Airo A Series User manual

PIATTAFORME AEREE SEMOVENTI
SELF-PROPELLED WORK-PLATFORMS
PLATES-FORMES DE TRAVAIL AUTOMOTRICES
SELBSTFAHRENDE HUBARBEITSBÜHNEN
PLATAFORMAS ELEVADORAS AUTOPROPULSADAS
ZELFRIJDENDE HOOGWERKERS
SJÄLVGÅENDE ARBETSPLATTFORMAR
SAMOKRETNE RADNE PLATFORME
"A" SERIES
A12 JRTD A15 JRTD
USE AND MAINTENANCE MANUAL
- ENGLISH - ORIGINAL INSTRUCTIONS
AIRO is a division of TIGIEFFE SRL
Via Villa superiore, 82 - 42045 Luzzara (RE) ITALY-
[phone] -[phone]
WEB: www.airo.com
057.20.UEM-EN
2020 - 12

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 3
Revision date
Description of revision
2010-01
•Manual issue.
2010-11
•Biodegradable oil instructions introduced.
•Temperatures and oil list updated.
2010-12
•Instructions for emergency towing with optional pump introduced.
2011-05
•Amended information on “Commissioning and first inspection, subsequent inspections
and title transfer report”.
•Added “Total quantity of battery electrolyte” in Technical Data.
•Corrected "Max. power" diesel engine and inserted "Adjusted Power".
2013-10
•Specified instructions for harness anchoring points.
2014-09
•Inserted information on maximum limits of manual forces.
•Changed Name and Surname of CEO.
2015-01
•CE Conformity Declaration Updated.
•Added position of hands instruction.
2015-10
•Type of usable hydraulic oil updated.
•Added indication for spare parts. They must be original or approved by the
manufacturer of the machine in any way.
•Added "Leaving at height”.
2015-11
•Tilt alarm operation description updated.
2018-05
•Data sheets were added with units of measurement of the international system and US
unit of measurement.
•Changed Name and Surname of CEO.
•Unified First and Second Part.
2019-07
•Updated procedure description of commissioning declaration in Italy.
2020-01
•Added "OPTIONAL control system for TIER4F/STAGE5 engines".
•Updated normative references and certifying body.
2020-12
•Corrected the technical data converted to the US measuring system.
•Updated paragraph 5.6 "Manual emergency controls": inserted emergency control
procedure with the new hydraulic block.
•Added paragraph 7.2.4.3: Maintenance of the discharge filter.
•Updated paragraphs 7.2.6.1 and 7.2.6.2 with pictures of the new hydraulic blocks.
•Updated information on engine oil, hydraulic oils and lubricating greases.
•Hydraulic scheme updated due to installation of new hydraulic blocks.
•Updated wiring diagram for Trackunit preparation.
•Updated facsimiles of EC declarations of conformity: monolingual text.

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 4
Tigieffe thanks you for purchasing a product of its range, and invites you to read this manual. Here you can find all the
necessary information for a correct use of the purchased machine; therefore, you are advised to follow the instructions
carefully and to read the manual thoroughly. The manual should be kept in a suitable place where no damage can occur to
it. The content of this manual may be modified without prior notice and further obligations in order to add changes and
improvements to the units already delivered. No reproduction or translation may take place without the written permission of
the owner.
Contents:
1. INTRODUCTION................................................................................................................................7
1.1. Legal aspects..................................................................................................................................................7
1.1.1. Delivery of the machine .................................................................................................................................... 7
1.1.2. Declaration of commissioning, first check, further periodical checks and transfers of ownership..................... 7
1.1.2.1. Declaration of commissioning and first check................................................................................................... 7
1.1.2.2. Further periodical checks.................................................................................................................................. 8
1.1.2.3. Transfers of ownership. .................................................................................................................................... 8
1.1.3. Operator training and information ..................................................................................................................... 8
1.2. Tests performed before delivery ...................................................................................................................8
1.3. Intended use.................................................................................................................................................... 8
1.3.1. Leaving at height............................................................................................................................................... 9
1.4. Description of the machine............................................................................................................................9
1.5. Control panels............................................................................................................................................... 10
1.6. Power supply.................................................................................................................................................10
1.7. Machine life, demolition and decommissioning ........................................................................................10
1.8. Identification..................................................................................................................................................11
1.9. Location of main components..................................................................................................................... 12
2. TECHNICAL FEATURES OF STANDARD MACHINES..................................................................13
2.1. Model A12 JRTD............................................................................................................................................13
2.2. Model A15 JRTD............................................................................................................................................16
2.3. Vibrations and noise.....................................................................................................................................19
3. SAFETY PRECAUTIONS ................................................................................................................20
3.1. Personal protective equipment (PPE).........................................................................................................20
3.2. General safety norms...................................................................................................................................20
3.3. Use instructions............................................................................................................................................ 21
3.3.1. General ........................................................................................................................................................... 21
3.3.2. Handling.......................................................................................................................................................... 21
3.3.3. Operating procedures ..................................................................................................................................... 22
3.3.4. Wind speed according to Beaufort scale......................................................................................................... 23
3.3.5. Pressure of the machine on ground and load-bearing capacity of ground...................................................... 24
3.3.6. High-voltage power lines................................................................................................................................. 25
3.4. Dangerous situations and/or accidents......................................................................................................25
4. INSTALLATION AND PRELIMINARY CHECKS.............................................................................26
4.1. Becoming acquainted with the machine.....................................................................................................26
4.2. Preliminary operation checks......................................................................................................................26
5. USE INSTRUCTIONS ......................................................................................................................27
5.1. Platform control panel.................................................................................................................................. 27
5.1.1. Drive and steering........................................................................................................................................... 29
5.1.2. Platform positioning movements..................................................................................................................... 30
5.1.2.1. Pantograph (lower boom) lifting/lowering........................................................................................................ 30
5.1.2.2. Upper boom lifting/lowering ............................................................................................................................ 30
5.1.2.3. Jib lifting/lowering............................................................................................................................................ 30
5.1.2.4. Telescopic boom extension/retraction ............................................................................................................ 30
5.1.2.5. QUICK UP/QUICK DOWN (optional).............................................................................................................. 31
5.1.2.6. Turret orientation (rotation) ............................................................................................................................. 31
5.1.2.7. Jib rotation (optional) ...................................................................................................................................... 31
5.1.2.8. Platform rotation.............................................................................................................................................. 31
5.1.2.9. Platform levelling............................................................................................................................................. 31

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 5
5.1.3. Other functions of the platform control panel...................................................................................................32
5.1.3.1. Manual horn ....................................................................................................................................................32
5.1.3.2. Emergency stop ..............................................................................................................................................32
5.1.3.3. Warning lights..................................................................................................................................................32
5.1.3.3.1. Enabled control panel green warning light (ZA) ..............................................................................................32
5.1.3.3.2. Flat battery red warning light (ZB) –(Only active on electric models) .............................................................32
5.1.3.3.3. Diesel engine fault / low fuel red warning light (ZC) ........................................................................................33
5.1.3.3.4. Danger red warning light (ZD).........................................................................................................................33
5.1.3.3.5. Overload red warning light (ZE) ......................................................................................................................33
5.2. Ground control panel and electric control unit..........................................................................................34
5.2.1. Ground control panel and electrical control unit OPTIONAL for TIER 4 FINAL and STAGE 5 engines..........35
5.2.2. On-off key and control panel selector (A)........................................................................................................36
5.2.3. Emergency stop button (B)..............................................................................................................................36
5.2.4. Diesel heat engine start button (C)..................................................................................................................36
5.2.5. User interface display (D)................................................................................................................................37
5.2.6. MURPHY display and DPF regeneration ........................................................................................................37
5.2.7. Powered-on machine warning light (E)............................................................................................................40
5.2.8. Diesel engine warning lights (G, H, L, M)........................................................................................................40
5.2.9. Levers of movement of the platform (N, O, P, Q, R, S, T, U) ..........................................................................40
5.3. Platform access.............................................................................................................................................41
5.4. Machine start-up............................................................................................................................................41
5.4.1. Diesel engine start-up .....................................................................................................................................42
5.5. Machine stop .................................................................................................................................................42
5.5.1. Normal stop.....................................................................................................................................................42
5.5.2. Emergency stop ..............................................................................................................................................42
5.5.3. Diesel engine stop...........................................................................................................................................43
5.6. Emergency manual controls ........................................................................................................................44
5.6.1. Hydraulic block of type A.................................................................................................................................44
5.6.2. Hydraulic block of type B.................................................................................................................................45
5.7. Socket for electric tool connection (Optional)............................................................................................46
5.8. Fuel level and re-fuelling (models “ED”, “D”).............................................................................................47
5.9. End of work....................................................................................................................................................47
6. HANDLING AND CARRYING..........................................................................................................48
6.1. Handling.........................................................................................................................................................48
6.2. Transportation...............................................................................................................................................49
6.3. Emergency towing of the machine..............................................................................................................50
6.3.1. Machine emergency towing (standard) ...........................................................................................................50
6.3.2. Machine emergency towing (optional).............................................................................................................51
7. MAINTENANCE...............................................................................................................................52
7.1. Machine cleaning ..........................................................................................................................................52
7.2. General maintenance....................................................................................................................................53
7.2.1. Various adjustments........................................................................................................................................54
7.2.2. Greasing..........................................................................................................................................................55
7.2.3. Hydraulic circuit oil level check and change....................................................................................................56
7.2.3.1 Biodegradable hydraulic oil (Optional) ............................................................................................................57
7.2.3.2 Emptying .........................................................................................................................................................57
7.2.3.3 Filters ..............................................................................................................................................................57
7.2.3.4 Washing ..........................................................................................................................................................57
7.2.3.5 Filling...............................................................................................................................................................57
7.2.3.6 Commissioning / check ...................................................................................................................................57
7.2.3.7 Mix...................................................................................................................................................................58
7.2.3.8 Micro-filtration..................................................................................................................................................58
7.2.3.9 Disposal ..........................................................................................................................................................58
7.2.3.10 Topping up ......................................................................................................................................................58
7.2.4. Hydraulic filter replacement.............................................................................................................................59
7.2.4.1. Suction filter ....................................................................................................................................................59
7.2.4.2. Return filter......................................................................................................................................................59
7.2.4.3. Discharge filter ................................................................................................................................................60

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 6
7.2.5. Telescopic boom sliding blocks clearance adjustment ................................................................................... 60
7.2.6. Circuit movements pressure relief valve operation check............................................................................... 61
7.2.6.1 Pressure relief valve of proportional movement circuit ................................................................................... 61
7.2.6.2. Pressure relief valve of ON-OFF movement circuit......................................................................................... 62
7.2.7. Operation check of the turret inclinometer ...................................................................................................... 63
7.2.8. Adjustment of the overload controller (load cell)............................................................................................. 65
7.2.9. Overload controller by-pass –ONLY FOR EMERGENCY OPERATIONS ..................................................... 66
7.2.10. Operation check of M1 microswitches ............................................................................................................ 67
7.2.11. Operation check of dead-man pedal safety system........................................................................................ 68
7.3. Starter battery ...............................................................................................................................................69
7.3.1 Battery maintenance....................................................................................................................................... 69
7.3.2 Starter battery recharge.................................................................................................................................. 69
7.3.3 Battery replacement........................................................................................................................................ 69
8. MARKS AND CERTIFICATIONS.....................................................................................................70
9. PLATES AND STICKERS................................................................................................................71
10. CHECK REGISTER .........................................................................................................................73
11. ELECTRIC DIAGRAMS ...................................................................................................................88
12. HYDRAULIC DIAGRAM ..................................................................................................................97
13. DECLARATION OF CONFORMITY EC FACSIMILE ......................................................................99

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 7
1. INTRODUCTION
This Use and Maintenance Manual provides general instructions concerning the complete range of machines indicated on
the cover. Therefore, the description of their components, as well as control and safety systems, may include parts not
present on Your machine since supplied on request or not available. In order to keep pace with the technical development
AIRO-Tigieffe s.r.l. reserves the right to modify the product and/or the use and maintenance manual at any time without
updating the units already delivered.
1.1. Legal aspects
1.1.1. Delivery of the machine
Within EU (European Union) member countries the machine is delivered complete with:
▪Use and Maintenance manual in your language.
▪CE mark applied on the machine.
▪CE conformity declaration.
▪Guarantee certificate.
▪Declaration of internal testing.
Only for Italy:
▪Instructions on commissioning declaration with INAIL and on the application for the first periodic check on the INAIL
portal.
It is to be noted that the Use and Maintenance Manual is an integral part of the machine and a copy of this, together with
copies of the documents certifying that the periodical checks have been carried out, must be kept on board in its suitable
container. In the event of a transfer of ownership the machine must always be provided with its use and maintenance
manual.
1.1.2. Declaration of commissioning, first check, further periodical checks and transfers of
ownership
The legal obligations of the owner of the machine vary according to the country of commissioning. It is therefore
recommended to inquiry about the procedures in force in your country from the boards responsible for industrial safety. This
manual contains a final section called "Check register" for a better filing of documents and recording of any modifications.
1.1.2.1. Declaration of commissioning and first check
In ITALY the owner of the Aerial Platform must notify the use of the machine to the local competent INAIL and submit it to
periodical compulsory checks. The first of such checks is performed by the INAIL within sixty days from a request being
made. In the event of such time passing without the inspection being made, the employer can call in the ASL (Local Health
Unit) or qualified public or private services. Subsequent checks are made by the already-mentioned parties within thirty
days from a request being made. In the event of such time passing without these checks being made, the employer can call
in qualified public or private services. The checks are on a payment basis and the employer (machine owner) will be
charged for them. For these checks, the territorial inspection boards (ASL/USL or ARPA) and INAIL can be supported by
qualified public or private services. The qualified private institutes acquire the qualification of responsible for the public
service and refer directly to the public structure that controls this function.
For the commissioning declaration in Italy it is necessary to login to the INAIL portal. Follow the instructions delivered
together with other documents during the machine delivery, as well as the information about the portal.
The INAIL will assign a serial number and when the First Check is performed the “technical identification sheet” will be
completed indicating only the details obtained from the already-operating machine or from the instruction manual. Such
document shall form an integral part of the machine documentation.

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 8
1.1.2.2. Further periodical checks
Yearly checks are compulsory. In Italy it is necessary that the owner of the Aerial Platform must apply for a periodical check
by sending a registered letter to the local competent inspection board (ASL/USL or ARPA or other qualified public or private
services) at least twenty days before the expiry of the year from the last check.
NB: If a machine without a valid control document should be moved in an area outside the competence of the usual
inspection board, the owner of the machine must ask the inspection board, competent for the new territory where the
machine is to be used, for the annual check.
1.1.2.3. Transfers of ownership.
In case of transfer of ownership (in Italy) the new owner of the Aerial Platform must notify the ownership of the machine to
the local competent inspection board (ASL/USL or ARPA or other qualified public or private services) by enclosing a copy of:
▪Declaration of conformity issued by the manufacturer.
▪Declaration of commissioning carried out by the first owner.
1.1.3. Operator training and information
The employer must ensure that the workers appointed to use the equipment are adequately and specifically trained so they
are able to use the Elevating Work Platform in a proper and safe way and also avoid the risks caused by other people.
1.2. Tests performed before delivery
Before being placed on the market, each MEWP undergoes the following tests:
▪Braking test.
▪Overload test.
▪Operating test.
1.3. Intended use
The machine described in this use and maintenance manual is a self-propelled aerial platform intended for lifting persons
and materials (equipment and work materials) in order to carry out maintenance, installation, cleaning, painting, de-painting,
sand-blasting, welding operations, etc.
The max. capacity allowed (which varies according to the model –see paragraph “Technical features”) is divided as follows:
▪80 Kg for each person on board.
▪40 Kg for equipment.
▪The remaining load is represented by the material being worked.
In any case NEVER exceed the maximum capacity allowed as indicated in paragraph "Technical features”. Persons, tools
and work materials can be loaded on the platform only from the access position (platform lowered). It is absolutely forbidden
to load persons, tools and work materials on the platform when it is not in access position.
All loads must be positioned inside the cage; do not lift loads (even if complying with the maximum capacity allowed)
hanging from the platform or from the lifting structure.
Do not carry large-sized panels since they increase the resistance to wind force thus causing the machine to overturn.
While the machine is being displaced with lifted platform, no horizontal loads can be loaded onto the platform (operators on
board are not allowed to pull wires or ropes, etc.).
An overload controller stops the operation of the machine if the load on the platform exceeds by 20% approx. the nominal
load (see chapter "General use rules”) and platform is lifted.
The machine cannot be used in areas where road vehicles operate. Always surround the working area by means of suitable
signs when the machine is used in public areas.
Do not use the machine to tow trucks or other vehicles.

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 9
All types of machine use other than those for which it was designed must be approved in writing by the machine
manufacturer following a specific request on the part of the user.
Do not use the machine for purposes other than those for which it was designed, except after making
a request and having obtained written permission in this sense from the manufacturer
1.3.1. Leaving at height
The mobile elevating work platforms are not designed by taking into account the risks of the “leaving at height” because the
only access position considered is when the platform is completely lowered. For this reason, this activity is formally
forbidden.
However, there are exceptional conditions in which the operator needs to access or leave the work platform not in the
access position. This activity is normally defined as “leaving at height”.
The risks connected to the “leaving at height” do not depend exclusively on the MEWP (mobile elevating work platform)
characteristics; a specific risk analysis carried out by the employer can authorize this specific use by taking into account:
▪The working environment characteristics.
▪The absolute prohibition to consider the work platform as a fixing point for people working outdoors.
▪The use of the machine at xx% of its performances to avoid that additional forces created by a specific operation or
bending of the structure move away the access zone from the unloading zone. Provide for some tests in order to
define these limitations.
▪Provide for a specific evacuation procedure in case of emergency (for example: an operator always on the work
platform, one at the ground control panel while a third operator leaves the lifted platform).
▪Provide for a specific training of the staff both as operator and transported staff.
▪Equip the unloading zone with all the devices that are necessary to avoid the risk of fall of the staff that
accesses/leaves the platform.
What said above is not a formal authorization of the manufacturer for the “leaving at height”, but it wants to supply
information to the employer - who is fully responsible for that - which can be useful for the planning of this exceptional
activity.
1.4. Description of the machine
The machine described in this use and maintenance manual is a mobile elevating work platform equipped with:
▪Motorized chassis equipped with wheels.
▪Hydraulically driven rotating turret.
▪Articulated boom operated by hydraulic cylinders (the number of articulations and cylinders varies according to
machine model).
▪Operator platform (the max. capacity varies according to the model - see chapter "Technical features”).
The chassis is motorised to allow the machine to move even with lifted platform (see "Use instructions”) and has two rear
driving wheels and two front driving and steering wheels. The rear wheels are equipped with parking brakes, positive logic
type (when drive controls are released brakes are automatically activated).
The turret rests on a turntable fixed to the chassis and can be oriented (rotated) by 370° non-continuous around the central
axle of the machine by means of irreversible endless screw.
The lifting system, with articulated boom, can be divided into three main structures:
▪The first, with vertical extension, consists of a “double parallelogram” system named “pantograph”.
▪The second, consists of a lifting boom with telescopic extension.
▪The third, consists of a terminal boom called "Jib" (the Jib is fixed as a standard, as an option it is rotating of about
180° totally).
The hydraulic cylinders which move the articulated structure are provided with over-center valves directly flanged on the
same. These devices allow the booms to remain in position even if one of the supply tubes accidentally breaks.

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 10
The platform, hinged to the end of the “jib”, can be rotated by 180° totally (90° on the right and 90° on the left) by means of
a rotary actuator fitted with over-centre valve. It is fitted with rails and toe boards of prescribed height (the rails height 
1100 mm; the toe boards height 150 mm; in the access area the toe board height is 100 mm). The platform levelling is
automatic and is ensured by mechanical ties and two cylinders in closed circuit. The manual level compensation is possible
by acting on the relevant control only with completely lowered booms (and with “Jib” inclination ranging between +10° and –
70° with respect to the horizontal axis).
1.5. Control panels
The machine is equipped with two control panels:
▪On the platform for normal use of the machine.
▪On the turret (or on the ground) you can find the emergency controls to lower or stop the machine in emergency
situations, a key-selector to select the control panel and to start the machine.
1.6. Power supply
The machines are powered by Diesel heat engine.
Both the hydraulic and the wiring diagrams are equipped with all necessary protections (see electric and hydraulic circuit
diagrams annexed to this manual).
1.7. Machine life, demolition and decommissioning
The machine has been designed to last for 10 years in normal operating environments, if properly used and serviced.
Within this period, the manufacturer must carry out a complete inspection/overhaul.
If disposal of the unit is necessary, comply with current local regulations.
In Italy, the demolition/decommissioning must be notified to the local ASL / USL or ARPA.
The machine consists mainly of metal parts which are easy to be identified (steel for the most parts, and aluminium for the
hydraulic blocks); thus, we can state that the machine can be recycled at 90%.
European standards and those transposed by the member countries relating to respect for the
environment and the disposal of wastes envisage heavy administrative and penal fines in case of
infringement.
In case of demolition/decommissioning, carefully keep to the provisions of applicable regulations,
especially as regards materials such as hydraulic oil and batteries.

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 11
1.8. Identification
In order to identify the machine, when spare parts and service are required, always mention the information given in the
serial number plate. Should this plate (as well as the various stickers applied on the machine) be lost or illegible, it is to be
replaced as soon as possible. In order to identify the machine when no plate is available the serial number is also stamped
on the chassis. To locate the plate and the stamp of the serial number, see the following picture. It is recommended to copy
such data in the following boxes.
MODEL: _____________________
CHASSIS: ______________________
YEAR: __________________
SG XXXXXX
Fig.1

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 12
1.9. Location of main components
The picture shows the machine and its own components.
1) Control panel
2) Ground controls
3) Electric control unit
4) Hydraulic oil tank
5) Diesel fuel tank
6) Diesel Engine
7) Drive pump
8) Movement pump
9) Hydraulic drive motors
10) Turret rotation hydraulic motor
11) 230V plug (optional)
12) Spirit level (optional) for visual
check of machine levelling
13) Lifting cylinders
14) Starter battery
15) Power assisted steering
16) Inclinometer
17) Overload controller sensor (load
cell)
18) Turntable.
Fig. 2
1
2
3-4-5-
7-8-16
6-7-8
9
9
13
13
13
11-12
10-18
17
15
14

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 13
2. TECHNICAL FEATURES OF STANDARD MACHINES
THE TECHNICAL FEATURES OF THE PRODUCTS IN THE FOLLOWING PAGES CAN BE MODIFIED
WITHOUT PRIOR NOTICE
2.1. Model A12 JRTD
A12 JRTD
Dimensions:
Maximum working height
12.2
m
40’
ft
Max. platform height
10.2
m
33' 5"
ft
Ground clearance
250
mm
9.8"
in
Max. outreach from turntable centre
7.1
m
23’ 3”
ft
Turret rotation (not continuous)
370
°
370
°
Platform rotation
180
°
180
°
Platform height for safety speed activation
< 3
m
< 9’ 10”
ft
Internal steering radius
1.25
m
4' 1"
ft
External steering radius
3.6
m
11' 10"
ft
Maximum capacity (m)
230
Kg
507
lbs
Max. number of people on the platform (n) –indoors
2
2
Tool and material weight (me) (2) –indoors
70
Kg
154.3
lbs
Max. number of people on the platform (n) –outdoors
2
2
Tool and material weight (me) (2) –outdoors
70
Kg
154.3
lbs
Maximum drive height
Max
Max
Maximum platform dimensions (5)
0.8 x 1.4
m
2' 7" x 4’ 7"
ft
Max. hydraulic pressure
380
bar
5511
psi
Max. pressure of lifting circuit
250
bar
3626
psi
Tyre dimensions (4)
Ø 730 x 230
mm
Ø28.7" x 9.0"
in
Tire type (4)
10 x 16.5
10 x 16.5
Transport dimensions
5.6 x 1.8 x 2.09
m
18' 4" x 5’ 11" x6’ 10”
ft
Transport dimensions with retracted jib
4.0 x 1.8 x 2.45
m
13' 1" x 5’ 11" x 8’ 0"
ft
Machine weight (unloaded) (1)
5800
Kg
12786.8
lbs
Stability limit:
Longitudinal slope
4
°
4
°
Transversal slope
4
°
4
°
Maximum wind speed (3)
12.5
m/s
27.96
mph
Maximum manual force
400
N
90
lbf
Max. load per wheel
2600
Kg
5732
lbs
Performance:
Drive wheels
4
4
Max. drive speed
6
km/h
3.7
mph
Safety drive speed
0.6
km/h
0.37
mph
Oil tank capacity
90
Lt.
23.7
gal
Gradeability
38
%
38
%
Max. operating temperature
+50
°C
122
°F
Min. operating temperature
-15
°C
5
°F

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 14
Diesel Power YANMAR “Stage III”
Diesel engine type
3TNV-88
3TNV-88
Max. motor power
28.2
kW
37.8
hp
Adjusted Power
25
kW
33.5
hp
Starter battery
12 / 132
V/Ah
12 / 132
V/Ah
Total electrolyte quantity of battery
7
Lt.
1.85
gal
Diesel oil tank capacity
70
Lt.
18.5
gal
Diesel Power YANMAR “Stage V / Tier 4 final”
Diesel engine type
3TNV-88
3TNV-88
Max. motor power
27.5
kW
36.8
hp
Adjusted Power
25
kW
33.5
hp
Starter battery
12 / 135
V/Ah
12 / 135
V/Ah
Total electrolyte quantity of battery
7
Lt.
1.85
gal
Diesel oil tank capacity
60
Lt.
15.85
gal
380V three-phase electrical pump (optional)
Motor power
NA
kW
NA
hp
Max. absorbed current
NA
A
NA
A
Max. drive speed
NA
km/h
NA
mph
230V single-phase electric pump (optional)
Motor power
NA
kW
NA
hp
Max. absorbed current
NA
A
NA
A
Max. drive speed
NA
km/h
NA
mph
(1) In some cases, different limits can be fixed. It is recommended to comply with the data shown on the machine plate.
(2) me = m –(n x 80).
(3) Wind speeds higher or equal to 12.5 m/s indicate that the machines can be also used outdoors; Wind speeds equal to 0 m/s indicate that the
machines can be used INDOORS ONLY.
(4) Standard rough terrain tyres 10x116.5 filled with polyurethane foam.
(5) Standard steel platform 800x1400 mm; Optional steel platform 800x1800 mm.

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 15

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 16
2.2. Model A15 JRTD
A15 JRTD
Dimensions:
Maximum working height
15.1
m
49’ 6”
ft
Max. platform height
13.1
m
42’ 11”
ft
Ground clearance
250
mm
9.8”
in
Max. outreach from turntable centre
8.8
m
28' 10"
ft
Turret rotation (not continuous)
370
°
370
°
Platform rotation
180
°
180
°
Platform height for safety speed activation
< 3
m
< 9’ 10”
ft
Internal steering radius
1.25
m
4' 1"
ft
External steering radius
3.6
m
11’ 10”
ft
Maximum capacity (m)
230
Kg
507
lbs
Max. number of people on the platform (n) –indoors
2
2
Tool and material weight (me) (2) –indoors
70
Kg
154.3
lbs
Max. number of people on the platform (n) –outdoors
2
2
Tool and material weight (me) (2) –outdoors
70
Kg
154.3
lbs
Maximum drive height
Max
Max
Maximum platform dimensions (5)
0.8 x 1.4
m
2’ 7” x 4’ 7”
ft
Max. hydraulic pressure
380
bar
5511
psi
Max. pressure of lifting circuit
250
bar
3626
psi
Tyre dimensions (4)
Ø 730 x 230
mm
Ø28.7" x 9.0"
in
Tire type (4)
10 x 16.5
10 x 16.5
Transport dimensions
6.5 x 1.8 x 2.09
m
21’ 4” x 5’ 11” x6’ 10”
ft
Transport dimensions with retracted jib
4.7 x 1.8 x 2.40
m
15’ 5” x 5’ 11” x7’ 10”
ft
Machine weight (unloaded) (1)
6630
Kg
14617
lbs
Stability limit:
Longitudinal slope
3.5
°
3.5
°
Transversal slope
3.5
°
3.5
°
Maximum wind speed (3)
12.5
m/s
27.96
mph
Maximum manual force
400
N
90
lbf
Max. load per wheel
3000
Kg
6614
lbs
Performance:
Drive wheels
4
4
Max. drive speed
6
km/h
3.7
mph
Safety drive speed
0.6
km/h
0.37
mph
Oil tank capacity
90
Lt.
23.7
gal
Gradeability
35
%
35
%
Max. operating temperature
+50
°C
122
°F
Min. operating temperature
-15
°C
5
°F

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 17
Diesel Power YANMAR “Stage III”
Diesel engine type
3TNV-88
3TNV-88
Motor power
28
kW
37.5
hp
Starter battery
12 / 132
V/Ah
12 / 132
V/Ah
Total electrolyte quantity of battery
7
Lt.
1.85
gal
Diesel oil tank capacity
70
Lt.
18.5
gal
Diesel Power YANMAR “Stage V / Tier 4 final”
Diesel engine type
3TNV-88
3TNV-88
Max. motor power
27.5
kW
36.8
hp
Adjusted Power
25
kW
33.5
hp
Starter battery
12 / 135
V/Ah
12 / 135
V/Ah
Total electrolyte quantity of battery
7
Lt.
1.85
gal
Diesel oil tank capacity
60
Lt.
15.85
gal
380V three-phase electrical pump (optional)
Motor power
NA
kW
NA
hp
Max. absorbed current
NA
A
NA
A
Max. drive speed
NA
km/h
NA
mph
230V single-phase electric pump (optional)
Motor power
NA
kW
NA
hp
Max. absorbed current
NA
A
NA
A
Max. drive speed
NA
km/h
NA
mph
(1) In some cases, different limits can be fixed. It is recommended to comply with the data shown on the machine plate.
(2) me = m –(n x 80).
(3) Wind speeds higher or equal to 12.5 m/s indicate that the machines can be also used outdoors; Wind speeds equal to 0 m/s indicate that the
machines can be used INDOORS ONLY.
(4) Standard rough terrain tyres 10x116.5 filled with polyurethane foam.
(5) Standard steel platform 800x1400 mm; Optional steel platform 800x1800 mm.

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 18

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 19
2.3. Vibrations and noise
Noise tests have been carried out under the most unfavourable conditions to study the effects on the operator. The level of
acoustic pressure weighed (A) at work places does not exceed 70dB(A) for each electrical model.
For the Diesel engine models, the level of acoustic pressure weighed (A) at work places does not exceed 106dB(A), the
level of acoustic pressure at ground control panel does not exceed 85dB(A), the level of acoustic pressure at platform
control panel does not exceed 78dB(A).
As to vibrations in ordinary working conditions:
▪The average weighted quadratic value in frequency of the acceleration which the upper members have to withstand
is below 2.5 m/sec² for each of the models to which this Use and Maintenance manual refers.
▪The average weighted quadratic value in frequency of the acceleration which the body has to withstand is below
0.5 m/sec² for each of the models to which this Use and Maintenance manual refers.

Use and Maintenance Manual –A12 JRTD A15 JRTD Series
Page 20
3. SAFETY PRECAUTIONS
3.1. Personal protective equipment (PPE)
Always wear personal protective equipment according to current regulations concerning industrial health and safety (in
particular, hard hat and safety shoes are COMPULSORY).
It is the operator or safety manager’s responsibility to choose the personal protective equipment (PPE) depending on the
activity to be carried out. For their correct use and maintenance, refer to the equipment manuals themselves.
The use of safety harness is not compulsory except in certain countries with specific regulations. In Italy, the consolidation
act on safety, Law Decree 81/08, has made the use of a safety harness mandatory.
The harness is attached to one of the anchorages reported by labels, as in the following picture.
Fig. 3
3.2. General safety norms
▪Only adults (18 years old), after carefully reading this manual, are allowed to use the machine. The
employer is responsible for training.
▪The platform is intended for people carriage; therefore, it is necessary to comply with the current local
regulations relevant to this class of machines (see paragraphs 1).
▪At least two users must operate the machine, one of them on the ground, able to carry out the emergency
operations described in this handbook.
▪Always keep the machine at a safety distance from power lines as indicated in the next chapters.
▪Use the machine according to the capacity values indicated in the technical features section. The
identification plate shows the maximum number of people allowed on the platform at any one time, the
maximum capacity and the tool and material weight. Never exceed the indicated figures.
▪Do NOT use the framework of the platform or any of its elements for grounding connections while welding
on the platform.
▪It is absolutely forbidden to load and/or unload persons and/or material with platform not in the access
position.
▪It is the machine owner and/or safety manager’s responsibility to check that the maintenance and repair
operations are carried out by skilled personnel.
