Airo A25is User manual

Airo Wireless, Inc.,
US/CAN: 12 Piedmont Center, Suite 205, Atlanta, GA 30305 USA [phone]
[email protected] http://www.airowireless.com
EMEA: 23 Hinton Road, Bournemouth, Dorset BH1 2EF UK [phone]
[email protected] http://www.airowireless.eu
The new Intrinsically Safe Airo A25is mobile device
combines Voice, Built-in GPS, Push-To-Talk, Web and
Enterprise Data telematics, along with Intrinsically
Safe certication UL913, in a single ruggedized
handset.
Built on the same platform as the highly successful
A25 and specically designed to provide non-
incendive, intrinsic safety for ex-hazardous
environments, the A25is can replace vehicle
telematics, enterprise data devices, laptops with
air cards, and extra cell phones at a much lower
cost. It provides cell phone and Push-to-Talk (PTT)
capability, is equipped with super-accurate GPS,
runs on a Windows Mobile platform and accesses
unique and powerful business-critical functions.
The A25is improves ROI by reducing equipment
purchases and absorbing functionality of a variety
of other equipment into a single convenient
handheld unit that operates in potentially explosive
environments such as Petroleum, Chemicals,
Fertilizer, Coal, Propane, Fuel Distribution, Reneries,
Paint Processing, Granaries, Mining, Alcohol
Processing, Oil Platforms, Natural Gas, and Solvents.
Now, your Global workforce has a single device
supporting cutting-edge mobile technology.
Intrinsically Safe
Rugged Mobile Device

NETWORKS
Quad Band GSM 850/900/1800/1900,
GPRS & EDGE
SIZE
Super Rugged Monoblock
Dimensions: 142.4 mm x 68 mm x 24.4 mm
Weight: 275 grams
ENVIRONMENTAL
Temperature: -20° C to 50° C
Drop: 1.25m drop to concrete — 26 times
Shock: 20g peak
Vibration: 0.001 g²/Hz at 12.5 Hz, 0.034 g²/Hz
at 20-40 Hz, 0.0000057 g²/Hz at 200 Hz, 1 hr/
axis duration simulating 1,000 miles transport
Water: 26.5 liters of water per 929 cm²
Humidity: 95% for 48 hours
Sand/Dust: No ingress of dust
Certications: IP 67 and MIL STD 810-F
(Independent testing for Shock, Drops, & Water)
Intrinsically Safe: Certied UL 913 Class 1 Division 1;
ATEX Certication in process.
BATTERY
Standard battery1570 mAh Li-Ion Polymer
OPERATING SYSTEM
Windows Mobile 6
CPU
Intel® XScale PXA270, 416 MHz
Clock: 416MHz
Instruction Set: ARMv5TE
MEMORY / SD
RAM: 64 MB
Flash: 128 MB
ROM Type: Flash EEPROM
miniSD: Maximum capacity 2GB
DISPLAY
Type: TFT, 16 million colors
Size: 240x320 pixels, 2.8 inches
Resolution: 240x320
Color Depth: 16 bit/pixel
While every effort has been made to achieve technical accuracy, information in this document is subject change without notice and does not represent a
commitment on the part of Airo Wireless, Inc. or any of its subsidiaries, afliates, agents, licensors, or resellers. There are not warranties, expressed or implied,
with respect to the content of this document.
Copyright © 2009 Airo Wireless, Inc. All Rights Reserved. Airo™, Airo Wireless™, marks, images, and symbols are the exclusive properties of Airo Wireless, Inc.
and the stylized “a” is a registered trademark of Airo Wireless, Inc. with the U.S. Patent and Trademark Ofce and this and other marks may be pending in
other countries. The A25™ including components or features thereof and/or associated software are protected by copyright, international treaties and
various patents pending. All other brands, product names, company names, trademarks and service marks are the properties of their respective owners.
CONTROL PERIPHERALS
Keyboard: QWERTY Touchscreen
Directional Pad
Alpha Numeric Keyboards
DATA
GPRS: Multi-slot Class 12
EDGE: Multi-slot Class 12
Fixed Internal Antenna
Bluetooth: Class 2 v2.0
USB: v2.0
Optional Wireless LAN/Wi-Fi
OPTIONAL PUSH TO TALK
PTT: Kodiak Networks®
OMA: PoC
FEATURES AND ACCESSORIES
Speakerphone
Audio jack
Speech recognition
Bluetooth accessory data married w/location/time
Fixed vehicle cradle mount
Standard 2 year warranty,
Optional extended 3 year warranty, Device leasing
STANDARD/OPTIONAL SOFTWARE
Integrated GPS tracking and communications
GPS Dashboard application
Mapping client application with group view
Airo GroupLocate™ and view
Airo GroupLocate™ and PTT call
Interface to all device management tools
Remote upgrades and on-the-y updater
Web-based device management
NETWORK-INDEPENDENT GPS
< 5 meter accuracy w/ < 1 min TTFF from cold start
Low power consumption per location x (as low
as 0.0025% of total battery power)
More then 20,000 real-time correlations with
variable-length integration for superior performance
in harsh signal environments
< 1.5 µW standby power
-150 dBm for deep indoor or poor GPS signal areas
Technical
Specications
