Air Monitor FAN-E Operating and maintenance manual

FAN-E Airflow Measuring Station
INSTALLATIONPROCEDURE
WARRANTY
AirMonitorCorporation(hereinafterreferredtoas"Seller")warrantsthatatthetimeofshipment,productssold
pursuant to this contract will be free from defects in materials and workmanship, and will conform to the
specificationsfurnishedorapprovedinwritingbySeller.Nowarrantyisgiventhatdeliveredproductswillconform
to catalog sheets, data sheets, and the like, which are subject to change without notice.
Sellerwillrepairorreplace,atitsoption,anyproductslistedunderthiswarrantywhichisreturnedfreightpre-
paidtoSellerandwithintheearlieroftwo(2)yearsafterstart-uportwenty-seven(27)monthsaftershipment,
proveupontestandexaminationbySellertobedefectivewithinthetermsofthiswarranty. Thewarrantyperiod
foranyitemrepairedorreplacedshallbeforthetimeremainingonthewarrantyperiodfortheoriginalcomponents.
Purchaser shall notify Seller in writing of such defect within sixty (60) days of discovery of the defect.
This warranty does not extend to any product sold by Seller which has been the subject of misuse, neglect,
accident,damageormalfunctioncausedbyinterconnectionwithequipmentmanufacturedbyothers,improper
installationorstorage,orusedinviolationofinstructionsfurnishedbySeller,nordoesitextendtoanyproduct
which has been repaired or altered by persons not expressly approved by Seller. Nor does Seller warrant
equipmentagainstnormaldeteriorationduetoenvironment;noritemssuchasthermocouples,electrodes,and
similaritemssubjecttowearorburnoutthroughusage. Adjustmentsforitemsorequipmentnotmanufactured
bySellershallbemadetotheextentofanywarrantyofthemanufacturerorsupplierthereof.Sellershallnotbe
liableforanyspecialorconsequentialdamagesorforlossofdamagedirectlyorindirectlyarisingfromtheuse
oftheproducts. Seller'swarrantyshallbelimitedtoreplacementof defectiveequipmentand shallnotinclude
fieldremovalandinstallationexpenses.
Thewarrantysetforthaboveisinlieuofallotherwarrantieseitherexpressorimpliedandconstitutesthefullextent
ofAirMonitorCorporation'sliabilitytothecustomer,oranyotherpartyforbreachofwarranty. THEREARENO
EXPRESSWARRANTIESEXCEPTASSETFORTHHEREIN. THEREARENOIMPLIEDWARRANTIESOF
MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE, WHICH ARE PARTICULARLY
DISCLAIMED.
INSPECTION& HANDLING.
FAN-Esshould be carefully inspected for damage prior to installation. Reportdamage to your Freight Department,or
contactthe delivery carrier.
Almost any means of handling can be utilized depending on the length and weight of the station. Stations may
be handled while in any position. However, it is important not to drop or mishandle a station such that damage is
done to air straightener cell, sensing arms, signal connection fittings, or flanges.

FAN-EAirflow Measuring Station
- 2 -
ORIENTATION OF STATION. Using theAIRFLOW directional arrow on the side of the station to determine correct
orientation,installthe station with the honeycomb air straightener facing airflow.
INSTALLATION OF STATIONS. Toachievepublished performancestandards,thelocationof FAN-E inductworkmust
complywith theMinimumRequirementsfor Installationonthefollowing page.Whenever possible,theFAN-Eshould be
installed in long, unobstructed, straight runs of ductwork with 75% of the straight run upstream of the FAN-E.
CAUTION:FAN-E Stations should not be used to strengthen or support connecting ductwork, and holes
should not be drilled into the casing other than through connecting flanges.
FAN-Es are furnished in flanged and non-flanged designs.
FASTENERS. The FAN-E can be attached to adjacent ductwork by means of its 90º connection flanges, or with
a sheetmetal collar for FAN-Es without flanges. Connection flanges are not pre-drilled, allowing the installer a
choice of fastener types, sizes, and spacing consistent with similar elements in the ductwork, and standard
industry practices, to ensure an airtight installation.
SIGNAL TUBING. Signal tubing for total and static pressure takeoff connections may be 1/4" OD if the distance
from the measuring device to the transmitter is 200' or less.
CAUTION: External fittings on the FAN-E must not be rotated or twisted during installation of connection
fittings. After tubing is completed, signal lines should be leak tested prior to operation.
SPLIT STATION INSTALLATIONS. Units larger than 144" in height or width are split for shipment and require
field assembly. Assembly hardware and external signal manifolding is provided.

FAN-EAirflow Measuring Station
-3-
AIRBORNE CONTAMINANTS.The levels of air filtration and cleanliness associated with commercial HVAC
Systems, whether supply/return/exhaust/outside air, are satisfactory for operation of the FAN-E. Industrial
applications containing airborne contaminants may require periodic manual or automatic cleaning using
compressed air applied via the signal fittings, and/or physical cleaning.
MINIMUM REQUIREMENTS FOR INSTALLATION.
Note: FAN-E locations shown are NOT ideal. They indicate the minimum clearance required from air
turbulence producing sources. Wherever possible, the FAN-E should be installed where greater runs of
straight duct (or clearances) than shown exist.

Rectangular Duct: x = Circular Duct: x = Duct Diameter
2 H x W
H + W






FAN-EAirflow Measuring Station
-4-
1050 Hopper Avenue • Santa Rosa, CA 95403 • 707-544-2706 •
www.airmonitor.com
INSTALL5A,(2-16)
CUSTOMER SERVICE. AirMonitorCorporation provides in-house technical support for all our products:
Monday through Friday, 7 am to 5 pm (pst)
Phone:[phone]or 1-800-AIRFLOW
Fax:[phone]
If after contacting the Customer Service Department it is determined that equipment will require return toAir Monitor
Corporationfor further repair,a ReturnAuthorizationnumberwill be issued.
AConfirmation of ReturnAuthorization with shipping instructions will be sent via facsimile or e-mail. Equipment to be
returned to Air Monitor should be returned in its original shipping container if possible. If this is not possible, ensure
equipment is packaged sufficiently to protect it during shipment.
Caution: All damage occurring during transit is the Customer’s responsibility.
List the Return Authorization (R/A) number on the packing list and clearly mark this number on the outside of each
shipping container. Costs associated with the return of equipment to Air Monitor Corporation are the customer’s
responsibilityregardless whether the repair/return is underwarranty.
Once the Customer Service Department determines that the equipment repair is under warranty, the item will be
repaired and returned to the customer at no charge. If the equipment is not under warranty, customer will need to
approvea repair quote which willbeinvoiced along with return shippingcharges.
