AGM ASP TM-384 Series User manual

USER MANUAL
ASP TM-384
THERMAL IMAGING MONOCULAR

© 2019 AGM Global Vision. All rights reserved worldwide.
This documentation is subject to change without notice.
No parts of this manual, in whole or in part, may be copied, photocopied, translated, or
transmitted by any electronic medium or in machine-readable form without the prior written
permission of AGM Global Vision.
If you have questions that are not covered in this manual, or need service, contact AGM Global
Vision customer support for additional information prior to returning a product.
AGM Global Vision
173 West Main Street
PO Box 962
Springerville, AZ 85938
Tel. [phone]
Fax [phone]
[email protected]
www.agmglobalvision.com
EXPORT INFORMATION
Buyer acknowledges that all products supplied by AGM Global Vision are subject to U.S. export control laws,
including, but not limited to, the Export Administration Regulations, the International Economic Emergency
Powers Act, and various U.S. embargoes and sanctions. AGM Global Vision products may not be exported,
re-exported, or transferred contrary to U.S. export control laws. In particular, AGM Global Vision products may
not be exported, re-exported, or transferred to prohibited countries, individuals, organizations, or entities,
including but not limited to those individuals and entities listed on the List of Specially Designated Nationals
and Blocked Persons administered or maintained by the U.S. Office of Foreign Assets Control (“OFAC”), the
various lists maintained by the Bureau of Industry and Security of the Department of Commerce, and the U.S.
State Department and Buyer represents and warrants that neither Buyer nor any of its officers, directors, or
employees are on such lists. Distribution or resale by Buyer to such countries, individuals, organizations, or
entities is expressly prohibited. Buyer has and will maintain a positive process to ensure compliance with this
Section.
2019.07.05

3ASP TM-384 USER MANUAL
LIST OF CONTENTS
TITLE PAGE
Safety Summary 4
SECTION 1. GENERAL INFORMATION 5
1.1 System Description 5
1.2 Key Features 5
1.3 Standard Components 6
SECTION 2. OPERATING INSTRUCTIONS 7
2.1. Basic Operations 7
2.2 Main Function 10
SECTION 3. MAINTENANCE INSTRUCTIONS 15
3.1 Maintenance 15
3.2 Troubleshooting 15
SECTION 4. WARRANTY INFORMATION 17
4.1 Warranty Information and Registration 17
SECTION 5. SPECIFICATIONS 19

4AGM Global Vision
SAFETY SUMMARY
• Read and follow all instructions
• Read all warnings
• Only use the attachments/accessories specified by the manufacturer
• All service must be provided by the manufacturer
WARNING:
LASER LIGHT SUPPLEMENT:
The laser radiation emitted from the device can cause eye injuries, burning of skin or inflammable
substances. Before enabling the Light Supplement function, make sure no human or inflammable
substances are in front of the laser lens.
Do not place the device where minors can fetch it.
WARNING:
This product contains natural rubber latex, which may cause potentially fatal allergic reactions! If
you are allergic to latex, it is important that you strictly avoid exposure to products that contain it.
WARNINGS AND CAUTIONS:
• All the electronic operation should be strictly compliance with the electrical safety regulations,
fire prevention regulations and other related regulations in your local region.
• Please use the power adapter, which is provided by normal company. The power consumption
cannot be less than the required value.
• Do not connect several devices to one power adapter as adapter overload may cause over-heat
or fire hazard.
• Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnetism radiation. Avoid the device installation on vibrations surface or places
subject to shock (ignorance can cause equipment damage).
• Do not place the device in extremely hot (refer to the specification of the device for the
detailed operating temperature), cold, dusty or damp locations, and do not expose it to high
electromagnetic radiation.
• The device cover for indoor use should be kept from rain and moisture.
• Exposing the device to direct sun light, low ventilation or heat source such as heater or radiator
is forbidden (ignorance can cause fire danger).
• Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfunction however), and affecting the endurance of sensor at the
same time.
• For long-term storage of the battery, make sure you fully charge it every half year, to ensure the
battery quality. Otherwise, you may damage the battery.
NOTES:
The detector spectral band provides better visibility through smoke, dust, rain, smog, etc.
Infrared radiation does not travel through glass. As a result, the monocular does not detect objects
if they are behind glass windows or other barriers.

5ASP TM-384 USER MANUAL
1 GENERAL INFORMATION
1.1 SYSTEM DESCRIPTION
The handheld thermal monocular is a handheld thermal camera with functions of observation, hot
spot mark, distance measurement, Wi-Fi hot spot, and so on. The high-sensitivity built-in IR
detector provides you with clear view even in total darkness.
TABLE 1-1. ASPTM-384 SYSTEM DESCRIPTION
ITEM DESCRIPTION ITEM DESCRIPTION
1Body 8LED Indicator
2 Lens Cap 9 Eyepiece
3 Power Button 10 Focus Knob
4MODE Button 11 USB Interface
5Capture Button 12 Battery Status Indicator
6Menu Button 13 Tripod Screw
7Zoom Button
FIGURE 1-1. ASP TM-384 MAIN PARTS
11
10
12
13
1
2
34
56
789

6AGM Global Vision
1.2 KEY FEATURES
• High performance chip, and DDE (Digital Detail Enhancement) technique
• 1024 × 768 Resolution OLED display
• Built-in rechargeable Li-Ion battery
• Up to five hours continuous running (Wi-Fi hot spot function off)
• USB Cable
• Small in size and light in weight
• Limited 3-year warranty
1.3 STANDARD COMPONENTS
The standard components of the ASPTM-384 are shown in Figure 1-2 and listed in Table 1-2.
The ITEM NO. column indicates the number used to identify items in Figure 1-2.
TABLE 1-2. ASPTM-384 STANDARD COMPONENTS
ITEM NO. DESCRIPTION QUANTITY
1Asp Monocular 1
2 USB Cable 1
3Neck Belt 1
4Neck Belt 1
5Operation Manual 1
6 Protective Bag 1
45
236
1
FIGURE 1-2. ASPTM-384 STANDARD COMPONENTS

7ASP TM-384 USER MANUAL
2 OPERATING INSTRUCTIONS
2.1. BASIC OPERATIONS
2.1.1 UNPACKING
The following steps must be completed prior to each mission.
1. Open the carrying case, remove the monocular, and verify that all components are accounted
for.
2. Inspect the monocular for any obvious evidence of damage to the optical surfaces, body,
eyecup, operation buttons, etc. Ensure that all optical surfaces are clean and ready for use.
Clean all optical surfaces with a lens tissue.
2.1.2 CHARGING THE MONOCULAR
NOTE:
Please charge the monocular with the delivered USB cable and power adapter. The charging
temperature should be 0 °C to 45 °C (32 °F to 113 °F).
1. Lift the USB cover.
USB INTERFACE
BATTERY
STATUS
INDICATOR
FIGURE 2-1. ASP TM-384 CHARGING

8AGM Global Vision
2. Plug in the USB cable and connect the other terminal into the power adapter.
3. Plug the power adapter to the power source.
When the monocular is turned on, the OSD (on-screen display) shows the battery status. When you
see the Low Battery status, charge the monocular and ensure it’s working properly.
TABLE 2-1. BATTERY LED INDICATOR STATUS
INDICATORS FUNCTIONS
Red Flash Error occurred.
Solid Red Battery is properly charged.
Solid Green Battery is fully charged.
Off Battery is not charged.
2.1.3 BUTTONS
TABLE 2-2. BATTERY LED INDICATOR STATUS
BUTTONS FUNCTIONS
Power Hold: Power On/Off
MODE Press: Switch Pallet
Hold: Distance Measure On/Off
Capture Press: Capture Snapshot
Hold: Start/Stop Record Video
Menu Press: Shutter Release
Hold: Menu Operation
Zoom ± Press: Digital Zoom
POWER LED INDICATOR
FIGURE 2-2. BUTTONS AND LED INDICATOR

9ASP TM-384 USER MANUAL
2.1.4 POWER ON AND OFF
Power On
Hold the POWER button for four seconds and the LED indicator in the front turns green. After the
device is powered on, the indicator keeps green.
Refer to the figure below for the main view of the monocular.
Power Off
When the monocular is turned on, hold the POWER button for four seconds to power off the device.
2.1.5 THERMAL VIEW OBSERVATION
1. Power on the monocular.
2. Hold the monocular and make sure the eyepiece covers your eye.
3. Slide the sight adjust knob to adjust the diopter until the OSD text or image is clear.
NOTE:
You must perform the sight adjustment before any further use of the monocular.
4. Point the monocular towards the target of the view.
WI-FI HOT SPOT BATTERY
DIGITAL ZOOM STORAGE
FIGURE 2-3. THE MAIN VIEW
SIGHT ADJUST KNOB
FIGURE 2-4. ASPTM-384 FOCUS KNOB

10 AGM Global Vision
2.1.6 BASIC OPERATION
Connect the thermal monocular to your PC with USB cable, you can export the recorded videos
and captured snapshots.
1. Hold the button to enter the menu and select the icon .
2. Press and the icon turns to and the Wi-Fi hot spot function is disabled.
3. Connect the thermal monocular to your PC with USB cable, you can see a detected removable
disk.
NOTES:
When you connect the device to PC for the first time, it installs the drive program automatically.
When you connect the device to PC, the device displays images, but functions such as recording,
capturing and Wi-Fi hot spot are disabled.
File Export
1. Connect the thermal monocular to your PC with USB cable and open the detected disk.
2. Enter DCIM>100EZVIZ to view the videos and snapshots.
- Select and copy the videos to PC and play the file with the player.
- Select and copy the snapshots to PC and view the files.
3. Disconnect the device from your PC.
Upgrade
1. Connect the thermal monocular to your PC with USB cable and open the detected disk.
2. Copy the upgrade file and paste it to the root directory of the device.
3. Disconnect the device from your PC.
4. Reboot the monocular and the device upgrades automatically. The upgrading process will be
displayed in the main interface.
2.2 MAIN FUNCTION
2.2.1 MENU OPERATION
When the monocular is turned on, hold the button for three seconds to display the OSD menu.
FIGURE 2-5. THE MAIN MENU
