AiroDoctor V10P-ID User manual

airodoctor.com 1
Please carefully read this manual
before using the product
AiroDoctor
In-duct air purier system V10P-ID
Manual

airodoctor.com2
AiroDoctor
In-duct air purier system V10P-ID
thank you for purchasing the AiroDoctor
V10P-ID in-duct air purier system.
In order to facilitate the installation and
operation of this product, we recommend
to carefully read this manual and store
it in a safe place. Use these operating
instructions as a reference for a qualied and
standardized installation, proper operation
and maintenance.
If any questions arise during operation,
please contact our customer service or your
local reseller.
Content
Important safety instructions ________________________________________________ 3
Features / Overview __________________________________________________________ 3
Installation / Assembly _______________________________________________________ 4
Status display / control / troubleshooting ___________________________________ 6
Technical data _________________________________________________________________ 8
Dear Customer,

airodoctor.com 3
AiroDoctor
In-duct air purier system V10P-ID
Important safety instructions
For safety reasons and to ensure proper
operation of the product, all relevant
regulations, rules and instructions must
be strictly followed.
Upon receipt, goods must be immediately
checked to exclude damages during
transportation and ensure that they
match the products ordered. Claims may
be forfeited if the claim is not made in due
time.
Storage must be vibration-free, dry and
free from temperature fluctuations.
Proven damage resulting from transport
or storage is not covered by the warranty.
Tampering with the goods for any
other purpose is not permitted and will
invalidate the warranty in any case!
Features / Overview
In-duct air purifier system V10P-ID is
used for cleaning the air ow in small and
medium-sized HVAC systems. The fanless
UV photocatalytic module is suitable for
new installations as well as to retrofit
existing HVAC systems.
AiroDoctor air purication principle is
based on the photocatalysis eect. The
unique lter, internationally patented,
certied and tested as highly eective,
emits no harmful by-products.
International expert‘s reports and certications conrm the
highly eective performance of AiroDoctor‘s photocatalysis
technology.
Viruses &
Bacteria
Gases &
Odors
Allergens &
Fine Dust
An expert‘s report by the
Charité Institute in Germany
recommends AiroDoctor’s
technology for use in even very sensitive environments
like daycare facilities and schools. Tests show that no
harmful by-products are generated by the patented
UV-A photocatalytic process.

airodoctor.com4
AiroDoctor
In-duct air purier system V10P-ID
Installation / Assembly
Assembly instruction
The proper installation placement of the
device is after the lters of the ventilation/
air conditioning (HVAC) unit.
The connections are designed according
to DIN 24147 in „nipple dimension“, i.e. the
connections t into the existing spiral ducts.
The line connections must be made airtight.
kAssembly can be carried out in any
orientation.
kThe ow direction is marked on the
device.
kThe ControlBox 10P must be accessible
and serviceable, not covered or
obstructed by other objects, walls, or
ceiling.
kIn the vicinity of heating elements,
observe ambient temperatures (<50°C).
Pressure loss, power reduction
The resulting pressure drop is 40 Pa.
Assembly and electrical work
The connection to the power line must be
carried out by trained personnel, following
local regulations, using the RST 16/3 device
and the supplied cable.
Preferably, connect the unit to the power
supply of the HVAC system to switch the
unit ON and OFF simultaneously with the
existing system.
The green LED will confirm the correct
connection of the device, now in standby
mode, ready to use.
To reduce operating costs and extend
product life, the device will activate the air
purication process automatically and only
when the internal sensor detects an air ow
(dierential air pressure sensor > 20 Pa).

airodoctor.com 5
AiroDoctor
In-duct air purier system V10P-ID
Status display / control / troubleshooting
Regularly inspect the air duct for external objects that might obstruct or damage
the module. Check the device and ensure that the LEDs are properly working.
LED
indicator light Status Troubleshooting
green
on ready for operation operating voltage
is present –
o not ready for
operation no operating voltage check electrical
connection
blue
on photocatalysis in
operation system running –
o photocatalysis o
ventilation system o -
no air ow
check ventilation
system
air ow too low -
unit switched o check air ow
operating voltage missing /
indicator light green?
check electrical
connection
device error / internal defect exchange / repair
Green LED (A):
the unit is properly connected
to a valid power source (Standby
mode).
Blue LED (B):
the device is actively purifying
the air (photocatalytic process in
progress).
Function
control Display Operating voltage /
load current photocatalysis Max. deviation
Press and
hold the check
button (C)
top voltage 12 V - + 1.0 V
down current 2.2 A - + 0.6 A
current (two units) 4.5 A - + 1.0 A
Checking the photocatalytic unit
Checking is only possible when the unit is switched on.
If the values on the display are signicantly dierent from those in the chart, one or more LEDs are possibly
faulty and need to be replaced.
A
B
C
D

airodoctor.com6
AiroDoctor
In-duct air purier system V10P-ID
Technical data
Range of use
kInstallation situation:
• new installation in HVAC systems
• retrotting existing HVAC systems
kFilter box (passive) working principle
UV-LED photocatalysis
kAutomatic activation when airow is detected.
kOperating condition check
kFunctional condition check
kMaintenance-free
Dimensions
Duct ø Length 1 (mm) Length 2 (mm) Width (mm) Height 1 (mm) Height 2 (mm)
250 356 280 294 398 294

airodoctor.com 7
AiroDoctor
In-duct air purier system V10P-ID
SPECIFICATIONS V10P-ID
Duct size diameter (mm) 250
Product description Fanless air purication system for integration into new
or existing duct system
Working principle /
technology
UV-A photocatalysis (wavelength 385 nm) +
titanium dioxide (TiO2 )
Scope of application pre-ltered air (free from pollen & dust) /
not suitable for aggressive gases
Air ow rate
Operating temperature 0 - 50 °C
Pressure loss 40 Pa
Noise emission 0 dB (passive)
Dimensions D×W×H (mm 50 × 320 × 390
Weight (kg) 7.0
Installation position /
duct size
in duct system / adapted to the shape and diameter
of the air ducts
Control ControlBox V10
Item no. CB-230/12-V10
Dimensions D×W×H (mm) 250 × 160 × 90
Protection class IP 65
Connection on site via RST 16/3 device connection
Voltage 230 V AC - 50 Hz
Load current 0.2 A (1 PCO module) / 0.3 A (2 PCO modules)
Power 40 W (1 PCO module) / 60 W (2 PCO modules)
Activation dierential air pressure sensor > = 20 Pa
Voltage photocatalysis 12 V DC
Status display Standby mode, ready for operation = green LED
Air purication in progress = blue LED
Functionality check
By pressing the check button (C)
LED voltage - 12 V
LED current - 4.5 A
1×photocatalysis up to 4.7 m/s
2×photocatalysis up to 7.2 m/s
