AirLive WN-200HD User manual






i
W
N-200HD
2.0 Mega Pixel Wireless
150Mbps IP Camera
User’s Manual

Copyright & Disclaimer
i
AirLive WN-200HD User’s Manual
Copyright & Disclaimer
No part of this publication may be reproduced in any form or by any means, whether
electronic, mechanical, photocopying, or recording without the written consent of
OvisLink Corp.
OvisLink Corp. has made the best effort to ensure the accuracy of the information in
this user’s guide. However, we are not liable for the inaccuracies or errors in this
guide. Please use with caution. All information is subject to change without notice
This product contains some codes from GPL. In compliance with GPL agreement,
AirLive will publish the GPL codes on our website. Please go to www.airlive.com and
go to the "Support->GPL" menu to download source code.
All Trademarks are properties of their respective holders.

Copyright & Disclaimer


AirLive WN-200HD User’s Manual ii
FCC Statement
Federal Communication Commission Interference Statement This equipment has
been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one of the following measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
zConsult the dealer or an experienced radio/TV technician for help.
FCC Caution
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation. For product available in the USA/Canada market, only
channel 1~11 can be operated. Selection of other channels is not possible.
This device and its antenna(s) must not be co-located or operation in conjunction with
any other antenna or transmitter.
IMPORTANT NOTE
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.

Table of Contents
iii
AirLive WN-200HD User’s Manual
Table of Contents
1. Introduction.....................................................................................................1
1.1 Overview.........................................................................................1
1.2 Features..........................................................................................2
1.3 System Requirements.....................................................................2
1.4 Package Contents...........................................................................3
1.5 Physical Description........................................................................3
1.5.1 Front View ..............................................................................3
1.5.2 Bottom View ...........................................................................4
1.6 Hardware Installation.......................................................................6
2. Getting Started...............................................................................................8
2.1 IP Wizard.........................................................................................8
2.1.1 View......................................................................................10
2.1.2 LAN ......................................................................................10
2.1.3 Wireless................................................................................13
2.2 UPnP for Windows........................................................................16
2.3 Install the IP Camera behind NAT router.......................................17
2.4 Configure IP Camera via Web UI..................................................18
2.4.1 Login as User .......................................................................19
2.4.2 Login as Administrator..........................................................20
3. Configure the Camera..................................................................................21
3.1 Monitor the Image Section ............................................................21
3.2 View Profile...................................................................................21
3.3 Streaming Protocol........................................................................21
3.4 Language......................................................................................21
3.5 Two-Way Audio.............................................................................21
3.6 Full Screen....................................................................................22
3.7 Active Control................................................................................22
3.7.1 Digital Zoom .........................................................................23
3.7.2 Snapshot ..............................................................................23
3.7.3 Record..................................................................................24
3.7.4 Volume .................................................................................25
3.7.5 About....................................................................................25
4. Monitor the Image Section ...........................................................................27
4.1 Monitor the Image Section ............................................................27
4.2 Configure via Web UI....................................................................27
4.2.1 Network ................................................................................27

Table of Contents


AirLive WN-200HD User’s Manual
iv
4.2.2 Wireless................................................................................29
4.2.3 DDNS...................................................................................33
4.2.4 PPPoE..................................................................................35
4.2.5 Steaming ..............................................................................37
4.2.6 UPnP....................................................................................38
4.2.7 Bonjour.................................................................................39
4.2.8 IP Filter.................................................................................40
4.2.9 IP Notification .......................................................................41
4.3 Camera – Adjust Camera Parameters ..........................................43
4.3.1 Picture..................................................................................43
4.3.2 Privacy Mask........................................................................45
4.4 System – Configure and Maintain .................................................46
4.4.1 System .................................................................................46
4.4.2 Date & Time..........................................................................48
4.4.3 Maintenance.........................................................................49
4.5 Video – Configure Profile ..............................................................51
4.5.1 Common...............................................................................52
4.5.2 Video Profile.........................................................................53
4.5.3 ROI.......................................................................................54
4.6 Audio – Audio Parameters ............................................................55
4.6.1 Setting..................................................................................55
4.6.2 Manage User Name, Password and Login Privilege ............56
4.6.3 E-Mail...................................................................................57
4.6.4 Object Detection...................................................................58
4.6.5 Storage – Status and Configuration of SD card....................60
4.6.6 Recording List- Files List inside SD Card .............................61
4.6.7 Event Sever..........................................................................61
4.6.8 Event Schedule ....................................................................66
5. Troubleshooting & FAQ................................................................................72
5.1 Monitor the Image Section ............................................................72
5.2 PING .............................................................................................78
5.3 Bandwidth Estimation....................................................................79
5.4 Specification Table........................................................................80
5.5 Configure Port Forwarding Manually.............................................82
5.6 DDNS............................................................................................85
5.7 Power Line Frequency ..................................................................92
5.8 3GPP Table...................................................................................94
5.9 UPnP.............................................................................................95

1. Introduction
1
AirLive WN-200HD User’s Manual
1 1. Introduction
1.1 Overview
This camera is an inexpensive and fully scalable surveillance device. Because
the Network Cameras can be plugged into your existing local area network
(LAN), you will potentially save thousands of dollars from unnecessary cabling.
The device is accessible via the LAN or Internet connection. Connect your
device directly to a local area network or xDSL modem, and with Microsoft®
Internet Explorer you get instant, on demand video streams. Within minutes
you can set up the device to capture a video sequence to a PC. The live video
can be uploaded to a website for the world to see.

1. Introduction


AirLive WN-200HD User’s Manual
2
1.2 Features
zEasy installation with setup wizard (IP Wizard II)
zUPnP device discovery and NAT router transversal for easy installation
zDynamic IP Service, DIPS®, to search your IP camera from Internet easily
zH.264, MPEG4 and JPEG triple compression simultaneously
z2 Mega-pixel resolution
zUp to 9-profile encoder simultaneously
z2 Mega-pixel or 720P mode selectable
zUp to 30 fps for 720P mode
zUp to 15 fps for 2 Mega-pixel mode
zUDP / TCP / HTTP protocols selectable
zIEEE 802.11n wireless LAN
zWEP/WPA/WPA2-PSK wireless security
z3GPP for 3G mobile remote application
zDigital zoom
zBuilt-in microphone
zAudio line out
zTwo-way audio
zIntelligent motion detection up to 10 zones
zGo to preset once motion triggered
zImage transmission using an FTP or e-mail for event
zDDNS and PPPoE
zMulti-channel control software for surveillance application
zOn-line firmware upgrade
1.3 System Requirements
zMicrosoft Internet Explorer 6.0 or later
zMicrosoft Media Player 11.0 or later (to playback recorded file)
zVGA Monitor resolution 1280 x 1024 or higher
zPentium-4 3.6 GHz or higher
zMemory Size: 1GB or more
zWindows XP, Vista, 7

1. Introduction
3
AirLive WN-200HD User’s Manual
1.4 Package Contents
User can find the following items in the package:
zThis camera is the main element of the product.
zCamera Stand with screws
zDetachable WLAN antenna
zPower adapter dedicates 12V DC electric power output to Network
Camera.
zUser’s manual CD provides important information and instructions for
operating the Network Camera.
zQuick start guide provides important information and instructions for
installing this device.
If any of the above items are missing, please contact your dealer immediately.
Note: Using a power supply with a different voltage than the one included with
the Network Camera will cause damage and void the warranty for this product.
1.5 Physical Description

1.5.1 Front View

1. Introduction


AirLive WN-200HD User’s Manual
4
1. Lens & Focus Ring
User could use this ring to adjust focus manually.
2. Microphone
The Camera has built-in an internal microphone. This microphone is hidden
in the pinhole located on the front panel.
3. Micro SD Card Slot
User can insert a micro SD card into this slot for event recording.
1.5.2 Bottom View
1. Audio Output Jack
Audio-out Jack allows this device to output audio or alerting sound.
2. DC Power Jack
The input power is 12VDC.
Note that supply the power to the Camera with the power adapter included in
package. Otherwise, the improper power adapter may damage the unit and
result in danger.

1. Introduction
5
AirLive WN-200HD User’s Manual
3. Antenna
User can attach the included antenna to antenna connector (SMA type) or
use another high-gain antenna to get higher performance.
4. Factory Default Reset
This button is hidden in the pinhole. This button is used to restore the all
factory default settings. Sometimes restarting the camera will make the
system back to a normal state. If the system still got problems after restart,
user can restore the factory default settings and install it again. To restore
the device, please follow the steps below:
(1) Insert the paper clip or other tool and press and hold the button down
continuously.
(2) Hold it at least 5 seconds and release the tool. Then the device has been
restored to default settings and reboot again.
Note: Restoring the factory default setting will lose the all previous settings
included IP address forever. User needs to run the IPWizard II program to
search the device and configure it to let the device work properly again.
5. LAN Socket
The LAN socket is a RJ-45 connector for connections to 10Base-T Ethernet
or 100Base-TX Fast Ethernet cabling. This Ethernet port built N-Way
protocol can detect or negotiate the transmission speed of the network
automatically. Please use Category 5 cable to connect the Network
Camera to a 100Mbps Fast Ethernet network switch or hub.
6. LAN LED (green color)
This LED will be flashing while network accessing via Ethernet.
7. Power / Wireless LED (orange color)
This LED is used to indicate whether DC power is on or not. In addition, this
LED will be flashing while the wireless accessing of the Camera.

1. Introduction


AirLive WN-200HD User’s Manual
6
1.6 Hardware Installation
1. Attach the Camera with the included stand
2. Place the Camera on the table or fix it onto ceiling or wall
Use three screws to fix the Network Camera onto the ceiling or wall. You could
also put the Network Camera on the table directly.

1. Introduction
7
AirLive WN-200HD User’s Manual
3. Plug an Ethernet cable into the Camera
Connect an Ethernet cable to the LAN socket located on the Network
Camera’s bottom and attach it to the network.
4. Connect the external power supply to Camera Connect the attached power
adapter to the DC power jack of the Network Camera.
Note: Use the power adapter, 12VDC, included in the package and connect it
to wall outlet for AC power.

2. Getting Started


AirLive WN-200HD User’s Manual
8
2 2. Getting Started

2.1 IP Wizard
Once you have installed the Network Camera well and powered it on, the
network accessing type LED will turn on. It means the system is booting up
successfully. Furthermore, if you have a proper network connection, and
access to the Network Camera, the LED will flash green under wired mode or
orange under wireless mode.
When you installed the Camera on a LAN environment, you have two easy
ways to search your Cameras by IPWizard II or UPnP™ discovery. Here is the
way to execute IPWizard II to discover Camera’s IP address and set up related
parameter in a Camera.

2. Getting Started
9
AirLive WN-200HD User’s Manual
When launch the IPWizard II, a searching window will pop up. IPWizard II is
starting to search Network Cameras on the LAN. The existed devices will be
listed as below.

2. Getting Started


AirLive WN-200HD User’s Manual
10
2.1.1 View
If IPWizard II finds network devices, View button will be available. Please
select the device you want to view and click the View button. Then you could
see the video from camera directly. Furthermore you could double click the left
button of mouse to link to the network device by browser.
2.1.2 LAN
In case you want to change the IP related parameters of wired interface,
please select the device you want to configure and click the LAN button.
Relative settings will be carried out as below.

2. Getting Started
11
AirLive WN-200HD User’s Manual
You could modify the relative settings of the selected device. Click “<<” button
will quit the LAN setting procedure and click “>>” button will move to next page
as below.

2. Getting Started


AirLive WN-200HD User’s Manual
12
In case, you do not want to change username and/or password, then just click
“Submit” button to perform your setting accordingly. Click “<<” button will go
back to previous page.
If you like to change username and/or password of the device, just click the
check button. Then, the related fields will show up as below.
After keying in new username and password, click “Submit” button to perform
your setting accordingly. Click “<<” button will go back to previous page.

2. Getting Started
13
AirLive WN-200HD User’s Manual
2.1.3 Wireless
In case you want to change the IP related parameters of wireless interface,
please select the device you want to configure and click the WIRELESS button.
Relative settings will be carried out as above.

2. Getting Started


AirLive WN-200HD User’s Manual
14
Click SSID to select your wireless AP or router and key in WEP or WPA key.
Click >> to next step:

2. Getting Started
15
AirLive WN-200HD User’s Manual
Make sure wireless setting and then submit it.
Click OK to confirm these parameters, then IPWizard II will start to configure
this camera with specified information.
