Flux Reference Series User manual

COMPONENT SPEAKER
INSTALLATION MANUAL
Reference Series
RC 361
Maestro Competition Series
MC Comp 361

Passive Crossover
You already bought one of the best German Car Hifi Component loudspeak-
er System. With our latest vehicle adaptive crossover technology, you will
get the maximum listening pleasure and ultimate sound reproduction you
ever hear.
WARNING
Attention
Please read all the warnings that can be found in this manual. You can install
all components in your vehicle and experience an ultimate step by step car
audio instalation procedure with proper mechanical and electrical instala-
tions.
Hearing Damage
Continuous, excessive exposure to sound pressure levels in excess of 85dB
can cause a loss of hearing. FLUX Components are capable of producing
sound pressure levels greater than 85dB.
Volume and Driver Awareness
Use of sound components can impair your ability to hear necessary traffic
sound and may constitute a hazard while driving your vehicle. FLUX except
no liability for hearing loss boardly injury or property damage as result of
use or missused of this product.
Congratulations
Warranty Return
FLUX product guarantee only applies if the enclosed guarantee card is
retruned to us and our dealer within you buy this product, maximum 10
(ten) day of purchase.
1

Passive Crossover
FEATURES AND CONTENTS
Product Features
- Reference Series (RC 361)
FLUX T 160 R3 • 6.5” midwoofer, 4 layer (paper+glass fiber+silk+ceramic) cone
• 37mm v/c with 90mm magnet diameter
• Aluminium die cast basket, vented basket
• copper reverse dust cap
FLUX M 80 R • 3” midrange, 4 layer (paper+glass fiber+silk+ceramic) cone
• 25mm v/c with vented basket, neodymium magnet
• Copper reverse phase plug
• Aluminium die cast basket, screw connector
FLUX HT 28 R • 28mm v/c with special hand coated silk dome
• Duralium housing, screw connector
• Vented magnet with additional rear chamber
FLUX XR 361 • 3 way passive crossover for RC 361
• Real 24 KT gold plated
• Selectable input for single/dual/triple amplifiers
• Double sided PCB with 2 OZ copper thickness to maximize signal transfers
• Using selected silver solder to maximize contacts
• Selected component to maximize each frequency characteristic to
achieve the best tonal accuracy
FLUX T 160 MC3 • 6.5” midwoofer, triple sandwich (paper+glass fiber+silk) cone
• 37mm v/c with 90mm magnet diameter
• Auminium die cast basket, vented basket
• Aluminum reverse dust cap
FLUX M 80 MC • 3” midrange, triple sandwich (paper+glass fiber+silk) cone
• 25mm v/c with vented basket, neodymium magnet
• Duralium reverse phase plug
• Aluminium die cast basket, screw connector
FLUX HT 25 MC • 27 mm v/c with special hand coated silk dome
• Duralium housing, screw connector
• Vented magnet with additional rear chamber
FLUX XMC 361 • 3 way passive crossover for RC 361 comp
• Real 24 KT gold plated
• Selectable input for single/dual/triple amplifiers
• Double sided PCB with 2 OZ copper thickness to maximize signal transfers
• Using selected silver solder to maximize contacts
• Selected component to maximize each frequency characteristic to achieve
the best tonal accuracy
- Maestro Competition Series (MC Comp 361)
2

Passive Crossover
Getting Started
It is recommended that your new FLUX speakers are installed by an au-
thorized FLUX Authorized Dealers. This will ensure the use of proper in-
stallation techniques and material, and also will save you a lot of time and
efforts.
Do not use your car until all component of the loudspeaker system have
been secured to the interior framework. Failure to do so, may cause danger-
ous to a vehicle flying projectitle during a sudden stop or accident.
Do not drill or drive screws through any vehicle interior or carpeted floor
before inspecting the underside for potential punctures to control lines or
cables. Take extreme care when working near the fuel tank, gas lines brakes
or hydraulic lines and electrical wiring.
Turn off the audio system. It is also advisable to disconnect the negative
[ - ] terminal of your vehicle battery whenever performing installation
work. If the installation finished turn on the various components and slowly
advance the volume.
Remember to check and re-check all connections to insure proper installa-
tion and use.
Do not exceed the indicated maximum operational power.
Please make sure the same polarity in loudspeaker, crossover and ampli-
fier are guaranted. if speakers are wired out of phase, an unnatural sound
without bass is the result.
INSTALLATION
3

Passive Crossover
Positioning & Choosing a Location
Using a component speaker gives you the freedom to place the woofer
and tweeter separately in your car. It could be good or bad in terms of
sound quality, it depends where you put it.
3 Way Speaker System
With 3 way speaker system consisting of fixed tweeter and midbass
drivers, but its application is added again named midrange driver that
allows you to create a character of high frequency or vowel sounds more
focused and bold, this is for the midrange capable of filling the missing
high frequency due to the limited ability of tweeters and midbass. The
speakers of this type can produce a quality sound with better imaging
of the system 2 way though just use midbass holder with original angle.
With this, easy to remodel back into a standard audio system again. Mid-
bass drivers can be more focused and solid vocal sound or high frequen-
cy sounds more thicker due to the tweeter and midrange are placed on the
dashboard on the pillar A.
4
Woofer
6”
Woofer
6”
Midrange
3”
Tweeter
Tweeter

Installation Components
Installation Using 1 Amplifier
Amplifier
Selector A
1 Amp
Input Jumper Positions
On
Off
On
Off
Selector B
1 Amp
Input Jumper Positions
On
Off
On
Off
Input
Selector A
Input
Selector B
WARNING
Install 2 (two) Amplifier or more, jumper input must be installed correctly.
Wrong installation on input jumper can damage the Amplifier
XR 361
+ - + -
+ -
+ -
HT 28R
T 160 R3
M 80 R
Reference Series [RC 361]
5

Woofer
Amplifier
Selector A
2 Amp
Input Jumper Positions
On
Off
On
Off
Selector B
2 Amp
Input Jumper Positions
On
Off
On
Off
Input
Selector A
Input
Selector B
WARNING
Install 2 (two) Amplifier or more, jumper input must be installed correctly.
Wrong installation on input jumper can damage the Amplifier
Installation Using 2 Amplifier
XR 361
HT 28R
T 160 R3
M 80 R
+ - + -
+ -
+ -
+ -
Reference Series [RC 361]
6
Tweeter
Midrange
Amplifier

Selector A
3 Amp
Input Jumper Positions
On
Off
On
Off
Selector B
3 Amp
Input Jumper Positions
On
Off
On
Off
Input
Selector A
Input
Selector B
WARNING
Install 2 (two) Amplifier or more, jumper input must be installed correctly.
Wrong installation on input jumper can damage the Amplifier
Installation Using 3 Amplifier
HT 28R
T 160 R3
M 80 R
+ - + -
+ -
+ -
+ -
+ -
XR 361
Reference Series [RC 361]
7
Midrange
Amplifier
Woofer
Amplifier
Tweeter
Amplifier

Standard Jumper Settings
1 2 3 1 2 3
FREQ Q
WOOFER
1 2 3 1 2 3
1 2 3 1 2 3 1 2 3 1 2 3
LP Q LP Q LEVEL
HP Q HP FREQ LEVEL LP FREQ
MIDRANGE
1 2 3 4 1 2 3 1 2 3
Level (dB) FREQ Q
TWEETER
1 2 3 4 1 2 3 1 2 3 1 2 3 1 2 3
1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3
Level (dB) FREQ Q LP Q LP Q LEVEL
HP Q HP FREQ LEVEL LP FREQ FREQ Q
WOOFER
MIDRANGE
TWEETER
Jumper positions are
attached, you can still
change it based on your
style of sound. Or it can
be adapted to the condi-
tions.
XR 361
Reference Series [RC 361]
8

Tweeter Setting
Level
1 2 3 4
0 dB
-3 dB
-6 dB
-9 dB
Hi Pass Freg
1 2 3
Hi Pass Q Factor
1 2 3
1 2 3 4
Level (dB)
1 2 3
FREQ
1 2 3
Q
Reference Series [RC 361]
9

Lo Pass Freg
1 2 3
Level
1 2 3
Hi Pass Freg
1 2 3
Hi Pass Q Factor
1 2 3
1 2 3
HP FREQ
1 2 3
LEVEL
1 2 3
LP FREQ
1 2 3
HP Q
Midrange Setting
Reference Series [RC 361]
10

Woofer Setting
1 2 3
LP Q
1 2 3
LP Q LEVEL
1 2 3
Lo Pass Q Factor
Lo Pass Freg
1 2 3
1 2 3
Lo Pass Q Level
1 2 3
Lo Pass Q Factor
1 2 3
FREQ
1 2 3
Q
Reference Series [RC 361]
11

Installation Components
Installation Using 1 Amplifier
Amplifier
Selector A
1 Amp
Input Jumper Positions
On
Off
On
Off
Selector B
1 Amp
Input Jumper Positions
On
Off
On
Off
Input
Selector A
Input
Selector B
WARNING
Install 2 (two) Amplifier or more, jumper input must be installed correctly.
Wrong installation on input jumper can damage the Amplifier
XMC 361
+ - + -
+ -
+ -
HT 25 MC
T 160 MC3
M 80 MC
Maestro Competition Series [MC Comp 361]
12

HT 25 MC
T 160 MC3
M 80 MC
Selector A
2 Amp
Input Jumper Positions
On
Off
On
Off
Selector B
2 Amp
Input Jumper Positions
On
Off
On
Off
Input
Selector A
Input
Selector B
WARNING
Install 2 (two) Amplifier or more, jumper input must be installed correctly.
Wrong installation on input jumper can damage the Amplifier
Installation Using 2 Amplifiers
XMC 361
+ - + -
+ -
+ -
+ -
Maestro Competition Series [MC Comp 361]
13
Woofer
Amplifier
Tweeter
Midrange
Amplifier

Selector A
3 Amp
Input Jumper Positions
On
Off
On
Off
Selector B
3 Amp
Input Jumper Positions
On
Off
On
Off
Input
Selector A
Input
Selector B
WARNING
Install 2 (two) Amplifier or more, jumper input must be installed correctly.
Wrong installation on input jumper can damage the Amplifier
Installation Using 3 Amplifier
+ - + -
+ -
+ -
+ -
+ -
XMC 361
HT 25 MC
T 160 MC3
M 80 MC
Maestro Competition Series [MC Comp 361]
14
Midrange
Amplifier
Woofer
Amplifier
Tweeter
Amplifier

Standard Jumper Settings
1 2 3 1 2 3
FREQ Q
WOOFER
1 2 3 1 2 3
1 2 3 1 2 3 1 2 3 1 2 3
LP Q LP Q LEVEL
HP Q HP FREQ LEVEL LP FREQ
MIDRANGE
1 2 3 4 1 2 3 1 2 3
Level (dB) FREQ Q
TWEETER
1 2 3 4 1 2 3 1 2 3 1 2 3 1 2 3
1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3
Level (dB) FREQ Q LP Q LP Q LEVEL
HP Q HP FREQ LEVEL LP FREQ FREQ Q
WOOFER
MIDRANGE
TWEETER
Jumper positions are
attached, you can still
change it based on your
style of sound. Or it can
be adapted to the condi-
tions.
XMC 361
Maestro Competition Series [MC Comp 361]
15

Tweeter Setting
Level
1 2 3 4
0 dB
-3 dB
-6 dB
-9 dB
Hi Pass Freg
1 2 3
Hi Pass Q Factor
1 2 3
1 2 3 4
Level (dB)
1 2 3
FREQ
1 2 3
Q
Maestro Competition Series [MC Comp 361]
16

Lo Pass Freg
1 2 3
Level
1 2 3
Hi Pass Freg
1 2 3
Hi Pass Q Factor
1 2 3
1 2 3
HP FREQ
1 2 3
LEVEL
1 2 3
LP FREQ
1 2 3
HP Q
Midrange Setting
Maestro Competition Series [MC Comp 361]
17

Woofer Setting
1 2 3
LP Q
1 2 3
LP Q LEVEL
1 2 3
Lo Pass Q Factor
Lo Pass Freg
1 2 3
1 2 3
Lo Pass Q Level
1 2 3
Lo Pass Q Factor
1 2 3
FREQ
1 2 3
Q
Maestro Competition Series [MC Comp 361]
18

Passive Crossover
Running In Period / Break In
To ensure such complex mechanical elements work in harmony with each
other, they must be allowed to function correctly are in this environment.
Such change in temperature and humidity are regarded as very hostile.
For speakers to benefit, a running-in period must be used to ensure they
are prepared for this. We recommend that once the system is ready for
listening the drive units should be run-in with medium volume setting,
with music that has the full bandwidths of frequencies. this running-in
period should be minimal 24 hours and for full potential should be a few
weeks. after which the excellent performance of your system can be fully
appreciated.
NOTES
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
..........................................................................................................................
....................................................................................................................
19
Other manuals for Reference Series
2
This manual suits for next models
3
Table of contents
Other Flux Speakers manuals
