AIR GREAN AG-D210 User manual

AG-D210 DEHUMIDIFIER
USER MANUAL
PLEASE READ THE ENTIRE MANUAL AND SAVE THESE INSTRUCTIONS
COMMERCIAL GRADE PORTABLE DEHUMIDIFIER

READ AND SAVE THESE INSTRUCTIONS
Thank you for choosing this AIRGRE A Ndehumidifier. We at
AIRGREANENTERPRISE truly appreciate your business. This
manual is intended to be asource of information on how to
operate, maintain and troubleshoot your new dehumidifier.
Please take the time to read through this manual thoroughly.
CONTENTS
SAFETY PRECAUTIONS
INTRODUCTION TO PRODUCT
DEHUMIDIFIER IDENTICATION FEATURES
OPERATION INSTRUCTION
SAFE OPERATION AND MAINTENANCE
OPERATION NOTICES
COMMON TROUBLESHOOTING
ERROR CODES
TECHNOLOGY SPECIFICATION
LIMITED WARRANTY
SAFETY PRECAUTIONS
BEFORE APPLICATION, PLEASE READ ALL THE INSTRUCTIONS.
• Before use, please confirm that the power supply is
115v60Hz.
• Be careful with movement of dehumidifier and avoid rolling
on and damaging power cord.
• Always turn off and unplug unit prior to performing routine
maintenance, or when not in use.
•Please use appropriate power supply, do not use an extension
cord.
• Install the drainpipe facing downward so condensation will
flow out the pipe.
• This unit must always be in upright position.
•If there is a power outage makes sure to un-plug this product.
Recommends that the dehumidifier operated on a dedicated
electrical circuit. In the event of a power failure, a spike in
voltage may occur when the power is reinstated. This can
damage the circuit board which is not covered under warranty.
1
2
2
3
4
4
5
5
5
6
1

DO NOT
• Do not put into water or operate near water source.
• Do not stop operation of the dehumidifier by pulling out
the power cord.
• Do not place the unit near the heat equipment or inflamma-
ble dangerous goods.
• Do not cover the louvered panes on the machine or it will
overheat.
• Do not operate in closed and narrow room.
INTRODUCTION TO PRODUCT
Dehumidifier is an electrical appliance which reduces and
maintains the level of humidity in the air. Eliminate musty
odor and to prevent the growth of mildew by extracting
water from the air, keeping your relative humidity in check.
2
1.Pick up the top foam 2.Use accessory tools
Unscrew 4 outer hexagon bolts
3.Flip the handle as follows
4.Screw on the
bolts with tools

DEHUMIDIFIER IDENTIFICATION FEATURES
OPERATION INSTRUCTION
INSTRUCTIONS OF BUTTONS:
1. ON/OFF: Each press ON/OFF, unit runs in a circulate
“on-off-on”
2. Humidity Down: When unit runs on dehumidify mode,
press Humidity Down button each time, humidity falls 1%,
press for 2 seconds, humidity falls by 5% per second.
3. Humidity Up: When unit runs on dehumidify mode, press
Humidity Up button each time, humidity raises 1%, press for
2 seconds, humidity raised by 5% per second.
4. DRAIN: This key can manually pulls all water out of trap.
“Accumulative work time” on display means how much time
unit have be operated”
3
ON/OFF DRAINHumidity Control +/-
+
DefrostDehumidify
Humidity % Total Running Time
Fan
Tank Full
Drain Hose
Filter
Water Pump
Handle
Control Panel
Power Cord Air Outlet
Handle
Wheel

INSTRUCTION OF FUNCTION MODE:
Unit makes a “BEEP” sound when powered on. Then when
switch button is in humidity mode, the indicator light of the
Dehumidifier will light up. The default setting for humidity is
60%, the machine’s dehumidifying range is 30%-90%. Use
the Humidity Up and Down buttons to adjust the humidity
setting. If you keep pressing the Humidity Down button when
the humidity setting is at 30%, the unit will go into continuous
dehumidify mode which will show as “CO” (Continuous
Operation) on the LCD display. The humidity % will flash
when setting the humidity, then display current humidity after
5 seconds.
SAFE OPERATION AND MAINTENANCE
• This machine is for indoor use only
• When there is any abnormal (burning smell), please shut off
the machine and unplug power. Fire, electric shock and
failure may be caused.
• If machine not in used for a long time, please unplug the
power cord. When cleaning the machine, stop it first and
unplug the power cord.
DO NOT
• Do not stop operation of dehumidifier by pulling out of the
power cord. Otherwise fire or electric shock accident may be
caused.
• Do not place near anything that gives off a heat source such
as; furnace or heater. This may cause a fire.
• Do not connect relay, extension cord or adaptor which this
machine. Otherwise, fire. Electric shock and overheating can
be caused.
• Do not repair, disassemble or alternate the machine without,
authorization so as to avoid fire or electric shock. This will
void your warranty.
4

OPERATION NOTICES
1. There is a 3 minute delay after machine has shut down
prior to next start up cycle.
2. When moving the machine, do not tip the machine for
over 45 degrees angle to avoid damaging the compressor.
3. The compressor gives out heat when it is operating, and
ambient temperature may rise 1-3 degrees.
4. The air inlet and outlet must be away from the wall at least
4 inches.
5. Working environment shall be closed tight to maximize
dehumidification effect.
6. Dust on the air publication filter mesh may impair its effect
or even cause failure. Please clear regularly. If there is dust in
the environment, it must be cleared once a week or once a
day. Pull down the front panel, clear the filter. Tap the filter
mesh slightly or eliminate the dust by vacuum cleaner or
place the filter in warm water and brush and then wash with
tap water and dry it. A clean filter will increase the unit’s overall
efficiency.
7. There is a door at the front of the machine. Press the top of
the door, to open it automatically. Remove the water tube;
connect one end with water outlet to the water tank, and the
other end through the water drainage port of the left side of
machine.
8. Maximum length of the tube is 20’.
COMMON TROUBLESHOOTING
5
Issue Causes Solution
Dehumidifier is
not operating.
Dehumidifier is
operating, but does
not dehumidify
Water leak
Unit is not plugged in
The machine is inclined
Water pipe is blocked
Level the machine
Remove the blocking object
Random noise
Dehumidifier is not placed solidly
Air outlet clogged
Stabilize unit
Clear the filter mesh
Power switch is not energized
Power failure
Fuse is melted
Dust accumulated in air purification filter mesh
Object blocking air inlet and outlet
The door or window is open
Clear the filter mesh
Remove the blocking object
Close the door and window
Connect the power cord
Energize the power
Check circuit breaker
Replace the fuse

6
ERROR CODES
This dehumidifier is able to automatically judge failure.
If there is any failure, there will be a failure code displayed
on the humidity display window.
TECHNOLOGY SPECIFICATION
LIMITED WARRANTY
The warranty period is one year for the general machine.
This warranty applies to repair or replacement of product
found to be defective in materials or workmanship. This
warranty does not apply to damage resulting from unusual
wear, abusive, unreasonable use or supplemental damage.
This warranty does not cover damage from unauthorized
repairs or from any use not in accordance with the instruction
manual. Defects that are the result of normal wear and tear
will not be considered manufacturing defects under this
warranty.
Failure Display Problem
E3
E4
E5
Humidity sensor failure
Water full
Defrost sensor failure
Model AG-D210
Power supply
Dehumidification capacity
Rated input power
Nominal current
Weight
Dimension (D,W, H)
Type of cooling agent
115V/60Hz
210 Pint per day
1030W
9.3A
110.2 lbs
20.5in x 21.3in x 36.6in
R410A

AIR GREAN ENTERPRISE, INC. OF CALIFORNIA
Website: www.airgrean.com
