AirLive BU-2015 User manual

Use
r
’s Manual
2-Megapixel Outdoor
IR NightVision
Bullet IP Camera
BU-2015

Copyright and Disclaimer
i AirLive BU-2015 User’s Manual
Copyright & Disclaimer
No part of this publication may be reproduced in any form or by any means, whether
electronic, mechanical, photocopying, or recording without the written consent of OvisLink
Corp.
OvisLink Corp. has made the best effort to ensure the accuracy of the information in this
user’s guide. However, we are not liable for the inaccuracies or errors in this guide.
Please use with caution. All information is subject to change without notice
This product contains some codes from GPL. In compliance with GPL agreement, AirLive
will publish the GPL codes on our website. Please go to www.airlive.com and go to the
"Support->GPL" menu to download source code.
All Trademarks are properties of their respective holders.

Copyright and Disclaimer
AirLive BU-2015 User’s Manual ii
FCC Statement
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the A
user is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment. This device complies
with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. For
product available in the USA/Canada market, only channel 1~11 can be operated.
Selection of other channels is not possible.
This device and its antenna(s) must not be co-located or operation in conjunction with any
other antenna or transmitter.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
WEEE Marking Warning:
The crossed out wheeled bin indicates the product must not be disposed together with
household waste. For the sake of the environment, the product should only be given to
entities involved in the reception of waste electronic and electrical equipment. The lists of
entities entitled to receive used equipment can be found on the websites of municipalities.
Some components of devices such as external wiring, circuit boards and liquid crystal
displays have a negative impact on the environment.

Table of Contents
AirLive BU-2015 User’s Manual
iii
Table of Contents
1. Overview .....................................................................................................1
1.1 Introduction ..........................................................................................1
1.2 Features...............................................................................................2
1.3 Product Specification ...........................................................................2
1.4 System Requirement ...........................................................................4
2. Package Contents and Installation...........................................................5
2.1 Package Content .................................................................................5
2.2 Connections.........................................................................................5
2.3 Install the Camera................................................................................7
2.4 Connect to IP Camera .........................................................................8
3. Using IP Camera via Web Browser.........................................................10
3.1 Windows Web Browser......................................................................10
4. Operating IP Camera via Mobile Phone .................................................11
4.1 Using IP Camera via iPhone..............................................................11
5. Operating the Network Camera ..............................................................14
5.1 Live View............................................................................................15
5.2 Configuration .....................................................................................16
6. Configuration ...........................................................................................17
6.1 System...............................................................................................17
6.2 Security..............................................................................................19
6.3 Network..............................................................................................20
6.4 IP Filter...............................................................................................23
6.5 Video..................................................................................................25
6.6 Motion ................................................................................................29

Table of Contents
AirLive BU-2015 User’s Manual iv
6.7 Event..................................................................................................31
6.8 Recording ..........................................................................................36
6.9 SDHC.................................................................................................37
6.10 Log...................................................................................................39
6.11 Device info .......................................................................................40
6.12 Maintenance ....................................................................................40

1. Overview
AirLive BU-2015 User’s Manual
1
1 1. Overview
This user’s manual explains how to operate this camera from a computer. Users should
read this manual completely and carefully before operate the device.
1.1 Introduction
AirLive BU-2015 is a high-level 2-Megapixel network camera which is designed for
professional outdoor surveillance and security applications. The built-in IR LEDs provides
high quality of night time monitoring with 15M viewing distance in darkness. Users are able
to view live video streaming over the Internet and also equipped with PoE function which
allows power and data to be transmitted via single Ethernet cable. This useful function
provides an easier installation, lower cabling costs and allows placement of AirLive PoE
cameras in locations without access to electrical source.
With the IP66 rated housing, AirLive BU-2015 offered water and dust proof features for
demanding environments. Also it can be easily installed and integrated into kinds of
surveillance project.

1. Overview
AirLive BU-2015 User’s Manual 2
1.2 Features
This manual will illustrate the steps of how to setup and operate this IP camera, so you’ll
soon be enjoying the benefits of these product features:
z2-Megapixel 1/2.5” CMOS Sensor
zUp to 30fps at 1920x1080 resolution
zSupport H.264/MPEG4/MJPEG multi-streaming
zMechanical IR-Cut Filter Removable
z22 units IR LED for 15M distance
zPower over Ethernet (IEEE802.3af)
zCompatible with ONVIF Standard
z4mm High Quality Lens
zSupport Samba Server Function for Local Storage
zSupport Motion Detection and Email notification
zMicroSD Card Support
zIP66 Weatherproof Housing
zFree Boundled 64-Channel Recording Software
1.3 Product Specification
Model BU-2015
Camera Type Outdoor IR Bullet Type
Image Sensor 1/2.5" CMOS Sensor
Max. Resolution 1920 X 1080
Lens Type 4mm/F1.8, Board Lens
Night Vision Yes
IR Distance (Max.) 15M
Minimum Illumination Color: 0.05 Lux
B/W: 0 Lux (IR On)
Mechanical IR-Cut Filter Yes
Auto Iris None
Viewing Angle D111.5°, H83.7°, V60.6°
Camera
Analog Video Out None
Video Compression H.264 High/Main/Baseline Profile, MPEG4
Simple Profile, MJPEG and 3GPP
30fps@1920x1080
30fps@1280x960
Video
Resolution and Frame
Rate
30fps@1280x720

1. Overview
AirLive BU-2015 User’s Manual
3
30fps@720x480
30fps@640x480
30fps@320x240
Multi-profile streaming
Streaming over UDP, TCP, or HTTP
3GPP mobile view
Configurable frame rate and bandwidth
Streaming
Support CBR and VBR
AE, AWB
Noise reduction
Brightness, Sharpness, Contrast,
Saturation
Mirror Vertical / Horizontal
Image Processing
Text, time and date OSD
Digital Zoom Yes
Shutter Time Auto, Manual: 1/15~1/10000sec,
Day/night dual programmable
Ethernet
One RJ45 Port; IEEE 802.3u Compliant
10/100 Mbps Fast Ethernet with
Auto-MDIX
PoE IEEE802.3af/at
Supported Protocols
TCP/IP, UDP, ICMP, DHCP, NTP, DNS,
DDNS, SMTP, FTP, HTTP, HTTPs,
Samba, PPPoE, UPnP, Bonjour, RTP,
RTSP and RTCP
Password protection
IP filter
Network
Security
HTTPS
Power LED Amber Color
LED Indicator Link/Act. LED Green Color
Network Processor DSP Base
Power Supply DC5V/2A (Optional)
Power Consumption 8 Watts Max.
RJ-45 10BaseT/100BaseTX
5V DC power jack
Connector
Reset Button
Operation Temp: -20℃~ 50℃
Humidity: 20% ~ 85% non-condensing
Environment Storage Temp: -20℃~ 60℃
Humidity: 0% ~ 90% non-condensing
Weather Proof IP66
General
SD card slot 32G MicroSD/SDHC

1. Overview
AirLive BU-2015 User’s Manual 4
Dimension φ73mm x 112mm
CamPro Express 64, CamPro
ProfessionalSoftware
Search & Installation- IP Wizard II
Event Triggers Motion detection
Motion Detection Up to 3 zones
FTP or NAS file upload
Event handler E-mail alter
UPNP Yes
ONVIF
Open API for software integration
Application Programming
Interface SDK
Video Buffer 5 sec. pre-alarm / 5 sec. post-alarm, up to
3MB
File upload via FTP, NAS, E-mail
Notification via email
Alarm Events
Save to SD card
Continuous Recording Yes
System Integration
Certificate CE, FCC-Class A
OS Windows® XP, Vista, 7
Browser IE 6.0 or later, Firefox 2.0 or later, Safari
Cell Phone With 3GPP player
Viewing System
Video Player VLC, Quick Time, Real Player, Core
Player
1.4 System Requirement
For normal operation and viewing of the network camera, it’s recommended that your
system meets these minimum requirements for proper operation:
Item Requirements
CPU Pentium-4 3.6 GHz or higher
VGA Monitor Resolution1280 x 1024 or higher
RAM Minimum 1 GB of RAM
Operating System Window XP, Vista or Windows 7
Web Browser Internet Explorer 7 or later; Apple Safari; Firefox; Google Chrome
Cell Phone 3GPP Player
Note: Please keep updating the latest Windows software and service package.
(Ex: Net Framework, Windows Media Player, Enhance ActiveX Security)

2. Package Contents and Installation
AirLive BU-2015 User’s Manual
5
2 2. Package Contents and
Installation
2.1 Package Content
User can find the following items in the package as below:
1. AirLive BU-2015 is the main element of the product.
2. Bundle CD includes IP Wizard II, CamPro Express64, Quick Start Guide, User Manual,
and Video clips.
3. Quick Start Guide provides important information and instructions for installing this
device.
4. Accessory Package including sunshield, bracket and screws.
Note: The power adapter is optional.
2.2 Connections
Power Source Requirement
This camera can work with 802.3af/at POE switch without the power adapter. However, if
you don’t have POE switch, you can use power adapter to provide power to camera.
Switch/Connector
There are various connectors of AirLive BU-2015 as shown in the figures below.
Please refer to the diagrams and tables accompanied with for using of each switch /
connector.

2. Package Contents and Installation
AirLive BU-2015 User’s Manual 6
1. RJ45 LAN socket: Connect to Hub / Switch / PoE Switch / PC.
This Ethernet port built N-Way protocol can detect or negotiate the transmission speed
of the network automatically. Please use Category 5 cable to connect the Network
Camera to a 100Mbps Fast Ethernet network switch or hub.
In the LAN socket, there are two LEDs embedded:
LAN LED (Green color)
Green Link Light indicates the network accessing.
Power (Amber color)
This LED is used to indicate whether DC power/PoE power is on or not.
2. DC-in: The input power is DC5V/2A.

2. Package Contents and Installation
AirLive BU-2015 User’s Manual
7
2.3 Install the Camera
Install the camera in LAN/WAN:
1. Plug an Ethernet cable into the camera
Connect an Ethernet cable to the LAN socket and attach it into the network.
2. Connect the external power supply to camera by power adapter or PoE switch.
3. Remove the front cover to adjust the focus and insert the MicroSD card if necessary.
4. Find the screws in the package to fix the sun shield on top.

2. Package Contents and Installation
AirLive BU-2015 User’s Manual 8
2.4 Connect to IP Camera
1. Insert the bundled CD into your PC/Laptop.
2. Auto Run screen pops up, click “Install Software ÆAirLive IP Wizard II” to install the
configuration tool.

2. Package Contents and Installation
AirLive BU-2015 User’s Manual
9
3. After completing installation, run the “Air Live IP Wizard II” to start to search the IP
camera.
4. The entire detected IP camera will be listed out.
5. If the Camera’s IP address is in the same IP segment as your LAN, select the founded IP
Camera and double click on the item. Then, the default browser will show up and connect
to the IP camera’s Web automatically.

3. Using IP Camera via Web Browser
AirLive BU-2015 User’s Manual 10
3 3. Using IP Camera via
Web Browser
3.1 Windows Web Browser
1. Open your web browser and enter the IP address or host name of the IP camera in the
Location / Address field of your browser.
2. Use the default account “admin” and default password “airlive”.
Note: The default user name “admin” and the password “airlive” are the default values.
You can change them in the Security Menu. (Please check “Configuration →Security”)

4. Operating IP Camera via Mobile Phone
AirLive BU-2015 User’s Manual
11
4.1 Using IP Camera via iPhone
You can access to your IP camera via your iPhone. Please follow the setting process below.
Then you can see the live view via iPhone.
4 4. Operating IP Camera
via Mobile Phone
2. Execute AirLive CamPro Mobile
1. Download AirLive CamPro
Mobile from APP store
3. Click Setup button. 4. Setup page appears

4. Operating IP Camera via Mobile Phone
AirLive BU-2015 User’s Manual 12
5. Click Add button.
6.Click LAN button and select the camera.

4. Operating IP Camera via Mobile Phone
AirLive BU-2015 User’s Manual
13
8. Key-in Username and Password
then click OK button.
7. Model, Address, HTTP Port info
appear on the page.
10. The video appears on the main screen.
9. Click Live View button.
Note: The image is continuous snapshots, not video. Thus, live image can’t be
recorded here.

5. Operating the Network Camera
AirLive BU-2015 User’s Manual 14
5 5. Operating the
Network Camera
Start-up screen will be shown as follow no matter an ordinary users or an administrator.
In the left side, you can control Live View in your main Browser. Please refer to the
description below:

5. Operating the Network Camera
AirLive BU-2015 User’s Manual
15
5.1 Live View
1. Language
BU-2015 support multi-language, please choose from the pull-down list.
2. Stream
The device supports multi-profile function for H.264, MEPG4 and JPEG simultaneously.
User can choose the proper and/or preferred profile which is listed here.
3. Protocol
A user can select proper streaming protocol according to network environment.
4. Original size / Preview Size
Switches live image view between original size (Depends on main stream setting) and
preview size (smaller size).
5. Digital Zoom
You can see larger objects in video.
Please note: that digital zoom uses computer algorithm to enlarge the video and may
lose some details.
6. Snapshot
Take a snapshot and save images into your computer.
7. Record
Press Record button to start recording. The video file is saved as ASF format into
your local PC. While you want to stop it, press Stop to stop recording.
8. Recording Location
Select the path to save the recording file.
