AIRFORCE F203 Technical manual

MONTAGE- UND GEBRAUCHSANWEISUNG
D
INSTRUCTIONS ON MOUNTING AND USE
PRESCRIPTIONS DE MONTAGE ET MODE D’EMPLOI
MONTAGEVOORSCHRIFTEN EN GEBRUIKSAANWIIZING
MONTAJE Y MODO DE EMPLEO
ISTRUZIONI DI MONTAGGIO E D’USO
GB
F
NL
ES
I
Model : F203Model : F204

4
Warnings
GB WARNINGS
The appliance should not be used by children under 8 years of age and by persons with
reduced physical, sensory and mental capabilities, or lack of experience and knowledge,
unless they are supervised or have received instructions regarding the safe use of the
appliance and are aware of the possible risks. Children must not play with the appliance.
Any intended cleaning and maintenance by the user should not be carried out by
children unless supervised. The hood should never be used without without the grid
properly tted! Never use the hood without the grill properly tted!
The accessible components can overheat when the cooktop is in use.
The hood must not be connected to the ues of other appliances that run on gas or
other fuels. When the hood is used at the same time as other appliances that run on gas
or other fuels, provision must be made for an adequate supply of air. No food must be
cooked ambé underneath the hood. The use of an unprotected ame could cause
damage to the lters and could cause res, so should be avoided. When frying food,
never leave the pan unattended because the cooking oil could are up. Please comply
with the technical and safety provisions set forth by your local competent authorities
regarding the ventilation of hoods.
This appliance conforms to European Directive 2002/96/EC, Waste Electrical and
Electronic Equipment (WEEE). Please dispose of this product correctly in the interest of
health and the environment.
The symbol on the product, or on the documents accompanying the product,
indicates that this appliance may not be treated as household waste. Instead it shall be
handedovertotheapplicablecollectionpointfortherecyclingofelectrical and electronic
equipment. Disposal must be carried out in accordance with local environmental
regulations for waste disposal. For more detailed information about treatment, recovery
and recycling of this product, please contact your local city oce, your household
waste disposal service or the shop where you purchased the product. If the power
cable is damaged you should, in the interest of safety, contact the manufacturer or the
manufacturer’s technical assistance service to request a replacement, or ask someone
who is similarly qualied.
Check also the drawings on the initial pages with the alphabetical and numerical
references in the explanatory text. Closely follow the instructions in this manual. We
cannot accept liability for any faults, detriment or re damage to the appliance due to
non-compliance with the manual’s instructions.

5
GBWARNINGS
You should ax the hood to a wall of sucient weight-bearing capacity, so not to one
made of plasterboard.
The cooker hood must be placed at a minimum distance of 65 cm from the cooking
plane for electric cookers and 65 cm for gas or mixed cookers. If the instructions for
installation for the gas hob specify a greater distance, this has to be taken into account.
Do not tile, grout or silicone this appliance to the wall. Surface mounting only. Do not
x chimney ue to furniture or y over shelves unless the chimney ue can be easily
removed, in case maintenance is ever required.
The cooker hood is provided with an upper air exit B for discharging fumes externally
for models including chimney ue C ( Suction Version A- exhaust pipe not supplied). If
cooking fumes and vapours cannot be externally discharged, the cooker hood can be
used in the recirculating version F: the installation of 1 active charcoal lter F allows the
recirculation of fumes and vapours through the upper grid G.
Make sure that there is a power socket near the hood and that the system has a 30 mA
dierential. The mains voltage must be the same as that on the label inside the hood.The
hood has a 1250 mm power cable with or without plug: if it does have a plug, connect
the hood to an accessible approved socket; or if it does not (connection direct to the
mains), t an approved bipolar switch with a minimum contact opening of no less than
3 mm (accessible). This installation and electrical connection must be executed by a
qualied technician.
If the cooking top is in use, the cooker hood must always operate.
Product performance test carried out in accordance with standard (EU) No 65/2014-
Ref: IEC 61591
Maximum performance is achieved by placing the mobile panels, if any, in the open
position.
















53.5
136.2
226
179.5
270
205
O60
81.2
150
138.5
20
45
55
135.5
66.5























20
GB
TSL
OPERATION

With the hood switched o, pressing any key will activate the control panel in stand-by mode. The
symbols are backlit by a white light, allowing you view and select the desired function.
Pressing one of the keys again will start the corresponding function, and its symbol will light up. After all
functions have been switched o, the control panel will remain in stand-by mode for around 30 seconds
and then switch o automatically.
A: Light ON/OFF key: press this touch sensor to switch on or o the lights of the hood.
C: Motor ON/OFF key (4 speed): press this touch sensor to switch on the hood extractor fan at the same
speed as it was when last switched o. Use the„D“ and„B“ keys to vary the speed (power) of extraction.
B: Decrease extraction speed (power) key: press this touch sensor to reduce the extraction speed of the
hood.
D: Increase extraction speed (power) key: press this touch sensor to increase the extraction speed of the
hood.
E: Timer key: when this touch sensor is pressed, independently of the extraction speed selected, the
timer function will be activated. Press once to set the timer for 5 minutes, press a second time for 10
minutes and a third time for 20 minutes. During this phase, the„E“ symbol will ash.
To reset the timer, press the motor key,„C“
F: Reset lters key: press this touch sensor to reset the signal that warns that the metal grease lter (1)
is saturated and the charcoal lter (2) should be replaced. (1) After 40 hours of using the hood, the„F“
symbol will ash to indicate the necessity of cleaning the metal grease lters.
(2) After 120 hours of using the hood, the„F“ symbol will light up to indicate the necessity of replacing
the activated charcoal lters.
Sensor function: pressing the „B“ and „D“ keys at the same time will activate the sensor. In this mode the
extraction speed sets itself automatically and the „B+D“ key ashes intermittently. To return to manual
operation, press either the„B“ or the„D“ key.
Note: 4 hours after the last key touch, the fan will automatically turn o.
All hoods with capacities exceeding 650 m3/h have the last timed speed; It lasts for 7 minutes, after
which it automatically returns to the last non-timed speed.

21
OPERATION GB
Maintenance
Prior to any maintenance operation ensure that the cooker hood is disconnected from the
electrical outlet.
Cleaning
The hood must be cleaned frequently both inside (apart from the area behind the grease lter)
and outside. Use a cloth moistened with denatured alcohol or neutral liquid detergents. Never use
products containing abrasives.
Warning
Failure to carry out the basic standards of the cleaning of the cooker hood and replacement of the
lters may cause re risks. Therefore we recommend observing these instructions.
Anti-grease Filter
must be cleaned once a month, with non abrasive detergents, by hand or in dishwasher on low
temperature and short cycle.When washed in a dishwasher, the grease lter may discolour slightly,
but this does not aect its ltering capacity.
Charcoal Filter - (only for lter version)
The active charcoal lters F are not washable nor regenerative. It should be changed every 6
months in normal use. The active charcoal lters capture unpleasant cooking odours.
Replacing lightbulbs
Warning! Prior to touching the light bulbs ensure they are cooled down.
Led Light
If the lighting group LED does not work, please contact the technical service center in order to
replace the whole group.
Reducing environmental impact:
To reduce energy consumption, we recommend you always use the lowest suction speed among
those suitable for the cooking mode currently active, avoid leaving the appliance running for more
than 15 minutes after burner shutdown and switch o the lights if you leave the cooking area.
