Aim AIVE Installation guide

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 1
AIM company l www.aim-fa.com
Basic manual
28th.OCT.2021 . Rev2.0

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 2
1. Introduction
1-1) Copyright and History
1-2) Introduction
1-3) Safety
1-4) Introducing and using AIVE
2. AIVE appearance and installation
2-1) Dimension of AIVE
2-2) Part names and Specifications
2-3) AIVE installation mechanism
2-4) AIVE installation power supply
2-5) Interface panel
3.Control of AIVE
3-1) Principle of operation
3-2) Status LED
3-3) AIVE PC program
3-4) Manual control
3-5) Digital IO
3-6) Ethernet control
3-7) IP change
Contents

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 3
Chepter1
1. Introduction
AIM company l www.aim-fa.com
1-1) Copyright and History
1-2) Introduction
1-3) Safety
1-4) Introducing and using AIVE

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 4
All information contained in this document is the property of AIM Co., Ltd., and all
or part of that information may not be reproduced without the prior written consent
of AIM Co., Ltd. This information is subject to change without notice. This document
is reviewed and revised regularly.
AIM is not responsible for any errors or omissions in this document. Requests for
corrections to user errors are always welcome. AIM Co., Ltd. respects the opinions of
our customers and will refer to them when preparing documents in the future.
Please send a comment by email below [e-mail]
2019 AIM reserves all rights to this document. AIVE is manufactured in South Korea
and is a registered trademark of AIM Co., Ltd.
History
Ver1.0 _ Sep.2019 AIVE2.0 First edition
Ver1.1 _ Apr.2020.04 AIVE2.1 Update
Ver2.0 _ Oct.2021 Renewal
1-1) Copyright and History

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 5
Mass supply
Variety of
products
Check product
location
Vibration
Turn it over and spread
Parts
supply
Parts handling
Hopper system Flexible feeder Vision system Industrial robot
1-2) Introduction
System configuration between robot and vision system
Turn it over Spread
Wide range and Accurate vibration
Turn it over and spread the product with accurate vibration
Stroke Frequency Time
Optimized control with Data
Vibration control in units of 0.1mm and 1Hz
•Three intuitive data controls
•Convenience such as manual
operation and PC control

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 6
What to do in an emergency
Use the power off button on the side of the AIVE. Press the emergency stop button
(Yellow background/Red push button) on all robots being used together. This
button de-energizes the feeder and follows the company’s or organization’s internal
procedures in case of an emergency. In case of fire, CO2is used to extinguish the
fire.
1-3) Safety
Safety function
Motor temperature sensor
It is set at 36℃, and when it exceeds this, an alarm code is displayed and the
power to the motor is cut off.
Peak limitation:
Forced stop when the motor maximum current time setting time exceeds 4000mA, 1Sec.
Motor stuck _temperature :
If the motor does not move due to external force, forced stop when the set time is exceeded.

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 7
The AIVE® feeder is available with a square plastic box attached to the top of the
vibrator and optionally a backlight to illuminate the part.
The plastic upper of AIVE® can be selected according to the product supplied, the
material required, and the color required for the thick product.
The AIVE® feeder is a vibration feeder that can supply a variety of components using a
visionary industrial robot system. The parts come in a variety of shapes and can be
made from a variety of materials.
Contact AIM Engineering for slippery, fragile, or precision parts.
AIVE® feeders are not suitable for handling liquid products or flexible materials.
1-4) Introducing and using AIVE
Most of the AIVE® components are located inside
the body. The top of the unit has an exposed
vibrating feeder and the top of the AIVE is equipped
with a user-supplied camera.
Pictured from the side is the outside of the AIVE®
feeder. Because the vibrating platform is translucent,
the camera can discern the silhouette of the plastic
part.

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 8
Chepter2
AIVE appearance
and installation
AIM company l www.aim-fa.com
2-1) Dimension of AIVE
2-2) Part names and Specifications
2-3) AIVE installation mechanism
2-4) AIVE installation power supply
2-5) Interface panel

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 9
2-1) Dimension of AIVE
AIVE2.1

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 10
AIVE3.0

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 11
2-2) Part names and Specifications
Basket
POM white
Cover
AL6061 Black
Interface
panel
General specification
Utility
•
DC24V / 2A
Vibration control
method
•
Trable distance ±
0.1 ~ 7.5mm
•
Frequency 10 ~ 90Hz
Communication
•
Ethernet(TCP/IP)
•
USB
•
Digital In Out
Convenience
•
Manual button
•
PC program
•
USB, Ethernet
Option
•
Calibration sheet
•
Flatform disk
Manual operation
It can only be used with the
power supply.
•
Statement LED
•
2Montion control
•
Back light on/off
•
Motor on, Home, Error reset
PC
program
•
Vibration setting
•
Test mode
•
High adjustment
Specification by model
AIVE2.0 AIVE3.0
Typical parts size
•
0.5 ~ 30mm
•
5~40mm
Payload
•
Total 600g
•
Basket 400g, Parts 200g
Vibration platform
•
120 x 150mm
•
180 x 230
Weight
•
4.7Kg
•
6Kg
Pick Hight
•
213.5mm
Maximum Hight
•
243.5mm
Footprint
•
244 x 230
•
290 x 324

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 12
2-3) AIVE installation mechanism
7.5mm
Home : 218.5mm
15mm
Hopper
Max : 216mm
Hopper
Bolt hole
The part without bolt holes is in
the direction of the hopper.
4-M6 Count bore

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 13
A24VDC power supply is supplied by the user.
2-4) AIVE installation power supply
Note!
USER must supply power directly. We do not support this. Power cables and
power supplies must comply with the specifications mentioned in the following
table.
Note: Be sure to select a 24VDC power supply that meets
the specifications in the table above. Using low-power
devices can cause system problems and prevent equipment
from working properly. Use an under feeder. Refer to the
following table for recommended power supplies.
Power supply
Power Specifications
Power cable
Connector PRC05-P2F, 3M
A : DC24V, B : N0
Power 24VDC (-10% + 5%) 2A
A 3m power cable is included as standard, and the connector
specifications are as follows.

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 14
3USB interface
•Parameter setting with AIVE PC
program
4Ethernet interface
•Supports universal communication
with PC, robot, and vision
•Parameter setting with AIVE PC
program
1Power switch
2Power supply input
•DC24V, 2A
1 2 3 4
5
7
6
8
9
5Input
6Output
input
1A1
2A2
3A3
4STROBE
5SPARE
6GND
2-5) Interface panel
Output
1Fault
2Ready
3Busy
4Spare
5Spare
6GND

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 15
7Communication control method selection
•Ethernet
•USB
1 2 3 4
5
7
6
8
9
8Status IO
Display the current status
•Ethernet/Manual/Servo on
•Ready, Run, Fault
•Manual on
9Manual button
Manual operation such as Digital IO
•Servo on/Home
•Func#1, Func#2
•Fault reset
•Manual on
•Back light

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 16
Chepter3
Control of AIVE
AIM company l www.aim-fa.com
3-1) Principle of operation
3-2) Status LED
3-3) AIVE PC program
3-4) Manual control
3-5) Digital IO
3-6) Ethernet control
3-7) IP change

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 17
3-1) Principle of operation
2)Stroke
Vertical travel distance. The unit is mm. Inputs up to 7.5mm are possible.
For example, 2mm moves around Home by 2mm up and 2mm down, for a total of 4mm.
3)Frequency
How fast are the iterations? It can be used up to 90Hz.
1)Motor on / Servo on
Activate the feeder's internal motor and encoder.
A precision encoder has a resolution of 1 micrometer.
AIVE provides fast vertical reciprocation while controlling precise positioning. It provides
smooth and precise vibration by reciprocating with acceleration/deceleration at a certain
position.
4)Time / Duration
This is the period during which vibrations work.
Home
Set value
Actual operating
distance
Turn it over Spread
Wide range and Accurate vibration

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 18
Ethernet : Turns on when Ethernet is connected.
Manual : Lights when Manual mode is activated.
Servo on : Lights when the motor is on.
Ready : The motor is on, the home is running, and the encoder is ready to be activated.
Run : AIVE is in the vibrating state.
Back light : The backlight is on.
Fault : Indicates an error condition.
3-2) Status LED

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 19
3-3) AIVE PC program
AIVE program installation
The program is AIVE.msi and the installation wizard allows the user to easily
install the AIVE program.
Run AIVE
The AIVE executable file is as follows.
AIVE Pc program user interface

2021-10-28
REV2.0
Flexible parts feeder system
AIM company l www.aim-fa.com 20
1
2
3
4
6
5
Composition of the AIVE screen
1Status Messages Window
Displays the status of various AIVEs and expresses messages.
•Check operation
•Check communication and connection status
•readiness check
Preparatory measures
3
Communication connection
2Vibration setting
4
Height adjustment
5
Test mode
6
