Airwell DS 18 RCG User manual

Split Ducted systems
DS 16/18/24 RCG
Comfort Range
AIR CONDITIONING
INSTALLATION INSTRUCTIONS
DS 16 RCG
DS 18 RCG
DS 24 RCG


GC 16 RCC & 18/24 RCC-S
GC 16 RCC
GC 18 RCC-S
GC 24 RCC-S
DS / CAT. NO. 000000 / ENG REV. 0209/2003
DS MAN. MENU

2

DISCONNECTION OF THE MAIN
POWER SUPPLY IS MANDATORY
BEFORE OPERATING IN THE
ELECTRIC BOX
GENERAL RECOMMENDATIONS
SAFETY ADVICES
❒When you are operating on your equipment, follow the safety measures
in force.
❒Installation and maintenance of the units should be carried out exclusively
by qualified personnel.
❒Make sure that the main power supply and its frequency are adapted to
the power required for operation, taking into account specific conditions of
location and the power required for any other appliance connected with the
same circuit.
WARNING
❒Switch off the power supply before starting maintenance.
❒he manufacturer declines any responsibility and the warranty will be
void if these Installation Instructions are not respected.
If you meet difficulties please call the echnical Service of your area.
❒Before placing the appliance on its final location, assemble if possible the
accessories (see instructions provided with each accessory).
❒
DS MAN. MENU

3
SUMMARY
CONTENTS OF THE PARCEL 4
ELECTRICAL CONNECTION SPECIFICATIONS 5
GENERAL POINTS 7
INSTALLATION 7
INSTALLATION OF THE OUTDOOR UNIT 8
COOLING LINKING PIPES BETWEEN INDOOR UNIT
AND OUTDOOR UNIT 8
LAY-OUT OFTHE PIPES 8
VACUUM OFTHE COOLING PIPES AND INDOOR UNIT 8
ACCESSORIES AVAILABLE 9
ELECTRIC CONNECTIONS 9
AIR SUCTION AND DISTRIBUTION 9
CHECKING BEFORE STARTING OPERATION 9
MAINTENANCE 10
EXPLANATORY ILLUSTRATIONS (see last page of these instructions)
DS MAN. MENU

4
1 DS
1bagwithreferencematerial
1warranty certificate
2sheet metal angle brackets
1bag with screws : 4 screws headed H M6
4 flat washers 8 x 30
4 flat washers 6 x 18
4 silentblocs
1Infrared remote control
1Remote infrared receiver
2Configuration plugs
CONTENTS OF THE PARCEL
REFRIGERANT PIPE CONNECTIONS
16 18 24
GAS PIPE Ø Pipe
LIQUID PIPE Ø Pipe
Refregirent charge in the outdoor
unit (factory charged) and charge
to be added on site
According toQDPHSODWH in outdoor unit
SIZE
1/2"
1/4"
5/8"
3/8"
DS MAN. MENU

5
* IMPORTANT: Cables should be sized depending on regulations in force:
they depend on the mode of installation and type of wires.
ELECTRICAL CONNECTION SPECIFICATION
S
INDOOR DS 16 RCG
OUTDOOR GC 16 RCC
Power supply 1/230V/50Hz *
COOLING+VENTILATION
Main power supply cable section* 3CORES 3CORES 5CORES 3CORES 5CORES
Cable section between units* 6CORES 6CORES 6CORES 6CORES 6CORES
DEHUMIDIFICATION MODE
(COOLING+VENTILATION+REVERSE
CYCLE)
Main power supply cable section* 3CORES 3CORES 5CORES 3CORES 5CORES
Cable section between units* 6CORES 6CORES 6CORES 6CORES 8CORES
DS 18 RCG
GC 18 RCC-S
*
DS 24 RCG
GC 24 RCC-S
*
STANDARD / HEATPUMP
DS MAN. MENU

6
GENERAL POINTS
LOCATION
- Donotinstalltheindoorunitinroomswhereinflammable
gas or acid or alkaline substances are stocked. The
aluminumand copper evaporator and/or the internal
plasticcomponents could be damaged.
- Donot install theindoorunit in workshopsorkitchens
whereoilvapoursattractedbytreatedaircouldsetdown
on the evaporator of the indoor unit and change the
performanceordamagetheinternalplastic partsofthe
unit.
- Installation of the unit will be easier when using a lift-
truck.Usethebaseofthepackingbyplacingitbetween
theunitandthe forksofthe truck.
BEFORE INSTALLATON
- Theappliance canbeinstalled:
wallmounted
ceilingmounted
- Itisrecommendedtoplacetheunitascloseaspossible
toitsfinal locationbefore unpacking.
- Avidplacingheavytools orweightsonthe packedunit.
Checkassoonasthepackinghasbeenopenedthatno
accessoriesrequiredforthe installationaremissing.
DO NOT LIFT THE UNIT AT THE DRAIN PIPE OR
THE COOLING CONNECTIONS, BUT ONLY AT
THE 4 ANGLES.
INSTALLATION
- Mark the location of each support rod, the refrigerant
lines,thecondensatedischargepipe,thepowersupply
cables and the remote control unit cable (see the
dimensions Fig. 1a and 1b).
SELECTION OF PRESSURES
- Preselect the fanspeed according to the model, so as
to obtain the desired pressure by moving 3 wires on
the speed selection terminal box (see table Fig. 19).
- Fasten the appliance on the wall with 4 screws (not
supplied)(Fig. 4).
CEILINGMOUNTED
- Therods canbefixed depending onthe type ofceiling,
as shown in (Fig. 2).
- Connect the drain pipe and check once more that the
unit is in a horizontal position.
DRAININGOF CONDENSATES
- Inorder todrain the condensates,the downward slope
ofthe drain pipe shouldbe 1 cm per meterwithout any
narrowing passage (Fig. 6).
Furthermore a siphon at least 50 mm high should be
installed to avoid bad odours in the room.
- Installan auxiliary pump todrain the condensates and
a level controller, if needed, to drain the condensates
at a higher level than the unit.
WALL MOUNTED
- Position the unit with a airbulb level on the rods by
tighteningfirst thebolds onthe side(Fig. 3), thenplace
the rubber shockabsorbers (Fig. 5) andfinally tighten
the nuts and lock nuts of the threaded rods.
DS MAN. MENU

7
- Thedrainpipe shouldbeheat insulatedwithinsulation
material 5to 10 mm thick, such as polyurethane,
propylaneorneoprene,avoiding condensation.
- Ifseveralunitsareplacedintheroom,the drainsystem
maybe installed as shown in Fig. 7.
INSTALLATION OF THE OUTDOOR UNIT
Minimum clearance to provide for (in mm)
(Fig.
8 ):
Avoidrecycling, even partially, betweenair suction and
discharge.
Fastening on the floor:
The unit is meant to be fastened directly on the floor:
4 holes ∅10 (Fig. 9).
In certain cases shock absorbing blocks can be placed
under the legs (ref.PAULSTRA N°.520027 or similar).
Hanging on the wall:
Theoutdoorunit canbe hungon thewall witha wall
bracket(accessory).
In any case the distance clearance space
between the wall and inlet at the rear of
the condenser should be respected
REFRIGERANT CONNECTION PIPES BETWEEN
INDOOR UNIT AND OUTDOOR UNIT
Theindoorunitsare connectedwiththeoutdoorunitsby
means of flare linking pipes
(copper pipe of cooling quality equipped at their ends
withflarenutsand insulatedovertheir wholelength).
PREPARATION OFTHE PIPES
- Usecopperpipesofcooling qualityandofa∅adapted
toeach model(see tableon page4).
- The gas pipe and the liquid pipe must
beinsulatedwithinsulatingmaterialatleast6mmthick.
- Placethe flarenuts onthe pipe endsbefore preparing
themwitha flaretool.
- The separately insulated pipes and their couplings
canthen befastened to thedrain pipe andthe electric
wireswitha clamp.
INSTALLATION OF THE REFRIGERANT CONNECTION
PIPES
- Make a hole ∅80 mm in the wall to pass the pipes
linkingthe outdoor unit with the indoor unit (Fig. 12).
LAY-OUT OF THE PIPES
The bending radius of the pipes should be equal to or
more then3.5 tilmesthe diameterof thepipe (Fig. 11).
Donotbend thepipes morethan 3timesin arow anddo
not make more than 12 bends on the total length of the
linkingpipe.
Incase the succionpipe has avertical part exceeding 8
meters, it is IMPERATIVE to install a siphon every
3 meters when the GC is placed at a higher level
(Fig. 15).
VACUUM OF PIPES AND
INDOOR UNIT
Only the outdoor unit is charged with R407C refrigerant.
Theindoorunitcontainsasmall quantityofaneutralgas.
This the reason it is imperative to vacuum the linking
pipesand theindoor unit.
ASSEMBLY
The outdoor unit is equipped with a valve allowing to
vacuumtheinstallation(large valve):
1 - Connect the linking pipes with the outdoor and the
indoorunit.
To obtain the right tightening, cover the surface with
cooling oil (Fig. 16).
The use of a counter wrench is required
to tighten the valves (Fig. 14).
mmnisnoisnemiD 61SD18/24SD
From 100 150
005005
0100 150
004004
500
(see table below and Fig. 8 & 9).
rear
From
From
From
From
front
left
right
above 500
DS MAN. MENU

8
The values of the tightening torque are shown in the
tablebelow.
2- Connect thevacuum pump withthe flare couplingof
the outdoor unit equipped with a process valve (large
coupling).
3- Start thevacuum pump andcheck that the needleof
the indicator goes down to -0,1 Mpa (-76 cm Hg).
Thepumpshould runduring atleast 15minutes.
4 - Before disconnecting the vacuum pump, check that
thevacuumindicator remainsinthesamepositionduring
fiveminutes.
5- Disconnectthe vacuum pumpand close theprocess
valve.
6-Removethecapofthe"GAS"and"LIQUID"valvesand
open them with a hexagonal wrench to free the
R407C containedin theoutdoor unit.Put thecaps back.
7 - Check that the linking pipes are sealed. Use an
electronicleakdetector ora soapysponge.
ADJUSTMENT OF THE CHARGE
Adjustmentof thecharge maybe neededdepending on
thelengthof thelinkingpipes andon theindoorunit.
This operation should be done expertly by qualified
personnel (regrigeration engineer). The additional
charge is to be added through the process valve of the
flarecoupling ofthe outdooorunit (largecoupling).
Anyactiononthe coolingcircuitsrequires tocomplywith
theCECOMAF GT1-001 recommendations. (related to
thedischarge ofR407C intotheatmosphere).
sepipehtfoØ euqroT
epip"4/1 epip"8/3 epip"2/1 epip"8/5 epip"8/7
mN02-51 mN53-03 mN45-05 mN57-07 mN59-09
ELECTRIC CONNECTIONS
POWERSUPPLY
The power supply is connected with the outdoor unit
(except DS16).
This appliance is meant to be permanently connected
witha fixedcable.
See the electric diagrams on the appliance
(Fig. 21a, b and c).
The connection is made with the outdoor unit after
removalof panel A (Fig.13).
AIR SUCTION AND DISTRIBUTION
SEE ACCESSORIES page 6 and see last page
of these instructions.
AIR RENEWAL
- Lateralportsallowto install separated ductsforfresh
airsuction and discarge in aneighbouring room.
- Remove the anti-condensation insulation and the
prepunchedsheetmetaloftheportsbyusingapiercer:
BE CAREFUL not to damage the heat exchanger
located at the rear.
- Fill the space between the ducts and the edge of the
portswith anti-condensationinsulation. Usematerials
resistingat atemperature of60°C whenthe appliance
isincontinuousoperation.
- Theductscanbe flexiblewithaspring coreoracoreof
corrugated aluminum, insulated at the outside
(glassfibers12to 25mmthick).
- Whentheinstallationisfinishedallductsurfacesshould
be anti-condensation insulated (expanded
polystyrene,expandedneoprene,6mmthick).
NON COMPLIANCE WITH THESE INSTRUCTIONS
WILL CAUSE CONDENSATE
TO DRIP
CHECKING BEFORE STARTING
OPERATION
POWER SUPPLY VOLTAGE
The voltage and frequency of the power supply of the
appliance should be in conformity with the values
indicatedonthe identityplates ofthe indoorandoutdoor
unit.
DS MAN. MENU

9
ELECTRIC WIRES
Theappliancesare meantto bepermanently connected
withafixedelectriccable.Donotuseasocket,noraflexible
cable to supply power or to link the indoor unit with the
outdoorunit.
DRAINING OF CONDENSATES
Check that the drain works efficiently by pouring water
intothecondensingtrayofthe indoorunit.Checkthatthe
couplings are sealed and heat insulated if necessary
drainpipeforprotectionagainstfreezingorcondensation.
CONNECTIONCOUPLINGS
Checkwithanappropriatedetectorthatthecoolinglinking
pipes are sealed, in particular the connecting valves of
theoutdoor unit.Check that thepipes are perfectlyheat
insulated.
CROSSING A WALL (Fig. 12)
Check that the passage of the pipes is sealed, in case
theypassthrough anoutsidewall.
Checkthat thelinking pipesdo not touchthe wall.
FASTENING
Check that the indoor and outdoor units are solidly
fastened.Putbacktheelements previouslyremoved.
MAINTENANCE
Beforeanyaction, SWITCH OFF thepowerswitch.
Theairfilter ismade ofacrylic fibersand canbe cleaned
withwater.
CHECK REGULARLY AND BEFORE THE
SEASON THAT THE AIR FILTER IS CLEAN
AFTER LONG PERIODS OF NON-OPERATION
Beforeputting theappliance again inoperation:
- Checkandcleanthe outdoorunit,inparticular theheat
exchanger.
- Cleanorreplace theairfilters ofthe indoorunit.
- Checkandcleanthe condensingtrayof theindoorunit
aswellas theoutdoorunits ofthe heatpump.
- Checkthat electricconnections aretight.
NOTE:
Iftheoutdoorunitisequippedwithacrankcaseheater on
the compressor, put the compressor under power 12
hoursbeforeputting thesystem intooperation.
SWITCH OFF THE REMOTE CONTROL OF THE
AIR TREATEMENT UNIT AND SWITCH ON THE
POWER SUPPLY
DS MAN. MENU

10
FIG. 1a, 1b
Electricbox 250×190X70
Drainof condensates
Filtre
Filtre
Freshair intakeØ 125
Freshair intake Ø100
Flarecoupling
830X215X8
1160 X 215 X 8
Flarecoupling
250 X 190 X 70
DS 16/18 RCG
DS 24 RCG
DS MAN. MENU

11
A = 30 max.
A= max. 30
A = 30 máx.
Silentbloc
Largewasher
Nut
Counter-nut
Heatinsulateddrainpipe
Slopeof1 cm/m
NO NO
FIG. 6
FIG. 5
FIG. 4
FIG. 2 FIG. 3
DS MAN. MENU

12
Connection on the top of the pipe
Right Wrong
R
FIG. 8: GC18 & 24RCG
FIG. 7
FIG. 9: GC16RCG
FIG. 11
FIG. 12
FIG. 10
760
544
472 58
48
220
236
260
88.5
58
WIRING
CONNECTIONS
SUCTION TUBE
(FLARED)
LIQUID TUBE
(FLARED)
VALVE
CONNECTIONS
AIR INTAKE
AIR OUTLET
237
50
843
690
545
490
302
350
151.5 151.5
300
325
370
WIRING
CONNECTIONS
103
90
75
AIR INTAKE
AIR OUTLET
330
50
R≥ 3,5 ∅
R≥3,5
DS MAN. MENU

13
A "GAS" pipe
B "LIQUID" pipe
Linking > 9 meters
GC
ST
Hmax.= 10m
A
FIG. 15
FIG. 13
FIG. 14
FIG. 16
DS MAN. MENU

14
A "GAS" pipe
B "LIQUID" pipe
C Flare nut
D Pipe insulation
E Insulating sleeve
D
A
B
CE
GC
ST
Grilleof decompression
FIG. 17
FIG. 18
DS MAN. MENU

15
Tableofhigh speedpressure
ABC
H M L H M L H M L
BU GY RD VT BU RD BK VT BU
DS 16/18 RCG
Correspondanceofconnection
EXAMPLE:To obtain a pressure of a 3 mm water column for a DS16 RCG .
Inthetableofpressures:spotthelettercorrespondingwiththedesiredpressure (B).Inthetableofconnections:
spot in column Bthe wires to be connected with the terminal. strip: H-> VT; M-> BU; L->RD.
BK BLACK OG ORANGE
BU BLUE RD RED
SPEED SELECTION TERMINAL BOARD
ABC
S16 RCGD
m016
3
h/ 200 Pa 400 Pa 667 Pa
S18 RCGD
m086
3
h/ 133 Pa 333 Pa 533 Pa
AB
Õ
CD
4 RCG2SD
m029 h/ .266 Pa 400 Pa 933 Pa 1466 Pa
ABCD
H M L H M L H M L H M L
GY BN RD OG VT RD WH OG BN BK WH GY4 RCG2SD
FIG. 19
GY GRAY BN BROWN
WT WHITE VT VIOLET
DS MAN. MENU

16
45 mm
avecles2visfournies.
Fasten the bracket of the remote control on the wall.
For connection and "How to Use", see MURC 715 supplied with the appliance
Press gently on the clips to remove the cover
PC Assembly
8 RED
7GREY
6 WHITE
5GREEN
4 BROWN
3YELLOW
2ORANGE
1GOLDBRAID
- A 7m shielded cable with connectors at
bothendsis provided with theequipment
forinterconnecting the controlpanel and
infrared receiver.
- In case of difficulties with the connector,
cut it off the cable and wire the cable
directly on the infrared receiver terminal
board.
- In this case, follow the color codes
shown on the terminal board,
corresponding to the 7 cable
conductors plus the bonding braid, to
be connected to the last terminal,
marked Gd.
- To guarantee satisfactory connection,
fit the cable ends with terminals for a
0.25 mm² size .
A longer length can be provided on special request.
FIG. 20
DS MAN. MENU

17
GTW)
*1 N ~ 230 V
50 Hz
7
6
4
N
3
L
6
5
4
N
3
L
L1
8
9
Sensor wire coming from the DS
DS 16 RCG GC 16 RCC
FIG. 21a
DS MAN. MENU

18
GTW)
7
6
4
N
3
L
6
5
4
N
3
L
L1
8
9
* 1 N ~ 230 V
50 Hz
Sensor wire coming from the DS
DS 18 RCG GC 18 RCC-S
FIG. 21b
DS MAN. MENU

19
N
DS 24 RCG GC 24 RCC-S
1 N ~ 230 V
4
5
6
Y
6
5
4
N
3
N
3
L3
X
7
L2
L
L1
L
N
L
8
9
- - - - Withelectric heating.
FIG. 21c
ensor wire co ing fro the
DS MAN. MENU

Single Phase units Power to Indoor Unit
Model Interconnecting Cable
Wires (mm2) Circuit Breaker
(without Heating Element) Maximum Current
GC16RCC5 x 2.5 20 A 10.7
GC18RCC-S 5 x2.5 20 A 11.4
Use power supply wire sizes as per local electrical codes and regulations.
Figure 22a. Single PhaseUnits:Electrical Scheme powersupply toindoor
Single Phase units Power to Outdoor Unit
Model Interconnecting Cable
Wires (mm2) Circuit Breaker
(without Heating Element) Maximum Current
GC24RCC-S 6 x 2.5 20 A 14.3
Use power supply wire sizes as per local electrical codes and regulations.
Figure 22b.Single PhaseUnits: Electrical Scheme power to outdoor.
20
DS MAN. MENU
