AirLive SD-3030 User manual

SD-3030
3-Megapixel 30X Optical Zoom
Speed Dome IP Camera with
Smart Tracking
User’s Manual

Copyright and Disclaimer
iAirLive SD-3030 User’s Manual
Copyright & Disclaimer
No part of this publication may be reproduced in any form or by any means, whether
electronic, mechanical, photocopying, or recording without the written consent of OvisLink
Corp.
OvisLink Corp. has made the best effort to
ensure the accuracy of the information in this user’s guide. However, we are not liable for
the inaccuracies or errors in this guide. Please use with caution. All information is
subject to change without notice
All Trademarks are properties of their respective holders.

Copyright and Disclaimer
AirLive SD-3030 User’s Manual ii
FCC Statement
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the A
user is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment. This device complies
with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. For
product available in the USA/Canada market, only channel 1~11 can be operated.
Selection of other channels is not possible.
This device and its antenna(s) must not be co-located or operation in conjunction with any
other antenna or transmitter.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.

Table of Contents
AirLive SD-3030 User’s Manual
iii
Table of Contents
1. Overview................................................................................................... 1
1.1 Introduction........................................................................................ 1
1.2 Features ............................................................................................ 2
1.3 Product Specification......................................................................... 2
1.4 System Requirement......................................................................... 6
2. Package Contents and Installation......................................................... 7
2.1 Package Content............................................................................... 7
2.2 Connections....................................................................................... 7
2.3 Mounting the Camera...................................................................... 10
2.4 Connect to IP Camera ..................................................................... 12
3. Using IP Camera via Web Browser....................................................... 15
3.1 Windows Web Browser.................................................................... 15
4. Operating IP Camera via Mobile Phone ............................................... 17
4.1 Using IP Camera via iPhone............................................................ 17
5. Configuration of Main Menu.................................................................. 20
5.1 Live View......................................................................................... 21
5.2 System ............................................................................................ 23
5.3 Streaming ........................................................................................ 23
5.4 PTZ.................................................................................................. 24
5.5 Logout ............................................................................................. 24
6. System.................................................................................................... 25
6.1 System ............................................................................................ 25
6.2 Security ........................................................................................... 27
6.3 Network ........................................................................................... 33
6.4 DDNS.............................................................................................. 40
6.5 Mail.................................................................................................. 41
6.6 FTP.................................................................................................. 41
6.7 HTTP............................................................................................... 42

Table of Contents
AirLive SD-3030 User’s Manual
iv
6.8 Application....................................................................................... 43
6.9 Motion Detection.............................................................................. 47
6.10 Network Failure Detection.............................................................. 53
6.11 Periodical Event............................................................................. 55
6.12 Manual Trigger............................................................................... 58
6.13 Audio Detection.............................................................................. 61
6.14 Smart Tracking............................................................................... 65
6.15 Storage Management .................................................................... 71
6.16 Recording...................................................................................... 76
6.17 Schedule........................................................................................ 77
6.18 File Location.................................................................................. 78
6.19 View Information............................................................................ 78
6.20 Factory Default .............................................................................. 81
6.21 Software Version............................................................................ 82
6.22 Software Upgrade.......................................................................... 83
6.23 Maintenance.................................................................................. 84
7. Streaming............................................................................................... 85
7.1 Video Format................................................................................... 85
7.2 Video Compression ......................................................................... 87
7.3 Video OCX Protocol......................................................................... 89
7.4 Video Frame Rate............................................................................ 90
7.5 Audio ............................................................................................... 91
8. PTZ.......................................................................................................... 93
8.1 Preset.............................................................................................. 93
8.2 Cruise.............................................................................................. 94
8.3 Auto Pan.......................................................................................... 95
8.4 Sequence ........................................................................................ 96
8.5 Home............................................................................................... 97
8.6 Tilt Range ........................................................................................ 98
8.7 Privacy Mask.................................................................................. 99

Table of Contents
AirLive SD-3030 User’s Manual
v
8.8 Camera-Exposure...........................................................................100
8.9 Camera-WB...................................................................................102
8.10Camera-Misc1...............................................................................104
8.11Camera-Misc2...............................................................................106
8.12Camera-Profile ..............................................................................108
8.13Camera-Default .............................................................................110
9. Appendix...............................................................................................111
A. Video Resolution..............................................................................111

1. Overview
AirLive SD-3030 User’s Manual
1
1
1.
Overview
This user’s guide explains how to operate this camera from a computer.A user should read
this manual completely and carefully before operating the device.
1.1 Introduction
The SD-3030 IP Camera is a practical and fully scalable surveillance device. Users are
able to view live video streaming over the Internet, and it is only one of the many benefits
for using SD-3030 IP Camera. It is also equipped with a PoE port which allows power and
data to be transmitted via a single Ethernet cable. This useful function provides an easier
installation, lower cabling costs and allows placement of AirLive PoE cameras in locations
without access to electrical source.
With the IP-66 waterproof housing, AirLive SD-3030 suits environments such as stairs,
main entrance, street, and basement.

1. Overview
AirLive SD-3030 User’s Manual
2
The device is accessible via the LAN or Internet connection. Connect your device directly to
a local area network or xDSLmodem, and with Microsoft® Internet Explorer you get instant,
on demand video streams. Within minutes you can set up the device to capture a video
sequence to a PC. The live video can be uploaded to a website for the world to see.
1.2 Features
This manual will illustrate the steps of how to setup and operate this IP camera, so you’ll
also soon be enjoying the benefits of these product features:
1/2.8" Sony Progressive Scan CMOS Sensor
3 Megapixel + SXGA Real-Time at Dual Streaming
Built-in Smart Tracking Function
Up to 30x Optical Zoom
Up to 30fps @ 3 Megapixel and 60fps @ 1080p Full HD
Weather-Proof IP 66 Rated Housing
Pan / Tilt Resolution of 0.225°
Motion / Audio Detection
Backlight Compensation
Quad Streams Support
3D Noise Reduction
Defog function
2-Way Audio
Wide Dynamic Range
Auto and Manual PTZ Calibration
-40°C~50°C Wide Temperature Range
Compatible with ONVIF Standard
802.3at 60W PoE+ Support for Heater Activation
Mechanical IR-Cut Filter Removable
Micro SDXC Memory Card Slot for Local Storage
Free 64-Channel Recording Software
1.3 Product Specification
Model
SD-3030
Camera
Camera Type
Speed Dome Type
Max Resolution
2048x1536
Image Sensor
1/2.8" 3Mega Sony CMOS sensor
Sensor
Resolution 2048x1536

1. Overview
AirLive SD-3030 User’s Manual
3
Lens Type
4.4 ~ 132 mm
F=1.4 ~ 4.7
Night Vision
Yes
Max IR Distance
None
Minimum
Illumination 0.04 LUX
Mechanical
IR-Cut Filter Yes
Auto Iris
Yes
Viewing Angle
Wide: 60.5
ﾟ
(H) 47.5
ﾟ
(V)
Tele: 2.5 ﾟ(H) 1.9 ﾟ(V)
Pan/Tile Control
Pan Degree 0°~360°
Tilt Degree -10°~190°
Preset Points-Up to 300 preset point
Camera Tour-Up to 8 sequence
Analog Video
Out Yes
Video
Video
Compression H.264 (HighProfile/MainProfile/Baseline) MJPEG
Video Profile
681
Resolution and
Frame Rate
30FPS @ 2048 x 1536 (4:3)
60FPS @ 1280 x 1024 (4:3)
60FPS @1024 x 768 (4:3)
60FPS @800 x 600 (4:3)
60FPS @ 640 x 480 (4:3)
60FPS @ 1920 x 1080 (16:9)
60FPS @ 1280 x 720 (16:9)
60FPS @ 720 x 480
60FPS @ 352 x 240
Streaming
Multi-profile streaming
Streaming over UDP, TCP, or HTTP
M-JPEG streaming over HTTP (for non IE browser)
Configurable frame rate and bandwidth
Support both CBR and VBR
Region of
Interest none
AE, AWB

1. Overview
AirLive SD-3030 User’s Manual
4
Processing
Text, time and date OSD
Digital Zoom
10X
Audio
Audio Encoder
G.711 / G.726
Audio Streaming
Two-way
Audio
Input/Output Speaker & microphone I/O port
Network
Ethernet
1Gbps Ethernet (RJ-45)
PoE
IEEE802.3at PoE+
Wireless
None
Supported
Protocols
IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS,
ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP,
SNMP, QoS, ONVIF, ARP
Security
Password protection
IP filter
HTTPS
Users
Up to 20 simultaneous users
LED and Button
Power LED
Amber Color
Link/Act. LED
Green Color/Flash Green
Reset Button
Reboot and Factory Default (Press the button for at
least 20 seconds to restore the system)
General
Network
Processor DSP Base
System ROM
1GB(Flash)
System RAM
2GB
Power Supply
AC24V
Power
Consumption 57 Watts Max.
Connector
1Gbps Ethernet (RJ-45)
24V AC power jack
Audio I/O
4 DI / 2 DO
BNC
Reset button
Environment
Operation: Temp: -40
℃
~ 50
℃
Humidity: 0% ~ 90% non-condensing
Storage: Temp: -40
℃
~ 50
℃
Humidity: 0% ~ 90% non-condensing

1. Overview
AirLive SD-3030 User’s Manual
5
SD card slot
Micro SDXC 64GB
Dimension
191.9 mm (D) x 282.1 mm (H)
System Integration
Software
CamPro Express 64,CamPro Professional,
CamPro VMS
Search & Installation-IP Wizard II
Event Triggers
Motion detection
Network Failure Detection
Periodical Event
Manual Trigger
Audio Detection
External input via DI interface
Motion Detection
10
Event handler
FTP file upload
E-mail alert
HTTP
PTZ
DO (digital output) alarm
UPNP
Yes
Application
Programming
Interface
Open API for software integration
SDK
Video Buffer
Pre- and post- alarm buffering
Alarm Triggers
Intelligent video motion detection, audio detection
and external input
Alarm Events
File upload via FTP, email, SD card
Notification via email, HTTP, and TCP
External output activation
Continuous
Recording Yes
Viewing System
OS
Windows VISTA / Windows XP / Windows 7/
Windows 8
Browser
Internet Explorer (8.0+) / Chrome / Firefox / Safari
Cell Phone
CamPro Mobile
Video Player
VLC, Quick Time, Real Player, Core Player

1. Overview
AirLive SD-3030 User’s Manual
6
1.4 System Requirement
For normal operation and viewing of the network camera, it’s recommended that your
system meets these minimum requirements for proper operation:
Item
Requirements
CPU
Pentium-4 3.0 GHz or higher/Core2 Duo, 2GHz or higher
VGA Monitor
Resolution1280 x 1024 or higher
RAM
Minimum 1 GB of RAM, (2GB or above is recommended)
Operating
System Window XP, Vista or Windows 7
Web Browser
Internet Explorer 8 or later; Apple Safari; Firefox; Google
Chrome
Note: Please keep updating the latest Windows software and service package.
(Ex: Net Framework, Windows Media Player, Enhance ActiveX Security)

2. Package Contents and Installation
AirLive SD-3030 User’s Manual
7
2.1 Package Content
A user can find the following items in the package as below:
1. AirLive SD-3030 is the main element of the product.
2. Bundle CD includes Setup Wizard II, CamPro Express64, Quick Start Guide, User
Manual, and Video.
3. Quick Start Guide provides important information and instructions for installing this
device.
4. Accessory Package
2.2 Connections
Power Source Requirement
This camera can work with 802.3at PoE+ switch. However, if you need to operate this
camera below 8 degree Celsius, please purchase the optional power adapter for the heater
to work.
Switch/Connector
There are various connectors located on AirLive SD-3030’s back plate as shown in the
figures below.
Please refer to the diagrams and tables accompanied with for using of each switch /
connector.
2
2.
Package Contents and
Installation

2. Package Contents and Installation
AirLive SD-3030 User’s Manual
8
1. Alarm I/O:
AirLive SD-3030 supports 4 digital alarm inputs and 2 digital alarm outputs. Please
make sure the alarm connections are properly wired before starting to configure alarm
related settings in section “SystemApplication (Alarm Settings).”
Please refer to the pin definition table below for alarm system wiring.
2. Reset Button: This button is used to restore all the factory default settings. Sometimes,
restarting the device will make the system back to a normal state.
3. BNC:
AirLive SD-3030 supports BNC connector for Analog video output.
\
Pin
Connector
Definition
1
Alarm I/O
Alarm I/O connection
2
Default Button
Press the button for at least 20 seconds to restore the system.
3
BNC
For analog video output
4
RJ-45
For network and PoE+ connections
5
Power
Power connection
6
Audio I/O
Audio I/O connection
7 MicroSD Card Slot
Insert the microSD card into the card slot to store videos and
snapshots. Do not remove the microSD card when the camera
is powered on.

2. Package Contents and Installation
AirLive SD-3030 User’s Manual
9
4. RJ45 LAN socket: Connect to PC or Hub/Switch.
This Ethernet port has built N-Way protocol which can detect or negotiate the
transmission speed of the network automatically. For connections up to 1Gbps Fast
Ethernet.
In the LAN socket, there are two LEDs embedded:
LAN LED (green color)
Green Link Light indicates good network connection.
Power (orange color)
This LED is used to indicate whether DC power is on or not.
5. AC-in Jack: The input power is 24VAC.
Please refer to the illustration below on how to connect the power connector through the
supplied power adaptor.
Note: Supply the power to the Network Camera with the power adapter, which is Not
included in package.
6. Audio I/O Connectors
Please refer to the illustrations below to set up the audio according to the audio pin
definition.
7. Micro SD Card Slot: Micro SD Card Slot allows you to insert a memory card for
expansion of storage.
Pin
Definition
1
AC 24V 1
2
GND
3
AC 24V 2
Pin
Definition
1
Audio Out
2
GND
3
Audio In

2. Package Contents and Installation
AirLive SD-3030 User’s Manual
10
2.3 Mounting the Camera
1. Attaching the Standard Mount Kit - AirLive ACC-WMK-SD20 (Optional)
Fix the camera with bundle wall mount kit as below.
Wall Mounting:
Follow the steps below to mount AirLive SD-3030 with the Standard Wall Mount.
Make a cable entry hole on the wall to recess the cables. Otherwise, users
could push up the cable entry board on the Standard Wall Mount’s mounting plate
to place the cables.
Fix the Standard Wall Mount on the wall with proper screws and screw anchors.
Attach the Waterproof Rubber to the Standard Wall Mount.
Run the cable(s) through the Standard Wall Mount.

2. Package Contents and Installation
AirLive SD-3030 User’s Manual
11
NOTE: Please block the cable entry hole with the supplied sponge to avoid
insects entering the Wall Mount.
Thread the cable(s) through the Mounting Kit and join the Mounting Kit to the
Standard Wall Mount with the supplied screws and washers. Then, adjust the
Waterproof Rubber to the joint.
Connect the cable(s) to AirLive SD-3030.
Join AirLive SD-3030 to the Mounting Kit with the supplied screw and washers.
2. Connecting to LAN (“4”)
You can use the provided Ethernet cable to connect the camera to your local area
network (LAN). When you connect the PoE switch, the camera is powered on
automatically. You can verify the power status from the Power LED on the Ethernet
port. Once connected, the Link LED starts flashing green light and the camera is on
standby and ready for use now.

2. Package Contents and Installation
AirLive SD-3030 User’s Manual
12
3. Connect the external power supply to Camera (Optional)
Connect the power adapter to theAC power jack of the camera.
Once you have installed the camera well and powered it on, the power LED (orange)
will turn on later. When the power LED is turned on, it means that the system is booting
up successfully. Furthermore, when you have a proper network connection and access
to the camera, the LAN LED (green) will flash.
Note: Use the 24VAC power adapter, which is Not included in the package, and
connect it to wall outlet for AC power.
2.4 Connect to IP Camera
1. Insert the bundle CD into your PC/Laptop.
2. Auto Run Screen then shows up; click “Install Software “IPWizard II” to install the
configuration tool software.

2. Package Contents and Installation
AirLive SD-3030 User’s Manual
13
3. After completing installation, run the configuration tool software.

2. Package Contents and Installation
AirLive SD-3030 User’s Manual
14
4. The Software scans the network and finds the IP Camera and then lists them in the
dialog box.
5. If the Camera’s IP address is in the same IP segment as your LAN, select the detected IP
Camera and double click on the item. Then, the default browser will show up and connect
to the IP camera’s Web interface automatically.
