AirVax 33X2 User manual

*AIRVAX is a representative brand of air purifier developed and produced by IDEAVAX in Korea.
IDEAVAX CO., LTD.
2007 IDEAVAX CO.,LTD. All rights reserved
IDEAVAX is a registered trademark or trademark of IDEAVAX CO.,LTD in the Korea and/or other Countries.
33X2
The world’s first Permanence-Static Electricity-Film-Filter Air Purifier.

WHAT MAKES AIRVAX SPECIAL?
- It takes in dust with particle size of less than 0.3㎛
- It takes in all sorts of allergens such as VOC, which causes atopy.
- All functions are working even without filter change; only simple cleaning is required.
- It does not cause any pollutant such as ozone, and other greenhouse gases.
FEATURES
1. INSTALLING THE MAIN UNIT
INSTALLATION
Unseal the box and retrieve the
unit from the box carefully. Place the unit on an appropriate place and insert the plug into a
wall outlet. Check whether the
light blinks on the indicator.
Select the mode by
pressing a button or using the
remote control
(see page 9 for more details).
2. INSTALLING THE REMOTE CONTROL
Open the cover as shown below. Mount the battery as shown
below (Lithium Battery CR2032). Replace the cover.
2

CONTENTS
PART NAMES
1. MAIN UNIT
2. ACCESSORIES
Remote control Lithium battery
(CR2032) Manual
-AIR PURIFIER-
FEATURES 2
1. WHAT MAKES AIRVAX SPECIAL?
INSTALLATION 2
1. INSTALLING THE MAIN UNIT
2. INSTALLING THE REMOTE CONTROL
CONTENTS 3
PART NAMES 3
1. MAIN UNIT
2. ACCESSORIES
SAFETY PRECAUTIONS 4
1. RISK OF ELECTRIC SHOCK
2. CAUTIONS RELATED TO THE OPERATION
OF THE PRODUCT
LIMITATIONS ON THE USE OF THE
REMOTE CONTROL 5
INSTALLATION GUIDELINES 5
FILTER GUIDELINES 5
CATE AND MAINTENANCE 5
1. FILTER CLEANING
2. MAIN UNIT
OPERATION 6
1. OPERATING THE MAIN UNIT
2. OPERATING THE REMOTE CONTROL
SPECIFICATIONS 6
CONSUMER SERVICE 7
1. LIMITED WARRANTY FOR CONSUMERS
Air intake Air intake
Viewfinder
Jack connector
Air outlet
e-film filter for nano-Dust
Indicator / Operator
Remote control sensor
Air outlet
Top cover
Front Back
3
Adapter(1.0 A)
AC 110~240V/DC12V AC-DC

SAFETY PRECAUTIONS
1. RISK OF ELECTRIC SHOCK
Do not use the unit if the AC-DC Adapter or plug is damaged or the connection to the wall outlet is loose
(
electric shock, short circuit, and/or fire may occur).
Do not damage, break, coat, forcefully bend, pull, twist, bundle, pinch or place heavy objects on the AC-DC Adapter.
(may damage the power cord, which in turn may cause fire and/or electric shock).
Use AC 120V and DC 12V only
(to avoid fire and/or electric shock).
Do not modify. Repair and disassembly of this product should be performed by authorized service personnel only
(to avoid fire, electric shock, and/or bodily injury). Contact your dealer or IDEAVAX Service Center for repair.
Periodically remove dust from the power plug
(accumulated dust on the power plug may result in poor insulation from humidity, etc., thereby causing fire
and/or electric shock).
When cleaning the unit, be sure to remove the power plug from the wall outlet. Never touch the power plug
with wet hands
(electric shock and/or bodily injury may occur).
Do not use the unit where there are oil ingredients such as cooking oil in the air
(surface of the unit may crack).
Do not apply benzene or paint thinner or spray insecticide on the unit
(
cracking, electric shock, and/or fire may occur).
Do not allow the unit to take in flammable gases, sparks from lit cigarettes, incense, etc.
(may cause the unit to ignite).
Do not use the unit in humid areas such as bathrooms or areas near moisture
(
electric shock and/or malfunction may occur).
Do not insert your fingers or foreign objects into the intake or air outlet
(
electric shock and/or malfunction may occur).
When unplugging the unit, always hold the plug; never pull the cord
(electric shock and/or fire due to short circuit may occur).
Ventilate when using the unit together with a heating appliance
(to avoid carbon monoxide poisoning).
Remove the power plug when the unit is not in use
(to avoid electric shock due to poor insulation and/or fire due to short circuit).
For safety, have the AC-DC Adapter replaced by the manufacturer, its service agent, or other qualified person
in case of damage.
The battery must be removed from the remote control before it is disposed. Dispose of used batteries safely.
2. CAUTIONS RELATED TO THE OPERATION OF THE PRODUCT
Do not block the intake and air outlet.
Do not use the unit near or on hot objects such as a stove. Avoid using the unit in areas where it may come
into contact with steam.
Do not use the unit on its side
(deformation, malfunction, and/or overheating of the motor may occur).
Do not install in areas where oily residue is generated, e.g., kitchen.
Do not use detergent in cleaning the unit
(may damage the unit or cause cracking or malfunction of the sensor).
Do not operate the unit without the filter
(no purification effect will be generated; may also cause trouble).
Do not wash the e-Film filter for nano-dust
(wet e-film filter for nano-dust can cause breakdown or fault in
the product).
Do not carry the product by the top cover
(the top cover is made for opening and shutting the product;
breakdown may occur if the product is not completely closed or when shaken due to fall).
4

LIMITATIONS ON THE USE OF THE REMOTE CONTROL
DO NOT USE THE REMOTE CONTROL IN THE FOLLOWING LOCATIONS:
·Any location where inverter lighting equipment or electronic spontaneous lighting equipment are installed
The remote control may become inoperable. In this case, move away from such lighting equipment or change locations.
·Location exposed to direct sunlight
The unit may not receive signals from the remote control.
The unit may not respond to the signals of the remote control if the ends of the fluorescent lighting turn black or lights flicker due to
the expiration of the service life; note, however, that this is not a malfunction of the remote control or the main unit. In this case,
replace the lighting with new fluorescent tubes.
INSTALLATION GUIDELINES
·Allow a distance of at least 7 feet (2m) from equipment generating electric waves such as televisions, radios,
or wave clocks (to avoid electric interference).
·Avoid locations where curtains, etc., may come into contact with the intake or air outlet
(curtains, etc., may get dirty, or malfunction may occur).
󱈢EFFECTIVE OPERATION
·Place on a stable surface with sufficient air circulation
FILTER GUIDELINES
·Do not wash a contaminated filter. Instead, remove the dust using a vacuum cleaner or a brush.
·Dust may accumulate on the unit even when it is not operating.
Therefore, cover the unit with any vinyl material when the product will not be used for a long time.
CARE AND MAINTENANCE
1. FILTER CLEANING
Turn off power and
unplug the cord from the
wall outlet.
Turn the top cover to the
opposite direction of
“OPEN.”
Take note of the pollution
level on Viewfinder on
the reverse side.
Open the cover by turning
the top cover toward the
“OPEN” direction.
Use a brush or a vacuum
cleaner to remove dust
from the upper filter.
Place the unit on the
ground, plug the cord,
and turn on power again.
2. MAIN UNIT
To prevent dirt or stains on the main unit, clean as often as necessary (stains may be difficult to remove later if
they are not cleaned immediately).
Wipe with a soft, dry cloth. For stubborn stains or dirt, use a soft cloth soaked in warm water (squeeze off excess water).
Do not use volatile fluids on the unit (benzene, paint thinner, polishing powder, etc., may damage the surface of the unit).
Do not use detergents in cleaning the unit (detergent ingredients may damage the surface of the unit).
Keep the unit dry. Keep unit away from moisture.
Schedule of Filter Change
The E-Film filter for the nano-Dust of AIRVAX can be
reused after simple, quick cleaning even when the gap is
filled with dust and the unit does not take in as much dust
as the new filter. When used for a long time, however, the
filter may be severely discolored. Therefore, change the
filter at least once every three years. For more detailed
information, contact the head office.
5

Button Click Mode Contents Display
Once (ON) The unit will operate at MEDIUM fan level
Normal mode The two lights at the bottom of the LED will be turned on.
Twice High mode The unit will operate at HIGH fan leve
The three lights on the LED will be turned on.
Three times Silent mode The unit will operate quietly using minimal air intake.
The light on top of the LED will be turned on.
Four times OFF Power is turned off.
Both lights are turned off.
OPERATION
1. OPERATING THE MAIN UNIT
2. OPERATING THE REMOTE CONTROL
When you start the remote control, the LED will blink rapidly and shift to the appropriate mode.
Model AIRVAX-33X2
Power supply Input :120V/60Hz Output :12V/1.0A
Fan level Fan level adjustment High mode Normal mode Silent mode
operation Rated power 4W 2W 1W
Fan level CFM(m3/min.)84(2.4)63(1.8)42(1.2)
Applicable floor surface 269 sq.ft.* (25m2)
Cord length 5.9ft (1.8m)
Dimensions(W×D×H)6-15/16 in.×6-15/16 in.×11-1/2 in
177mm×177mm×292mm
Weight 4.6 lbs (2.1 kg)
* The applicable floor surface area is appropriate for operating the unit at maximum fan level.
SPECIFICATIONS
ON/OFF
The First click will turn on power; the second click will turn off power.
High mode
The unit will operate at HIGH fan leve.
Normal mode
The unit will operate quietly using minimal air intake.
Silent mode
The unit will operate quietly using minimal air intake.
6

CONSUMER SERVICE
1. LIMITED WARRANTY FOR CONSUMERS
LIMITED WARRANTY FOR US USERS
IDEAVAX CO., LTD., warrants to the first consumer purchaser that this AIRVAX product (“Product”) is free
from defective workmanship and materials when shipped in its original container and agrees to repair the
defect or replace the defective product or part thereof with a new or remanufactured equivalent at no charge
to the purchaser in terms of parts or labor for the period(s) set forth below.
This warranty does not apply to the accessories of the product or to the additional excluded item(s) set forth
below or to a unit whose exterior has been damaged or deformed, subjected to improper voltage or other
misuse, abnormal service, or handling, or whose design or assembly has been altered or modified.
To avail yourself of the benefits of this limited warranty, follow the steps set forth below and present your proof
of purchase to the servicer.
The limited warranty described herein supplements whatever implied warranties may be granted to
purchasers by law.
ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR USE ARE LIMITED TO THE PERIOD(S) STARTING FROM THE DATE OF PURCHASE SET FORTH
BELOW. Note, however, that some states do not allow limitations on the implied warranty period.
Neither the sales personnel of the dealer nor any other person is authorized to make warranties other than
those described herein or to extend the period of any warranty beyond the period described herein on behalf
of AIRVAX.
The warranties described herein shall be the sole and exclusive warranties granted by AIRVAX and shall be
the sole and exclusive remedy available to the purchaser. The correction of defects in the manner and for the
period described herein shall constitute the complete fulfillment of all liabilities and responsibilities of AIRVAX
to the purchaser in relation to the product and imply the full satisfaction of all claims, be they based on
contract, negligence, strict liability, etc.
Under no circumstances shall AIRVAX be liable or in any way responsible for any and all damages or defects
in the product due to repairs or attempted repairs performed by persons other than an authorized servicer.
Neither shall AIRVAX be liable or in any way responsible for any incidental or consequential economic or
property damage. Note, however, that some states do not allow the exclusion of incidental or consequential
damages.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS
THAT MAY VARY FROM STATE TO STATE.
󱇱Model number and description of your unit:
AIRVAX 33X2 Air Purifier; be sure to have this information ready when you require service for your unit
󱇱Warranty period for this unit:
One (1) year from the date of purchase, covering parts and labor
󱇱Additional item(s) excluded from the Warranty Coverage (if any):
Accessories of the product, filter, etc., or any printed matter
󱇱Where to obtain service:
󱇱What to do to obtain service:
FOR SUPPLY, ACCESSORIES, OR PRODUCT INFORMATION, VISIT OUR WEBSITE AT www.airvax.co.kr.
7

IDEAVAX SERVICE CENTER
Call us at:
Or write to us at:
Please provide the following information when writing or calling
model number, serial number, date of purchase, complete mailing address (including zip code),
telephone number where you can be reached during daytime (including area code), and
description of the problem.
For your protection
To enable us to serve you better when you call for service or report loss or theft, please record
the following model and serial number as indicated at the back of the unit:
MODEL NUMBER: AIRVAX 33X2 SERIAL NUMBER:
DATE OF PURCHASE: Dealer Name:
Address:
City: State:
Zip: Telephone:
