Airone ANT 076 User manual
Add:10605 Concord Street Suite 440,Kensington MD.20895
Hot Line:+1.800.895.5280; www.bigerstone.com
Page 1of 9
AirOne ANT 076 Wi-Fi Car Dash Cam 2.4" LCD Color Screen FHD 1080p 170 Degree Wide Angle
Dashboard Camera Recorder with Sony Exmor Video Sensor, G-Sensor, WDR,
Loop Recording,Included 8G Memory Card
User Manual -EN.
I.Product Introduction ：
01. Power: Short press: power on / Long press: power off 02.UP Key
03. Down Key 04. Speaker
05. Light Indicator 06.Screen 2.4 inch
07. Recording / OK Key
08. M / MODE KEY: On Main Menu, Short Press: Mode / Long Press: Menu; During recording: Short press: Lock the
video / Long press: Open the mute function (Note: The short press all means menu function if there is no special
version in the below.)
09. Lens buckle
10. MIC hole
11. TF card
12.Power Socket (12V)
13. Reset
14. Lens
II．Driving shooting operation
Preparatory Work: Set the car DVR to a suitable place on the car windscreen, then adjust it to the best angle, insert
the TF card and connect with the car charger.
Plug in the DVR charger to the car cigar lighter port(12V-24V), it will automatically start and default into the camera
Add:10605 Concord Street Suite 440,Kensington MD.20895
Hot Line:+1.800.895.5280; www.bigerstone.com
Page 2of 9
mode to record, so as to prevent missing recording due to forget to boot. When the car is turned off, the unit will
automatically shut down, and save the image data.
Suggestion: In order to use this device to make the perfect recording, we recommend the following settings:
1.After inserting TF card, format the TF card at first, which can improve the compatibility of the TF card. If not doing
so, it will appear "error or not formatted". We highly recommend genuine high-speed class10 or higher class TF card.
2.Open loop recording function, it can cover previous records if the TF card capacity is full, and avoid not recording.
3. Operation steps: Press the MENU button once to enter the menu, then press ◁/▷to choose up and down with
suitable operation, Press OK to enter the settings, and then press ◁/▷key to select the parameters you need,
select OK and press OK, and then press the MENU button once to exit.
III.Specifications
1. Video compression format: H.264
2. Loop shooting section save: 1 \ 3 \ 5 \ 10 minutes
3. Video save format: MOV
4. Power supply: car charger 12V
5. Support TF card, the maximum support 32GB
6. Recording function
7. Reset function
8. Output: AV video
9. Picture Save Format: JPG
10. Video resolution: 1080P / 720P \ WVGA \ VGA \ QVGA
11. Video frame rate: 30FPS
12. Image than the column: 4: 3 (2.4-inch screen)
13. Working temperature: -30 - 70 degrees
14. Working humidity: 15-85% RH
15. Storage temperature: -40-80 degrees
IV. Operating Instruction
1.Photo function: Long press “M/Mode”, enter the photo mode and press OK to take photos.
Step: Press “M/Menu”, enter menu, close Wi-Fi, in camera mode (pause video), long press the “M / Mode” button
once to switch, press OK and take a picture at one time.
2.Photo & Video browsing : Press “M/Menu”, enter menu, close Wi-Fi, in camera mode (pause video), long press the
“M / Mode” button twice to switch, press“◁/▷”button to browse the video and Photo.
Format the TF card (emptying the TF card information) : it needs to be operated when the camera is stopped
Specific operation is as follows: the first to enter the general Settings interface, short press the MENU use“◁/
▷”choose the formatting options, click OK to enter the TF card format, then press OK to confirm once interface,
reuse “◁/▷” button to confirm or cancel, and then press the OK key to perform operations.
Menu setting item introduction (to be operated after stopping the camera or stopping playback)
Add:10605 Concord Street Suite 440,Kensington MD.20895
Hot Line:+1.800.895.5280; www.bigerstone.com
Page 3of 9
Setting of the camera MENU (in camera mode (pause video) press MENU button to enter the camera MENU
Settings) :
1. Resolution: there are 1080PFHD1920×1080 / 720P 1280×720 / WVGA 848×480 / VGA 640×480 (step: press the
MENU button one time - - press ◁/▷the key selection resolution - - press OK to enter - - press ◁/▷key
selection resolution parameter - - press OK key to confirm)
2. Loop recording : close /1 minutes / 3 minutes /5 minutes.This will automatically cover the earliest video after your
memory card is full, so that you can't continue to shoot after the full card is full.(step: press the MENU button one
time to press ◁/▷button loop video - press REC/OK to enter - - press ◁/▷the key selection time - - click
OK to confirm)
3. HDR: open/close;When choose "on", automatically processing camera effect under different illumination
conditions, make the light shadow details are more apparent (step: press the MENU button one time to press ◁/▷
button - press OK to enter - - press ◁/▷button - > - click OK to confirm)
4. exposure compensation: according to different environment light source, choose a different exposure can achieve
a better visual effect (step: press the MENU button one time to press ◁/▷button - press OK to enter - - press
◁/▷button - > - click OK to confirm)
5. Video audio: open/close;When the "open" is selected, the voice will be recorded together, when choose close the
voice will wot be record together .(step: press the MENU button one time to press ◁/▷key adjustment to press
OK to enter, press ◁/▷button - > - click OK to confirm)
6. Date label: after opening, the date and time will be displayed on the video or photos, once you choose close it will
no longer be displayed.(step: press the MENU button one time to press◁/▷button to press OK to enter, press ◁/
▷the key selection - selected "on or off" - - click OK to confirm the recognition)
7. G-SENSOR close/low/medium/high;The sensitivity of gravity sensor can be set according to your needs, which can
better save image data during collision.(step: press the MENU button one time to press ◁/▷button to press OK to
enter, press◁/▷keys to choose the selected "off/low/medium/high" - - click OK to confirm)
General menu settings (enter to general menu settings according to step 1):
1. Wi-Fi Setting: OFF or ON (Step:Press MENU button twice →press ◁/▷button to choose Wifi, press OK to enter,
press ◁/▷keys to choose “Off / ON”)
2. Date and time settings: year / month / day / hour / minute / second (step: press MENU key twice → press◁/▷
key to select → press OK to enter → press ◁/▷key to adjust → press OK to make the previous or next selection →
press◁/▷to adjust → press OK to confirm until it is set). Date Format: Set the year / month / day format (Step:
Add:10605 Concord Street Suite 440,Kensington MD.20895
Hot Line:+1.800.895.5280; www.bigerstone.com
Page 4of 9
Press MENU key twice→ Press◁/▷to select → Press OK to enter → Press OK again to select the last item or the
next item to choose year,month,date format → press ◁/▷format to set → press OK to confirm)
3. Screen saver: off / 15 seconds / 30 seconds / 1 minute, when driving the screen has protection. (Step: Press MENU
twice → press ◁/▷key to select → press OK to enter → press ◁/▷select → press OK to confirm)
4. Beep sound: On / Off (Step: Press MENU twice → press ◁/▷key to select → press OK to enter → press ◁/▷
select → press OK to confirm)
5. Language English / Simplified Chinese / Traditional Chinese / Portuguese / Japanese / Russian / French / German
and other 9 languages. (Step: Press MENU twice → press ◁/▷key to select → press OK to enter → press ◁/▷
select → press OK to confirm)
6. Frequency: 50HZ / 60HZ; (Step: Press MENU twice → press ◁/▷key to select → press OK to enter → press ◁/
▷to select → press OK to confirm
7. Format: You can format the TF card. (Step: Press MENU twice → press ◁/▷key to select → press OK to enter →
press ◁/▷select → press OK to confirm)
8. Default setting: yes / no (select "Yes", the machine will return to the initial setting) (Step: Press MENU twice →
press ◁/▷key to select → press OK to enter → press ◁/▷select → press OK)
9. Version (step: press MENU twice → press ◁/▷key to select → press OK to enter the view)
WIFI MODE
1. Search “AirOne Dashcam” APP, download and install.
2. After installation, there will be a APP logo as below:
3. Connect Wi-Fi
Enter the setting of smart phone → open Wi-Fi → search the name of dash camera → enter password
“12345678” → Connected.
4. Click on the “AirOne Dashcam”, enter APP, the UI will show as below.
Add:10605 Concord Street Suite 440,Kensington MD.20895
Hot Line:+1.800.895.5280; www.bigerstone.com
Page 5of 9
5. Enter “DASHCAM” , the UI is as below:
Note: Click Camera, it will switch to “Photo” mode. It will show “Take
Photo success”.
6. Enter “CAMERA” , the UI is as below: Click camera to take photo, it will show “Take photo success”
7. Enter “PLAYBACK” Or click “File”, to check and edit (Download or Delete) the video and photo.
Add:10605 Concord Street Suite 440,Kensington MD.20895
Hot Line:+1.800.895.5280; www.bigerstone.com
Page 7of 9
A. Default Setting: Reset the software B. Quality Setting: Set the Definition of the image
V.Precautions
9. Please insert TF card before recording, first use TF card, please first format the TF card on the machine, please
Add:10605 Concord Street Suite 440,Kensington MD.20895
Hot Line:+1.800.895.5280; www.bigerstone.com
Page 8of 9
refer to the formatting option. Please set the time before recording. Because the system will detect the time to
record, if not set the time,it may not appear video.
10. This car DVR recording mode allows you to select cyclic recording. When the storage capacity is full, the car DVR
will automatically restarts recording from the original storage video and overwrites the oldest file.
(Note: In order to avoid all the files deleted at one time, at the time of recording, the saved file can be set to 1
minutes / 3 minutes / 5 minutes for a section, when the TF card is full and re-recording, the file will recover One by
one). If you choose to turn off the video save time, when the storage capacity is full, it will show that the card is full
and stop recording.
Ⅵ.Common problems
1. Can not starting up after connect the car charger:Please check the car charger to confirm if it can work,or make
sure the fuse burnout; if any problem it need to replace the car charge or the fuse.
2. Can not record: Please check if it insert the TF card or if the TF card in good quality; if
Still any problem,you should re-insert TF card or replace it.
Crash phenomenon: please press the reset button (reset) to resolve.
4.Recording become vague:Please check if the lens in duty,clear the lens.
5.The recorder date is wrong:Please enter to the Menu and reset the the date and time.
Camera Specifications
Key Specs
Field of View
170 degrees
Automatic Incident Detection
Yes
G-Sensor
Yes
Recording Resolution
1920 x 1080
Compatibility
Universal
Camera Mounting Location
Other
Vehicle Camera Type
Other
Recording and
Playback
Field of View
170 degrees
Automatic Incident Detection
Yes
G-Sensor
Yes
Recording Resolution
1920 x 1080
Loop-Cycle Recording
Yes
Image Sensor Type
Sony IMX 323
Camera Power Source
Vehicle Battery,no battery
Expandable Memory Compatibility
Micro SD 32GB(Max)
Recording Feature
Yes
Compatibility
Compatibility
Universal
Features
Integrated Microphone
Yes
Night Vision
Yes
Display
Screen Included
Yes
Screen Size
2.4 inches
Add:10605 Concord Street Suite 440,Kensington MD.20895
Hot Line:+1.800.895.5280; www.bigerstone.com
Page 9of 9
Screen Resolution
960*240
Mounting
Camera Mounting Location
Other
Mount Included
Yes
Mount Type
Static sticker with 3M adhesive
Screen Mounting Location
Dash camera
Input
Number Of Auxiliary Inputs
1
Number Of USB Port(s)
1
Dimension
Product Height
0.15Inches
Product Width
0.24 inches
Product Depth
0.37 inches
Product Weight
0.22 Lb
Package Dimension
7.6×4.8×2.6 inches
Whole Set Weight
0.66 Lb
General
Vehicle Camera Type
Other
Color
Black
Color Category
Black
Model Number
ANT076
Language
English / Français / Español / Português /
Deutsch / Italiano / 简体中文 /繁体中文
/ Pусский / Japanese
Warranty
Manufacturer's Warranty - Parts
1 Year
Manufacturer's Warranty - Labor
1 Year
Other
Product Name
Wifi Dash camera
Brand
AirOne
UPC
680270750784
