AIRFORCE F179 Technical manual

MONTAGE- UND GEBRAUCHSANWEISUNG
D
INSTRUCTIONS ON MOUNTING AND USE
PRESCRIPTIONS DE MONTAGE ET MODE D’EMPLOI
MONTAGEVOORSCHRIFTEN EN GEBRUIKSAANWIIZING
MONTAJE Y MODO DE EMPLEO
ISTRUZIONI DI MONTAGGIO E D’USO
GB
F
NL
ES
I
NÁVOD K MONTÁŽI A POUŽITÍCZ
INSTRUKCJE MONTAŻU I OBSŁUGI
PL
Model : F179

4
Warnings
GB WARNINGS
The appliance should not be used by children under 8 years of age and by persons with
reduced physical, sensory and mental capabilities, or lack of experience and knowledge,
unless they are supervised or have received instructions regarding the safe use of the
appliance and are aware of the possible risks. Children must not play with the appliance.
Any intended cleaning and maintenance by the user should not be carried out by
children unless supervised. The hood should never be used without without the grid
properly tted! Never use the hood without the grill properly tted!
The accessible components can overheat when the cooktop is in use.
The hood must not be connected to the ues of other appliances that run on gas or
other fuels. When the hood is used at the same time as other appliances that run on gas
or other fuels, provision must be made for an adequate supply of air. No food must be
cooked ambé underneath the hood. The use of an unprotected ame could cause
damage to the lters and could cause res, so should be avoided. When frying food,
never leave the pan unattended because the cooking oil could are up. Please comply
with the technical and safety provisions set forth by your local competent authorities
regarding the ventilation of hoods.
This appliance conforms to European Directive 2002/96/EC, Waste Electrical and
Electronic Equipment (WEEE). Please dispose of this product correctly in the interest of
health and the environment.
The symbol on the product, or on the documents accompanying the product,
indicates that this appliance may not be treated as household waste. Instead it shall be
handedovertotheapplicablecollectionpointfortherecyclingofelectricalandelectronic
equipment. Disposal must be carried out in accordance with local environmental
regulations for waste disposal. For more detailed information about treatment, recovery
and recycling of this product, please contact your local city oce, your household
waste disposal service or the shop where you purchased the product. If the power
cable is damaged you should, in the interest of safety, contact the manufacturer or the
manufacturer’s technical assistance service to request a replacement, or ask someone
who is similarly qualied.
Check also the drawings on the initial pages with the alphabetical and numerical
references in the explanatory text. Closely follow the instructions in this manual. We
cannot accept liability for any faults, detriment or re damage to the appliance due to
non-compliance with the manual’s instructions.

5
GBWARNINGS
You should ax the hood to a wall of sucient weight-bearing capacity, so not to one
made of plasterboard.
The cooker hood must be placed at a minimum distance of 60 cm from the cooking
plane for electric cookers and 60cm for gas or mixed cookers. If the instructions for
installation for the gas hob specify a greater distance, this has to be taken into account.
Do not tile, grout or silicone this appliance to the wall. Surface mounting only. Do not
x chimney ue to furniture or y over shelves unless the chimney ue can be easily
removed, in case maintenance is ever required.
The cooker hood is provided with an upper air exit B for discharging fumes externally
for models including chimney ue C ( Suction Version A- exhaust pipe not supplied). If
cooking fumes and vapours cannot be externally discharged, the cooker hood can be
used in the recirculating version F: the installation of 1 active charcoal lter F allows the
recirculation of fumes and vapours through the upper grid G.
Make sure that there is a power socket near the hood and that the system has a 30 mA
dierential. The mains voltage must be the same as that on the label inside the hood.The
hood has a 1250 mm power cable with or without plug: if it does have a plug, connect
the hood to an accessible approved socket; or if it does not (connection direct to the
mains), t an approved bipolar switch with a minimum contact opening of no less than
3 mm (accessible). This installation and electrical connection must be executed by a
qualied technician.
If the cooking top is in use, the cooker hood must always operate.
Product performance test carried out in accordance with standard (EU) No 65/2014-
Ref: IEC 61591
Maximum performance is achieved by placing the mobile panels, if any, in the open
position.





















 






































 









































 







AVVERTENZE I
29
GBOPERATION
General Notes: the control system is touch-sensitive. To activate any function, it is only necessary to
touch the button lightly.
Light ON/OFF: switches the hood lights on and o.
Motor ON/OFF (8 speeds+2 timed high speeds): tapping this control will start and stop the motors.
Speed control buttons: Pressing the „1,2,3,4,5,6,7,8“ buttons sets the speed (power) of aspiration
desired. The speed can be selected directly, or by gradually changing through the possible speeds.
High Speed 1: tapping this control activates the „High Speed 1“ aspiration speed. This will time-out
after approx. 8 minutes, after which the speed will return to level 8.
High Speed 2: tapping this control activates„High Speed 2“ aspiration speed. This will time-out after
approx. 7 minutes, after which the speed automatically reverts to level 8.
Grease lters saturated: when the motor is started, this indicator button will light for ve seconds in a
colour that shows the level of lter saturation: Green 0-75%, Orange 76-99%. If the indicator shows a
constant red, this means the metal grilles need to be washed (typically after 40 hours of use).
Carbon lters saturated: when the motor is started, this indicator button will light for ve seconds in
a colour that shows the level of lter saturation: Green 0-75%, Orange 76-99%. If the indicator shows
a constant red, this means the carbon lters need to be washed or replaced (typically after 120 hours
of use).
Grease / Carbon lters saturated“ when the indicator button shows red, pressing it will reset the
indicator. WARNING: This operation should be performed only after correct maintenance of the
respective lter(s).
NOTE: after four hours of uninterrupted operation since the last touch of any of the cooker hood’s
buttons, the hood will switch itself o automatically.
1 2 3 4 5 6 7 8
PTC

30
AVVERTENZE I
Titolo
OPERATIONGB
TSL 3
General notes: Any function can be activated by pressing softly the button under the symbol.
A. ON/OFF light button: By essing this button the hood’s lights switch on.
B. ON/OFF motor button: By pressing this button the extracting motor can be activated/stopped.
1.2.3.4. Speed regulator button: By progressing this button the hood activates the selected extracting
speed.
Funzione Timer: By pressing once again the Selectedspeed button,the timer will last for 5 minutes. This
function can be applied to all 4 available speeds.
Grease lter saturation: After every 40 hours of use of the hood, the button B or 3+4 indicator shows
byashing slowly that the grease lters need to be washed.
Charcoal lter saturation: After every 120 hours of use of the hood, the button B or 3+4 indicator by
asihing fast shows that the charcoal lters need to be replaced.
Note: By pressing for at least 5 minutes the button 3+4 will reset the lters saturation indicator.
Attention! This function should only be used after performing the maintenance of the lters.
Automatic functioning through the heath sensor:
By pressing the button 1 2 at the same time, the hood starts the automatic functioning. The indicators
of the 4 speeds will ash in sequence . After more or less 30 seconds the temperature sensor will start
the motor choosing the right extracting speed.The speed will change according to the heath coming
from the hob.
By pressing B the manual functioning can be restored.
Always clean the glass of the control for a correct functioning.
All hoods with capacities exceeding 650 m3/h have the last timed speed; It lasts for 7 minutes, after
which it automatically returns to the last non-timed speed.

31
OPERATION GB
Maintenance
Prior to any maintenance operation ensure that the cooker hood is disconnected from the
electrical outlet.
Cleaning
The hood must be cleaned frequently both inside (apart from the area behind the grease lter)
and outside. Use a cloth moistened with neutral liquid detergents. Never use products containing
abrasives.
Warning
Failure to carry out the basic standards of the cleaning of the cooker hood and replacement of the
lters may cause re risks. Therefore we recommend observing these instructions.
Anti-grease Filter
must be cleaned once a month, with non abrasive detergents, by hand or in dishwasher on low
temperature and short cycle.When washed in a dishwasher, the grease lter may discolour slightly,
but this does not aect its ltering capacity.
Charcoal Filter - (only for lter version)
Carbon lters can be regenerated only once by washing at low temperature in a dishwasher, then
drying in an ordinary kitchen oven at 90ºC for approx. 10 minutes. Each lter must be regenerated
or replaced as soon as the respective warning indicator on the hood lights up. For hoods without
lter replacement warning indicators, we recommend washing / replacement approximately every
six months assuming the hood and cooker are in normal use.
Reducing environmental impact:
To reduce energy consumption, we recommend you always use the lowest suction speed among
those suitable for the cooking mode currently active, avoid leaving the appliance running for more
than 15 minutes after burner shutdown and switch o the lights if you leave the cooking area.
Replacing lightbulbs
Warning! Prior to touching the light bulbs ensure they are cooled down.
Led Light
If the lighting group LED does not work, please contact the technical service center in order to
replace the whole group.

AFLIF179 Ed.04-10-17
@
