Airing Air03 User manual

1
Table of Contents
User Manual
Indoor Bluetooth Speaker
GENERAL INFORMATION 2
Introduction 2
Features 2
Bluetooth Wireless Communication Technology 2
Parts Included in the Box 3
OPERATION INSTRUCTION 4
Switching on/off AIR034
Pairing AIR03 with Bluetooth Devices 4
Music Playback5
MAINTENANCE 6
Product Registration 7
Limited Warranty 7
Specifications 8
Trouble Shooting / FAQ 9
Contacting Customer Service 11

2
Introduction
Features
Bluetooth Wireless Communication Technology
Parts Included in the Box
Thank you for purchasing this Airing Indoor Bluetooth Speaker product. This
product has been manufactured with the highest standards of safety and quality.
Traditionally designed adds elegant wooden box, 8Wats x 2 SAT, 15W Woofer, you
surely will enjoy using this speaker！
Simple design for displaying on shelf
Solid wooden flourishing with piano painting
Bluetooth Class 2, transmitting / receiving working distance up to 10m
Support Bluetooth V2. 1
Supports A2DP Bluetooth wireless audio profile for use with iPhone,
iPod touch, iPad and other Bluetooth enabled devices
8W x 2 Stereo speaker output power + 15W Woofer to enrich bass sound
quality
BQB approved and fully compatible with other Bluetooth enabled devices
Bluetooth is a standard of close range radio-communication technology that was
drawn up by Ericsson, IBM, Intel, Nokia and Toshiba. With Bluetooth technology,
we can achieve the highest transmission rate among cell phones, computers,
printers, PDAs and other devices. The maximum transmission range of class II is
10 meters while the maximum transmission ranges of class I can reach up to 100
meters.
A. Bluetooth Speaker (x1)
B. AC adapter (x1)
C. Line-in cable (x1)
Overview:
1 VOL -
2 VOL +
3 Bluetooth LED indicator
4 Power LED indicator
5 Soft cushion for supporting the speaker
6 3.5mm line-in jack
7 Power cable connected with speaker
8 Power on/off button

3
Operation Instruction
1. Switching on/off AIR03
Function
Operation
LED indicator
Switching on
AIR03
Switch power on/off
button to on
Bluetooth LED indicator is on
Switching off
AIR03
Switch power on/off
button to off
Bluetooth LED indicator is off
Remarks:
Every time AIR03 is switched on, it will enter pairing mode automatically.
Power LED indicator is on as long as AIR03 is switched on.
You can switch off AIR03 to disconnect from the Bluetooth device.
2. Pairing AIR03 with Bluetooth devices
A. Pairing with a Bluetooth cell phone
Please make sure your cell phone is Bluetooth-enabled. Specific pairing steps may
vary with different cell phones. Please refer to the user manual of your cell phone
for further information. The general pairing steps are as follows:
a) Keep AIR03 and Bluetooth cell phone within 1 meter when pairing.
b) Switch on AIR03 to let it enter pairing mode (Bluetooth LED indicator
flashes).
c) Switch on your cell phone’s Bluetooth function and search for Bluetooth
devices. After the search is completed, select “AIR03” from the Bluetooth
device list.
d) According to indication, enter password or PIN No: “0000” and press “Yes”
or “confirm”.
e) After successful pairing, select “AIR03” from the Bluetooth device list
and press “connect”. The Bluetooth LED indicator will remain on when
connected successfully.
B. Pairing with a Bluetooth stereo transmitter
Different Bluetooth transmitters have different pairing ways. Please refer to the
user manual of your Bluetooth transmitter for further information. The general
pairing steps are as follows:
a) Keep AIR03 and Bluetooth transmitter within 1 meter when pairing.
b) Switch on AIR03 to let it enter pairing mode (Bluetooth LED indicator
flashes).
c) Switch on your Bluetooth transmitter and let it enter pairing mode.
d) The transmitter will search and connect with AIR03 automatically. After
successful connecting, the Bluetooth LED indicator of AIR03 will remain on.
Remarks:
If AIR03 is switched on and doesn’t connect to any devices, it keeps pairing
mode all the time and Bluetooth LED indicator flashes.
AIR03 will return to pairing mode automatically after disconnecting from a
Bluetooth device.
3.Music Playback
A. Connecting with a A2DP cell phone or Bluetooth transmitter
a) Connect your cell phone or Bluetooth transmitter with AIR03.
b) You can listen to your music from AIR03 now when playing it back.
c) Press VOL+ to turn up the volume, press VOL-to turn down the volume.
B. Connecting with a non-Bluetooth music player
a) Connect your music player with AIR03 by using a 3.5mm to 3.5mm audio
cable.
b) You can listen to your music from AIR03 now when playing it back.

4
Maintenance
Product Registration
Limited Warranty
Remarks:
If there is an incoming or outgoing call while AIR03 is connected to your cell
phone for music playback, it will pause at once and resume after the call
ended.
When AIR03 is connected to a non-Bluetooth audio device, the Bluetooth is
off and the Bluetooth function will not be available. If you want to play music
from a Bluetooth device you have to unplug the 3.5mm audio cable first.
Read the following recommendations before using AIR03. Following these you
will be able to enjoy our product for many years.
Keep it dry and don’t take it to damp places so as to avoid the product’s
internal circuit being affected.
Keep the product away from direct sunlight or hot places. High temperatures
will shorten the life of electronic devices, destroy the battery or distort certain
plastic parts.
Don’t expose the product to cold areas. It may damage the internal circuit
board.
Don’t try to disassemble the product as it may get damaged if you are not
professional.
Don’t let it fall down onto the floor or other hard surfaces. The internal circuit
might get damaged.
Don’t use intensive chemical products or detergent to clean the product.
Don’t scratch the surface with sharp things.
Thank you for purchasing Airing Indoor Bluetooth Speaker. Please register
your product at www.airing.nl for your warranty.
Please reference your item# (AIR03) and/or UPC (851489004030) to register
it.
For technical assistance and more information, please feel free to contact
UniStrong technical support or customer service at www.airing.nl.
The manufacturer warrants this product to be free from defects in materials and
workmanship for a period of one (1) year from date of purchase. This warranty
applies only to the original consumer purchaser and only to products used in
normal use and service. If this product is found to be defective, the manufacturer’s
only obligation, and your exclusive remedy, is the repair or replacement of the
product at the manufacturer’s discretion, provided that the product has not been
damaged through misuse, abuse, accident, modifications, alterations, neglect or
mishandling. This warranty shall not apply to any product that is found to have
been improperly installed, set-up, or used in any way not in accordance with the
instructions supplied with the product. This warranty shall not apply to a failure of
the product as a result of an accident, misuse, abuse, negligence, alteration, or
faulty installation, or any other failure not relating to faulty material or
workmanship. This warranty shall not apply to the finish on any portion of the
product, such as surface and/or weathering, as this is considered normal wear and
tear. The manufacturer does not warrant and specially disclaims any warranty,
whether expressed or implied, of fitness for a particular purpose, other than the
warranty contained herein. The manufacturer specifically disclaims any liability
and shall not be liable for any consequential or incidental loss or damage,
including any labor/ expense costs involved in the replacement or repair of said
product.

5
Trouble Shooting / FAQ
Specifications
Bluetooth Version Bluetooth V 2.1
Bluetooth Profile A2DP
Frequency Response
L/R OUT:540HZ-20KHZ
WOOFER OUT:44-200Hz
Operating Distance 10 meters, class II
Power Supply AC adaptor
Working Temperature 0℃~55℃
Storage Temperature -20℃~70℃
Dimensions 14.95"W x 7.48"D x 6.30"H
Weight 10.14 lb
Problem/Question
Solution/Answer
AIR03 cannot be powered
on.
1. Make sure that the DC cord is firmly
connected to the unit and that the power
outlet is turned on.
2. Ensure that the Power ON / OFF switch is at
ON position. When the speaker is powered
ON, the Power LED Indicator will be lighted
up.
AIR03 cannot connect to a
Bluetooth device.
1. Ensure AIR03 already entered pairing mode.
2. Ensure the Bluetooth device is in the
effective working range.
3. Delete the AIR03 name entry from your
Bluetooth device paired memory list and
re-pair your device with AIR03.
4. Ensure that both your Bluetooth device and
AIR03 are not connected to any other
devices.
5. On some Bluetooth device, you may need to
select AIR03 as your default output device
after pairing is completed.
AIR03 is connected to a
Bluetooth cell phone but
doesn’t play music.
1. Ensure your cell phone supports Bluetooth
A2DP o r AV R C P profile.
2. Ensure your cell phone is in the effective
Bluetooth working range.
The sound of AIR03 crackles
or has a loud hum or
buzzing.
1. Turn your Bluetooth device or other source
component’s volume down.
2. Unplug the power supply and connect AIR03
to a different AC outlet.
3. Move unit away from potential sources of
interference, such as microwave ovens,
fluorescent lights, etc.

6
Trouble Shooting / FAQ
Contacting Customer Service
Problem/Question
Solution/Answer
AIR03 has no sound. 1. Verify that the volume is not muted.
2. Verify that there is no other device connected to
AIR03.
3. Check the connection between your Bluetooth
device and AIR03.
4. Try restarting AIR03 or your Bluetooth device.
How far is the effective
range between AIR03 and
a Bluetooth device?
According to the Bluetooth standard, the maximum
controllable range of Class II speaker is 10 meters.
But it varies under different environments and
depends on the paired cell phone.
What is A2DP? A2DP means the Advanced Audio Distribution
Profile. It’s a Bluetooth profile that allows for the
wireless transmission of stereo audio from an A2DP
source to an A2DP receiver.
What is AVRCP? AVRCP means the Audio/Video Remote Control
Profile. It’s a Bluetooth profile that allows Bluetooth
devices to control media playback on remote devices.
It’s typically used with A2DP devices for
next/previous track selection and pause/play
functions.
Still have questions?
Please feel free to contact our customer service.
