Intro uction
Presenter RC201 is more than a presenter. Its mouse function makes it a
handy tool to enhance your experiences and enjoyments during
presentations.
Bluetooth
®
®®
®
wireless technology makes RC201 to transmit up to 30 feet
(10 meters).
With its omni-directional transmission, you can confidently conduct the
business meeting, hold the conference, and instruct the teaching lesson.
Presentation hotkey can open the prepared PowerPoint files. Laser point
helps to catch audiences’ attention.
Features
1.Innovative design of omni-directional Presenter let you
conduct a perfect presentation
2.Presentation hotkey allows you to start the prepared
PowerPoint files conveniently
3.Laser point helps you to catch audiences’ attention
4.Work with a value software, aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT
5.Slim type design, you may store it in your notebook’ s
PCMCIA slot easily
Package Contents System Requirements
Presenter RC201
Value Software
aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT
CD-ROM
Coin Type Lithium
battery CR2032 x 1
USB type Bluetooth
Dongle (Optional
device)
Built in Bluetooth
®
®®
®
wireless
technology (PC) or external Dongle
with Bluetooth
®
®®
®
wireless technology
 Bluetooth
®
®®
®
profile need to support
HID minimum
Microsoft® Windows® 2000 SP4, XP
SP2, Vista
64MB RAM recommended
CD-ROM drive or DVD-ROM drive

Bluetooth Presenter RC201
4
Key Definition

Bluetooth Presenter RC201
5
Installation an Operation
When Presenter RC201 isn
When Presenter RC201 isnWhen Presenter RC201 isn
When Presenter RC201 isn’
’’
’ t in use, please take off the
t in use, please take off the t in use, please take off the
t in use, please take off the
battery to save power.
battery to save power.battery to save power.
battery to save power.
1.
1.1.
1. Installation of battery
Open the back cover of Presenter and insert a Coin Type
CR2032
CR2032CR2032
CR2032 Lithium battery with the diagram inside the battery
chamber.
2. Power on the function of Bluetooth
®
wireless technology
Turn on the function of Bluetooth
®
®®
®
wireless technology if
your NB builds in a receiver with Bluetooth
®
®®
®
wireless
technology, or insert a Bluetooth
®
® ®
®
dongle and turn on the
Bluetooth
®
®®
®
wireless technology function.
3. Install aimMaster BT
Insert the CD to your computer. The following window will
pop up. You can also run the installation by click setup.exe.
Note: You also can download the latest application
software from http://www.aimpro21.com/ > Support >
Download Center

Bluetooth Presenter RC201
6
Click “ Next”
Click “ Next”

Bluetooth Presenter RC201
7
Click “ Install”
Choose “ Yes, I want to launch aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT now”
and click “ Finish” to start using aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT .

Bluetooth Presenter RC201
8
A
imMxxxxx
If you didn’ t select “ Yes, I
want to launch aimMaster
aimMaster aimMaster
aimMaster
BT
BTBT
BT
now” , double click the
shortcut icon of aimMaster
aimMaster aimMaster
aimMaster
BT
BTBT
BT
shown on your desktop
to activate aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT .
The message window will
pop up for 3 seconds to
remind you that the
aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT is activated.
You will see the aimMaster
aimMaster aimMaster
aimMaster
BT
BTBT
BT
icon ( Bluetooth®
connection is unbinding) or
( Bluetooth® connection
is binding) on the system tray. The system tray icon will
be disappeared when the receiver is removed.

Bluetooth Presenter RC201
9
4. Use aimMaster BT application to auto-pair with Presenter
RC201
1) Press and hold button on the presenter for 3-5
seconds.
The presenter will enter the pairing mode for 1 minute
and the blue LED indicator flashes 1 time per 1-2
seconds till the pairing is complete.
Please make sure the presenter is in pairing mode
before going to the next step.
2) Start the Bluetooth
®
service of your Desktop or Laptop
first.
3) Right click the “ aimMaster BT ” icon on the
system tray, and select the “ Auto Pair” item to do
Bluetooth
®
auto-pair. (“ Widcomm” is a kind of
Bluetooth
®
driver. “ aimMaster BT” will detect what kind
of Bluetooth
®
driver your platform uses automatically)
After pairing, the icon on system tray will change to
.
4) Use Presenter
You may start to use the Mouse and LASER, LEFT, RIGHT,
PAGE UP, PAGE DOWN buttons for presentation.

Bluetooth Presenter RC201
10
5. Set file hotlink
1) Double click the “ aimMaster BT ” icon on the
system tray, and the main window of “ aimMaster BT ”
will pop up.
2) Click the button “ Browse” (or “ Clear” ) on the
window to set (or clear) the hotlink of the file. (up to 3
files)
3) When the file hotlink(s) is set, pressing on
Presenter will open the linked file(s) for presentation.
6. Use mark function
In a presentation, you can use the mark pen to highlight
some important articles or blank the screen to catch the
audiences’ attention.
aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT supports two mark pens, Check Pen and Line
Pen. It also provides a blank function. You can blank the
screen so that the audiences will focus on your speech.
When you enter mark function
mark function mark function
mark function , you can click the RIGHT
button to choose one of the 4 modes, Check Pen, Line Pen,
Mouse and Blank.

Bluetooth Presenter RC201
11
Check Pen Mode
Check Pen ModeCheck Pen Mode
Check Pen Mode
Press and hold the RIGHT button for
2 seconds to enable mark function
mark functionmark function
mark function. The
first mode entered is Check Pen Mode. A
check symbol will replace the cursor
symbol and the aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT icon on the
system tray will be changed from to .
In the Check Pen Mode, each LEFT
click will leave a red check mark below
the cursor position.
Please refer to the following table for the
different modes.
Mark Pen Mode
Cursor
Mark System Tray
Check Pen
Line Pen
Mouse n.a.
Blank n.a. n.a. n.a.
Note: When you turn on your computer, please remember to
run aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT , otherwise when you press and hold
RIGHT button for 2 seconds, you can NOT
NOTNOT
NOT enter the Check
Mark Mode.

Bluetooth Presenter RC201
12
Line Pen Mode
Line Pen ModeLine Pen Mode
Line Pen Mode
Click the RIGHT button once;
aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT will go from the
Check Pen Mode into the Line
Pen Mode. The cursor symbol
becomes and the aimMaster
aimMaster aimMaster
aimMaster
BT
BTBT
BT
icon on the system tray is
changed from into .
In the Line Pen Mode, press and
hold the LEFT button will
draw a red line from right end of
the cursor location and this
red line extends towards the
right direction. The longer you
hold the LEFT button , the
longer the red line is.
Mouse Mode
Mouse ModeMouse Mode
Mouse Mode
Click the RIGHT button
again to go from the Check
Mode into the Mouse Mode. In
this mode, the cursor becomes
an arrow . The aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT
icon will change to on the
system tray. It has the normal mouse functions. You can
move the Mouse STICK and LEFT/RIGHT click your
hyper-link file that is inserted in your Presentation file.
In the Mouse Mode, click the RIGHT button to go back
to the Check Pen Mode. In this way, the 3 modes, Check
Pen, Line Pen, and Mouse, are cycled by the RIGHT button
clicks.

Bluetooth Presenter RC201
13
Undo
UndoUndo
Undo the Marks
the Marks the Marks
the Marks
To undo the Check/Line Marks you have done on the screen,
click PAGE UP button once will clear the latest Check/Line
Mark. The further PAGE UP clicks will undo the marks until
all the Check/Line marks are cleared.
Clear
ClearClear
Clear all
all all
all Marks
MarksMarks
Marks
To clear all Check/Line Marks, you may either click PAGE
DOWN button once, or, press the ESC key of your keyboard.
the mark function is then disabled .
When you want to use mark pen again, press and hold
RIGHT button for 2 seconds to enable the ma
mama
mark
rk rk
rk
function
functionfunction
function
and enter the Mark Pen Mode as we described
previously.
Blank
Blank Blank
Blank the Screen
the Screenthe Screen
the Screen
When the mark function
mark function mark function
mark function is enabled, press and hold the
RIGHT button for 1 second, the screen becomes blank.
To get back the original screen, click PAGE DOWN button
once. aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT will go back to one of the 3 modes,
Check Mark, Line Mark, and Mouse.
Quit from
Quit from Quit from
Quit from aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT
If your receiver is unplugged
from the computer, the icon
on the system tray will be
hidden, but aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT is
still running. Please move
the cursor above the
aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT icon on the
system tray, click the RIGHT
button and then, LEFT click “ quit” to exit from
aimMaster BT
aimMaster BTaimMaster BT
aimMaster BT .

Bluetooth Presenter RC201
14
Note
NoteNote
Note：
：：
：
1. Low battery
When the battery of Presenter reduced to lower voltage, the
icon on the system tray will change to . The battery
voltage also can be checked from the main window of
aimMaster BT.
2. Mouse function using guide
The mouse function operation is different from a “ touch
pad” . You may see it as an “ 8-directional buttons” on
the mouse pad. With them, you can move the cursor easily.
similar to a mouse Left-Key.
similar to a mouse Right-Key.
The 8-directional buttons on mouse pad are
shown on the left figure.

Bluetooth Presenter RC201
15
Specifications
Item Description
Standard
Bluetooth
®
®®
®
wireless technology
specification version 2.0
compatible
Frequency
Band
2.4GHz~2.4835GHz unlicensed
ISM Band
Output Power 0.25mW ~ 2.5mW (Bluetooth
Power Class II)
Range >10 meters (free space)
Battery CR 2032
Operating
voltage
3.2V ~ 2.8V
Dimension 86 x 53.8 x 4.9 mm
Weight < 25g (including battery)
Certification
Approval
CE , FCC , BQB
Bluetooth
BluetoothBluetooth
Bluetooth
®
®®
®
Timing:
Timing: Timing:
Timing:
Press connection button 3 sec to go into pairing mode
From pairing mode to sleep mode: 1 min
From active mode to idle mode: 0.5 sec
From idle mode to sleep mode: 10 mins
Pairing mode: LED flashes in first 3 secs

Active mode: LED flashes 1 time (per sec for mouse pad) while
pressing the button
Idle mode: LED flashes 1 time per 10 secs
 Sleeping mode: LED stops flashing

Bluetooth Presenter RC201
16
Troubleshooting
You can’ t use the mark pen when you press and hold
You can’ t use the mark pen when you press and hold You can’ t use the mark pen when you press and hold
You can’ t use the mark pen when you press and hold the
the the
the
RIGHT button for more than 2 seconds
RIGHT button for more than 2 secondsRIGHT button for more than 2 seconds
RIGHT button for more than 2 seconds
You need to run aimMaster
aimMaster aimMaster
aimMaster BT
BTBT
BT exe file before you can enable
the mark function. Then you can press and hold the RIGHT
button for more than 2 seconds to start using mark pen.
Note:
Note:Note:
Note:
If you plan to use a computer that does not belong to you, you
need to store the aimMaster
aimMaster aimMaster
aimMaster BT
BTBT
BT exe file into a USB flash drive.
Plug it into the computer to be uses for the presentation, and
double click this exe file before the presentation.
C
CC
Computer
omputer omputer
omputer does
doesdoes
does no
no no
not
tt
t respon
respon respon
respond to clicks on the pre
d to clicks on the pred to clicks on the pre
d to clicks on the presenter
sentersenter
senter
T
TT
The presenter red indicator does not flash when you click the
he presenter red indicator does not flash when you click the he presenter red indicator does not flash when you click the
he presenter red indicator does not flash when you click the
presenter
presenter presenter
presenter buttons
buttonsbuttons
buttons
The pairing is lost
The pairing is lostThe pairing is lost
The pairing is lost
Please refer to section “ Installation and Operation” and
do the Bluetooth
®
pairing again on page 9.
The presenter ba
The presenter baThe presenter ba
The presenter batteries run out of electricity.
tteries run out of electricity.tteries run out of electricity.
tteries run out of electricity.
Please change a new Lithium battery CR2032.
The laser pointer is still working
The laser pointer is still workingThe laser pointer is still working
The laser pointer is still working
The battery voltage might be too low although the laser
pointer is still working. Please change another new battery
CR2032.

Bluetooth Presenter RC201
17
Y
YY
Your cursor is mo
our cursor is moour cursor is mo
our cursor is moving too fast or
ving too fast orving too fast or
ving too fast or too
too too
too slow when you use the
slow when you use the slow when you use the
slow when you use the
Mouse of the presenter
Mouse of the presenterMouse of the presenter
Mouse of the presenter
Please go to the control panel of your PC system to adjust the
mouse speed.
You changed a new
You changed a new You changed a new
You changed a new Bluetooth
BluetoothBluetooth
Bluetooth
®
®®
®
dongle
dongledongle
dongle
You need to re-pair the presenter and the dongle. Please
follow the instruction of pairing on Page 9.
You
You You
You can
cancan
can’
’’
’ t remove the
t remove thet remove the
t remove the Bluetooth
BluetoothBluetooth
Bluetooth
®
®®
®
pairing
pairingpairing
pairing
If you use IVT Bluetooth
®
driver, you can use Presenter normally
after the Bluetooth
®
pairing is established, but it can’ t be
removed.

Bluetooth Presenter RC201
18
Appen ix – Install Bluetooth Dongle
Bluetooth dongle is an optional device if your PC doesn’ t
build in Bluetooth. It is easy for you to install it. If the dongle
has its own driver, please install it first. Then plug the dongle
into the USB port of your computer. If the dongle has no extra
driver, it will be detected by the operating system automatically,
and use the Microsoft standard driver.
Before you use it, please make sure your computer follow the
system requirements as bellow:
1. Make sure the system is at least Windows XP Service pack
2 or above.
2. After installing the dongle and software, please restart the
computer to ensure all the functions work correctly.
