Aim RF240/611 User manual

RC240 3D Mouse Presenter V1.2
1
Motion Sensor Presenter
RF240/611

RC240 3D Mouse Presenter V1.2
2
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.

RC240 3D Mouse Presenter V1.2
3
Table of Contents
PACKAGE CONTENTS.................................................................................4
SYSTEM REQUIREMENTS.............................................................................4
RECHARGING THE PRESENTER .....................................................................4
KEY DEFINITIONS ......................................................................................5
USE PRESENTER WITHOUT RUNNING AIMMASTER™ PRO SOFTWARE ......................5
INSTALL AIMMASTER™ PRO .........................................................................5
START USING PRESENTER...........................................................................6
POWER ON THE PRESENTER ..........................................................................6
POWER OFF THE PRESENTER .........................................................................6
USE MICRO SD CARD .................................................................................6
BASIC MODE ...........................................................................................6
Language .........................................................................................6
Exit .................................................................................................6
Basic Mode Key Definitions ....................................................................7
Virtual Laser Pointer .............................................................................7
Enable/Disable 3D Mouse ......................................................................7
Open/Close Slide Show .........................................................................8
Page Up/Down and Scrolling ..................................................................8
Group Vibrating...................................................................................8
Change 3D Mouse Speed ......................................................................8
Volume Adjust ....................................................................................8
STANDARD MODE ......................................................................................9
Standard Mode Key Definitions ................................................................9
Place Check Mark.............................................................................. 10
Draw Line Mark ................................................................................. 10
Undo or Remove all Marks. .................................................................. 10
Timer Setting ................................................................................... 10
Show Timer ..................................................................................... 11
Plug & Present.................................................................................. 11
Change Laser Icon............................................................................. 12
Group Vibrating................................................................................. 12
LINK PRESENTER WITH RECEIVER .................................................................... 13
ADVANCE MODE ..................................................................................... 13
Change Hotkey Map ........................................................................... 13
Use the Motion keys ........................................................................... 15
CHECK RELEASE NUMBERS.......................................................................... 16
FEATURES ............................................................................................ 17
PRODUCT SPECIFICATIONS ....................................................................... 17
Q & A .................................................................................................. 18

RC240 3D Mouse Presenter V1.2
4
Package Contents
 Presenter
 Receiver

aimMaster™ Pro Software CD (for Microsoft® Windows®
7/Vista/XP), Quick Instruction Guide, and User's Manual
(stored in the Receiver flash memory)
 USB Recharge Cable
 Leather Bag
 Quick Instruction Guide Sheet
System Requirements
 Microsoft® Windows® 7/Vista/XP
 1GB RAM recommended
 CD-ROM drive or DVD-ROM Drive
 USB Port
Recharging the Presenter
Fully charge the Presenter by connecting the miniUSB connector of the
USB cable to the Presenter miniUSB Port. Connect the Presenter with the
computer by the USB cable. The orange light of the LASER key is
flashing. Wait for about 2.5 hours until the light of LASER key changes
to blue; the Presenter is fully charged and ready for use. Click any key will
flash the blue light on the LASER key. The battery can last more than
20 hours for continuous usage. When the battery capacity is low, click any
key will flash the orange light on the LASER key.

RC240 3D Mouse Presenter V1.2
5
Key Definitions
Use Presenter without running aimMaster™ Pro software
Before installing the powerful Presenter Auxiliary Tools – aimMaster™ Pro ,
you can use the functions include 3D Air Mouse, Page Up/Down, Group
Vibration alarm, Volume Adjust, etc. However, the Virtual Laser Pointer
can’t work.
Install aimMaster™ Pro
Insert the CD to your computer. The following windows will pop up.
Follow the instructions to install aimMaster™ Pro .
Double Click the shortcut icon of aimMaster™ Pro
shown on your desktop to activate aimMaster™ Pro .
The message window will pop up three seconds to
remind you that the aimMaster™ Pro is activated.
You will see the aimMaster™ Pro icon on the
System Tray.

RC240 3D Mouse Presenter V1.2
6
Start Using Presenter
The default mode entered is Basic mode that comes with the basic
functions. There are two more operation modes could be used:
Standard Mode: allows you to use Check/Line Marks and other functions.
Advanced mode: allows you to use motions keys for more commends.
Power ON the Presenter
Click the POWER key once to turn on the Presenter. The purple light
on the LASER key flashes once to confirm the ON status.
Power OFF the Presenter
Press and hold the POWER key for 3 seconds until the purple light on
the LASER key is lit. Release the POWER key. The purple light on
the LASER key flashes several times to confirm the OFF status. If the
Presenter is not working for 30 minutes, the Presenter will be turned off
automatically to save the battery power.
Use micro SD Card
Insert a micro SD card into the slot of the Receiver of RC132/611. You
may store the files into this memory.
Basic Mode
Please don’t forget to execute aimMaster™ Pro
(then the icon is shown on the System Tray),
otherwise the Virtual Laser Pointer isn’t
operable.
Language
Right click the
aimMaster™ Pro icon ,
and click “Language” tab from pop-up
menu. You will see a dialogue window.
Select the language you prefer.
Exit
aimMaster™ Pro does not use many
system resources. You may quit this background application to release the
memory when you don’t need it. Right click the icon and click “Exit” from
pop-up menu to close aimMaster™ Pro .

RC240 3D Mouse Presenter V1.2
7
Basic Mode Key Definitions
Key Action Function
If Presenter is Off, this click turns power to On.
Click If Presenter is On, this click forces Slide Show
(shift F5) or Close Slide Show (ESC)
POWER Press & hold until
Purple LED is On
Turns Presenter to Off.
Click
Enables or Disables 3D Mouse.
If 3D Mouse is enabled, the blue light of
LASER key is flashing.
LASER
Press & Hold Show the Virtual Laser Pointer Icon, (Laser Pointer
icon is changeable, refer to P10)
Click Page up
UP Press & Hold Scroll up
Click Page down
DOWN Press & Hold Scroll down
OK Press & Hold
Turn Presenter clockwise to increase the system
Volume, and turn Presenter counter-clockwise to
reduce the system volume
LEFT Click Mouse Left key, only when 3D Mouse is enabled
RIGHT Click Mouse Right key, only when 3D Mouse is enabled
FEATURE
No function
Flashes Amber: Presenter is Charging
Charging Off: Presenter is fully charged
Flashes Blue: when battery is between 100% ~
40% of full capacity.
LED on
LASER
key Click any key Flashes Amber: when battery is under 40% of full
capacity.
Virtual Laser Pointer
Press and hold LASER key to
activate the emulated Laser
Pointer. Move Presenter will move
the Laser pointer on the screen.
Please refer to the User’s Manual
to select your own virtual laser
pointer icon.
Enable/Disable 3D Mouse
Click LASER key once to enable the 3D Mouse. The blue light on the
LASER key is flashing. The RIGHT and LEFT keys are Mouse Right
and Left button respectively.
Click LASER key once again to disable the 3D Mouse. The blue light

RC240 3D Mouse Presenter V1.2
8
on the LASER key is turned off. The RIGHT and LEFT keys are NOT
Mouse Right and Left now.
When 3D Mouse is not moving for 30 seconds, the Presenter turns off the
3D Mouse automatically to save the battery power.
Open/Close Slide Show
Clicking POWER key once will open PowerPoint
file to Slide Show or close the Slide Show.
Page Up/Down and Scrolling
Clicking the UP key will initiate a page up operation
while clicking DOWN will initiate a page down.
Press and hold UP or DOWN key, it will execute the
scrolling up or scrolling down feature respectively.
Group Vibrating
If the meeting host wants to
pass some predefined
message (e.g., time end) to
the orator, he may use
another set of Presenter to
send signal to the orator.
The host just presses and
holds the FEATURE key
for more than 2 seconds
until it starts to vibrate, the
Presenter on the orator’s hand will also vibrate for 5 seconds. (Note: the
2nd Presenter should be linked with Receiver in advance. Refer to P13 for
the linking information.)
Change 3D Mouse Speed
Right click the
aimMaster
TM
Pro icon on the
System Tray. Select the Mouse Speed tab.
Then choose one of the 3 speeds.
Volume Adjust
Press and hold OK key, rotating
Presenter clockwise will enlarge
the volume. Rotating
counter-clockwise will decrease
the volume. The volume meter will
be shown on the right up corner of
the screen.

RC240 3D Mouse Presenter V1.2
9
Standard Mode
Standard Mode has all the functions
in Basic Mode plus many other useful
features.
Right click the aimMaster™ Pro icon
and select Mode from the
pop-up menu. Choose “Standard
Mode”. The icon in System Tray
becomes .
Standard Mode Key Definitions
Refer to the following key definitions for the functions you may use.
Key Action Function
If Presenter is Off, this click turns power to On
Click If Presenter is On, this click forces Slide Show
(shift F5) or Close Slide Show (ESC)
POWER Press & hold until
Purple LED is On
Turns Presenter to Off.
Click
Enables or Disables 3D Mouse.
If 3D Mouse is enabled, the blue light of
LASER key is flashing.
LASER
Press & Hold Show the Virtual Laser Pointer, (Laser Pointer
icon is changeable, refer to P10)
Click
Each click will cycle from Mouse Cursor Check
Mark Line Mark. The cursor changes from
  respectively. The icon on the
System tray will be changed as   .
FEATURE
Press & Hold for 2
seconds
All Presenters vibrate for 5 seconds (the host can
inform time-end to the orator).
In Mouse Cursor operation Page up
Click In Check Mark or Line Mark
operation
Undo previous
mark
UP
Press & Hold Scroll up
In Mouse Cursor operation Page down
Click In Check Mark or Line Mark
operation
Clear all marks
DOWN
Press & Hold Scroll down
Click
In Check Mark operation, a Check Mark is
placed.
OK
Press & Hold
In Line Mark operation, a red line is drawn,
the longer time you press, the longer red line
extends to the right.

RC240 3D Mouse Presenter V1.2
10
Turn Presenter clockwise to increase the system
Volume, and turn Presenter counter-clockwise to
reduce the system volume
Mouse Left key, only when 3D Mouse is enabled.
LEFT Click When 3D Mouse is disabled, the Timer will be
shown on the right corner of the screen.
RIGHT Click Mouse Right key, only when 3D Mouse is
enabled.
Flashes Amber: Presenter is charging
Charging Off: Presenter is Fully charged
Flashes Blue: when battery is between
100%~40% of full capacity.
LED on
LASER
key Click any key Flashes Amber: when battery is under 40% of full
capacity.
Place Check Mark
You can place red Check Marks
and draw Line Marks on the
screen to emphasis the
important parts.
Click LASER key once to
activate 3D Mouse. Click
FEATURE key once to enable
the Check Mark. Move Presenter
to control the position of the
Check Symbol cursor. Each
click of OK key will place a
Check Mark on the screen.
Draw Line Mark
Click FEATUER key again to enable the
Line Mark. Press and hold OK key to
draw the red line. The longer time you
press, the longer red line extends to the
right.
Undo or Remove all Marks.
Press UP key to undo the previous
mark or DOWN key to clear all the
marks.
Timer Setting
Right click the aimMaster
TM
Pro icon on
