AISWEI ASW08KH-T1 User manual

2023 Version: V02
(For ASW08KH-T1 ，ASW10KH-T1 ，ASW12KH-T1)
AiSWEI Technology (Shanghai) Co.,Ltd.
www.solplanet.net

Three phase Hybrid Inverter User Manual
1
Catalog
1 Notes on this Manual ...........................................................................................................................................4
1.1 Scope of Validity........................................................................................................................................ 4
1.2 Target Group .............................................................................................................................................4
1.3 Symbols Used............................................................................................................................................ 4
2 Safety ..................................................................................................................................................................... 4
2.1 Important Safety Instructions...................................................................................................................4
2.2 Battery Safety Instructions ......................................................................................................................7
2.3 Notes on this Manual Explanation of Symbol ......................................................................................7
2.4 CE Directives ............................................................................................................................................. 8
3 Introduction ........................................................................................................................................................... 8
3.1 Basic features.............................................................................................................................................8
3.2 Simple schematic diagram of system wiring ........................................................................................8
3.3 System Diagram ....................................................................................................................................... 9
3.4 Work Modes............................................................................................................................................. 10
3.4.1 Work modes: Self-consumption mode .....................................................................................................................10
3.4.2 Work modes: Custom mode....................................................................................................................................... 10
3.4.3 Work modes: Reserve power mode ......................................................................................................................... 11
3.4.4 Off-grid mode ............................................................................................................................................................... 12
3.5 Dimension.................................................................................................................................................12
3.6 Terminals of Hybrid inverter ................................................................................................................. 12
4 Technical Data ....................................................................................................................................................14
5 Installation............................................................................................................................................................ 16
5.1 Check for Physical Damage ................................................................................................................. 16
5.2 Packing List ............................................................................................................................................. 16
5.3 Mounting ...................................................................................................................................................17
5.3.1 Installation Guide .........................................................................................................................................................17
5.3.2 Space Requirement .................................................................................................................................................... 18
5.3.3 Mounting Steps ............................................................................................................................................................ 18
6 Electrical Connection .........................................................................................................................................19
6.1 Grid Connection.......................................................................................................................................19
6.2 PV connection..........................................................................................................................................20
6.3 BACKUP Connection..............................................................................................................................21

Three phase Hybrid Inverter User Manual
2
6.4 Battery Connection .................................................................................................................................23
6.5 CT Connection......................................................................................................................................... 24
6.6 DRM Connection .................................................................................................................................... 25
6.7 Wi-Fi Connection .................................................................................................................................... 25
6.8 RS485 Connection .................................................................................................................................25
6.9 Inverter Manipulation ............................................................................................................................. 26
6.10 Instructions for LED Indicator .............................................................................................................27
7 Fault diagnosis and solutions .......................................................................................................................... 27
Contact information................................................................................................................................................31

Three phase Hybrid Inverter User Manual
3
For the latest documents in all supported languages, please visit:
www.solplanet.net
Read this entire document before installation.
PRODUCT SPECIFICATIONS
All specifications and descriptions contained in this document are verified to be accurate at the time of
printing. However, because continuous improvement is a goal at SOLPLANET, we reserve the right to make product
modifications at any time.
The images provided in this document are for demonstration purposes only. Depending on product version and market
region, details may appear slightly different.
ERRORS OR OMISSIONS
To communicate any inaccuracies or omissions in this manual, send an email to
[e-mail]
ELECTRONIC DEVICE: DO NOT THROW AWAY
Proper Disposal of batteries is required. Refer to your local codes for disposal requirements
MADE IN CHINA
Copyright © AISWEI Technology (Shanghai) Co., Ltd. 2022. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of
AISWEI Technology (Shanghai) Co., Ltd.
Trademarks and Permissions
and other AISWEI trademarks are trademarks of AISWEI Technology (Shanghai) Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
The information in this document is subject to change without notice. Every effort has been made in the preparation of this
document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do
not constitute a warranty of any kind, express or implied.
All other trademarks contained in this document are the property of their respective owners and third use herein does not
implysponsorship or endorsement of third products or services. The unauthorized use of any trademark displayed in this
document or on the product is strictly prohibited.

Three phase Hybrid Inverter User Manual
4
1 Notes on this Manual
1.1 Scope of Validity
This manual is an integral part of solplanet three phase hybrid inverter, it describes the assembly, installation,
commissioning, maintenance and other information of the product. Please read it carefully before operating.
The descriptions in this manual are applicable to the following models of inverters:
ASW08KH-T1
ASW10KH-T1
ASW12KH-T1
1.2 Target Group
This manual is for qualified electricians. The tasks described in this manual only can be performed by qualified
electricians.
1.3 Symbols Used
The following types of safety instructions and general information appear in this document as described below:
Indicates a hazard with a high level of risk which, if not avoided, will result in death
or serious injury.
Indicates a hazard with a medium level of risk which, if not avoided, could result in
death or serious injury.
Indicates a hazard with a low level of risk which, if not avoided, could result in
minor or moderate injury
Indicates a potentially hazardous situation which, if not avoided, could result in
equipment damage, data loss, performance deterioration, or unanticipated results.
Notice is used to address practices not related to personal injury.
Supplements the important information in the main text. NOTE is used to address
information not related to personal injury, equipment damage, and environment
deterioration.
2 Safety
2.1 Important Safety Instructions
Danger to life due to high voltages in the inverter! All work must be carried out by qualified electrician.
The appliance is not to be used by children or persons with reduced physical sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given supervision or instruction.
Danger of burn injuries due to hot enclosure parts!
During operation, the upper lid of the enclosure and the enclosure body may become hot.
Possible damage to health as a result of the effects of radiation!
Do not stay closer than 20 cm to inverter for any length of time.

Three phase Hybrid Inverter User Manual
5
Grounding the PV generator.
Comply with the local requirements for grounding the PV modules and the PV generator. It is recommends
connecting the generator frame and other electrically conductive surfaces in a manner which ensures continuous
conduction and ground these in order to have optimal protection of system and persons.
Ensure input DC voltage ≤Max. DC voltage. Overvoltage may cause permanent damage to inverter or other losses,
which will not be included in warranty!
Authorized service personnel must disconnect both AC and DC power from inverter before attempting any
maintenance or cleaning or working on any circuits connected to inverter.
Do not operate the inverter when the device is running.
Risk of electric shock!
Prior to the application, please read this section carefully to ensure correct and safe application. Please keep the
user manual properly.
Accessories only together with the inverter shipment are recommended. Otherwise, may result in a risk of fire,
electric shock, or injury to person.
Make sure that existing wiring is in good condition and that wire is not undersized.
Do not disassemble any parts of inverter which are not mentioned in installation guide. It contains no user-
serviceable parts. See Warranty for instructions on obtaining service. Attempting to service the inverter yourself may
result in a risk of electric shock or fire and will void your warranty.
Keep away from flammable, explosive materials to avoid fire disaster.
The installation place should be away from humid or corrosive substance.
Authorized service personnel must use insulated tools when installing or working with this equipment.
PV modules shall have an IEC 61730 class A rating.
Never touch either the positive or negative pole of PV connecting device. Strictly prohibit touching both of them at the
same time.
The unit contains capacitors that remain charged to a potentially lethal voltage after the MAINS, battery and PV
supply has been disconnected.
Hazardous voltage will present for up to 5 minutes after disconnection from power supply.
CAUTION-RISK of electric shock from energy stored in capacitor, never operate on the inverter couplers, the MAINS
cables, Battery cables, PV cables or the PV generator when power is applied. After switching off the PV, battery and
Mains, always wait for 5minutes to let the intermediate circuit capacitors discharge before unplugging DC, battery in

Three phase Hybrid Inverter User Manual
6
plug and MAINS couplers.
When accessing the internal circuit of inverter, it is very important to wait 5 minutes before operating the power circuit
or demounting the electrolyte capacitors inside the device. Do not open the device beforehand since the capacitors
require time sufficiently discharge!
Measure the voltage between terminals UDC+ and UDC- with a multi-meter (impedance at least 1M ohm) to ensure
that the device is discharged before beginning work (35VDC) inside the device.
Surge protection devices (SPDs) for PV installation
Over-voltage protection with surge arresters should be provided when the PV power system is installed.
Lightning will cause a damage either from a direct strike or from surges due to a nearby strike.
Induced surges are the most likely cause of lightning damage in majority or installations, especially in rural areas
where electricity is usually provided by long overhead lines. Surge may be included on both the PV array conduction
and the AC cables leading to the building.
Specialists in lightning protection should be consulted during the end use application.
Using appropriate external lightning protection, the effect of a direct lightning strike into a building can be mitigated in
a controlled way, and the lightning current can be discharged into the ground.
Installation of SPDs to protect the inverter against mechanical damage and excessive stress include a surge arrester
in case of a building with external lightning protection system (LPS) when separation distance is kept.
To protect the DC system, surge suppression device (SPD type2) should be itted at the inverter end of the DC
cabling and at the array located between the inverter and the PV generator, if the voltage protection level (VP) of the
surge arresters is greater than 1100V, an additional SPD type 3 required for surge protection for electrical devices.
To protect the AC system, surge suppression devices (SPD type2) should be itted at the main incoming point of AC
supply (at the consumer’s cutout), located between the inverter and the meter/distribution system; SPD (test impulse
D1) for signal in according to EN 61632-1.
All DC cables should be installed to provide as short a run as possible, and positive and negative cables of the string
or main DC supply should be bundled together.
Avoiding the creation of loops in the system.
Spark gap devices are not suitable to be used in DC circuits once conducting, they won’t stop conducting until the
voltage across their terminals is typically more than 30 volts.
Anti-Islanding Effect
Islanding effect is a special phenomenon that grid-connected PV system still supply power to the nearby grid when
the voltage loss is happened in the power system. It is dangerous for maintenance personnel and the public.
PE Connection and Leakage Current
High leakage current!
Earth connection essential before connecting supply.
Incorrect grounding can cause physical injury, death or equipment malfunction and increase electromagnetic.
Make sure that grounding conductor is adequately sized as required by safety regulations.

Three phase Hybrid Inverter User Manual
7
Do not connect the ground terminals of the unit in series in case of a multiple installation. This product can
cause current with a d.c component,where a residual current operated protective (RCD) or monitoring (RCM)
device is used for protection in case of direct or indirect contact, only an RCD or RCM of type B is allowed on
the supply side of this product.
2.2 Battery Safety Instructions
ASW H-T1 Series hybrid inverter should be worked with high voltage battery, for the specific parameters such as battery
type, nominal voltage and nominal capacity etc.
As accumulator batteries may contain potential electric shock and short-circuit current danger, to avoid accidents that
might be thus resulted, the following warnings should be observed during battery replacement:
1) Do not wear watches, rings or similar metallic items.
2) Use insulated tools.
3) Put on rubber shoes and gloves.
4) Do not place metallic tools and similar metallic parts on the batteries.
5) Switch offload connected to the batteries before dismantling battery connection terminals.
6) Only personal with proper expertise can carry out the maintenance of accumulator batteries.
2.3 Notes on this Manual Explanation of Symbol
This section gives an explanation of all the symbols shown on the inverter and the label.
Symbols on the Type Label
Symbol
Explanation
CE Mark
The inverter complies with the requirements of the applicable CE
guidelines.
TUV certified.
RCM Mark
Certification.
Beware of hot surface.
The inverter can become hot during operation. Avoid contact during
operation.
Danger of high voltages.
Danger to life due to high voltages in the inverter!
Risk of electric shock!
Observe enclosed documentation
The inverter cannot be disposed together with the household waste. Disposal information
can be found in the enclosed documentation。
Do not operate this inverter until it is isolated from battery, mains and on-site PV generation
suppliers.

Three phase Hybrid Inverter User Manual
8
Danger to life due to high voltage.
There is residual voltage existing in the inverter after powering off .
which needs 5 min to discharge.
Wait 5 min before you open the upper lid or the DC lid.
2.4 CE Directives
This chapter follows the requirements of the European low voltage directives, which contains the safety instructions and
conditions of acceptability for the endues system, which you must follow when installing, operating and servicing the unit.
The Grid connected inverter meets the requirement stipulated in Low Voltage Directive (LVD) 2014/35/EU and
Electromagnetic Compatibility (EMC) Directive 2014/30/EU. The grid connected inverter leave the factory completely
connecting device and ready for connection to the mains and PV supply, the unit shall be installed in accordance with
national wiring regulations. Compliance with safety regulations depends upon installing and configuring system correctly,
including using the specified wires.
The system must be installed only by professional assemblers who are familiar with requirements for safety and EMC. The
assembler is responsible for ensuring that the end system complies with all the relevant laws in the country where it is to
be used.
3 Introduction
3.1 Basic features
ASW H-T1 Series hybrid inverter is a high-quality inverter which can convert solar energy to AC energy and store energy
into battery.
The inverter can be used to optimize self-consumption, store in the battery for future use or feed into public grid. Work
mode depends on PV energy and user’s preference. It can provide power for emergency use during the grid lost by using
the energy from battery and inverter generated from PV.
3.2 Simple schematic diagram of system wiring
ASW H-T1 Series hybrid inverter is designed with two BACKUP interface for customer to choose based on the local rules.
ASW H-T1 Series hybrid inverter applies to the wiring rules that requires the Live line and Neutral line of BACKUP must be
disconnected with the Live line and Neutral line of grid (applies to most countries).

Three phase Hybrid Inverter User Manual
9
The wiring diagram is for reference only, and the complete electrical connection shall meet the requirements of local
regulations.
Please control the home loads, and make sure it’s within the “BACKUP output rating” under BACKUP mode,
otherwise the inverter will shut down with an “overload fault” warning.
Please confirm with the mains grid operator whether there are any special regulations for grid connection.
3.3 System Diagram
The arrow on the CT points from inverter to the public grid, as shown.
As shown in the figure, the CT1 line is yellow, the CT2 line is green, and the CT3 line is red.
Do not misconnect the phase sequence.
Backup load is connected to Backup1 or Backup2 port.
Because the length of CT line is limited, the inverter needs to be installed near the parallel dot, otherwise the

Three phase Hybrid Inverter User Manual
10
anti-countercurrent function cannot be used.
Please control the home loads, and make sure it’s within the “BACKUP output rating” under BACKUP mode,
otherwise the inverter will shut down with an “overload fault” warning.
Please confirm with the main grid operator whether there are any special regulations for grid connection.
BACKUP1 for very important load, BACKUP2 for important or normal load.
When power is outage or when there is no grid power .
1) If the battery does not report low voltage or undervoltage alarm, the inverter will supply power to both
BACKUP1 and BACKUP2.
2) If battery voltage is too low for full load or undervoltage alarm, the inverter only can supplies power to
BACKUP1.
Inverter provides multiple work modes based on different requirements.
3.4.1 Work modes: Self-consumption mode
3.4.1.1 When PV, Grid, Battery is available
1 ) Solar energy provides power to the loads as fi rst priority, if solar energy is suffi cient to power all connected loads,
solar energy excess power will provide to charge battery, and then redundant power will feed to grid .
2 ) Solar energy provides power to the loads as first priority , if solar energy and battery are not sufficient to power all
connected loads, utility energy ( Main Grid) will supply power to the loads with solar energy at the same time .
3.4.1.2 When PV, Grid is available (without battery):
3) Solar energy provides power to the loads as first priority, if solar energy is sufficient, the excess power will feed to
grid.
4) Solar energy provides power to the loads as first priority, if solar energy is not sufficient to power all connected
loads, Grid energy will supply power to the loads at the same time.
3.4.2 Work modes: Custom mode
3.4.2.1 When PV, Grid, Battery is available:
5) On charge time, solar energy will charge battery as first priority . The excess energy will supply power to the loads.
If solar energy is sufficient to supply loads and charge battery, and If there's still some extra energy, then the
excess power will feed the power to grid

Three phase Hybrid Inverter User Manual
11
6) On charge time, solar energy will charge battery as irst priority. Then the excess solar energy will supply power to
loads. If solar energy is not sufficientto charge battery and supply loads, grid will supply all the connected loads
with solar energy together.
7) On discharge time, solar energy provides power to the loads as first priority, if solar energy is sufficient to supply
loads, and if there's still some extra energy from solar energy, then the excess power and battery will deliver the
power to the grid at the same time.
8) In the period of no charge or discharge, the solar power supply loads at first priority, excess energy to the grid.
3.4.2.2 When Grid, Battery is available (PV is disconnected)
9) On charge time, grid will charge battery and supply power to the connected loads at the same time.
1 0) On discharge time, if load power is less than battery power, battery will supply power to loads as first priority,
the excess power will be feed to grid.
11) On discharge time, if load power is more than battery power, battery and grid will supply power to the loads at
the same time.
3.4.3 Work modes: Reserve power mode
3.4.3.1When PV, Grid, Battery is available:
12) Solar energy will charge battery as first priority, if solar energy is excess, the excess power will supply load. If there's
still some extra energy, then the excess power will feed the power to grid.
13) Solar energy will charge battery as first priority, if solar energy is excess, the excess power will supply load. If solar
energy is not sufficient to charge battery and supply loads, grid will supply power to loads.

Three phase Hybrid Inverter User Manual
12
3.4.3.2 When Grid, Battery is available (PV is disconnected)
14) Grid will supply power to load and charge battery at the same time.
If set anti-Reverse function allowable, once on the work mode of Self- use, Peak shift, battery priority, the system will not
feed power to grid.
3.4.4 Off-grid mode
3.4.4.1 When PV, Battery is available Grid is disconnected):
15) A. Solar energy provides power to the loads as irst priority, if solar energy is sufficient to power all connected
loads, solar energy will provide to charge battery .
16) B. Solar energy provides power to the loads as irst priority, if solar energy is not sufficient to power all connected
loads, battery energy and solar energy will supply power to the loads at the same time.
3.5 Dimension
Unit: mm
3.6 Terminals of inverter

13
This plugs are reserved
Function
label
Description
PV string 1 Input port
PV1+
PV string 1 positive input
PV1-
PV string 1 negative input
PV string 2 Input port
PV2+
PV string 2 positive input
PV2-
PV string 2 negative input
Communication interface
COM1
RS485 port
COM2
WI-FI stick interface
BAT Port
BAT+
Battery positive input
BAT-
Battery negative input
Signal line interface
UPDATE
Upgrading software Ports
DRM
Function temporarily retained
CT
Connect to CT (current transformer)
DRY IO
Dry contact
BMS
BMS communication to Battery
CAN
CAN communication
NTC
NTC detection
Grid
①
Grid line A phase
②
Grid line B phase
③
Grid line C phase
④
Grid line Neutral
⑤
Grid line PE
GEN
( Diesel generator function is
unreleased currently)
⑥
GEN line A phase
⑦
GEN line B phase
⑧
GEN line C phase
⑨
GEN line Neutral
⑩
GEN line PE
Backup1
⑪
Backup1 line A phase
⑫
Backup1 line B phase
⑬
Backup1 line C phase
⑭
Backup1 line Neutral ，
⑮
Backup1 line PE
Backup2
⑯
Backup2 line A phase
⑰
Backup2 line B phase
⑱
Backup2 line C phase
⑲
Backup2 line Neutral
⑳
Backup2 line PE
Three phase Hybrid Inverter User Manual

Three phase Hybrid Inverter User Manual
14
Qualified electrician will be required for the installation.
4 Technical Data
Model
ASW08kH-T1
ASW10kH-T1
ASW12kH-T1
PV Input
Max. PV array power
12 kWp STC
15 kWp STC
18 kWp STC
Max. input voltage
1000 V
MPP voltage range
180 V ~ 850 V
Min. input voltage / start voltage
125V/180V
No. of independent MPPT trackers /
strings per MPPT input
2 / (1/1)
Max. input current per MPP tracker
13 A
Max. short-circuit current per MPP
tracker
25A
Battery
Battery type
Lithium-ion
Battery voltage range
125 V ~ 600 V
Max. charging current / Max.
discharging current
50 A / 50A
Rated. charging current / Rated.
discharging current
40A/40A
AC output
Nominal AC voltage
3W+N+PE, 220 / 380 V; 230 / 400 V; 240 / 415 V
AC voltage range
360V~440V
Rated AC grid frequency
50 Hz / 60 Hz
AC grid frequency range
50 Hz±5Hz / 60 Hz±5Hz
Rated active power
8 kW
10 kW
12 kW
Rated apparent power
8 kVA
10 kVA
12 kVA
Max. apparent power
8.8 kVA
11 kVA
13.2 kVA
Rated grid output Current (@400V)
11.6 A
14.5 A
17.4 A
Max. grid output current
12.7A
15.9A
19.1A
Harmonics THDi (@ Nominal power)
< 3%
AC input
Rated grid voltage
3W+N+PE, 220 / 380 V; 230 / 400 V; 240 / 415 V
Rated grid frequency
50Hz / 60Hz
Rated apparent power
16 kW
20 kW
24 kW
Max. input apparent power from grid
17.6 kVA
22 kVA
26.4 kVA
Rated input current from grid
23. 1 A
28.9A
34.7 A
Max. input current from grid
25.5 A
31.8A
38.2 A
BACKUP
output
Nominal output voltage
3W+N+PE, 220 / 380 V; 230 / 400 V; 240 / 415 V
Nominal output frequency
50 Hz / 60 Hz
Rated apparent power
8 kVA
10 kVA
12 kVA
Max. output apparent power
8 kVA
10 kVA
12 kVA

Three phase Hybrid Inverter User Manual
15
Model
ASW08kH-T1
ASW10kH-T1
ASW12kH-T1
Peak output apparent power
8.8kVA
11kVA
13.2kVA
Rated Current (@400V)
11.6 A
14.5 A
17.4 A
Max. output current
12.7A
15.9A
19.1A
Max. switch time
≤20 ms
Output THDi (@ Linear load)
<2%
Efficiency
MPPT efficiency
≥99.5%
Max efficiency
97.90%
98.20%
98.20%
Euro efficiency
97.20%
97.50%
97.50%
Max. battery to load efficiency
96.50%
96.50%
96.60%
Safety
protection
DC-side disconnection device
●
PV string- / Battery input reverse
polarity protection
● / ●
All-pole sensitive residual current
monitoring unit
●
Anti-islanding protection
●
AC output over current protection
●
AC output short circuit current
protection
●
AC over voltage protection
●
Protection class (as per IEC 62109-
1)
I
overvoltage category (as per IEC
62109-1)
AC: III; DC: II
General
data
Power factor at rated power /
adjustable displacement
≥0.99 / 0.8 leading to 0.8 lagging
Dimensions (W / D / H)
570 / 200 / 600 mm
Device weight
35 kg
36kg
Installation
Wall-mounted
Operating temperature range
-25 °C~+60 °C
Noise emissions (typical)
< 35 dB(A)
Standby consumption
< 3 W
Cooling concept
Natural convection
Ingress protection rating (as per IEC
60529)
IP65
Climatic category (according to IEC
60721-3-4)
4K4H
Max. permissible value for relative
humidity
0~95%
(non-condensing)
Max. operating altitude
4000m (>2000m power derating)
Country of Manufacture
THE PEOPLE' S REPUBLIC OF CHINA

Three phase Hybrid Inverter User Manual
16
Model
ASW08kH-T1
ASW10kH-T1
ASW12kH-T1
Features
Inverter topology (Solar/ battery)
Transformer less / Transformer less
User interface
LED & App
Communication with BMS
RS485 / CAN
Communication with meter
RS485
Communication with portal
WIFI stick
Integrated power control / Zero
export control
● / ●
Standard
Compliance
Grid
EN 50549- 1, RfG 3
Safty
EN 62109-1, EN 62109-2
EMC
IEC 61000-6- 1/-2/-3/-4, IEC 61000-3- 11, IEC61000-3- 12
The certification will continue to increase
5 Installation
5.1 Check for Physical Damage
Make sure the inverter is intact during transportation. If there is any visible damage, such as cracks, please contact your
dealer immediately.
5.2 Packing List
Open the package and take out the product, please check the accessories first. The packing list shown as below.
C
F
G
A
D
E
B

Three phase Hybrid Inverter User Manual
17
Object
Description
A
Inverter
B
Bracket
C
Expansion screws and pan-head screws
D
PV connectors (2*positive, 2*negative)
E
WIFI stick (optional)
F
User manual
G
Current transformer
5.3 Mounting
5.3.1 Installation Guide
ASW H-T1 Series hybrid inverter is designed for outdoor installation (IP 65). Make sure the installation site meets the
following conditions:
1) Not in direct sunlight.
2) Not in areas where highly flammable materials are stored.
3) Not in potential explosive areas.
4) Not in the cool air directly.
5) Not near the television antenna or antenna cable.
6) Not higher than altitude of about 2000m above sea level.
7) Not in environment of precipitation or humidity (＞95%).
8) Under good ventilation condition.
9) The ambient temperature in the range of -20℃ to +60℃ .
10) The slope of the wall should be within ± 5° .
11) The wall hanging the inverter should meet conditions below:
solid brick/concrete, or strength equivalent mounting surface.
Inverter must be supported or strengthened if the wall’s strength isn’t enough (such as wooden wall, the
wall covered by thick layer of decoration)
Please AVOIDE direct sunlight, rain exposure, snow laying up during installation and operation.

Three phase Hybrid Inverter User Manual
18
5.3.2 Space Requirement
Position
minimum spacing
Left
300mm
Right
300mm
Top
300mm
Bottom
300mm
5.3.3 Mounting Steps
5.3.3.1 Tools required for installation.
Installation tools: crimping pliers for binding post and RJ 45, screwdriver, manual wrench etc.
Step 1: Screw the wall bracket on the wall
Place the bracket on the wall and mark down the position of the 4 holes.
Drill holes with driller, make sure the holes are deep enough (at least 60mm) to support the inverter.
Install the expansion tubes in the holes and tighten them. Then install the wall bracket with the expansion
screws.
Step 2: Place the inverter on the wall mounted bracket by holding the handle on the side.

Three phase Hybrid Inverter User Manual
19
Step 3: Tighten the ixing screws on both sides of the inverter.
Step 4: If necessary, customer can install an anti-theft lock on the left-bottom of the inverter.
6 Electrical Connection
6.1 Grid Connection
ASW H-T1 Series hybrid inverter is designed for three phase grid Voltage is 380/400V, frequency is 50/60Hz.
Table 4 Cable and Micro-breaker recommended
Inverter
ASW08kH-T1
ASW10kH-T1
ASW12kH-T1
Cable
4~6 mm²
6~10 mm²
Micro-breaker
20A
32A
32A
Note:
Copper cable is recommended.
If aluminum core cable is used, the cable with larger cross-sectional area shall be selected.
Micro-breaker should be installed between inverter and grid, any load should not be connected with inverter
directly.
Connection Steps:
1 ) Step1. Check the grid voltage.
Check the grid voltage and compare with the permissive voltage range (Please refer to technical data).
Disconnect the circuit board from all the phases and secure against re-connection.
2 ) Step2. Remove the waterproof lid from the grid port on the inverter.
3 ) Step3. Make AC wires.
Choose the appropriate wire (Cable size: refer to Table 4).
Reserve about 60mm of conductor material sectional area.
Remove 10mm of insulation from the end of wire.
