Aiphone LE-SS User manual

- INSTRUCTIONS -
The LE-SS and LE-SSR are a vandal proof and weather resistant sub stations designed for use with the systems listed
above. They're constructed with 12 gauge stainless steel, and the LE-SSR features a red mushroom call button. The
units either flush mount into a 2-gang box, or surface mount with the SBX-2G. Each unit includes tamper proof screws
and a tool for installation.
LE-SS/LE-SSR
Vandal Resistant Sub Stations for LAF-C, LEF, LEM, AP-M, MP-S Systems
Aiphone Communication Systems
1700 130th Ave. N.E.
Bellevue, WA 98005
[phone]
FAX [phone]
TOLL FREE TECHNICAL SUPPORT: [phone]
TOLL FREE FAX LINE: [phone]
E-MAIL: [email protected]
LE-SS(R) Instr.
1103BKJS
SPECIFICATIONS:
Power Source: Supplied by master station
Speaker: 20 ohms, 2.5" diameter, water proof and puncture resistant, 2.4 oz. magnet
Call Button: SPST call button. Call tone rings at master as long as button is held down. LED will remain lit for approx.
20 seconds (LEF, LEM-3, MP-3S, AP-5/10M only). Call tone only on LEM-1DL, LEM-1, and MP-1S.
LE-SS: Limited stop button. LE-SSR: Limited stop, red mushroom button
Communication: Hands free at sub. Master is push-to-talk,release-to-listen.
Faceplate: 12 gauge stainless steel
Mounting: Flush mount into a 2-gang box. Surface mount into SBX-2G, sold separately. Tamper proof screws
included (6x32 for use with flush gang box) with T-10 TORX bit.
Terminations: Color-coded prewired pigtails
Wiring: 2 conductors in a 1-master LEF, MP-S, or AP-M system. 3 conductors in a multi-master LEF system.
Shielded cable is recommended. Use Aiphone #822202 for LEM or MP-S. Use #822202 or
#822203 for LEF. Use #832202 for AP-M systems.
Wiring Distance: See system that unit is being used with for distance specifications.
Dimensions (H x W x D): LE-SS/LE-SSR alone: 4-11/16" x 4-11/16" x 2"
With SBX-2G: 4-3/4" x 4-7/8" x 3-5/8" (Top) 2-3/8" (Bottom)
+
-
WIRING DIAGRAM:
1
2
~
10
E
+
-
Red
Blk*
Grn
Red
Blk*
Grn
LAF-C or LEF
Master LE-SS/LE-SSR
LE-SS/LE-SSR
PS-1225UL
* In single master system,
2 conductors homerun can
be used with the BLK and
GRN wires tied together
and "E" and "-" jumpered at
the master.
WIRING DIAGRAM:
1
E
~
10
E
AP-M or MP-S Master
Special
Order
Products
Modifying LE-SS/LE-SSR
to function with an
AP-M/MP-S master:
1. Cut Brown wire on CP038.
(Brown wire jumpers J8 to J10.)
2. Tie Brown wire from J8 to
Orange wire on J9.
3. Tie Brown wire from J10 to
Yellow wire on J11.
Tie Blk and Grn wires together for
all installations with the MP-S and
AP-M systems.
Red
Blk
Grn
Brn
Org
Brn
Yel
LE-SS/LE-SSR
Red
Blk
Grn
Brn
Org
Brn
Yel
LE-SS/LE-SSR
