AIC SILOX 140L User guide

heatingsyst e m s
siloX
EN
installation
and maintenance
manual
FOR THE INSTALLER AND THE USER
140·180·215·260·400·600·1000 L
DOMESTIC HOT WATER STAINLESS STEEL CYLINDERS
I10_087-00 • SILOX
SILOX
heatingsystems

2I10_087-00 • SILOX_EN
CERTIFIED PRODUCT
All our models are compliant with:
îEuropean Directive 97/23/EEC - Pressure Equipment (art. 3.3).
models that can operate with an electric heating element :
îEuropean standard EN 60335 - Safety in electrical and similar
îEuropean Directive 2006/95/EC - Low Voltage Directive.
îEuropean Directive 2004/108/EC - Electromagnetic Compatibility.
This implies that our products are marked with CE, that qualies them to be market-
ed in any country of the EU with all security guarantees.
The quality of our products is essential to us,
and we aim therefore at improving them contin-
ually. To this end, we reserve the right to change
the technical characteristics and features of our
products without prior notice. Please check for
the latest revision of the manual on our website
(www.myaic.eu).
The manufacturer shall not be held liable for any
malfunction of the product resulting from:
îThe failure to comply with the safety and
installation instructions provided herein,
îThe failure to comply with the safety and
operation instructions and recommenda-
tions provided herein,
îThe failure to have the appliance main-
tained regularly,
îA modication of the appliance that is not
approved by the manufacturer,
îThe use the product for any other purpose
than its intended use,
îThe use of components and accessories
that are not approved by the manufacturer.
Installer’s Responsibility
The installer is responsible for the correct instal-
lation and commissioning of the appliance ac-
cording to:
îThe instructions and recommendations
provided herein,
îThe applicable regulations and standards.
The installer shall provide the end-user with:
îAny relevant explanation about the operation
of the appliance and the hydraulic system as
well as the safety devices that are provided,
îAny instruction regarding periodic checks
to be performed and possible anomaly to
be reported,
îAll the documentation delivered with the
appliance and installed accessories.
The installer shall also inform the end-user of the
necessity to have the appliance checked and
maintained regularly by a qualied professional.
End-user’s Responsibility
To ensure the best performances and safety of
the appliance, the end-user shall:
îMake sure that the appliance is installed, and
commissioned by a qualied professional,
îMake sure that the appliance is checked
and maintained regularly by a qualied
professional,
îComply with all the instructions and recom-
mendations provided in the appliance docu-
mentation,
îMake sure to receive from the installer all
the necessary explanations related to the
operation of the appliance and the safety
devices,
îMake sure to receive from the installer all the
appliance and accessories documentation,
îKeep all the appliance documentation in a
safe place for future use.
The end-user shall use the product for its intend-
ed use.
îShould the installer or the end user not comply with the instructions and require-
ments stated in this manual, the warranty will be void.
îFor more information on the warranty terms and conditions, please connect to
our website: www.myaic.eu.
i

3
I10_087-00 • SILOX_EN
Table of ConTenTs
General InformatIon ....................................4
About This Manual ...............................................4
General Safety Instructions ..................................5
Product descrIPtIon ...................................6
SILOX Cylinders ...................................................6
Control Panel........................................................7
Optional Accessories ...........................................7
technIcal sPecIfIcatIons ..............................8
Dimensions...........................................................8
Product Data ........................................................9
Hydraulic Performance.........................................9
Recommendations for the Quality of Water .......10
G3 Requirements in the UK................................11
Hydraulic Kit Characteristics..............................14
Wiring Diagram...................................................15
Optional Heating Element Wiring Diagrams.......15
Product InstallatIon .................................16
Safety Instructions for the Installation................16
Package Contents .............................................16
Optional Accessories .........................................16
Unpacking the Product ......................................16
Installing and Preparing the Cylinder .................16
Optional Heating Element Installation ................17
Safety Instructions and Recommendations
for the Hydraulic Circuits ....................................18
Hydraulic Connections .......................................19
commIssIonInG ...........................................21
Filling the Cylinder..............................................21
Starting Up .........................................................21
Safety Instructions and Recommendations .......22
Periodic Checks and Maintenance Tasks ..........22
Draining the Cylinder..........................................24
troubleshootInG .......................................25
Manual Reset of Control and Safety Thermostat.... 25
Product fIche ...........................................26
Fig. 1. Product Description ................................................ 6
Fig. 2. Control Panel Description....................................... 7
Fig. 3. Optional DHW Hydraulic Kit ................................ 14
Fig. 4. SILOX Cylinder Wiring Diagram........................... 15
Fig. 5. Optional Heating Element Wiring Diagram ........ 15
Fig. 6. Heating Element Location .................................... 17
Fig. 7. SILOX Cylinder Connected to an External Heat
Generator (Boiler) - Typical Connection Diagram ...19
Fig. 8. SILOX Cylinder Used as an Electric Water
Heater - Typical Connection Diagram................. 20
Fig. 9. SILOX Cylinder Draining - Typical Connection
Diagram .................................................................. 24
INDEX OF ILLUSTRATIONS

This documentation is part of the product. It will be handed over to the end-user who will keep it,
with all the other applicable documents, in a safe place and readily available for use.
Before installing, operating or maintaining the appliance, please carefully read this manual and all
the applicable documents provided with the components and accessories. They contain essen-
tial safety information.
Symbols used in this Manual
Indicates an essential instruction
which, if not followed, can result
in a hazardous situation that can
cause serious damage to equip-
ment and/or injuries or death.
Indicates an important instruction
which, if not followed, could re-
sult in a hazardous situation that
could cause damage to equip-
ment and/or injuries.
Indicates an essential instruction
in relation with the presence of
electrical power and a danger of
electrical shock.
The electrical supply to the appli-
ance must be activated/deactivated
through the external circuit breaker
or the power supply cable must be
connected/disconnected.
The primary and DHW circuits of the
appliance must be full of water/empty.
Indicates an important piece of
information.
i
iCold water inlet connection.
Domestic Hot Water outlet connection.
Primary circuit supply connection.
Primary circuit return connection.
4I10_087-00 • SILOX_EN
General InformatIon
About This Manual

5
I10_087-00 • SILOX_EN
General InformatIon
îThis appliance must be installed ac-
cording to the applicable local regu-
lations and standards by a quali ed
professional.
îElectrical connections must be car-
ried out according to applicable local
regulations and standards by a quali-
 ed professional.
îThis appliance can be used by chil-
dren who are at least 8 years old and
by persons with reduced physical,
sensory or mental capabilities or lack
of experience and knowledge, provid-
ed that they are under supervision or
have been given instructions concern-
ing the use of the appliance in a safe
way and that they understand the haz-
ards involved.
îCleaning and user maintenance shall
not be performed by children without
supervision. Children shall not play
with the appliance.
îAny modi cation to the appliance and
its components is strictly forbidden
without the prior written consent of the
manufacturer.
îIf components need to be replaced,
only genuine factory parts or compo-
nents approved by the manufacturer
must be used.
When working on the appliance
and the system, make sure to
use the appropriate tools to
avoid damaging the pipes and
components.
îWhen unpacking the appli-
ance, check the integrity and
condition of the packaging
and that all the components
and accessories described
in the packing list are pres-
ent. Contact your supplier in
case of problem.
îWhen discarding the packaging, do not
contaminate the environment. Dispose of
it according to the applicable local regu-
lations on recycling.
i
îWhen the appliance is con-
nected to the electrical net-
work, it must be earthed.
îMake sure that a fuse or circuit breaker
of the recommended rating is installed
outside the appliance, so as to be able
to shut the power down.
îBefore performing any operation on
the electrical circuit, isolate the electri-
cal supply of the appliance through the
external power-cutting device (fuse,
circuit-breaker, etc.).
General Safety Instructions

6I10_087-00 • SILOX_EN
Product descrIPtIon
AIC’s SILOX water heaters are twin-wall cylinders
that are designed for the production and storage of
Domestic Hot Water. They consist of a steel outer
tank (primary) and a built-in stainless steel DHW
tank. At each draw-o of DHW and heating cycle,
the inner tank expands and contracts, which pre-
vents the adhesion and build-up of sediments.
heatingsystems
siloX
1. Inspection hatch / hand hole
2. Thermal insulation
3. Drywell for temperature sensor
4. DHW (inner) storage tank in stainless steel
5. Steel primary (outer) tank
6. Primary connection
7. Base cover
8. Connection for optional heating element installation
9. Dip tube
10. External jacket
11. Control panel with thermometer
12. Top cover
13. DHW connections
SILOX Cylinders The cylinders are installed vertically on the oor and
can be connected to various heating sources : boil-
er, heat pump, solar panels, etc.
They can also be equipped with an optional elec-
tric heating element, whose power varies accord-
ing to the model. Larger models equipped with an
optional heating element can operate on Tri-phase
electrical power. Please contact your AIC repre-
sentative to know which immersion heaters are
available for your appliance.
Fig. 1. Product Description
1
2
3
4
5
6
7
8
9
10
11
12
13

7
I10_087-00 • SILOX_EN
Product descrIPtIon
1. On/o indicator light
2. “Winter” indicator light (DHW produced using ex-
ternal heating generator, e.g. a gas boiler)
3. “Summer” indicator light (DHW produced using
opt. electric heating element)
4. Summer-Winter switch - to turn on/o the optional
heating element
Control Panel
siloX
heatingsystems
siloX
heatingsystems
5. Control and safety thermostat (set at 90°C)
6. Relay
7. Thermometer
8. Removable protective cover
Optional Accessories
Immersed Electric Heating Element
Your SILOX DHW cylinder can be equipped with
an optional 3, 6, 9 or 12
kW immersion heater (im-
mersed length of 400 mm).
Please contact your AIC
representative for more in-
formation.
The control panel contains the required items to
control the operation of the optional heating element
Fig. 2. Control Panel Description
when it is installed, provided that the electrical in-
stallation is carried out according to the wiring dia-
grams. Refer to “Wiring Diagram” on page 15.
DHW Hydraulic Kit
The DHW circuit needs to be equipped with a hy-
draulic kit that is provided as an accessory. Please
refer to “Hydraulic Kit Characteristics” on page
14 for the characteristics and contact your AIC
representative for more information.
1
2
3
4
5
6
7
8

Air Vent
Air Vent
A
Recirculation / T&P relief
valve installation location
B
C
H
G
I
DE
F
SX140 to SX600
SX1000
8I10_087-00 • SILOX_EN
technIcal sPecIfIcatIons
Dimensions
Dimensions (mm) SX140 SX180 SX215 SX260 SX400 SX600 SX1000
A 560 560 560 560 620 770 950
B1,030 1,280 1,530 1,770 1,725 1,730 2,250
C 835 1,085 1,335 1,575 1,510 1,490 1,925
D 215 215 215 215 180 190 335
E215 215 215 215 180 190 335
F—650 775 895 845 825 —
Connections (Ø - in.) SX140 SX180 SX215 SX260 SX400 SX600 SX1000
Cold water inlet ( ) [M] 3/4 3/4 3/4 1 1 1 11/4
DHW outlet ( ) [M] 3/4 3/4 3/4 1 1 1 11/4
DHW recirculation [M] 3/4 3/4 3/4 1 1 1 —
Air vent connection [F] 1/8 1/8 1/8 1/8 1/8 1/8 1/2
Primary circuit supply ( ) [F] 1 1 1 1 11/2 11/2 11/2
Primary circuit return ( ) [F] 1 1 1 1 11/2 11/2 11/2
G - optional immersion heater connection 2 2 2 2 2 2 2
H - Outer tank side connection 1 1 1 1 11/2 11/2 11/2
I - Outer tank side connection —1 1 1 11/2 11/2 —

9
I10_087-00 • SILOX_EN
technIcal sPecIfIcatIons
Product Data SX140 SX180 SX215 SX260 SX400 SX600 SX1000
Total water capacity l138 176 214 252 355 574 955
DHW capacity l92 127 161 195 265 433 712
Outer (primary) tank capacity l46 49 53 57 90 141 243
Heat transfer area m20.9 1.2 1.6 1.9 2.2 2.8 4.2
Max. DHW temperature °C 90
Max. primary temperature °C 110
Operating primary temp. °C 85
T&P valve temperature setting °C 90 - 95
Max. operating DHW pressure bar 8
Max. operating primary pressure bar 3
T&P relief valve pressure setting bar 7
Approx. empty weight Kg 50 60 70 80 90 133 239
Standing heat loss W49 53 56 61 99 103 113
Energy eciency class B B B B C C C
Hydraulic Performance* SX140 SX180 SX215 SX260 SX400 SX600 SX1000**
Peak Flow 45°C L/10’ 184 284 436 472 515 809 1,285
Peak Flow 60°C L/10’ 128 200 263 268 361 566 900
Peak Flow 45°C L/60’ 872 1,019 1,513 1,719 2,009 2,609 3,780
Peak Flow 60°C L/60’ 536 630 907 1,012 1,229 1,635 2,645
Continuous Flow 45°C L/h 826 882 1,293 1,508 1,793 2,161 3,490
Continuous Flow 60°C L/h 489 517 773 881 1,041 1,283 2,070
Heating time (10°C to 60°C) Min. 19 25 22 22 29 32 55
Recovery time (with
heating element)
3 kW Min. 161 205 250 294 414 670 1,114
6 kW Min. 81 103 125 147 207 335 557
9 kW Min. 54 68 83 98 138 223 371
12 kW Min. 40 51 62 74 104 167 279
Primary ow rate m3/h 2.6 3.5 4.2 5.5 6.4 7.2 8.3
* Primary ow water at 85°C - cold water from mains at 10°C
** SX1000 - Primary ow water at 90°C - cold water from mains at 10°C

10 I10_087-00 • SILOX_EN
Technical SpecificaTionS
Recommendations for the Quality of Water
To prevent the formation of scale and sludge in a
closed heating circuit through the penetration of
oxygen and carbonates, follow the recommenda-
tions below:
îBefore  lling the system, clean it according to
standard EN14336. Chemical cleaning agents
can be used.
îIf the circuit is in bad condition, or the cleaning
operation was not e cient, or there is a large
volume of water in the system (e.g. cascade),
it is recommended to separate the appliance
from the heating circuit using a plate heat ex-
changer or an equivalent accessory. In that
case, it is recommended to install a hydrocy-
clone or magnetic  lter on the system side.
îLimit the  ll operations. To control the quantity
of water added into the system, install a water
meter on the  lling line of the primary circuit.
No more than 5% of the total content of the
system is allowed annually.
îAutomatic  lling systems are not recom-
mended unless the  ll frequency is checked
and the levels of scale and corrosion inhibitor
are maintained at an appropriate level.
îIf the system needs to be re lled frequently,
check for leaks in the primary circuit.
îInhibitors may be used according to stand-
ard EN 14868.
îAn air separator (on the appliance supply
circuit) combined with a dirt separator (up-
stream of the appliance) must be installed
according to the manufacturer’s instructions.
îAdditives can be used to keep the oxygen in
solution in the water.
îUse the additives in accordance with the in-
structions of the manufacturer of the water
treatment product.
Water Hardness
îIf the hardness of the  ll water is higher than
20° fH (11,2° dH), soften it. At commission-
ing, the water should be soft.
îCheck regularly the water hardness and en-
ter the values in the maintenance log sheet
(provided at the end of the manual).
Water Parameters
îIn addition to the oxygen and the water hard-
ness, other parameters of the water must be
checked. Treat the water if the measured val-
ues are outside the range of the table below.
îAIC recommends to have the DHW circuit
operating at more than 60°C to prevent the
development of bacteria in the DHW circuit.
Water Parameters Range
Acidity 8.2 < pH < 9.0
Conductivity < 400 μS/cm (at 25°C)
Chlorides < 125 mg/l
Iron < 0,5 mg/l
Copper < 0,1 mg/l
Water hardness °fH °dH mmolCa(HCO3)2 / l
Very soft 0 - 7 0 - 3.9 0 - 0.7
Soft 7 - 15 3.9 - 8.4 0.7 - 1.5
Fairly hard 15 - 25 8.4 - 14 1.5 - 2.5
Hard 25 - 42 14 - 23.5 2.5 - 4.2
Very hard > 42 > 23.5 > 4.2
