Airrex HSC-HEPA2000 User manual

A
AI IR RR RE E  H HE E A A F Fi il lt tr ra at ti io on n  a ac ch hi in ne e
USER’S MANUAL
▶ Thank you for purchasing an AIRREX HEPA Filtration Machine.
BEFORE operation please read this user’s manual carefully.
▶ Keep this manual readily available.
▶ It is ESSENTIAL that you read the ‘NOTES ON SAFETY’carefully
before use and follow them at all times.
▶ This Machine is specified for use on a 115V. 60Hz.
single phase power supply. You must check that the local
electricity supply is the same and have the appropriate plug fitted
by a qualified electrician.
▶ The Warranty form is on Page 8. Please complete it now and keep
in a safe place.
▶ We have a policy of continual improving to our products.
The contents (features and specifications) in this manual are
therefore subject to change without notice.
HSC-HEPA2000

2
TABLE OF CONTENTS
■ Safety Instructions
■ Specifications
■ Wiring diagram
■ Controller
■ Trouble Shooting
■ Filter
■ Change of filter
■ Warranty
3
4
4
4
5
5
6
8

3
Safety Instructions
▶Insert the power plug into the outlet for 115V / 60Hz only.
▶When inserting the power cord into the outlet, turn off the switch before use.
▶Do not touch the product with a wet hand.
▶Do not put a heavy thing on the power cord.
▶When water enters into the product or the electricity part, pull out the power plug
and dry it completely before use.
▶On the day of thundering or lightning, remove the power cable, and do not use it.
▶Do not put the product at the humid place. It may occur a danger such as electric leak
or electric shock.
▶Do not install it at the place where inflammable gas is generated.
It may occur a danger of explosion.
▶Remove any obstacle at the inhaling hole and the exhaling hole.
▶When cleaning the surface of the product, pull the power cord out, and use soft cloth
for preventing a scratch.
▶Do not use wet cloth, wax or thinner.
▶Do not put a hand or foreign substance into the inhaling hole or the exhaling hole.
It may occur a malfunction to the product or a physical injury.
Keep this manual in a visible location near the cooler for easy reference.
The following instructions are for ensuring the user’s safety and to prevent any
physical injury or material damage. Please read carefully and follow all instructions.
There are two sections to these instructions: WARNING and CAUTION.
CAUTIONS
Specification
Voltage 115Va.c. 60Hz
Width 28.5 (inch)
Length 30 (inch)
Height 30 (inch)
Weight 132lb
AirFlow (High) 1,620CFM
AirFlow (Low) 1,410CFM

4
Controller
Wiring diagram
How to operate the product
0
0. 2
0. 4
0. 6
0. 8
1 . 0
1. Pressure Gauge
2. Pressur Sensing Port
3. Circuit Breaker
4. High-Off-Low Switch
1. Before connecting the power cord, confirm the switch is turned off without fail.
2. For starting the product, press the switch in the control panel to the low or high.
3. For stopping the operation, press the OFF.
①②③
④

5
Trouble Shooting
Trouble Check & Remedy
The machine cannot be ·Confirm that the power cord is correctly
operated connected with the outlet.
After operating, ·Due to an over electric current, the power
the power turns off. source is being cut.
Please check the circuit breaker.
Inhaling/ exhaling is weak. ·Check if the filter is damaged or contaminated.
Dust is flowed out of ·Check if the filter is damaged or correctly installed.
the exhaling hole.
Filter
DO NOT OPERATE THE AIRREX WITHOUT THE HEPA FILTER INSTALLED!
OPERATING WITHOUT THE HEPA FILTER INSTALLED OR USING NON-APPROVED
POWER CORDS MAY CAUSE DAMAGE TO THE ELECTRICAL SYSTEM OR
MECHANICAL COMPONENTS. FAILURE TO COMPLY WILL VOID ALL WARRANTIES.
1. Size : 27.5 X 25.3 X 0.6 (inch)
2. The filter can collect dust of 10~30㎛up
to 20~85% in accordance with
the standard of weight method
PRE-FILTER
1. Size : 24.0 X 24.0 X 0.8 (inch)
2. Aluminum frame is put around
the outer edge. It can collect dust of
10~20㎛up to 90% in accordance with
the standard of weight method.
PRE-FILTER PANEL

6
1. Size : 24.0 X 24.0 X 5.9 (inch)
2. It can collect dust of 0.3㎛ up to 99.97%
in accordance with the standard of
weight method
HEPA FILTER
Change of filter
◈ At the time the pressure gauge value is 0.64 in high, and more than 0.56 in low.
◈ At the time the filter is damaged due to a long-time use.
◈ At the time the inhaling power falls due to a clogging in the filter.
Time of filter change
◈ As the asbestos dust attached to the filter may be scattered, do work in a closed space,
wearing a protective gear
◈ Cut the main power, then do work.
◈ The removed filter after change must put in a doubled vinyl pack, then discard it legally.
Cautions for filter change
How to change filter
·1-1 After opening the door,
pull out the reinforced
staffs.
·1-2 Change the filter
contaminated or
damaged as the picture.
·Fix the filter in reverse order.
1-1
1. Pre-Filter change
1-2
Filter

7
·2-1 Open the door as
the picture.
·2-2. Using a tool as the
picture, pull off the
bracket fixing the filter
·2-3 Change the contaminated
or damaged pre-filter
panel and hepa-filter
in order.
·Fix the new filter in
reverse order.
2-1
2-3
MEMO.
2-2
2. Pre-Filter Panel, Hepa Filter change
Change of filter

PRODUCT
SERIAL NO:
DESCRIPTION
MODEL HSC-HEPA2000
DATE OF PURCHASE
WARRANTY
AIRREX HEPA FILTRATION MACHINE give more reliable performance, comfort and
durability the more they are used. They are built under a strict quality assurance
regime which includes inspection both during and after production and exhaustive
reliability testing.
In the unlikely event you have any problems, please contact your dealer or
distributor. If the problem is as a result of a production fault or failure, repairs will
be undertaken free of charge during the period of warranty subject to the
following warranty conditions:
1. The warranty period is 12 months from the date of first purchase.
2. If the problem has been caused by customer error or misuse, abuse or
damage, then all repairs will be charged for.
3. This warranty applies to your country.
4. Proof and date of purchase must be supplied.
5. Please complete the details below and keep this warranty in a safe place.
6. All transport charges back to the dealer are at the customers cost. Keep all
original packaging to facilitate return. Return to customer will be at dealers cost
(if genuine warranty claim).
Name of Company
Telephone No.
DISTRIBUTOR
Name :
Address :
Telephone :
CUSTOMER
DETAILS
(Applicable to first retail purchaser only)
Warranty Period ( ) Months
HEPHZIBAH CO.,LTD.
423-5 CHUNGCHUN-DONG, BUPYUNG-KU
INCHEON, KOREA
TEL : [phone]
FAX : [phone]
E-mail : [email protected]
Website : www.airrex.co.kr
