always use the most recent version of the Agilent
IO Libraries Suite. This version supports the newest
interfaces and operating systems, and has the most
advanced features.
1Verify that your PC meets the minimum system
requirements. Refer to the IO Libraries Web page at
www.agilent.com/find/iosuite or the IO Libraries
Suite Readme.
2Close all applications on your computer. Insert the Agilent
Automation- Ready CD in your CD- ROM drive or download
and install the IO Libraries software from
www.agilent.com/find/iosuite.
3Follow the instructions as prompted during the
installation. You can select either a Typical or a Custom
installation:
•Typical - In most cases, you can select the Typical
installation which installs the IO Libraries Suite using
the recommended settings.
NOTE
You must have Administrator privileges to install Agilent IO Libraries Suite
Connection Expert.

482357B User’s Guide
1 Installing the Agilent 82357B
•Custom - Select the Custom installation to:
aInstall the IO Libraries Suite in another directory
(for 32- bit operating systems only).
bSave disk space by not installing interface manuals.
cUse Agilent 32- bit VISA with another vendor's VISA
on the same PC in side- by- side mode. Details on
side- by- side mode are available at
www.agilent.com/find/side- by- side- install or in the
IO Libraries Suite help.
4After the IO Libraries suite is successfully installed, you
will see the IO icon on the Windows®taskbar
notification area.
Figure 1-2 IO icon on the Windows taskbar notification area

Installing the Agilent 82357B 1
82357B User’s Guide 5
Step 3: Connecting the 82357B
After the Agilent IO Libraries Suite software has been
installed, you can connect the 82357B to any USB port on
your PC or you can connect the 82357B via standard USB
hubs.
82357B hardware description
The Agilent 82357B provides a direct interface connection
from your PC USB port to GPIB instruments. The 82357B
includes an attached USB cable that is USB 2.0 compliant.
This cable is shielded and the connector is specified for up
to 1,500 insertions. An 82357B can be directly connected to
a single GPIB instrument or up to 14 GPIB instruments via
GPIB cables. Up to four 82357B converters may be
connected to your PC via standard USB hubs.
Figure 1-3 82357B Hardware Features
NOTE
If the Agilent IO Libraries Suite software have not been installed on your
PC, STOP. Install the libraries (see Step 2: Installing Agilent IO Libraries
Suite).
Green ACCESS LED
USB Cable
(Connect to USB port)
Red FAIL LED
Green READY LED
GPIB Connector
(Connect up to
14 GPIB instruments)

682357B User’s Guide
1 Installing the Agilent 82357B
Connecting the 82357B to your PC
This section shows steps to connect the 82357B to a USB
port on your PC or to your PC via a USB Hub.
1Connect to a USB Port. Make sure the PC is ON and
plug the 82357B USB cable into any available USB port
on your PC. Do not connect the 82357B to GPIB
instruments at this time.
Figure 1-4 Connecting the 82357B to Your PC
2Observe the LEDs. Observe the LEDs on the 82357B for
at least 10 seconds. See Chapter 2, “Using the Agilent
82357B” for a description of the normal LED sequence
during an initial installation of the 82357B.
aInitially, only the red FAIL LED should be ON. After a
few seconds, all three LEDs should be ON. When all
three LEDs are ON, this shows that the 82357B has
been successfully installed.
bIf all three LEDs are not ON after 10 seconds and all
Windows Plug- and- Play Manager activity has ceased,
STOP. See Chapter 3, “Troubleshooting the Agilent
82357B” for diagnostics information.

Installing the Agilent 82357B 1
82357B User’s Guide 7
Connecting the 82357B to a USB hub
This section shows steps to connect the 82357B to a USB
port on your PC via a standard USB hub.
1Plug the power adapter into the hub and into an electrical
outlet. Make sure the hub is operating in self- powered
mode. Figure 1- 5 shows a 4- port self- powered USB hub
with two 82357B USB/GPIB Interfaces connected.
2Make sure your PC is ON. Connect the USB cable of the
USB hub to any available USB port on your PC.
3Plug at least one 82357B USB/GPIB Interface into the
port of the USB hub. It is not necessary to connect GPIB
instruments to any 82357B at this time.
Figure 1-5 Connecting the 82357B to a USB Hub
NOTE
Any USB hub used with the 82357B MUST be self-powered (must not be
bus-powered or powered from the USB bus). Also, be sure to check the
applicable USB hub documentation for hub operating parameters, such as
power requirements and maximum length of USB cables.

882357B User’s Guide
1 Installing the Agilent 82357B
4Observe the LEDs on the 82357B for at least 10 seconds.
See Chapter 2, “Using the Agilent 82357B” for a
description of the normal LED sequence during an initial
installation of the 82357B.
aInitially, only the red FAIL LED should be ON. After a
few seconds, all three LEDs should be ON. When all
three LEDs are ON, this shows that the 82357B has
been successfully installed.
bIf all three LEDs are not ON after 10 seconds and all
Windows Plug- and- Play Manager activity has ceased,
STOP. See Chapter 3, “Troubleshooting the Agilent
82357B” for diagnostics information.
NOTE
For Windows Vista®and Windows 7, there will be no Windows Plug and
Play Manager Sequence because once 82357B is initially plugged into a
USB port it will automatically install the driver.
