Aiphone IS-DVF-HID-I User manual

Pg. 1
IS-DVF-HID-I
Vandal Resistant Color Video Door Station
with Built in HID iCLASS® Smart Card Reader
The IS-DVF-HID-I is an IS-series color video door station and an HID iCLASS® Card Reader, built
onto the same stainless steel faceplate. The card reader provides electronic access to a building
through a separate Access Control System, which is not supplied by Aiphone.
The IS-DVF-HID-I can connect to the IS-CCU or IS-SCU control units.
-INSTRUCTIONS-
NAMES & FUNCTIONS:
1. Camera 5. Name Placard
2. Microphone 6. Call status indicator
3. LED Light 7. Call button
4. Speaker 8. iCLASS Reader
FEATURES:
• All-in-one solution: Communication product &
card reader
• If a card is missing or malfunctioning,
audio/video communication can provide user
verication
• Standard Wiegand output to access panel
• Convenience of installing combined components
IS-DVF-HID-I
1
2
3
4
5
6
7
8
STEADYGREEN INDICATES CALL ANSWERED
PACKAGE CONTENTS:
IS-DVF-HID-I
Vandal-resistant Door Station
Security Driver
Flush backbox &
tamper-resistant screws
Blank name
placard
INSTALLATION:
• Forushmounting,cutaholeinthewallandusethe
supplied back box.
Box dimensions are: 11-3/4” H x 5-13/16” W x 1-3/4” D
• For surface mounting, use the SBX-ISDVFP surface
mount box.
This box can mount to a standard 1 gang box or to any
atsurface.

Pg. 2
IS-DVF-HID-I Instr.
0311JD
Aiphone Corporation
1700 130th AVE NE
Bellevue, WA 98005
[phone]
Fax: [phone]
WIRING DIAGRAM:
IS-DVF-HID-I
IS-CCU
IS-MV
Wiegand Wire Color
+ DC (10-16V) Red
Ground Black
Data0 Green
Data1 White
Shield Ground Drain
Green LED Orange
Red LED Brown
Beeper Yellow
Hold Blue
--- Violet
Connect the reader to the host according to the
wiring table below and the host installation guide.
IS-PU-UL
TESTING & OPERATION:
• When power is applied to the iCLASS® reader, the LED will turn RED while the beeper beeps
simultaneously3times(thelasttoneisahigherfrequency).TheLEDwillthenashonceafterthe
last tone. This indicates that the microcontroller is operating properly.
• Present an iCLASS ID card to the reader (hold card directly in front of reader). The LED
will momentarily turn green while the beeper beeps once, indicating that the card was read
successfully.
SPECIFICATIONS:
CARD READER:
Reader type: R10 (Rev. C)
Power Source: 10 ~ 16V DC
Current: 80mA (Avg); 300mA (peak)
Transmit Freq. 13.56 MHz
Terminations: Color-coded pre-wired pigtail
Wiring Distance: 500’
Operating Temp: 14° ~ 140°F / -10° ~ 60°C
Operating Humidity: 5-95% relative humidity
non-condensing
CAMERA:
Camera unit: CMOS camera
Scanning line: 525 lines
Min. illumination: 5 Lux at 1’6”
Terminations: RJ45 jack for audio/video
Screw terminals for door release
Operating Temp: 14° ~ 140°F / -10° ~ 60°C
Wiring Distance: 980’ with Cat5e/6 cable
Dimensions: 12-3/8” H x 7” W
w/SBX-ISDVFP: 12-13/16” H x 7-1/16” W x 2-13/16” D
(top), 1-13/16” D (bottom)
FCC WARNING:
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference that may cause undesired operation.
• For proper regulatory compliance, the drain wire should be disconnected at the power
supply end of the cable.
• Changesormodicationsnotexpresslyapprovedbythepartyresponsiblefor
compliance could void the user’s authority to operate the equipment.
• The Reader is intended to be powered from a limited power source output of a
previously certifed power supply
TOLL FREE TECHNICAL SUPPORT:
[phone]
E-MAIL: [email protected]
NO
COM
NC
To Strike
& Power
CAT-5e
CAT-5e
