Aiviq AGC-201 User manual

AUTOMATIC COFFEE
MAKER WITH GRINDER
MODEL NR: AGC-201
EN - READ ALL THE INSTRUCTIONS BEFORE USING
DK - LÆS ALLE INSTRUKTIONERNE FØR BRUG
SE - LÄS ALLA INSTRUKTIONER INNAN DU ANVÄNDER
NO - LES ALLE INSTRUKSJONENE FØR BRUK
APPLIANCES
®

01. GENERAL INTRODUCTION
02. IMPORTANT SAFEGUARDS
03. WHAT'S IN THE BOX
04. TECHNICAL SPECIFICATIONS
05. INSTALLATION
06. LCD INDICATORS
07. BUTTONS
08. FIRST USE
09. MAKING COFFEE WITH WHOLE BEANS
10. MAKING COFFEE WITH PRE-GROUND BEANS
11. SETTING THE PROGRAM TIME
12. SETTING THE AUTOMATIC SHUTOFF TIME
13. DESCALING
14. TO CLEAN GRINDER
15. FOOD CONTACT MATERIAL LIST
16. TRANSPORTATION AND DISPOSAL
17. NOTICE DURING DAILY USE AND MAINTENANCE
18. TROUBLESHOOTING
19. WARRANTY AND LIABILITY
01
01
03
04
05
05
06
07
08
10
10
11
12
14
15
16
16
16
18
CONTENTS
01
EN
01. GENERAL INTRODUCTION
02. IMPORTANT SAFEGUARDS
03. WHAT'S IN THE BOX
04. TECHNICAL SPECIFICATIONS
05. INSTALLATION
06. LCD INDICATORS
07. BUTTONS
08. FIRST USE
09. MAKING COFFEE WITH WHOLE BEANS
10. MAKING COFFEE WITH PRE-GROUND BEANS
11. SETTING THE PROGRAM TIME
12. SETTING THE AUTOMATIC SHUTOFF TIME
13. DESCALING
14. TO CLEAN GRINDER
15. FOOD CONTACT MATERIAL LIST
16. TRANSPORTATION AND DISPOSAL
17. NOTICE DURING DAILY USE AND MAINTENANCE
18. TROUBLESHOOTING
19. WARRANTY AND LIABILITY
01
01
03
04
05
05
06
07
08
10
10
11
12
14
15
16
16
16
18
CONTENTS

02
EN
01.General Introduction
This is a countertop drip coffee machine. The coffee beans are ground and
brewed to extract coffee with a mellow taste. The coffee strength is adjustable,
the maximum cup size is 12 cups and the filter can be cleaned. It has an
intelligent control display function, a reminder of coffee grinds disposal in filter
basket, and can realize the function of program time setting.
02.Important Safeguards
02.1. Danger to the user
CAUTION- Improper use of this appliance could result in minor injuries!
Please respect the following safety warnings:
(1)Read all instructions carefully before use.
(2)Do not use the appliance if it is faulty or damaged.
(3)Do not alter the built-in safety system.
(4)Do not touch hot surfaces & parts.
(5) This appliance is not intended for use by persons, including children, with
reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruc-
tion concerning the use of the coffee machine by a person responsible for their
safety.
(6)Children should be supervised to ensure that they do not play with the
appliance. Cleaning and user maintenance shall not be made by children
without supervision.
(7) Keep the appliance and its cord out of the reach of children.
(8) Install the coffee machine at a place where it can be taken care and
maintained at any time.
(9)The coffee bean shall be put in the bean container and pre-ground coffee
shall be put in the filter basket.
Danger of electric shock! Improper use of this appliance could result in
minor injuries!
Please respect the following safety warnings:
• Please comply with the relevant low voltage instructions and national or local
safety regulations.
• Connect the appliance to an efficiently earthed and correctly installed socket.
• Make sure the power supply voltage corresponds to the value indicated on
the rating label.
• Do not touch electrical parts.
• Be sure to turn off the appliance and unplug from the socket before mainte-
nance.
• The power cord can only be replaced by a qualified professional.

03
EN
02.2.Damage to the appliance
Warning! Improper use of this appliance could result in damage to
the appliance!
Please respect the following safety warnings:
(1)Do not run the appliance when the water tank is empty, otherwise the
appliance will run dry and may cause damage.
(2) If the appliance hasn't been used for a longtime, cleaning should be done
first before turning on the appliance.
(3)The appliance should be installed at a dry place and avoid the sunshine,
frost, or moist.
(4)If the problem cannot resolved as described in the trouble shooting, contact
Customer Services.
(5)Please use Aiviq original accessory attachments or spare parts only.
(6) Do not use the appliance if it is visibly damaged or found of leakage.
Contact the Customer Service for replacement or repair.
(7) Do not rinse the appliance under water. Do not use solvents, abrasive
detergents or alcohol to clean the coffee maker.
(8)The appliance shall not be installed on a surface that may be sprayed with
water. (9)Do not use freeze-dried coffee beans, otherwise it will cause damage
to the grinding group.
(10)If the appliance and its additional attachments are transported at tempera-
ture below 10°C ( 50°F), they should be placed at room temperature for three
hours before they are plugged in and started. Failure to comply with this
regulation may result in short-circuit hazard or damage to electrical compo-
nents due to condensate.
02.3. The quest for the perfect cup of coffee (Coffee Tips)
Proportion
The right proportion of coffee to water can extract the right amount of coffee,
and get the best taste.
Grind
Generally speaking, the finer the grinding will increase the extraction, while the
coarser the grinding will reduce the extraction.
Time
The length of time the water is in contact with the coffee determines the
amount of coffee extracted.
Temperature
Water temperature affects the extraction speed, the higher the temperature,
the faster the extraction speed, and visa versa.
Brew pause
Brew pause describes the brewing process of water passing through coffee
grounds. The more contact of water-flow and grounds, the more amount of
coffee extracted.

04
EN
03. What's in the box
03.1.Components
03.2.Assembling diagram
Filter
Filter basket
Filter basket holder
Glass carafe
Warming plate
Water level window
(MAX: 12 cups)
Control panel
Water tank (flips back cover)
Grinding control konb (fine/coarse)
Hopper
Hopper lid
Display screen

05
EN
1 : Filter assembling
2 : Set of glass carafe
3 : Water filter ( Optional ) assembling
4 : Water tank filling
5 : Coffee bean filling ( Close the hopper lid after filling )
6 : Filter cleaning
03.3.Accessories
Model No.
Ratingpower
Watertankcapacity
Net weight
AGC-201
900W
1.5L
4.3kg
Ratingvoltage
Ratingfrequency
Hoppercapacity
Size
AC 220-240V
50Hz
200g
L277*W207*H393mm
Water filter handleX1
( Optional ) ManualX1
Water filterX1
( Optional )
Cleaning brushX1Coffee scoopX1
03.4.Introduction of filter (optional)
This coffee machine is equipped with a high-quality water tank filter.
Food-grade PP one-piece shell. Through multi-layer filtration such as activated
carbon, softening resin, and high-precision filter net, it can effectively remove
residual chlorine, bleaching powder, organic matter, etc. in the water, and at the
same time soften the water, remove the magnesium ions, impurities and
colloids. It can protect the water safety of the whole machine, prolong the
service life of components, and improve the taste of coffee.
03.5.Installation Instructions of filter (optional)
1. Activate the filter, put it in clean water for 10-15 minutes, then rinse it with tap
water for 60 seconds.
2. Screw the filter body onto the filter handle.
3. Insert the filter into the groove of the water tank.
* Recommended replacement cycle: 30 days of use or 30 pots of coffee.
(depending on actual usage and local water quality)
04. Technical specifications
READAND SAVE THESE INSTRUCTIONS
APPLIANCES
TM
AUTOMATIC COFFEE
MAKER WITH GRINDER
MODEL NR: AGC-201

06
EN
Auto off
Remain visible on LCD:
1. Auto off is active
2. Auto off setting during PROG mode
Empty
Will appear in display
when the filter basket has not
emptied since last brew cycle
Auto on
Remain visible on LCD:
1. Auto on is active
2. Auto on setting during PROG mode
Pre-ground coffee
Remain visible during GRIND OFF mode
Strength
Indicate selected flavor strength
Cup
Indicate how many cups will be brewed
Clock
Remain visible indicate time of the day
Flash:
1.Time programming during time setting mode
2.Brew starting time during PROG mode
BREW/ CLEAN
Remain visible during BREW/ CLEAN mode
05. Installation
05.1. Location
When you place the appliance, you should respect the following safety
warnings to avoid
damage to the appliance:
(1)The distance between the power outlet and the appliance location shall not
exceed lm
(2)To leave certain space for convenience of operation and maintenance.
(3)Please leave enough space above the appliance to fill the coffee beans.
(4)The appliance gives off heat. Please leave a space of at least 5cm between
the surfaces
of the appliance and the side and rear walls.
05.2. Environment
When you install the appliance, you should respect the following safety
warnings to avoid
damage to the appliance:
(1) Keep surroundings at a temperature between 10 °C to 40 °C (50 °F to 104
°F)
(2) Relative humidity shall not exceed 80% rH
(3) The coffee machine is designed for indoor use only. Do not use it outdoors
to prevent it from being affected by weather (rain, snow, frost and freezing)!
05.3. Power Supply
The appliance must be earthed according to relevant national regulations. Make
sure thevoltage of the main power supply corresponds to the value indicated
on the appliance's rating label.
06. LCD indicators

07
EN
07. Buttons
GRIND OFF
HOUR
CUP
MIN
STRENGTH
PROG
BREW
ON/OFF
GRIND OFF
Switch of Preground coffee/whole
coffee beans
CUP
To set how many cups will be brewed
STRENGTH
To set the flavor strength
BREW
Start brewing , confirm or cancel
PROG mode
HOUR
Long press for 2 seconds to adjust current
hour under power on mode
MIN
Long press for 2 seconds to adjust current
minute under power on mode
PROG
Auto on time , automatically standby ,
and cleaning settings
ON/OFF
Manually turns coffee maker on or
standby

08
EN
08 First use
08.1 Setting the clock
GRIND OFF
HOUR
CUP
MIN
STRENGTH
PROG
BREW
ON/OFF
1. Plug the power cord.
2. "Screen time" will flash , press "HOUR" and "MIN" button to set the
clock to the current time. Hold buttons down to scroll through the digits.
( 12/24 hours switch : Hold "HOUR" + "MIN" buttons simultaneously for 3
seconds )
3. Press any function button besides "ON/OFF", "HOUR" or "MIN" to exit
mode and activate the selected function. "Screen time" will illuminate and
indicate the current time. The appliance will get back to the standby mode.
( If you do nothing for 8 seconds, the mode will be exited and selected function
will be activated )
08.2. Cleaning the appliance
( Please refer to 03.2.assembling diagram for the use of accessories )
1. Clean filter, filter basket and glass carafe with warm water, and assemble to
the appliance.
2. Get water with glass carafe and pour to the water tank. Observe the water
level and add water to the maximum capacity.
Note : Do no exceed the 12-cup line. Doing so could cause water overflow
from drain hole on the back of the appliance.
3. Press ON/OFF button to turn on the appliance.
4. Press GRIND OFF button. ( No need to add coffee beans or pre-ground
coffee)
5. Press brew button and the appliance starts cleaning. This process will take 10
minutes.
( There will be the sound of boiling water which means the cleaning is in
process, and beep sounds will remind you when cleaning ends.)
6. Repeat the procedure of 2.4.5, finish cleaning after 1-2 cycles.

09
EN
09 . Making coffee with whole beans
1.Twist and fix the filter handle to the water filter(optional)and insert it into the
bottom of the water tank.
2.Use glass carafe to get desired cups of water and pour to the water tank.
Note: Water quality shall comply to relevant standard.
2 cups of water is required to make 2 cups of coffee; 4 cups of water is required
to make 4 cups of coffee. More water will make the coffee weak.
2 cups indicator is at the top of the stainless ring.
3.Remove the hopper lid. Add enough beans and replace hopper lid.
Grind control knob
Grind control Grind
control knob will be found when removing hopper lid.
Number 9 indicates coarsest coffee grinding, and number 1
indicates finest coffee grinding.
Indicator
4.Open the filter basket holder, insert filter basket and then filter. Close the
filter basket holder after everything is in place. (User can choose proper size
paper filter to replace permanent filter as preferences)
Note : Be sure paper filter is fully opened and touching walls
of basket. Do not use both, a paper filter and the included
permanent filter at the same time. This will cause the unit to
overflow and damage the unit.

10
EN
5.Press the ON/OFF button to turn the coffee maker on. LED will illuminate with
display of "CUP"(default set 12) and "STRENGTH" (default set 1).
6.Press "CUP" to set the number of cups you want to brew and press
"STRENGTH" to set the preference flavor.
7.Brewing : Press "BREW" button, "BREW" LED will light up, "screen ring"
will flash and brewing will begin.
8.After brewing,beeps will sound to show brewing cycle is complete. "CUPS",
"STRENGTH" LED will go out, so is the screen ring, and it enters standby mode.
"Empty" LED lights up to notice emptying of filter basket.
Note : "EMPTY" LED will remain on if the basket is not emptied. The new
brewing cycle can only start when the basket is emptied.
GRIND OFF
HOUR
CUP
MIN
STRENGTH
PROG
BREW
ON/OFF

11
EN
2 cups indicator is at the top of the stainless ring.
10 . Making coffee with pre-ground beans
1.Use glass carafe to get desired cups of water and pour to the water tank.
Note: Water quality shall comply to relevant standard.
2 cups of water is required to make 2 cups of coffee; 4 cups of water is required
to make 4 cups of coffee. More water will make the coffee weak.
2. Add proper amount of ground coffee in the filter basket. (User can choose
proper size paper filter to replace permanent filter as preferences)
3. Press "GRIND OFF" button when the unit is turned on. "STRENGTH" LED
will go out ( The strength will be influenced by the selected ground coffee ) ,
"coffee scoop" LED will illuminate, and GRIND OFF function activated
4. Press "BREW" button and "BREW" LED illuminate, "screen ring" flash, and
brewing will begin.
11.Setting the program time
1.After entering auto on mode, continue to finish the step 1-5 in whole bean coffee
making, or step 1-3 in pre-ground coffee making
2.Press and hold the "PROG" button for 3 seconds to enter PROG mode when
the coffee maker is on. " " LED light up shows it is under Set Program Time mode .
Default time "6 : 20 AM" ( or the previously selected auto on time ) will flash.
GRIND OFF
HOUR
CUP
MIN
STRENGTH
PROG
BREW
ON/OFF
GRIND OFF
HOUR
CUP
MIN
STRENGTH
PROG
BREW
ON/OFF

12
EN
3.Press "HOUR" and "MIN" to set the time you want coffee to begin brewing.
Press and hold the "HOUR" and "MIN" button to stroll the time setting. Press
"CUP" and "STRENGTH" button to set the coffee cups and coffee strength.
4.Press "BREW" button and CLOCK LED will illuminate. Display time will return
to the current time, indicating AUTO ON is activated and it will start to brew at
the programmed time.
( Note : If you do nothing for 60 seconds during step 2 and 3, program mode
will be exited automatically. It will return to the starting mode and step 2 and
3 will not be saved. )
( Note : The Program mode cannot be entered if the coffee maker is in its brew
cycle. )
5.Deactivate AUTO ON - To press Brew button before programmed time,
CLOCK LED light off, indicating AUTO ON is deactivated.
12.Setting the automatic shutoff time
1. When the coffee maker is on ( Not at time setting mode or brewing mode ) ,
press and hold "PROG" button for 3 seconds until it enters Program mode.
2. Press "PROG" button again, OFF LED will illuminate and display time will flash,
indicating it enters automatic shutoff time setting mode. Set desired shutoff time
by pressing "HOUR" and "MIN" button. ( Default shutoff time is 2 hours )
( Note : Your coffee maker can be programmed to automatically shut off from
0 to 4 hours. )
GRIND OFF
HOUR
CUP
MIN
STRENGTH
PROG
BREW
ON/OFF
GRIND OFF
HOUR
CUP
MIN
STRENGTH
PROG
BREW
ON/OFF

13
EN
White vinegar with concentration of 4%
3. To save and exit, do nothing for 5 seconds after time setting. "OFF" LED
illuminates, indicating AUTO OFF mode activated.
4. To deactivate auto off, repeat the above operation and set the auto shutoff
time to 0:00. The "OFF" LED light off, indicating AUTO OFF mode is deactivated.
13.Descaling
If it is found that the steam is too much or the brewing time becomes longer when
in use, please use the descaling solution to the unit. Suggest to use it every 2 months.
( Warning : Only use white vinegar with concentration less than 8% for descaling
solution. Do not use red vinegar, natural vinegar, descaling powder or descaling
tablets for descaling, or the coffee maker may be damaged. )
1.Fill the water tank up to, but not exceeding, the 12 cup line with white vinegar
(concentration of 4%, dilute it with water if the concentration is too high)
2.Open the filter basket holder, insert filter basket and then filter. Close the filter
basket holder after everything is in place. (User can choose proper size paper
filter to replace permanent filter as preferences)

14
EN
3.Set the empty carafe in the coffee maker.
4.Press and hold "PROG" button for 3 seconds when the coffee maker is on,
and it enters programming mode. Press "PROG" button twice, "Cleaning" LED
illuminates, indicating the setting of cleaning is ready.
Press "BREW" button , "Display ring" flashes and the cleaning action begins.
"Display time" will show the cleaning time ( The clean cycle takes approximately
25 minutes). The unit will beep when the clean cycle successfully completes.
5. Empty the carafe and remove the filter carrying scale residue.
6. Refill the water tank with fresh water and press brew button. Run a fully brew
cycle with water only. Empty the carafe after brewing process.
Note : Please repeat step 6 if necessary to remove any cleaning solution that
could affect the flavor of your coffee.
GRIND OFF
HOUR
CUP
MIN
STRENGTH
PROG
BREW
ON/OFF
GRIND OFF
HOUR
CUP
MIN
STRENGTH
PROG
BREW
ON/OFF

15
EN
Grinding blade essembly
14.To clean grinder
If the grinder amount in the basket becomes less, or the coffee flavor becomes
weaker, please use the solution to clean the grinder . Suggest to clean every 2 weeks.
1.Scoop out the coffee beans in the hopper, clear the remaining beans completely
by running the coffee maker.
2.Under standby mode , press and hold the "GRINDS OFF" button until the grinder
cleaning door above the basket holder opens.
4.Open the basket holder and clean the grinder with brush from the beneath.
5.After cleaning, press "ON/OFF" button when it is confirmed that there is no foreign
material around the grinder cleaning door. The door will get back automatically.
6.Set the grinding blade assembly back.
GRIND OFF
HOUR
CUP
MIN
STRENGTH
PROG
BREW
ON/OFF

16
EN
15.Food contact material list
Description: Coffee maker
Type: Food contact
Component Service conditions
Hopper silicone strip /main
sealing strip/ seal ring of
hopper lid/0 ring of water
spout/ sprinkler seal ring/
airway tube/silicone tube
Grinding blade/
Grinding blade sleeve
Spring/motor screw
Carafe lid/top&bottom
housing&cover/water tank lid
/water spout/unidirectional
valve body/unidirectional valve
core/basket holder/basket/
filter/filter body/ filter lid/
filter handle/scoop
Do not use at temperature
above 100°C
Grinding box/grinding box lid/
grind adjusting holder/ blade
sleeve holder/ bean blending
head/powder throw off plate/
grinding hood
Do not use at temperature
above 100°C
Bean hopper, hopper cover Do not use at temperature
above 45°C
Heating tube Do not directly touch food
with strong acidity
Revolving door Do not use at temperature
above 110°C
Glass carafe
Material
Silicone
Stainless steel
SS304
PP
PA66
AS
Aluminium alloy
POM
Borosilicate glass
Do not use at temperature
above 150°C. Do not use in
microwave oven.
Note:The unit is not for long-term food storage.

17
EN
16.TRANSPORTATION AND DISPOSAL
10.1 Transport
1) Please keep all the packages for future use of transportation.
2) Water remaining in the coffee machine must be emptied thoroughly before
transportation, otherwise the coffee machine will be damaged.
3) After emptying the waterway, wipe and dry inside and outside of the coffee
machine completely.
10.2 Waste disposal
The waste generated during brewing is purely organic. Therefore, it can be
treated as general household waste.
10.3 Waste water disposal
The waste water generated during brewing and cleaning meets the characteris-
tics of general domestic waste water. Therefore, it can be discharged through
ordinary sewers.
10.4 Appliance disposal
1) This appliance and all auxiliary equipment contain high quality raw materials,
which shall be recycled.
2) This appliance must not be disposed of with household waste. Please comply
to correspondent national and local laws and regulations.
3) This appliance and all auxiliary equipment is designed and manufactured
according to the requirements of environmental protection treatment.
17.Notice during daily use and maintenance
(1)Only coffee beans are allowed to add in bean hopper. Never add water, sugar
or any other liquid, solid.
(2)Do not open basket holder and take out basket during working of the unit.
(3)Fill water tank with fresh water at room temperature. Do not add hot water
or ice water.
(4)Do not put your hand under spout while the drink is flowing, which would
cause danger of burns.
(5)When cleaning the appliance, do not use a brush or detergent to avoid
damaging the appearance of the coffee machine. Wipe with a soft cloth moist-
ened with water.
(6)Do not exceed MAX line when water filling in water tank, bean filling in hopper,
and ground filling in basket. If there is no MAX line, fill to the 80% of the capacity.
(7)Never cut power supply during the process of making coffee, reset or rinsing.
(8)Each day after use of this appliance, please empty the filter basket and clean it
thoroughly.
(9)To make a perfect coffee, it is recommended that the water tank be cleaned
and replaced with fresh water daily.
18.Troubleshooting
1.In the event of failure, malfunction or other damages, immediately unplug the
appliance.
2.In the event of problems during operation, first try and resolve them following
the information given in the below section. If this does not resolve the problem,
you should consult Customer Service.
3. Authorized professionals only are allowed to repair the appliance. The manu-
facturer is not liable for damage depriving from failure to respect this instruction
manual.
4.General problem and solution.

EN
18
Coffee is too
weak
Filter basket drips
oven after the
brew cycle is
completed
The coffee maker
is not working
Carafe overflowed
Water flows from
bottom of coffee
maker
1
2
3
4
5
6
7
8
9
PROBLEMNO. CAUSE SOLUTION
E01 Door opening failure Do not use the coffee maker.
Please contact Customer Service.
E02 Door closing failure Do not use the coffee maker.
Please contact Customer Service.
E03 Heating failure Do not use the coffee maker.
Please contact Customer Service.
Carafe is not in place The center of the carafe shall
direct to the basket water spout
Water level exceeded Max
Fill line on the water tank.
Water level shall be between
max fill line and min fill line
Coffee is not
hot enough Few brewing cups Full capacity and warming time will be longer
The coffee maker
is damaged
Do not use the coffee maker.
Please contact Customer Service
Too much water
in drip tray Clean warming plate regularly
Filter basket
overflowed
Edge of filter basket may
be clogged by ground
coffee.
Remove the extra ground coffee
Not plug in Check if the outlet is good
Basket holder is not
closed Close the basket holder
Others Do not use the coffee maker.
Please contact Customer Service
Strength setting is too low" " Increase the strength setting to “ ”
Ground is too coarse Turn the grinding control knob
to finer indication
Few brewing cups Increase number of cups
Grounds channel clogged Use cleaning function to clean
the grounds channel
Drip prevention
device may be clogged
Remove filter basket and clean
the drip prevention device
Steam condensation It is normal if few drips in short time.
Wipe the warming plate with cloth.
The grinder not
working and
smokes come out
Foreign material in the coffee
beans clog the grinder and
motor is burned
Do not use the coffee maker.
Please contact Customer Service.
The grinder not
working Wire lead drop out Re-connect the wire

EN
19
19.Warranty and Liability
Manufacturer is not liable for any damage or injuries depriving from improper
use listed as below:
(1)The coffee maker is improperly used.
(2)The coffee maker and its optional parts are not correctly installed, debugged,
operated, cleaned or maintained.
(3)The maintenance is not carried out regularly according to the guide.
(4)Failure to respect this instruction manual in relevant of safety warnings of
appliance storage, installation, operation and maintenance.
(5)The appliance is used under abnormal conditions.
(6) Repair is not performed correctly.
(7)Use non-original parts produced by .
(8)The damage is caused by foreign matters, accident, vandalism or other
irresistible reasons.
