Aiphone GT Video-intercom System Guide
Aiphone GT Video Intercom System Guide
This guide may make it easier to understand the capabilities of the Aiphone GT
video intercom system, by providing
●More detail than is presented in the Aiphone GT brochures.
●A broader overview than provided in the Aiphone GT module data-sheets.
●More accessible presentation of some of the information that is provided in
the Aiphone GT installation manuals.
This guide is brought to you by Clever Home, and is intended to supplement (and
not replace) the above Aiphone documents, to which links are provided on the last
page below.
Suitable Applications for the Aiphone GT video-intercom
Multi-tenant dwelling apartments, units, or offices, where outside visitors need to
be able to selectively call two or more dwellings from the site or building entrance.
For single residences or offices, consider using the beautiful Aiphone JK video
intercom instead.
Aiphone GT System Capacity
●1-16 entrances, each with their
own video intercom, or audio
intercom, and access control
entrance station.
●-500 tenants, each
individually callable from
entrance stations.
●0-500 access codes, with each
tenant having a unique code.
●5-6 digit access codes.
●1-4 video intercom stations
per apartment, with audio
broadcast communications
between internal stations.
●0-1 video intercom door
stations per tenant, if the GT-2C
master monitor station is used,
where each door station is located immediately outside each tenant's door.
(No more peep holes.)
●0-1 door bell buttons per tenant, located immediately outside each
tenant's door, when any GT master monitor station is used.
●0-4 Concierge stations that may individually call other Concierge stations,
individual tenants, receive manual calls from tenants, receive automatically
diverted calls from entrance station to individual tenants (after hours for
example), and receive Aiphone Security Suite alarms.

Copyright © 2011 Clever Home Pty Ltd 20 Boronia Avenue Croydon South VIC 313 ABN890882278 5 Fax [phone] Ph 9722 9210 [email protected]
www.cleverhome.com.au
Aiphone GT Video-intercom System Guide
GT Entrance Stations
Two types of entrance stations are available for the Aiphone
GT video intercom system, Integrated and Combined
Integrated Entrance Stations on a single flush-mount
stainless steel plate (i.e. the GT-DM), which includes a 170°
wide (and 100° high) angle digital PTZ video inter-intercom
camera, 10 key keypad, 3.5” colour LCD display (for a
greeting message, tenant names and numbers, and system
status), motion sensor, and voice annunciation.
Combined Entrance Stations with semi-flush mount
interchangeable steel faceplate modules, that mount within
different size and shape steel frames. The modules available
for Combined type entrance stations include the
●Camera module (GT-VA) with 170° wide (and 100°
high) angle digital PTZ .
●Audio Speech module (GT-DA) that supports voice
annunciation, and which can be used with or without
the GT-VA camera module,
●10 key module (GT-10K),
●Switch module (GT-SW) with 4 directory cards and 4
direct call buttons, and call button panels with 1, 2, 3
or 4 buttons as an alternative to the GT-10K when
there are less than 4-8 tenants, and
●Name Scrolling module (GT-NS) with VFD display for a
greeting message, tenant names and numbers, and
system status.
●Prox card reader modules that
may be used with the Combined
Type GT entrance stations
(GF-HID, GF-HID-I, GH-XP).
Aiphone GT-DM
Aiphone
GTV-DES104
Aiphone GTA-DES
Aiphone GTV-DES202

Copyright © 2011 Clever Home Pty Ltd 20 Boronia Avenue Croydon South VIC 313 ABN890882278 5 Fax [phone] Ph 9722 9210 [email protected]
www.cleverhome.com.au
Aiphone GT Video-intercom System Guide
GT Door Stations
Are GT Door Stations different to GT Entrance Stations?
Yes. While GT entrance stations are located at the entrance to a building, set of
units, or office complex, and allow a visitor to contact any one of the many tenants,
GT door stations
●Are located immediately outside the tenant's door.
●Allow a visitor standing outside a tenant's door to contact that tenant only.
●Use different video intercom modules than entrance stations.
●Can replace old-style tenant door peep holes.
●Only work with Aiphone GT-2C master monitor stations.
A GT door station may only be used outside an apartment, unit, or office, if the GT
master monitor station used by that tenant is an Aiphone GT-2C. Other GT master
monitor stations do still however support a door bell button located immediately
outside the tenant's door (as does the GT-2C as well).
There are four different door stations that may be used with the GT video
intercom system.
Video intercom camera door stations from the single residence Aiphone JK Series
may be used with the GT-2C master monitor station, when placed immediately
outside the tenant's door. Choose from the flush mount stainless steel plate JK-DVF
door station, the JK-DV surface mount zinc die-cast (left) door station, or the plastic
surface mount JK-DA. All of these JK door stations feature a 170° wide angle digital
PTZ camera, similar to that used in the GT video intercom entrance stations.
If the tenant requires an audio-only door station, then the Aiphone GT-D door
station may be used.
Aiphone JK-DVF
Door Station
Aiphone
JK-DV Door
Station
Aiphone GT-D
Audio-only
Door Station
Aiphone
JK-DA Door
Station

Copyright © 2011 Clever Home Pty Ltd 20 Boronia Avenue Croydon South VIC 313 ABN890882278 5 Fax [phone] Ph 9722 9210 [email protected]
www.cleverhome.com.au
Aiphone GT Video-intercom System Guide
Internal Tenant Stations
Master monitor stations have the capability to support up to three additional
sub-master monitor stations, or monitor stations, within the same tenant's
apartment, unit, or office.
Sub-master monitor stations must work in conjunction with a master monitor
station.
Monitor stations may be used on their own if the tenant only requires only one
station inside, or as more economical (but less capable) master and sub-master
monitor stations if the tenant requires more than one station.
There are two Aiphone GT master monitor stations, the GT-2C and the GT-1C.
The GT- C master monitor station would be most
tenant's first choice. The GT-2C features include
(blue-highlighted features are unique to this
monitor)
●Up to 4 video-intercom monitor stations
per tenant; one GT-2C plus up to three GT-
H sub-master monitor stations.
●All four monitor stations are powered by a
local power supply in the apartment. (One
24VDC 2A power supply may power 4 adjacent tenants with GT-2Cs and no
sub-master stations, or two adjacent tenants with sub-master monitors.)
●Support for a tenant door station for better security and elimination of the
old-style peep hole.
●Support for a tenant door bell button.
●Digital PTZ (Pan-Tilt-Zoom) viewing of 170°
wide angle camera views from entrance
stations or a local door station.
●Audio communication between internal
tenant stations, entrance stations, door
station, or concierge/guard stations.
●Optional GT-HS handset may be added for
private conversations.
●Video identification of visitors at door or
entrance stations.
●Recording visitor images automatically, so you may see who stopped by
upon return, or also at any time you like manually.
●Supports Aiphone Suite Security.
●Unlock doors.
●Local NTSC video output for CCTV integration.
Aiphone GT-2H
Sub-Master
Aiphone GT-2C Master

Copyright © 2011 Clever Home Pty Ltd 20 Boronia Avenue Croydon South VIC 313 ABN890882278 5 Fax [phone] Ph 9722 9210 [email protected]
www.cleverhome.com.au
Aiphone GT Video-intercom System Guide
The GT-1C master monitor station features include
●Up to video-intercom monitor stations
plus audio-intercom stations per tenant;
one GT-1C plus up to one video-intercom
monitor station, and up to two audio-
intercom monitors.
●Powered from GT-VBC and GT-BC.
●Support for a tenant door bell button.
●Digital PTZ (Pan-Tilt-Zoom) viewing of 170°
wide angle camera views from entrance
stations.
●Audio communication to entrance stations, or concierge/guard stations.
●Optional GT-HS handset may be added for private conversations.
●Video identification of visitors at entrance stations.
●Unlock doors.
The GT-1M-L monitor station may serve as a master monitor, or as a sub-master
monitor, and its features include
●Up to video-intercom monitor stations plus
audio-intercom stations per tenant; one GT-
1M-L plus up to one video-intercom monitor
station, plus up to two audio-intercom monitors.
●Powered from GT-VBC and GT-BC.
●Support for a tenant door bell button.
●Audio communication between entrance
stations, or concierge/guard stations.
●Video identification from entrance stations.
●Unlock doors.
The GT-1A hands-free and GT-1D handset audio
monitor stations may serve as master monitor, or
as sub-master monitors, and their features include
●Up to 4 audio-intercom stations per
tenant.
●Powered from GT-BC.
●Support for a tenant door bell button.
●Audio communication between
entrance stations, or concierge/guard
stations.
●Unlock doors.
Aiphone GT-1C Master
Aiphone
GT-1M-L
Monitor
Aiphone
GT-1A
Audio
Monitor
Aiphone GT-1D
Audio Monitor

Copyright © 2011 Clever Home Pty Ltd 20 Boronia Avenue Croydon South VIC 313 ABN890882278 5 Fax [phone] Ph 9722 9210 [email protected]
www.cleverhome.com.au
Aiphone GT Video-intercom System Guide
The GT-MK concierge or security guard monitor station features include
●Up to 4 concierge/guard stations per GT video
intercom system in expanded configuration, or
up to 2 stations in standard configuration.
●Powered from local 4VDC power supply.
●Support for optional local door bell button.
●Audio communication with entrance stations,
tenant stations, or other concierge/guard
stations – call and answer calls.
●Handset for conversation privacy.
●Visitor screening from entrance stations.
●Unlock doors.
●Caller ID with call-back.
●Supports and uses call tone and display to
clearly distinguish between incoming standard calls, and emergency calls
made via the GFK-PS water-proof emergency help module.
●Able to be manually programmed using the GT-MK itself, or by Windows
PC using Free Aiphone GT setup software (see below) connected via a USB
socket on the GT-MK.
Aiphone GT Setup Software
Free setup software for Windows PCs is available to make creating and modifying
tenant names, locations, and access codes for your Aiphone GT multi-tenant video
intercom system easier. This free software may be downloaded from
http //www.cleverhome.com.au/software/Aiphone-GT-video-intercom-setup-
software.zip
Your Windows PC connects to your Aiphone GT multi-tenant video intercom by
USB cable to the GT-NS-V/GT-NS Name Scrolling entrance display module, the GT-
DMV/GT-DM integrated entrance station, or the GT-MK concierge/guard station.
Alternatively, all of the above stations may be programmed manually directly at the
stations – the PC software simply provides a more productive way of managing
tenant information for your GF video intercom system.
Aiphone
GT-MK
Monitor

Copyright © 2011 Clever Home Pty Ltd 20 Boronia Avenue Croydon South VIC 313 ABN890882278 5 Fax [phone] Ph 9722 9210 [email protected]
www.cleverhome.com.au
Aiphone GT Video-intercom System Guide
GT Monitor Station Option Connectors
GT monitor stations have one or two Options connectors on their back, which have
the pin-outs and functions identified below.
Door Bell input allows a door bell button located immediately outside the tenant's
door to be connected to the tenant's master monitor station. The door bell should
have contacts that are normally open, and be non-latching (momentary action).
Emergency Alarm Input allows connection of a switch to generate a security
alarm. Switch contacts should be normally closed, and be latching.
Security/Utility inputs 1 to 3 allow connection of security sensors or switches for
Aiphone Security Suite support, or other utility functions.
Doctor Call Input allows connection to a switch to automatically allow entry of a
doctor or other emergency service. generate a security alarm. Switch contacts
should be normally closed, and be latching.
Option Contact output may be used to activate lights or an external call buzzer,
using the GT-RY relay to buffer the Option Contact output.
Video Out output provides an NTSC direct video signal for displays <3m away.
Only live video is sent to the Video Output, there is no video output when viewing
previously recorded pictures, or menu pages. CCTV integration support is
provided by via this NTSC video output, and Display Transfer output relay
contacts that may be used to activate external monitors via an optional GT-RY
external signalling relay. Both of these outputs are accessed using the 4 pin option
connector on the back of the GT-2C master stations. This connector is not provided
with the GT-2C, even though the 12 pin option connector is.

Copyright © 2011 Clever Home Pty Ltd 20 Boronia Avenue Croydon South VIC 313 ABN890882278 5 Fax [phone] Ph 9722 9210 [email protected]
www.cleverhome.com.au
Aiphone GT Video-intercom System Guide
GT Video-intercom System Configurations
There are two different system configurations, the Standard Configuration for
smaller systems, and the Expanded Configuration for larger systems. The
maximum capacities for each type of GT video intercom system configuration are
compared in the table below.
Maximum Supported Standard
Configuration
Expanded
Configuration
Entrance Stations 5 (3 per trunk)
3 if a door release button
is connected to a direct
select type entrance
station.
16 (8 per trunk)
Tenant Stations per
Sub Trunk Line
N/A 125 (25 per trunk)
Concierge/Security Guard
Stations
2 4
Tenant Stations 48 (25 per trunk)
100 if only the GT-1D and
GT-1M-L monitor stations
are used.
(50 per trunk for GT-1D)
(25 per trunk for GT-1M-L)
500
Stations per Tenant
(other than GT-2C)
4 (2 monitor stations) 4 (2 monitor stations)
4-way Video Junction
Units
6 per trunk N/A
Bus Control Units 1 1 per common trunk line
1 per sub trunk line
GT-2C Master Stations per
Tenant
1 1
Sub-master Stations 3 3
Maximum Supported Modules Table.
PolyEthylene core cable
Two core PolyEthylene (PE) cable that is unshielded, untwisted, and has a PVC
outer protective jacket, a must be used for audio and video distribution wiring for
any GT installation. The most readily obtainable PE cable is 0.9mm. There is a
table in the GT video-intercom installation manual indicating the maximum cable
distances between all GT modules – you should refer to the 0.8mm column in this
table if 0.9mm PE cable is being used in the installation.

Copyright © 2011 Clever Home Pty Ltd 20 Boronia Avenue Croydon South VIC 313 ABN890882278 5 Fax [phone] Ph 9722 9210 [email protected]
www.cleverhome.com.au
Aiphone GT Video-intercom System Guide
GT Standard Configuration
The Standard Configuration for a GT video-intercom system is illustrated below.
The configuration from the residence (or tenant) trunk lines to the tenant monitor
stations is the same for the Standard and the Expanded Configurations, and is
illustrated is a subsequent section.
The video output from the video entrance station is connected to the GT-VBC Video
Bus Control Unit, which has 6 trunk line outputs.
The audio and control output from the entrance station is connected to the GT-RC
Bus Control Unit, and then out to 6 trunk lines from a Distribution Point (that must
be provided by the installer).
The separation of the video and audio/control distribution allows an audio
intercom-only system to be implemented by omitting the video component of the
modular entrance station, the GT-VBC, and all of the video distribution cabling.
There is a table in the GT video-intercom installation manual indicating the
maximum cable distances between all GT modules, depending upon the gauge of
PE cable used. The 0.8mm column should be used from this table if 0.9mm PE
cable is being used in the installation.
While only one modular entrance station is shown above, any of the modular
entrance stations, or the integrated entrance station may be used. Also, multiple
entrance and concierge stations are supported, as indicated in the “Maximum
Supported Modules” table above.

Copyright © 2011 Clever Home Pty Ltd 20 Boronia Avenue Croydon South VIC 313 ABN890882278 5 Fax [phone] Ph 9722 9210 [email protected]
www.cleverhome.com.au
Aiphone GT Video-intercom System Guide
GT Expanded Configuration
The Expanded Configuration GT system uses the GT-VBX Expanded Video Bus
Control Unit and the GT-BCX Expanded Bus Control Unit to provide 4 additional
sub trunk lines, allowing up to 4 sets of GT-VBC and GT-BC control units (the same
units used in a Standard Configuration GT system) to be used instead of just one
set. The GT-VBX and GT-BCX must be mounted adjacent to each other, as their
interconnecting cable is only 40cm long.
Two additional GT-BC Bus Control Units are also able to be used to provide two
sets of trunk lines for entrance stations and concierge/security guard stations.
