Airstream iZone User manual
iZone
®
Installation and User
Manual
Section Description Page No.
1.0
Installation 4
1.1 Standard wiring layout for open / close zone system 4
1.2 Wiring layout when temperature controlled zones are installed 5
1.3 Wiring when more that 3 colour touch screens are installed 6
2.0
System configuration 8
2.1 Changing the password 8
2.2 Set the number of zones 8
2.3 Set the number of constants 8
2.4 Change the tag lines 8
2.5 Locking / unlocking user airflow volume adjustment 8
2.6
Zone set up 9
1.4 Installation instructions 7
Table of contents
Table of contents
Section Description Page No.
3.0
User manual 10
3.0 Home screen 10
3.1 Zone control 11
3.1.1 Edit zone names and settings 12
3.1.2 Adjusting temperature controlled zones 13
3.2 Favorites 14
3.2.1 Assign and edit favorites 15
3.3 Zone airflow summary 16
3.3.1 Changing zone airflows 17
3.4 Schedules 18
3.4.1 Setting and editing a schedule 19
3.5 Setting the time 20
3.6 Setting the home screen colour 21
3.7 Further assistance 22
1.1 Standard wiring layout for open / close zone system
iZone
Inventive
.
Intelligent
.
Intuitive
CCPU
Central Processing Unit
CCTS
Zone 1
Zone 3
Zone 2
Zone 4
Zone 6
Zone 10
Zone 8
Zone 9
Zone 7
Zone 5
CT24AC
10 Zone system with 1 colour touch screen shown above
CZDA
1.2 Wiring layout when temperature controlled zones are installed
CCPU
Central Processing Unit
iZone
Inventive
.
Intelligent
.
Intuitive
CCTS in
Tem erature
Controlled zone
Zone 1
Zone 3
Zone 2
Zone 4
Zone 6
Zone 7
Zone 5
CT24AC
7 Zone system with 2 colour touch screens shown above
iZone
Inventive
.
Intelligent
.
Intuitive
CCTS
CDTS
Installed into the
su ly air duct off
the fan coil unit
CZDA
1.3 Wiring when more than 3 colour touch screens are installed
CCPU
Central Processing Unit
iZone
Inventive
.
Intelligent
.
Intuitive
CZDA
Zone 3
Zone 2
Zone 4
Zone 6
Zone 5
CT24AC
6 Zone system with 4 colour touch screens shown.
A maximum of 12 zones and 12 colour touch screens can be supported by one
iZone system
iZone
Inventive
.
Intelligent
.
Intuitive
CCTS
CDTS
iZone
Inventive
.
Intelligent
.
Intuitive
iZone
Inventive
.
Intelligent
.
Intuitive
CNEM
Network Extension Module
CT24AC
Zone 1
CCTS
CCTS
CCTS
1.4 Installation instructions
1. The CCPU can be installed on top of the indoor fan coil unit.
2. Do not run the blue network cables along side 240 Volt wiring.
3. When installing network cables down wall cavities or chasing network cables into walls, tape up and protect the RJ45 connector to avoid
damage to the connectors.
4. Always install zones in consecutive ports starting at Zone 1. The back of the CCPU is marked with the zone port numbers.
5. Do not directly hardwire the CT24V into the AC unit’s power supply. This may void the warranty as it will require an electrician in the event
that a repair of the iZone system is required.
6. Connect Zone Damper Actuators (CZDA) to the zone ports using the RJ11 cables as shown.
7. Connect the Colour Touch Screens (CCTS) to the CCTS ports using the RJ45 cables. If you are connecting more than 3 CCTS to the
system you will need to connect a Network Extension Module (CNEM) to the CCPU using a short RJ45 cable.
8. If any CCTS is being used for zone temperature control connect a Duct Temperature Sensor (CDTS) to the CDTS port. Install the sensor
into the supply air duct upstream of all dampers. Secure the sensor in place by using reinforced aluminium tape.
9. Connect the power supply to the(CT24AC) port.
10. When installing temperature controlled zones ensure the CCTS for the associated zone is installed in a location that is representative of
the temperature in the room / zone . The CCTS should be installed at approximately 1600mm above the floor and should not be subject to
draughts, direct sunlight or heat from equipment such as computers, TV screens etc. The supply air outlets to this room must not blow
conditioned air directly onto the touch screen, as the temperature sensor is located in the CCTS.
2.0 System configuration
WARNING ! Only qualified iZone installers should configure the iZone System. Incorrect configuration could result in damage to your air con-
ditioning unit and system.
2.1 To configure your system click on the System Config icon on the home page.
Enter the system password “wamfud” and press the enter button. The enter button must always be touched to save changes.
2.2-2.5 You will now be in the System Configuration area:
iZone
Inventive
.
Intelligent
.
Intuitive
Inventive . Intelligent . Intuitive
iZone
!
"#$
%
"#
$%
!
&'()
*
2.6 Zone set up
iZone
Inventive
.
Intelligent
.
Intuitive
+#
+#
#
#
"
"
'
,
,
'
'-
,
".
,
!'/
+
3.0 User manual
1. To get back to the Home
screen at any time press
3. When entering names or
values using the keyboard
it is easier to use a thin
object such as a toothpick.
Do not use sharp, hard
objects as they may
damage the screen. The
enter button must always
be pressed to save the
changes you have made.
4. Some functions may have
been locked by your
installer to ensure the
commissioned values are
not changed. To make
changes to these values
contact your installation
company.
(0
iZone
Inventive
.
Intelligent
.
Intuitive
1
2%
!
&')
2%
!
&')
2
3&')
2
,4,
&')
5.6,
'2
%'
-,%
2
&'()
2
#&')
2,
%&')
2!
,%&'0)
2%
%
"&
)
/,7
,
%,
((
/
,
48'2
3
&')
/
,,
/
,
/
,%
-
3.1 Zone control
iZone
Inventive
.
Intelligent
.
Intuitive
/4(
'2
-
'&')
/'
2
/'
2
/
,,
,
,
2"
3.1.1 Edit zone names & settings
iZone
Inventive
.
Intelligent
.
Intuitive
2
2
2+
#
6
-,
,
4+
#
-
(
6
2
#
(
3.1.2 Adjusting temperature controlled zones
/
$
/
'9%
+,
6,
+,
6,
2,
24
%,
/
&,
4)
-
iZone
Inventive
.
Intelligent
.
Intuitive
2
2
2
/
%
,"
2"
,
3.2 Favorites
iZone
Inventive
.
Intelligent
.
Intuitive
2,"4
%,3
/
(
2
&''()
(
3.2.1 Assign and edit favorites
/
4
-
iZone
Inventive
.
Intelligent
.
Intuitive
2
:
/,
'
63
,
2"
,
3.3 Zone airflow summary
iZone
Inventive
.
Intelligent
.
Intuitive
4
(
-
/
#3
/+
#3
2
#3''(
(
3.3.1 Changing zone airflows
/
,
#
/
+#3
-
iZone
Inventive
.
Intelligent
.
Intuitive
2
+#
2"
#,
/
#3
&,0;)
2
+#
2
#
2
#
3.4 Schedules
5,,%,
,%,'2
%2<8
(
2
,
&''()
/%%
/%%
iZone
Inventive
.
Intelligent
.
Intuitive
(*
3.4.1 Setting and editing a schedule
/
,
3
/%
2++
iZone
Inventive
.
Intelligent
.
Intuitive
/,
,'2
,'
2"
,
2
2",
%'=
>0,00
2?
,3
/,
'
2,,
,
3.5 Setting the time
iZone
Inventive
.
Intelligent
.
Intuitive
6%
0
/
9
?
,
6
2@
,
